Model No. HRCCEL59930
Serial No.
Serial Number Decal
(underneath frame)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, please call:
1-888-936-4266
Mon.–Fri. 8h00 until 18h30 EST
(excluding holidays).
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
_
USER'S MANUAL
Visit our website at
www.healthrider.com
Next page ->

Summary of Contents

  • Page 1

    1-888-936-4266 Mon.–Fri. 8h00 until 18h30 EST (excluding holidays). CAUTION Read all precautions and instruc- tions in this manual before using this equipment. Keep this manual for future reference. USER’S MANUAL Visit our website at www.healthrider.com...

  • Page 2: Table Of Contents

    LIMITED WARRANTY ............. .Back Cover HealthRider is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precau- tions before using the elliptical exerciser. 1. Read all instructions in this manual before using the elliptical exerciser. 2. It is the responsibility of the owner to ensure that all users of the elliptical exerciser are adequately informed of all precautions.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Congratulations for selecting the new HealthRider AIRE STRIDER E60 elliptical exerciser. The AIRE STRIDER E60 is an incredibly smooth exerciser that moves your feet in a natural elliptical path, minimizing the impact on your knees and ankles. And the unique AIRE STRIDER E60 features adjustable resistance and incline to help you get the most from your exercise.

  • Page 5: Assembly

    ASSEMBLY Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included allen wrenches, assembly requires a phillips screwdriver wrenches , a rubber mallet As you assemble the elliptical exerciser, use the drawings below to identify the small parts used for assembly.

  • Page 6: Table Of Contents, Axle Through The Motor Screw, Make Sure That The

    2. Identify the Pivot Axle (14), which is the longest axle. Slide a Ramp Cover (48) onto an M6 x 16mm Patch Screw (76) as shown. Tighten the Patch Screw into one end of the Pivot Axle. Apply a small amount of the included grease to the Pivot Axle.

  • Page 7

    5. Apply a small amount of grease to the axle on the Left Crank Arm (34). Identify the Left Pedal Leg (4), which is marked with an “L” sticker. Slide the Left Pedal Leg onto the axle on the Left Crank Arm (34). (Note: It may be helpful to use a rubber mallet to tap the Left Pedal Leg on.

  • Page 8

    7. Apply a small amount of the included Teflon to a paper towel. Rub a thin film of the lubricant onto each Upper Body Leg (31). Identify the Left Upper Body Arm (112), which is marked with an “L” sticker. Slide the Left Upper Body Arm onto the left Upper Body Leg (31).

  • Page 9

    9. Have another person hold the Console (17) near the Upright (2). Connect the Upper Wire Harness (95) to the wire har- ness on the Console (17). Connect the Pulse Extension Wire (101) to the pulse wire on the Console. Next, locate the two ground wires that are attached to the Upright (2).

  • Page 10: How To Use The Elliptical Exerciser

    HOW TO USE THE ELLIPTICAL EXERCISER HOW TO PLUG IN THE POWER CORD This product must be Grounded Outlet Box grounded. If it should malfunction or break down, grounding Grounding Pin provides a path of least Grounded Outlet resistance for electric current to reduce the risk of electric shock.

  • Page 11

    CONSOLE DIAGRAM Note: If there are sheets of clear plastic on the face of the console, remove the plastic. FEATURES OF THE CONSOLE The advanced console offers a selection of features designed to make your workouts more enjoyable and effective. When the manual mode of the console is selected, the resistance of the elliptical exerciser and the angle of the ramp can be changed with the touch of a button.

  • Page 12

    HOW TO USE THE MANUAL MODE Press any button on the console or begin pedaling to turn on the console. Make sure that the power cord is properly plugged in (see page 10). Next, press any button on the console or begin pedaling to turn on the console.

  • Page 13

    Note: The console can show the total number of hours that the elliptical exerciser has been used and the total number of revolu- tions pedaled. To view this information, hold down the Program button for about three seconds. The left display will show the total number of hours that the elliptical exerciser has been used.

  • Page 14

    HOW TO USE RESISTANCE AND PACE PROGRAMS Press any button on the console or begin pedaling to turn on the console. See step 1 on page 12. Select one of the six resistance and pace programs. When the power is turned on, the manual mode will be selected.

  • Page 15

    Adjust the angle of the ramp as desired. See step 4 on page 12. Monitor your progress with the two displays. See step 5 on page 12. Measure your heart rate if desired. See step 6 on page 13. Turn on the fan if desired. See step 7 on page 13.

  • Page 16

    If you have selected heart rate program 8, the letters “PLS” and the current target heart rate setting will flash in the left display. Press the – and + buttons repeat- edly to change the target heart rate setting, if desired.

  • Page 17

    HOW TO CONNECT YOUR CD PLAYER, VCR, OR COMPUTER To use iFIT.com CDs, the elliptical exerciser must be connected to your portable CD player, portable stereo, home stereo, or computer with CD player. See pages 17 to 18 for connecting instructions. To use iFIT.com videocassettes, the elliptical exerciser must be con- nected to your VCR.

  • Page 18

    HOW TO CONNECT YOUR HOME STEREO Note: If your stereo has an unused LINE OUT jack, see instruction A below. If the LINE OUT jack is being used, see instruction B. A. Plug one end of a 1/8” to RCA stereo audio cable (available at electronics stores) into the jack beneath the console.

  • Page 19

    HOW TO CONNECT YOUR VCR Note: If your VCR has an unused AUDIO OUT jack, see instruction A below. If the AUDIO OUT jack is being used, see instruction B. If you have a TV with a built-in VCR, see instruction B. If your VCR is connected to your home stereo, see HOW TO CONNECT YOUR HOME STEREO on page 18.

  • Page 20

    HOW TO USE IFIT.COM CD AND VIDEO PROGRAMS To use iFIT.com CDs or videocassettes, the elliptical exerciser must be connected to your portable CD play- er, portable stereo, home stereo, computer with CD player, or VCR. See HOW TO CONNECT YOUR CD PLAYER, VCR, OR COMPUTER on page 17.

  • Page 21

    HOW TO USE PROGRAMS DIRECTLY FROM OUR WEB SITE Our Web site at www.iFIT.com allows you to play iFIT.com audio and video programs directly from the internet. To use programs from our Web site, the ellip- tical exerciser must be connected to your home com- puter.

  • Page 22: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and properly tighten all parts of the elliptical exerciser regularly. Replace any worn parts immedi- ately. For smooth operation of the elliptical exer- ciser, inspect and clean the ramp regularly using a soft cloth and mild detergent.

  • Page 23: Conditioning Guidelines

    CONDITIONING GUIDELINES WARNING: Before beginning this or any exercise pro- gram, consult your physician. This is espe- cially important for persons over the age of 35 or persons with pre-existing health problems. The pulse sensor is not a medical device. Various factors may affect the accuracy of heart rate readings.

  • Page 24: Part List, Exploded Drawing

    PART LIST—Model No. HRCCEL59930 To locate the parts listed below, see the EXPLODED DRAWING on pages 26 and 27. Key No. Qty. Description Frame Upright Ramp Left Pedal Leg Right Pedal Leg Rear Stabilizer Rear Stabilizer Endcap Front Stabilizer Front Stabilizer Endcap Left Pedal Right Pedal Incline Motor...

  • Page 25

    Key No. Qty. Description M8 x 35mm Button Bolt Upper Foam Grip Lower Foam Grip M4 x 63.5mm Tek Screw Wheel Wheel Bushing M8 x 19mm Patch Screw Left Upper Body Arm Torque Washer Note: # indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover of this manual for information about ordering replacement parts.

  • Page 28

    • The MODEL NUMBER of the product HRCCEL59930) • The NAME of the product (HealthRider • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the part(s) (see pages 24 to 27) LIMITED WARRANTY ICON OF CANADA, INC., (ICON), warrants this product to be free from defects in workmanship and...
