Before connecting, operating or adjusting this product,
please read the instructions completely.
Please keep this manual for future reference.
Note:
"EB" on the packaging indicates the United Kingdom.
Operations in these instructions are described using
remote control, but you can do the operations with the
main unit if the controls are the same.
Your unit may not look exactly as illustrated.
Table of contents
Safety precautions ................................ 2
Caution for AC mains lead .................... 3
Placement of speakers .......................... 3
Getting started ....................................... 4
Overview of controls ............................. 6
Discs ....................................................... 7
FM radio .................................................. 9
DAB ......................................................... 10
Timer ....................................................... 14
Sound adjustment ................................. 15
External unit ........................................... 16
Troubleshooting guide .......................... 18
Specifi cations ........................................ 19
Maintenance ........................................... 19
EB
Operating Instructions
CD Stereo System
Model No.
SUPPLIED ACCESSORIES
SUPPLIED ACCESSORIES
Please check and identify the supplied accessories.
Use numbers indicated in parentheses when asking for
replacement parts. (As of February 2007)
1 x Remote control
(N2QAYB000088)
1 x FM indoor antenna
(RSA0007-L1)
1 x Antenna plug
adaptor
(K1YZ02000013)
SC-NS55DB
1 x AC mains lead
(K2CT3CA00004)
1 x DAB "T" antenna
(N1EADY000001)
2 x Remote control
batteries
RQTV0188-2B
