Belkin Wireless G Router User Manual

Wireless g router
Hide thumbs Also See for Wireless G Router:

Advertisement

Wireless G
Router

User Manual

F5D7230-4

Advertisement

Table of Contents
loading

Summary of Contents for Belkin Wireless G Router

  • Page 1: User Manual

    Wireless G Router User Manual F5D7230-4...
  • Page 3: Table Of Contents

    Table of Contents Introduction ........1 Benefits of a Home Network .
  • Page 5: Introduction

    Introduction Thank you for purchasing the Belkin Wireless G Router (the Router). The following two short sections discuss the benefits of home networking and outline best practices for maximizing your wireless home network range and performance. Please be sure to read through this User Manual completely, and pay special attention to the section entitled “Placement of your Router for Optimal Performance”...
  • Page 6: Placement Of Your Router For Optimal Performance

    To achieve the best wireless network coverage for your “wireless clients” (i.e., computers enabled by Belkin Wireless Notebook Network Cards, Wireless Desktop Network Cards, and Wireless USB Adapters): •...
  • Page 7 Introduction Avoid Obstacles and Interference Avoid placing your Router near devices that may emit radio “noise,” such as microwave ovens. Dense objects that can inhibit wireless communication include: • Refrigerators • Washers and/or dryers • Metal cabinets • Large aquariums •...
  • Page 8 • For Belkin wireless networking products, use the detailed Site Survey and wireless channel information included with your Wireless Network Card. See your Network Card’s user guide for more information.
  • Page 9 Introduction For more information regarding our networking products, visit our website at www.belkin.com/networking or or call Belkin Technical Support at: US: 877-736-5771 800-223-5546 ext. 2263 310-898-1100 ext. 2263 UK: 0845 607 77 87 Australia: 1800 235 546 New Zealand: 0800 235 546 Singapore: 65 64857620 Europe: www.belkin.com/support...
  • Page 10: Product Overview

    In minutes you will be able to share your Internet connection and network your computers. The following is a list of features that make your new Belkin Wireless G Router an ideal solution for your home or small office network.
  • Page 11 Product Overview Integrated 10/100 4-Port Switch The Router has a built-in, 4-port network switch to allow your wired computers to share printers, data and MP3 files, digital photos, and much more. The switch features automatic detection so it will adjust to the speed of connected devices.
  • Page 12 In minutes you will be able to share your Internet connection and network your computers. The following is a list of features that make your new Belkin Wireless G Router an ideal solution for your home or small office network.
  • Page 13: Knowing Your Router

    Knowing your Router Package Contents • Belkin Wireless G Router • Quick Installation Guide • Belkin Easy Install Wizard Software CD with User Manual • Belkin RJ45 Ethernet Networking Cable • Power Supply System Requirements • Broadband Internet connection such as a cable or DSL modem with RJ45 (Ethernet) connection •...
  • Page 14 Knowing your Router The Router has been designed to be placed on a desktop. All of the cables exit from the rear of the Router for better organization and utility. The LED indicators are easily visible on the front of the Router to provide you with information about network activity and status.
  • Page 15 Knowing your Router Wired Computer Status LEDs These LEDs are labeled 1–4 and correspond to the numbered ports on the rear of the Router. When a computer is properly connected to one of the wired computer ports on the rear of the Router, the LED will light.
  • Page 16 Knowing your Router Reset button is located on the bottom of the unit. Power Jack Connect the included 5V DC power supply to this jack. Connections to Computers (Wired Computer Ports) - BLUE Connect your wired (non-wireless) computers to these ports. These ports are RJ45, 10/100 auto-negotiation, auto-uplinking ports for standard UTP category 5 or 6 Ethernet cable.
  • Page 17 Knowing your Router Resetting the Router Push and release the “Reset” button. The lights on the Router will momentarily flash. The Power/Ready light will begin to blink. When the Power/Ready light becomes solid again, the reset is complete. Restoring the Factory Defaults Press and hold the “Reset”...
  • Page 18: Connecting And Configuring Your Router

    SUCH AS NOTEBOOK CARDS AND DESKTOP CARDS. Setup Assistant Belkin has provided our Setup Assistant software to make installing your Router a simple and easy task. You can use it to get your Router up and running in minutes. The Setup Assistant requires that your Windows 2000 or XP computer be connected directly to your cable or DSL modem and that the Internet connection is active and working at the time of installation.
  • Page 19 Connecting and Configuring your Router Step 1 Hardware Connections – Follow the Quick Installation Guide (QIG) Unplug your modem’s power cord. Put the Router next computer to the modem. Raise the router modem Router’s antennas. Locate the networking cable that connects your modem and computer.
  • Page 20 Connecting and Configuring your Router Step 2 Set Up the Router – Run the Setup Assistant Software Shut down any programs that are running on your computer at this time. Turn off any firewall or Internet-connection-sharing software on your computer. Insert the CD into your computer.
  • Page 21 Connecting and Configuring your Router Confirmation Screen Verify that you have completed all QIG steps by checking the box to the right of the arrow. Click “Next” to continue. Progress Screen Setup Assistant will show you a progress screen each time a step in the setup has been completed.
  • Page 22 Connecting and Configuring your Router 1.1 Checking Settings The Setup Assistant will now examine your computer’s network settings and gather information needed to complete the Router’s connection to the Internet. 1.2 Verifying Hardware Connections The Setup Assistant will now verify your hardware connection.
  • Page 23 Connecting and Configuring your Router 1.3 Naming your Wireless Network The Setup Assistant will display the default wireless network name or Service Set Identifier (SSID). This is the name of your wireless network to which your computers or devices with wireless network adapters will connect.
  • Page 24 Connecting and Configuring your Router 1.5 Configuring the Router The Setup Assistant will now configure your Router by sending data to the Router and restarting it. Wait for the on-screen instructions. Note: Do not disconnect any cable or power off the Router while the Router is rebooting.
  • Page 25 Connecting and Configuring your Router Congratulations You have finished installing your new Belkin Router. You will see the Congratulations screen when your Router can connect to the Internet. You can begin surfing by opening your browser and going to any website.
  • Page 26 Connecting and Configuring your Router Troubleshooting If the Setup Assistant is not able to connect to the Internet, you will see the following screen. Follow the on-screen instructions to go through the troubleshooting steps. 1.7 Optional: Assistance Connecting Other Computers This optional step will help you to connect additional wired and wireless computers to your network.
  • Page 27 Connecting and Configuring your Router Congratulations Once you have verified that your other wired and wireless computers are properly connected, your network is set up and working. You can now surf the Internet. Click “Next” to take you back to the main menu.
  • Page 28: Alternate Setup Method

    Alternate Setup Method The Web-Based Advanced User Interface is a web-based tool that you can use to set up the Router if you don’t want to use the Easy Install Wizard. You can also use it to manage advanced functions of the Router. From the Web-Based Advanced User Interface, you can perform the following tasks: •...
  • Page 29 Alternate Setup Method Turn your cable or DSL modem on by reconnecting the power supply to the modem. Mac or PC computer that was originally connected to the cable or DSL modem Network cable (to computer) To power adapter Existing networking cable (came with modem) Note: Your Router may have ports in different locations than depicted in the illustration above.
  • Page 30 Alternate Setup Method Step 2 Set up your Computer’s Network Settings to Work with a DHCP Server See the section in this User Manual called “Manually Configuring Network Settings” for directions. Step 3 Configure the Router Using the Web-Based Advanced User Interface Using your Internet browser, you can access the Router’s Web-Based Advanced User Interface.
  • Page 31 Alternate Setup Method Logging out of the Router One computer at a time can log into the Router for the purposes of making changes to the settings of the Router. Once a user has logged in to make changes, there are two ways that the computer can be logged out.
  • Page 32 Alternate Setup Method Internet Status Indicator This indicator is visible in all pages of the UI, indicating the connection status of the Router. When the indicator says “connection OK” in GREEN, the Router is connected to the Internet. When the Router is not connected to the Internet, the indicator will read “no connection”...
  • Page 33 Alternate Setup Method LAN Settings Shows you the settings of the Local Area Network (LAN) side of the Router. Changes can be made to the settings by clicking on any one of the links (IP Address, Subnet Mask, DHCP Server) or by clicking the “LAN”...
  • Page 34 Alternate Setup Method Step 4 Configure your Router for Connection to your Internet Service Provider (ISP) The “Internet/WAN” tab is where you will set up your Router to connect to your Internet Service Provider (ISP). The Router is capable of connecting to virtually any ISP’s system provided you have correctly configured the Router’s settings for your ISP’s connection type.
  • Page 35 Alternate Setup Method Setting your Connection Type From the “Connection Type” page, you can select the type of connection you use. Select the type of connection you use by clicking the button next to your connection type and then clicking “Next”...
  • Page 36 Alternate Setup Method Setting your Internet Service Provider (ISP) Connection Type to Dynamic IP A dynamic connection type is the most common connection type used with cable modems. Setting the connection type to “dynamic” in many cases is enough to complete the connection to your ISP. Some dynamic connection types may require a host name.
  • Page 37 Alternate Setup Method Setting your Internet Service Provider (ISP) Connection Type to Static IP A static IP address connection type is less common than other connection types. If your ISP uses static IP addressing, you will need your IP address, subnet mask, and ISP gateway address.
  • Page 38 Alternate Setup Method Setting your ISP Connection Type to PPPoE Most DSL providers use PPPoE as the connection type. If you use a DSL modem to connect to the Internet, your ISP may use PPPoE to log you into the service. If you have an Internet connection in your home or small office that doesn’t require a modem, you may also use PPPoE.
  • Page 39 Alternate Setup Method User Name This space is provided to type in your user name that was assigned by your ISP. Password Type in your password and re-type it into the “Retype Password” box to confirm it. Service Name A service name is rarely required by an ISP. If you are not sure if your ISP requires a service name, leave this blank.
  • Page 40 Alternate Setup Method Setting your Internet Service Provider (ISP) Connection Type to Point-to-Point Tunneling Protocol (PPTP) [European Countries Only]. Some ISPs require a connection using PPTP protocol, a type of connection most common in European countries. This sets up a direct connection to the ISP’s system. Type in the information provided by your ISP in the space provided.
  • Page 41 Alternate Setup Method My IP Address Provided by your ISP. Enter the IP address here. My Subnet Mask Provided by your ISP. Enter the IP address here. Connection ID Provided by your ISP. Enter the connection ID here. Disconnect after x minutes... This feature is used to automatically disconnect the Router from your ISP when there is no activity for a specified period of time.
  • Page 42 Alternate Setup Method Setting your Connection Type if you are a Telstra BigPond User ® [Australia Only]. Your user name and password are provided to you by Telstra BigPond. Enter this information below. Choosing your state from the drop-down menu will automatically fill in your login server IP address.
  • Page 43 Setting Custom Domain Name Server (DNS) Settings A “Domain Name Server” is a server located on the Internet that translates Universal Resource Locators (URLs) like “www.belkin. com” into IP addresses. Many Internet Service Providers (ISPs) do not require you to enter this information into the Router. The “Automatic from ISP”...
  • Page 44 Internet service. When you install the Router, its own MAC address will be “seen” by the ISP and may cause the connection not to work. Belkin has provided the ability to clone (copy) the MAC address of the computer into the Router.
  • Page 45 Alternate Setup Method Cloning your MAC Address To clone your MAC address, make sure that you are using the computer that was ORIGINALLY CONNECTED to your modem before the Router was installed. Click the “Clone” button . Click “Apply Changes” .
  • Page 46: Using The Web-Based Advanced User Interface

    Using the Web-Based Advanced User Interface Using your Internet browser, you can access the Router’s Web-Based Advanced User Interface. In your browser, type “192.168.2.1” (do not type in anything else such as “http://” or “www”) then press the “Enter” key. You will see the Router’s home page in your browser window.
  • Page 47: Changing Lan Settings

    10.x.x.x (where x is anything between 0 and 255). Subnet Mask There is no need to change the subnet mask. This is a unique, advanced feature of your Belkin Router. It is possible to change the subnet mask if necessary; however, do make changes to the subnet mask unless you have a specific reason to do so.
  • Page 48 IP address to change. ILocal Domain Name The default setting is “Belkin”. You can set a local domain name (network name) for your network. There is no need to change this setting unless you have a specific advanced need to do so. You can...
  • Page 49: Viewing The Dhcp Client List Page

    Using the Web-Based Advanced User Interface Viewing the DHCP Client List Page You can view a list of the computers (known as clients), which are connected to your network. You are able to view the IP address the computer, the host name (if the computer has been assigned one), and the MAC address of the computer’s network interface...
  • Page 50: Configuring The Wireless Network Settings

    Using the Web-Based Advanced User Interface Configuring the Wireless Network Settings Clicking on the header of the “Wireless” tab will take you to the “Wireless” header page. Under the “Wireless” tab, there are links that allow you to make changes to the wireless network settings. Changing the Wireless Network Name (SSID) To identify your wireless network, a name called the SSID (Service Set Identifier) is used.
  • Page 51 Using the Web-Based Advanced User Interface Using the Wireless Mode Switch Your Router can operate in three different wireless modes: “g and b”, “g only”, and “b only”. The different modes are explained on the next page.
  • Page 52 Using the Web-Based Advanced User Interface g and b Mode In this mode, the Router is compatible with 802.11b and 802.11g wireless clients simultaneously. This is the factory default mode and ensures successful operation with all Wi-Fi-compatible devices. If you have a mix of 802.11b and 802.11g clients in your network, we recommend setting the Router to g and b mode.
  • Page 53 Using the Web-Based Advanced User Interface networks. For best performance, use a channel that is at least five channels away from the other wireless network. For instance, if another network is operating on channel 11, then set your network to channel 6 or below.
  • Page 54: Securing Your Wi-Fi Network

    Using the Web-Based Advanced User Interface Securing your Wi-Fi Network ® Here are a few different ways you can maximize the security of your wireless network and protect your data from prying eyes and ears. This section is intended for the home, home office, and small office user. At the time of this User Manual’s publication, there are four encryption methods available.
  • Page 55 Most of the new wireless equipment in the market today supports both 64-bit and 128-bit WEP encryption, but you might have older equipment that only supports 64-bit WEP. All Belkin wireless products will support both 64-bit and 128-bit WEP. Encryption Keys After selecting either the 64-bit or 128-bit WEP encryption mode, it is critical that you generate an encryption key.
  • Page 56 Advanced Encryption Standard (AES) for encryption of data, which offers much greater security than WPA. WPA uses both Temporal Key Integrity Protocol (TKIP) and (AES) for encryption. For a list of Belkin wireless products that support WPA, please visit our website at www.belkin.com/networking.
  • Page 57 ���������� ������������ ����������������� ���������� ������������� ����������� ������������ The Wireless G Desktop Card cannot access the network because it is using a different network key than the network key that is configured on the Wireless G Router.
  • Page 58 Using the Web-Based Advanced User Interface Using a Hexadecimal Key A hexadecimal key is a combination of numbers and letters from A–F and 0–9. 64-bit keys are five two-digit numbers. 128-bit keys are 13 two-digit numbers. For instance: AF 0F 4B C3 D4 = 64-bit key C3 03 0F AF 0F 4B B2 C3 D4 4B C3 D4 E7 = 128-bit key In the boxes below, make up your key by writing in two characters between A–F and 0–9 in each box.
  • Page 59: Wep Setup

    Click “Apply Changes” to save the setting. WARNING: If you are configuring the Wireless G Router or access point from a computer with a wireless client, you will need to ensure that security is turned ON for this wireless client. If this is not done,...
  • Page 60 Click “Apply Changes” to save the setting. WARNING: If you are configuring the Wireless G Router or access point from a computer with a wireless client, you will need to ensure that security is turned on for this wireless client. If this is not done, your...
  • Page 61 Using the Web-Based Advanced User Interface Changing the Wireless Security Settings Your Router is equipped with the latest security standard called Wi-Fi Protected Access 2 (WPA2) and the legacy security standard called Wired Equivalent Privacy (WEP). Your Router also supports the Wi-Fi Protected SetupTM (WPS) specification, which simplifies the setup of a wireless network.
  • Page 62 Using the Web-Based Advanced User Interface Wi-Fi Protected Setup (WPS): Enabled or Disabled. Personal Identification Number (PIN) Method: In this method, a wireless client wishing to access your network must supply a 4- or 8-digit PIN to the Router. After clicking “Enroll”, you must start the WPS handshaking procedure from the client within two minutes.
  • Page 63: Wpa Setup

    . This patch works only with the Windows XP operating ® system. You also need to download the latest driver for your Belkin Wireless G Desktop or Notebook Network Card from the Belkin support site. Other operating systems are not supported at this time.
  • Page 64: Setting Wpa/Wpa2

    Using the Web-Based Advanced User Interface Setting WPA/WPA2 Select “WPA/WPA2-Personal (PSK)” from the “Security Mode” drop-down box. Select “WPA-PSK” for just WPA authentication, or “WPA2-PSK” for just WPA2 authentication, or you may select “WPA-PSK + WPA2- PSK” for WPA and WPA2 as the authentication type. Enter your pre-shared key.
  • Page 65: Guest Access (Optional)

    Using the Web-Based Advanced User Interface Guest Access (Optional) The guest pre-shared key allows guest users an Internet-only access to restrict them from entering your network and having access to files on your PCs. Enter your pre-shared key for guest access. This can be from eight to 63 characters and can be letters, numbers, or symbols.
  • Page 66 Setting up WPA for Wireless Desktop and Wireless Notebook Cards that are NOT Manufactured by Belkin If you do NOT have a Belkin WPA Wireless Desktop or Wireless Notebook Card, and it is not equipped with WPA-enabled software, a file from Microsoft called “Windows XP Support Patch for Wireless Protected Access”...
  • Page 67 Using the Web-Based Advanced User Interface Setting up Windows XP Wireless Network Utility to use WPA-PSK In order to use WPA-PSK, ensure you are using the Windows Wireless Network Utility by doing the following: Under Windows XP, click “Start > Control Panel > Network Connections”.
  • Page 68 Using the Web-Based Advanced User Interface Under the “Wireless Networks” tab, click the “Configure” button and you will see the following screen. For a home or small business user, select “WPA-PSK” under “Network Authentication”. Note: Select “WPA” if you are using this computer to connect to a corporate network that supports an authentication server such as a radius server.
  • Page 69: Using The Access Point Mode

    Using the Web-Based Advanced User Interface Using the Access Point Mode Note: This advanced feature should be employed by advanced users only. The Router can be configured to work as a wireless network access point. Using this mode will defeat the NAT IP sharing feature and DHCP server.
  • Page 70: Wireless Range Extension And Bridging

    Wireless Access Point. Note that you can only bridge your Belkin Wireless G Router (model F5D7230-4, F5D7231-4) to a Belkin Wireless G Range Extender/Access Point (model F5D7131, F5D7130). We do not support bridging with access points of other manufacturers at this time.
  • Page 71 Using the Web-Based Advanced User Interface Adding Another Network Segment Wirelessly Bridging an Access Point to your Router allows you to add a network segment in another area in the home or office without running wires. Connecting a network switch or hub to the Access Point’s RJ45 jack will allow a number of computers connected to the switch access to the rest of the network.
  • Page 72 Setting Up a Bridge Between your Wireless Router and a Secondary Access Point Bridging your Belkin Router to a secondary Access Point requires that you access the Router’s Advanced Setup Utility and enter the MAC address of the Access Point in the appropriate area. There are also a few other requirements.
  • Page 73 Using the Web-Based Advanced User Interface From a computer already connected to your Router, access the Advanced Setup Utility by opening your browser. In the address bar, type in “192.168.2.1”. Do not type in “www” or “http://” Note: before the number. If you have changed your Router’s IP address, use that IP address.
  • Page 74: Configuring The Firewall

    Using the Web-Based Advanced User Interface Configuring the Firewall Your Router is equipped with a firewall that will protect your network from a wide array of common hacker attacks including: • IP Spoofing • SYN flood • Land Attack • UDP flooding •...
  • Page 75 Using the Web-Based Advanced User Interface Configuring Internal Forwarding Settings The “Virtual Servers” function will allow you to route external (Internet) calls for services such as a web server (port 80), FTP server (Port 21), or other applications through your Router to your internal network. Since your internal computers are protected by a firewall, computers outside your network (over the Internet) cannot get to them because they cannot be “seen.”...
  • Page 76 Using the Web-Based Advanced User Interface Setting Client IP Filters The Router can be configured to restrict access to the Internet, email, or other network services at specific days and times. Restriction can be set for a single computer, a range of computers, or multiple computers. To restrict Internet access to a single computer, for example, enter the IP address of the computer you wish to restrict access to in the IP fields Next, enter “80”...
  • Page 77: Setting Mac Address Filtering

    Using the Web-Based Advanced User Interface Setting MAC Address Filtering The MAC address filter is a powerful security feature that allows you to specify which computers are allowed on the network. Any computer attempting to access the network that is not specified in the filter list will be denied access.
  • Page 78: Enabling The Dmz

    Using the Web-Based Advanced User Interface Enabling the Demilitarized Zone (DMZ) The DMZ feature allows you to specify one computer on your network to be placed outside of the firewall. This may be necessary if the firewall is causing problems with an application such as a game or video conferencing application.
  • Page 79 Using the Web-Based Advanced User Interface WAN Ping Blocking Computer hackers use what is known as “pinging” to find potential victims on the Internet. By pinging a specific IP address and receiving a response from the IP address, a hacker can determine that something of interest might be there.
  • Page 80: Utilities Tab

    Using the Web-Based Advanced User Interface Utilities Tab This screen lets you manage different parameters of the Router and perform certain administrative functions.
  • Page 81: Restarting The Router

    Using the Web-Based Advanced User Interface Restarting the Router Sometimes it may be necessary to restart or reboot the Router if it begins working improperly. Restarting or rebooting the Router will NOT delete any of your configuration settings. Restarting the Router to Restore Normal Operation Click the “Restart Router”...
  • Page 82 Using the Web-Based Advanced User Interface Restoring Factory Default Settings Using this option will restore all of the settings in the Router to the factory (default) settings. It is recommended that you back up your settings before you restore all of the defaults. Click the “Restore Defaults”...
  • Page 83 Using the Web-Based Advanced User Interface Saving a Current Configuration You can save your current configuration by using this feature. Saving your configuration will allow you to restore it later if your settings are lost or changed. It is recommended that you back up your current configuration before performing a firmware update.
  • Page 84 Using the Web-Based Advanced User Interface When the save is complete, you will see the following window. Click “Close”. The configuration is now saved. Restoring a Previous Configuration This option will allow you to restore a previously saved configuration. Click “Browse”. A window will open that allows you to select the location of the configuration file.
  • Page 85 Using the Web-Based Advanced User Interface You will be asked if you want to continue. Click “OK”. A reminder window will appear. It will take up to 35 seconds for the configuration restoration to complete. Click “OK”. A 35-second countdown will appear on the screen. When the countdown reaches zero, the Router’s configuration will be restored.
  • Page 86: Updating The Firmware

    Using the Web-Based Advanced User Interface Updating the Firmware From time to time, Belkin may release new versions of the Router’s firmware. Firmware updates contain feature improvements and fixes to problems that may exist. When Belkin releases new firmware, you can download the firmware from the Belkin update website and update your Router’s firmware to the latest version.
  • Page 87 Using the Web-Based Advanced User Interface Downloading a New Version of Firmware You will now be taken to the download page of “F5D7230-4 Firmware update - North America”. To download the new version of firmware, click the download logo ( A window will open that allows you to select the location where you want to save the firmware file.
  • Page 88 Using the Web-Based Advanced User Interface When the save is complete, you will see the following window. Click “Close”. The download of the firmware is complete. To update the firmware, follow the next steps in “Updating the Router’s Firmware”. Updating the Router’s Firmware In the “Firmware Update”...
  • Page 89 Using the Web-Based Advanced User Interface The “Update Firmware” box will now display the location and name of the firmware file you just selected. Click “Update”. You will be asked if you are sure you want to continue. Click “OK”. You will see one more message.
  • Page 90 Using the Web-Based Advanced User Interface Changing System Settings The “System Settings” page is where you can enter a new administrator password, set the time zone, enable remote management, and turn on and off the NAT function of the Router. Setting or Changing the Administrator Password The Router ships with NO password entered.
  • Page 91 Using the Web-Based Advanced User Interface Enabling Remote Management Before you enable this advanced feature of your Belkin Router, MAKE SURE YOU HAVE SET THE ADMINISTRATOR PASSWORD. Remote management allows you to make changes to your Router’s settings from anywhere on the Internet. There are two methods of remotely managing the Router.
  • Page 92 Enabling/Disabling UPnP UPnP (Universal Plug-and-Play) is yet another advanced feature offered by your Belkin Router. It is a technology that offers seamless operation of voice messaging, video messaging, games, and other applications that are UPnP-compliant. Some applications require the Router’s firewall to be configured in a specific way to operate properly.
  • Page 93 Using the Web-Based Advanced User Interface Enabling/Disabling Auto Firmware Update This innovation provides the Router with the built-in capability to automatically check for a new version of firmware and alert you that the new firmware is available. When you log into the Router’s Web-Based Advanced User Interface, the Router will perform a check to see if new firmware is available.
  • Page 94: Manually Configuring Network Settings

    Manually Configuring Network Settings In order for your computer to properly communicate with your Router, you will need to change your PC’s TCP/IP settings to DHCP. Manually Configuring Network Adapters in Windows 2000, NT, XP, or Vista Click “Start”, “Settings”, then “Control Panel”. Double-click on the “Network and dial-up connections”...
  • Page 95 Manually Configuring Network Settings Manually Configuring Network Adapters in Windows 98SE or Me Right-click on “My Network Neighborhood” and select “Properties” from the drop-down menu. Select “TCP/IP -> settings” for your installed network adapter. You will see the following window. If “Specify an IP address”...
  • Page 96 Manually Configuring Network Settings Restart the computer. When the computer restarts, your network adapter(s) are now configured for use with the Router. Set up the computer that is connected to the cable or DSL modem FIRST using these steps. You can also use these steps to add computers to your Router after the Router has been set up to connect to the Internet.
  • Page 97 Manually Configuring Network Settings Close the window. If you made any changes, the following window will appear. Click “Save”. Restart the computer. When the computer restarts, your network settings are now configured for use with the Router.
  • Page 98 Manually Configuring Network Settings Manually Configuring Network Adapters in Mac OS X Click on the “System Preferences” icon. Select “Network” from the “System Preferences” menu. Select “Built-in Ethernet” next to “Show” in the Network menu.
  • Page 99 Manually Configuring Network Settings Select the “TCP/IP” tab . Next to “Configure:” , you should see “Manually” or “Using DHCP”. If you do not, check the PPPoE tab to make sure that “Connect using PPPoE” is NOT selected. If it is, you will need to configure your Router for a PPPoE connection type using your user name and password.
  • Page 100: Recommended Web Browser Settings

    Recommended Web Browser Settings In most cases, you will not need to make any changes to your web browser’s settings. If you are having trouble accessing the Internet or the Web-Based Advanced User Interface, then change your browser’s settings to the recommended settings in this section. Internet Explorer 4.0 or Higher Start your web browser.
  • Page 101 Recommended Web Browser Settings Make sure there are no check marks next to any of the displayed options: “Automatically detect settings”, “Use automatic configuration script”, and “Use a proxy server”. Click “OK”. Then click “OK” again in the “Internet Options” page. Netscape Navigator 4.0 or Higher...
  • Page 102: Troubleshooting

    Troubleshooting Problem: Installation CD does not automatically start. Solution: If the CD-ROM does not start the Easy Install Wizard automatically, it could be that the computer is running other applications that are interfering with the CD drive. If the Easy Install Wizard screen does not appear within 15—20 seconds, open up your CD-ROM drive by double-clicking on the “My Computer”...
  • Page 103 Troubleshooting Problem: The Easy Install Wizard cannot find my Router. Solution: If the Easy Install Wizard is not able to find the Router during the installation process, please check the following items: If the Easy Install Wizard is not able to find the Router during the installation process, there may be third-party firewall software installed on the computer attempting to access the Internet.
  • Page 104 Troubleshooting Problem: The Easy Install Wizard cannot connect my Router to the Internet. Solution: If the Easy Install Wizard is not able to connect the Router to the Internet, please check the following items: Use the troubleshooting suggestions within the Easy Install Wizard.
  • Page 105 This will cause the Router to reattempt communication with the modem. If the “WAN” light on the Router is not lit after completing these steps, please contact Belkin Technical Support. Try shutting down and restarting your computer. Problem: •...
  • Page 106 Solution: If you are unable to connect to the Internet from a wireless computer, please do the following: Look at the lights on your Router. Your Belkin Router’s lights should be as follows: • The “Power” light should be on.
  • Page 107 Open your wireless utility software by clicking on the icon in the system tray at the bottom, right-hand corner of the screen. If you are also using a Belkin Wireless Card or Adapter with this Router, the tray icon should look like this (the icon may be red...
  • Page 108 (as opposed to wirelessly), ensure that “Broadcast SSID” is enabled. This setting is found on the Router’s wireless “Channel and SSID” configuration page. If you are still unable to access the Internet after completing these steps, please contact Belkin Technical Support.
  • Page 109 Troubleshooting Problem: My wireless network performance is inconsistent. Data transfer is sometimes slow. Signal strength is poor. I am having difficulty establishing and/or maintaining a Virtual Private Network (VPN) connection. Solution: Wireless technology is radio-based, which means connectivity and the throughput performance between devices decreases when the distance between devices increases.
  • Page 110 An access point is typically placed in the area not currently covered by your Wireless G Router, and is connected to the Router using either an Ethernet cable or through your home’s power lines using two Powerline Ethernet Adapters.
  • Page 111 Troubleshooting Problem: I am having difficulty setting up Wired Equivalent Privacy (WEP) security on a Belkin Wireless Router or Belkin Access Point. Solution: Log into your Wireless Router or Access Point. Open your web browser and type in the IP address of the Wireless Router or Access Point.
  • Page 112 Belkin client card (Wireless Network Card or Adapter). Solution: The client card must use the same key as the Wireless G Router or access point. For instance, if your Wireless Router or access point uses the key 00112233445566778899AABBCC, then the client card must be set to the exact same key.
  • Page 113 You also need to download the latest driver for your Belkin Wireless G Desktop or Notebook Network Card from the Belkin support site. Other operating systems are not supported at this time. Microsoft’s patch only supports devices with WPA-enabled drivers such as Belkin 802.11g products...
  • Page 114 Troubleshooting Problem: I am having difficulty setting up Wi-Fi Protected Access (WPA) security on a Belkin Wireless Router or Belkin Access Point for a home network. Solution: From the “Security Mode” drop-down menu, select “WPA-PSK (no server)”. For “Encryption Technique”, select “TKIP” or “AES”. This setting will have to be identical on the clients that you set up.
  • Page 115 Solution: Clients must use the same key that the Wireless G Router or access point uses. For instance, if the key is “Smith Family Network Key” in the Wireless G Router or access point, the clients must also use that same key.
  • Page 116 Click “OK”, then “Apply” to save the settings. Problem: I am having difficulty setting up Wi-Fi Protected Access (WPA) security, and I am NOT using a Belkin client card for a home network. Solution: If you are NOT using a Belkin WPA Wireless Desktop or Wireless Notebook Network Card and it is not equipped with WPA-enabled software, a file from Microsoft called “Windows XP Support Patch...
  • Page 117 For a home or small business user, select “WPA-PSK” under “Network Administration”. Select “TKIP” or “AES” under “Date Encryption”. This setting will have to be identical to the Wireless G Router or access point that you set up. Type in your encryption key in the “Network key” box.
  • Page 118 Troubleshooting What is the difference between 802.11b, 802.11g, 802.11a, and Pre-N? Currently there are four levels of wireless networking standards, which transmit data at very different maximum speeds. Each is based on the designation 802.11(x), so named by the IEEE, the board that is responsible for certifying networking standards.
  • Page 119 Troubleshooting Wireless Comparison Chart 600% faster Speed 11Mbps 54Mbps 54Mbps than standard 802.11g* Common Common Common household household household devices such devices such devices such as cordless as cordless as cordless 5GHz— phones and phones and phones and uncrowded microwave microwave microwave band...
  • Page 120 Troubleshooting Technical Support You can find technical support information at www.belkin.com/ networking or www.belkin.com/ through the tech support area. If you want to contact technical support by phone, please call: 877-736-5771 800-223-5546 ext. 2263 310-898-1100 ext. 2263 0845 607 77 87...
  • Page 121: Information

    Information FCC Statement DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC COMPATIBILITY We, Belkin International, Inc., of 501 West Walnut Street, Compton, CA 90220, declare under our sole responsibility that this device, F5D7230-4 to which this declaration relates, complies with Part 15 of the FCC Rules. Operation is...
  • Page 122: Fcc Radiation Exposure Statement

    Modifications The FCC requires the user to be notified that any changes or modifications to this device that are not expressly approved by Belkin International, Inc., may void the user’s authority to operate the equipment. Canada-Industry Canada (IC)The wireless radio of this device complies with RSS 210 Industry Canada.
  • Page 123 • EN 301 489 General EMC requirements for radio equipment. To determine the type of transmitter, check the identification label on your Belkin product. Products with the CE marking comply with the EMC Directive (89/336/EEC) and the Low Voltage Directive (72/23/EEC) issued bythe Commission of the European Community.
  • Page 124 Belkin warrants the Belkin product for the lifetime of the product. What will we do to correct problems? Product Warranty. Belkin will repair or replace, at its option, any defective product free of charge (except for shipping charges for the product). What is not covered by this warranty? All above warranties are null and void if the Belkin product is not provided to Belkin for inspection upon Belkin’s request at the sole expense of...
  • Page 125 Information Belkin reserves the right to review the damaged Belkin product. All costs of shipping the Belkin product to Belkin for inspection shall be borne solely by the purchaser. If Belkin determines, in its sole discretion, that it is impractical...
  • Page 126 +44 (0) 1933 35 2000 +44 (0) 1933 31 2000 fax © 2008 Belkin International, Inc. All rights reserved. All trade names are registered trademarks of respective manufactur ers listed. Apple, AirPort, Mac, Mac OS, and AppleTalk are trademarks of Apple Inc., registered in the U.S.
