Mini Digital Amplifier, with MIC Mixer and EQ
AMP-MA40
40 Watt Mini Digital Amplifier, with Mic Mixer/EQ
USER MANUAL
17141 Kingsview Ave. Carson CA 90746-1207 USA
Tel. 310-515-1900 * Fax 310-515-1606
Technical Support: 310-515-1900
Index:
1.
Introduction:...........................................................................................................2
2.
Product Picture .......................................................................................................2
3.
Features ..................................................................................................................3
4.
Specification...........................................................................................................4
5.
Audio Connections.................................................................................................5
6.
Buttons Controlling................................................................................................6
7.
RS232 Communication Protocol ...........................................................................8
8.
System Diagram ...................................................................................................10
9.
Panel Drawing ......................................................................................................11
10.
IR Control Package (Optional - Sold separately).................................................12
11.
Warranty................................................................................................................14
info@owi-inc.com
www.owi-inc.com
1
Advertisement
Chapters
Table of Contents
Related Manuals for OWI AMP-MA40
Summary of Contents for OWI AMP-MA40
-
Page 1: Table Of Contents
Mini Digital Amplifier, with MIC Mixer and EQ AMP-MA40 40 Watt Mini Digital Amplifier, with Mic Mixer/EQ USER MANUAL 17141 Kingsview Ave. Carson CA 90746-1207 USA Tel. 310-515-1900 * Fax 310-515-1606 info@owi-inc.com www.owi-inc.com Technical Support: 310-515-1900 Index: 1. Introduction:......................2 2. ... -
Page 2: Introduction
Mini Digital Amplifier, with MIC Mixer and EQ 1. Introduction AMP-MA40 is a small digital amplifier (Class-D), with EQ control and MIC mixer function. It is compact-size but powerful functions, including the bridge connection, dual-mono, EQ control, microphone mixer etc. -
Page 3: Features
Mini Digital Amplifier, with MIC Mixer and EQ 3. Features 2x20Watt@4Ω as the default amplifier output. Bridge connection function. The user can switch the AMP-MA40 to be 1x40Watt@8Ω by bridge connection. Dual-mono function. The user can sum up the stereo audio to two times mono audio. -
Page 4: Specification
Mini Digital Amplifier, with MIC Mixer and EQ 4. Specifications Audio Input Audio Output 2 ea. stereo audio, 1 ea. Amplifier, Input Output 1 ea. Mono MIC 1 ea. stereo audio 2 ea. RCA 1 ea. 3.5mm jack 1 ea. 3.5mm jack Input Connector Output Connector 1 ea. -
Page 5: Audio Connections
Connecting the four pins, like this 5.2 Bridge connection: 1x40Watt@8Ω The AMP-MA40 has the bridge connection, to double the output power at 1x40Watt@8Ω. It will sum up the input left channel and input right channel to be mono output, and the power is up to 40Watts. -
Page 6: Buttons Controlling
Mini Digital Amplifier, with MIC Mixer and EQ 5.3 Dual-mono output: 2x20Watt@4Ω The AMP-MA40 also has the function of double-mono output. It can sum up the left and right channel, to be the mono audio output. In this way, both of the outputs are showing the same mono audio. -
Page 7: Bass
Mini Digital Amplifier, with MIC Mixer and EQ 6.2 Volume/EQ controlling: The line volume and Microphone volume can be controlled by the buttons. The Mic Volume/Line volume/Line bass/Line treble will be selected by the buttons, and controlled up/down/mute by the function buttons. Please check the picture below: Select the function from this Turn up/down the level. -
Page 8: Rs232 Communication Protocol
Mini Digital Amplifier, with MIC Mixer and EQ 7. RS232 Communication Protocol Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none Command Function Desctription Feedback Code 1A1. Switching the audio to input 1 A: 1 -> 1 2A1. -
Page 9: Volume Of Mic
Turning up the volume of line audio. We should send the RS232 command: [ 603% Example 3 Preset the MIC volume to be “21” degree. We should send the RS232 command: [521%] Example 4 Checking the working status of AMP-MA40. We should send the RS232 command: [600%]... -
Page 10: System Diagram
Mini Digital Amplifier, with MIC Mixer and EQ 8. System Diagram 2x20Watt@4Ω Looping connection 1x40Watt@8Ω... -
Page 11: Panel Drawing
Mini Digital Amplifier, with MIC Mixer and EQ 9. Panel Drawing Unit: inches (mm) -
Page 12: Ir Control Package (Optional - Sold Separately)
AMP-IRMA40 Remote Control with Sensor for the Digital Amplifier AMP-MA40 The AMP-MA40 has an optional IR control function. It needs to work with the “AMP-MA40” package, including the IR receiver and IR remote (Model AMP-IRMA40RC). The model name for the IR Remote Control with the sensor is AMP-IRMA40 while AMP-MA40IR is the model name for the digital amplifier (AMP-MA40) plus the remote control and sensor (AMP-IRMA40). - Page 13 The IR receiver/sensor AMP-IRMA40S is used to receive the IR code from the remote controller AMP-IRMA40RC. It connects to the AMP-MA40 by 3pins capture screw connector, and receives the IR code by the IR sensor. The IR sensor can be sticked on the wall or ceiling.
-
Page 14: Warranty
Mini Digital Amplifier, with MIC Mixer and EQ 11. Warranty ---------------------------------------------------------------------------------------------------------------- OWI INCORPORATED Date Purchased: _____________________ 17141 Kingsview Ave Model Number: ______________________ Carson, CA 90746 (Keep this part for your record) -----------------------------------------------CUT AND MAIL-------------------------------------------- OWI INCORPORATED 17141 Kingsview Ave Carson, CA 90746...
