Related Manuals for Haier HWM90-0566
Summary of Contents for Haier HWM90-0566
- Page 1 Double drive Washing Machine This manual is for HWM90-0566 Please read this manual carefully before using. Retain it for future reference. 0030507805A...
-
Page 2: Table Of Contents
CONTENTS Names of the parts Safety precautions Installation and adjustment Install the water inlet hose Preparation before using in the laundries Usage of the detergent Use the operation buttons Close the top lid Finish washing Disposal after washing Trouble shooting Answer to question Packing list specifcation... -
Page 3: Names Of The Parts
Packing list Name User's manual Component of the water inlet hose The end connecting to the washing machine Jointer connecting the water inlet hose and the water faucet The end connecting to the water inlet hose jointer Bottom cover (Inside the inner tub of washing machine) Topping screws Inner cover component... -
Page 4: Safety Precautions
Safety precautions The washing machine must be positioned Please plug the power plug on special so that the plug is accessible. Be sure to pull the receptacle. Be sure to use three-pins plug off and close the water faucet in power receptacle. - Page 5 To change the direction of drain pipe, please contact the customer care agent of our company. Please don t use the washer in the environment below 0 C; if the washer has been stored below 0 C, please be sure to ensure the washer is placed under the room temperature for 24 hours and then use otherwise the washing effects may be lowered or the washer may be damaged.
-
Page 6: Installation And Adjustment
6 Push the "Start/Pause" button 5 Close the top lid As the top lid opened, the washer will automatically given alarm and stop running, exclusively during the adjustable nut draining... - Page 7 Steps of using the operation buttons and description of the steps Spin Reserve 1.Push "power" button to switch on the power 2.Push "program" button to select suitable full-auto program After the power is switched on, "normal"is automatically set. To select other full-auto program, please push the "program"...
-
Page 8: Install The Water Inlet Hose
Install the water inlet hose Confirm the water faucet Water faucet,suitable Outlet end surface It is required that the front end shall be longer than 10mm. The exit end face of the faucet shall be flat and smooth. If not please file it to avoid leakage. Connection between the water inlet hose jointer and the water faucet 1.Press the lower end of the lock lever and push down the slider. - Page 9 SPIN button, the machine have no reaction. Connection between the water inlet hose and the washer 1.Do not take off the water absorption cushion. Please check if the cushion is dropped or damaged before each usage. If it happens please contact our after-sale department immediately.
-
Page 10: Preparation Before Using
1 Preparation before washing Preparation before washing 1.Connect the water inlet hose 2.Confirm that the washing machine is earthed reliably. Then insert the power plug into the receptacle. Do not connect the earth terminal to the gas pipe and tap water pipe. 3.Put down the drain hose 4.slanting or uneven ground may result in unstable working or abnormal noise.
