WIRELESS FORECAST STATION
Model WS-9057U-IT-LC| Quick Setup Guide
This product offers:
INSTANT TRANSMISSION is the state-of-
the-art new wireless transmission
technology, exclusively designed and
developed by LA CROSSE TECHNOLOGY.
INSTANT TRANSMISSION offers you an
immediate update (every 4 seconds!) of all
your outdoor data measured from the
transmitters: follow your climatic variations
in real-time!
1
WWVB Radio controlled time with manual setting option
Time reception ON/OFF (user selectable)
12/24 hour time display
Time zone option ±12 hours
Daylight saving time (DST On/Off)
Weekday and day calendar display (year and month only in setting
mode)
Alarm setting with snooze function
Display 12 Moon phases throughout the year
Weather forecasting with weather tendency indicator
Indoor comfort indicator
Temperature display in °F/°C
Indoor and outdoor temperature display with MIN/MAX records and
time of reception
Humidity data display as RH%
Indoor and outdoor humidity display with MIN/MAX records
Relative air pressure hPa/ inHg with adjustable reference value
Weather icon sensitivity setting
Relative air pressure history for the past 24 hours (electronic
barometer with barometric pressure trend)
3
SETUP INSTRUCTIONS STEP BY STEP:
STEP 1:
Remove battery cover from the wireless forecast station. Lift up and pull
out to remove the cover.
Insert 2 NEW “C” batteries (not included) into the back of the wireless
forecast station. Observe the correct polarity (see marking inside the
battery compartment).
The Wireless Forecast Station will light up and show, indoor
temperature, humidity and pressure.
Do Not Mix Old and New Batteries
Do Not Mix Alkaline, Standard, Lithium or Rechargeable Batteries
STEP 2:
Ensure that the transmitter is within 10 feet of the wireless forecast
station.
Remove battery cover from TX29UDTH-IT transmitter: Slide the battery
cover down and lift off the back.
Insert 2 NEW AA batteries into the transmitter. Observe the correct
polarity.
5
INVENTORY OF CONTENTS
1.
Wireless Forecast Station
2.
Thermo/hygro transmitter (TX29UDTH-IT)
3.
Instruction manual
FEATURES:
The Wireless forecast station
Function Keys
Wall Mount
LCD
Battery
Display
Compartment
Foldable
Stands
2
LCD contrast selectable
Can receive up to 3 outdoor transmitters
Wireless transmission at 915 MHz
Signal reception intervals at 4 seconds
Low battery indicator
Table standing or wall mounting
Thermo-Hygro Transmitter
Remote transmission of outdoor
temperature and humidity to wireless
forecast station by 915 MHz signals
Alternate display of temperature and
humidity display
Water-resistant casing
Wall mounting case. (Mount in a sheltered
place. Avoid direct rain and sunshine
4
Within 3 minutes the Wireless forecast station will show readings in the
outdoor temperature area on the LCD.
Note: Allow the Wireless forecast station and the transmitter to stay
within 10 feet of each other for the first 15 minutes of set up.
TROUBLE SHOOTING:
If the wireless forecast station does not display the outdoor temperature
after 3 minutes, remove the batteries from both units and start the setup
process again.
For optimal 915MHz signal reception, the outdoor transmitter should be
placed within 330 feet (100 meters) from the indoor Wireless forecast
station.
The forecast icons on the Wireless forecast station require 48-60 hours
to synch with the barometric pressure, so immediate readings may not
be accurate.
SETUP WITH MULTIPLE TRANSMITTERS:
The wireless forecast station will accommodate up to three remote
outdoor transmitters (TX29UDTH-IT). The SNOOZE/CH button allows
6
