Summary of Contents for Haier HLC15E
- Page 1 HLC15B/HLC15E/HLC19E/HLC19W LCD TV/DVD Player Combo USER MANUAL Please read this manual carefully before using this TV set and keep it for future reference.
- Page 2 WARNING AND CAUTION CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.FOR ANY PROBLEM, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. THERE IS A LIGHTNING ARROW SYMBOL IN THE TRIANGLE: THIS SYMBOL INDICATES HIGH VOLTAGE IS PRESENT INSIDE. IT IS DANGEROUS TO MAKE ANY KIND OF CONTACT WITH ANY INSIDE PART OF THIS PRODUCT.
- Page 3 IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
- Page 4 SAVE THESE INSTRUCTIONS Thank you for using our Haier product. This easy-to-use manual will guide you in getting the best use of your product. Remember to record the model and serial number. They are on label in back of the unit.
-
Page 5: Table Of Contents
CONTENT Safety Notice Items... Front Panel Controls... Connection Options... Remote Control Key Functions... Remote Control Installing Batteries... Connection Instructions... Grounding... External equipment Connections... Antenna Connection... PC Setup... VCR Setup... Cable TV Setup... External AV Source Setup... Basic Operating Instructions... Turn on the LCD-TV... Audio Control... -
Page 6: Safety Notice Items
Safety Notice Items Incorrect usage may cause fire or electric shock. required when you are installing, using and cleaning this machine. To insure your safety and extend the life-span of LCD-TV, please read the following items carefully before using: l Please read and understand all the instructions before operation; Please keep this manual for later use;... -
Page 7: Front Panel Controls
TV channel down / to select the item in the menu TV channel up / to select the item in the menu 6. Power indicator 7.Remote Sensor Receives the signals from the remote control VOL+ CH+ POWER DC POWER SWITCH TV/AV/S-VIDEO/PC/COMPONENT HLC19W HLC15E DC POWER SWITCH... -
Page 8: Connection Options
Connection Options STOP PLAY/PAUSE OPEN/CLOSE PREV NEXT DVD insert Please see the real set of the DVD position Antenna Input Connect cable or antenna signals to the TV, either direc- tly or through your cable box. PC Audio Input Connect the audio output from the pc to the PC audio input port Video Input... -
Page 9: Remote Control Key Functions
Remote Control Key Functions When using the remote control, aim it towards the remote sensor on the TV POWER TV/AV TV/DVD OPEN/CLOSE SLEEP Q.VIEW INFO MENU STOP SETUP PAUSE/STEP FWD . PREV D.MENU REPEAT PLAY/ENTER ANGLE TITLE/PBC SEARCH PROGRAM AUDIO ZOOM EXIT FAV.LIST... -
Page 10: Remote Control
Remote Control Installing Batteries Remove the battery cover. Insert two size AA batteries matching the +/-polarities of the battery to the +/- marks inside the battery compartment. Precautions Make sure that there is no obstacle between the remote controller and television set. Keep the remote control away from heat sources or humid areas to ensure... -
Page 11: Connection Instructions
Connection Instructions Grounding Ensure that you connect the grounding / earth wire to prevent possible electric shock. If grounding methods are not possible, have a qualified electrician install a separate circuit breaker. Do not try to ground the unit by connecting it to telephone wires, lightening rods, or gas pipes. External Equipment Connections Antenna Connection - Antenna or Cable Service with a Cable Box Connections... -
Page 12: Pc Setup
Connection Instructions PC Setup You can use your LCD-TV as a monitor for your personal computer using a VGA cable (not supplied). Connection and use steps: 1.Read the user guide supplied with your computer and ensure that it has a VGA connector; 2.Make sure that the power of the LCD -TV and the PC are off;... -
Page 13: Vcr Setup
Connection Instructions VCR Setup - To avoid picture noise (interference), leave an adequate distance between the VCR and TV Connection and use steps: 1.Read the user guide supplied with your AV devices and ensure that it has Composite or S-Video connectors; 2.Make sure that the power of the LCD-TV and the AV device are off;... -
Page 14: Cable Tv Setup
Connection Instructions Cable TV Setup - After subscribing to a cable TV service from a local provider you can watch cable TV programming. The TV cannot display TV programming unless a TV tuner device or cable TV converter box is connected to the TV. - For further information regarding cable TV service, contact your local cable TV service provider(s). -
Page 15: Basic Operating Instructions
Basic Operating Instructions Turn on the LCD-TV When the POWER POWER TV/AV TV/DVD OPEN/CLOSE is turned on, the indicator light on the front of the LCD-TV SLEEP Q.VIEW INFO MUTE changes from red to green(or from dark to light). When the LCD-TV is turned off using the power button, the LCD-TV will go into standby mode and the indicator light turns red(or P.MODE... -
Page 16: Select The Tv Channel You Want
Basic Operating Instructions Select the TV Channel You Want You can use the number buttons on the remote control to directly select TV channels. And you can press the buttons on the remote control or on the panel to make a selection. -
Page 17: Button
Basic Operating Instructions - button Press to select additional channels (digital and analog) being broadcast by the same station. For example, to select digital channel “11.1”, press “11”, then press “-” and “1”; to select analog channel 13.0, press 13 first, then press - and 0.(You must press - and 0 when you select analog channel. -
Page 18: Menu Operations
Menu Operations * In this manual, the OSD (On Screen Display) may be differ from your TV These are examples to illustrate the TV's operation. Press TV/AV to select the input source. The menu for each source may be different . 1. -
Page 19: Video Menu Options Continued
Menu Operations Video Menu Options continued 3.Press VOL+/VOL- button to increase and decrease the level to adjust the selected option to your preference . 4. Repeat step 2 and step 3 until desired picture quality has been achieved . Function: BRIGHTNESS :Adjust the brightness of the picture . -
Page 20: Audio Menu Options Continued
Menu Operations Audio Menu Options continued You can adjust sound options to the levels you prefer. 2. Press CH+/CH- button to enter the audio menu and to go up and down to select the desired option . 3.Press VOL+/VOL- button to increase and decrease the level to adjust the selected option to your preference . -
Page 21: Function Menu Options
Menu Operations Function Menu Options 1. Press MENU button and VOL+/VOL- until the following menu appears on the screen. 2. Press CH+/CH- button to enter the function menu and to go up and down to select the desired option . 3.Press VOL+/VOL- button to increase and decrease the level to adjust the selected option to your preference . -
Page 22: Function Menu Options Continued
Menu Operations Function Menu Options Continued Note: Select CC1 for full translation of the primary language such as English in your area. Select CC2 for secondary language translation such as French or any other language that may be broadcast in your area. .DTV CAPTION (can only be available in DTV):Press CH+/- to select DTV CAPTION and VOL+ to enter . - Page 23 Menu Operations Function Menu Options Continued Text Opacity: Specify the opacity for the text color. Text Color: Select the text color or the opacity of the text box of caption display according to your own preference. Select a color and one of the opacity options. Edge Color: Press VOL+/VOL- to select the edge color according your own preference Edge Type: Press VOL+/VOL- to select the edge color according your own...
-
Page 24: Adjust Menu Options
Menu Operations Function Menu Options Continued TIMER ON MODE ON TIME --:-- Press CH+/CH- to select MODE and VOL+/VOL- to set it OFF/DAILY/ONCE. Press CH+/CH- to select ON TIME and VOL+ to enter. Press VOL+/VOL- to select the position you want to change and CH+/CH- to set. TIMER OFF: Press VOL+ to enter the submenu to set.. -
Page 25: Adjust Menu Options Continued
Menu Operations Adjust Menu Options Continued Functions: AUTO CONFIG : Automatically adjusts picture location frequency and phase parameters . PHASE : Removes any horizontal distortion and clears or sharpens the displayed characters . CLOCK : Adjust the TFT-LCD to match the PC input source clock frequency H POSITION : Picture horizontal position adjust V POSITION : Picture vertical position adjust . -
Page 26: Channel Menu Options Continued
Menu Operations Channel Menu Options Continued SKIP : If you want skip a channel , press VOL+/VOL- to select ON , and this channel will be skipped next time when you press CH+/CH- . You can press the digit buttons to select the channel . If you want to restore the channel , select OFF. -
Page 27: Lock Menu Options Continued
Menu Operations Lock Menu Options Continued This function enables you to block certain TV channels in accordance to the requirements established by the FCC. PARENTAL LOCK: Press VOL+/VOL- button to select ON or OFF. parental off means the lock function is turned off . If the Parental Lock is in "off" mode then function will not be active to accept the Parental Guidance signal. - Page 28 Menu Operations Lock Menu Options Continued PARENTAL LOCK TECHNOLOGY: The "P.L. Technology" allows you to use U.S. and Canadian Movies and TV PROGRAMS Guide ratings to block certain types of TV programs and movies. To clearly understand TV program rating codes, read the following information: U.S.
- Page 29 Menu Operations Lock Menu Options Continued To clearly understand Canadian program rating codes, read the following list: Canadian English Rating Chart This type of programming is intended for children under age 8. There is no offensive language, nudity or sexual content. C8+:These types of rated programs are generally considered acceptable for children 8 years and over.
-
Page 30: Dvd Features
DVD Features Basic Playback Preparations Preparations Press the TV/DVD button on the remote control to enter the DVD status. Basic playback Basic playback 1.Place a disc in the disc tray. If there is no disc placed on the disc tray in DVD mode, OPEN will display on the screen all the times) There is only one disc size... -
Page 31: Advanced Playback
DVD Features(Continued) Advanced Playback IMPORTANT NOTE: ALL DESCRIBED FUNCTIONS A FOR DVD DISCS. IF YOU PLAY OTHER DISC FORMATS THE OPERATION AND ON SCREEN DISPLAY WILL BE DIFFERENT. CAPTION SUBTITLE Press " SUBTITLE ", the screen will display "SUBTI- TLE 01/XX XXXXX", "01" indicates the ordinal number of this language;... -
Page 32: Special Function Playback
Special Function Playback JPEG DISC PLAYBACK When a disc containing standard JPEG picture files is inserted into the player, a navigation menu will be displayed automatically. Use the UP and DOWN cursor buttons to select a file then press PLAY/ENTER. The slide show will commence. Press PREVIOUS or NEXT to move between pictures. -
Page 33: Dvd System Setup
DVD System Setup DVD System Setup General Setup Process 1.Press the SETUP button, the SETUP General Setup Page,Preference Page will be displayed in turn. 2.Press CH+/- b item, then press submenu. PLAY/ENTER 3.Press CH+/- bu to select then press PLAY/ENTER to confirm. 4.Press SETUP repeatedly to exit the set-up menus. - Page 34 DVD System Setup(Continued) DVD System Setup General Setup Page ANGLE MARK: Users can select a particular camera angle when playing a DVD which offers multiple angles. This item allows you to set Angle Mark ON or OFF. On Screen Display (OSD) Language: Users can select on-screen display language.
- Page 35 DVD System Setup(Continued) DVD System Setup SETUP PLAY/ENTER SETUP PLAY/ENTER Preference Page The Preference Page is only available when there is no disc in the player. PARENTAL: The parental control function works in conjunction with the different censorship classes assigned to DVDs. These classes help to control the types of DVDs that the family watches, There are up to 8...
- Page 36 DVD System Setup(Continued) DVD System Setup SETUP PLAY/ENTER DEFAULT: Resets all settings (except password and parental lock status) for this DVD player back to the manufacturers original settings. Press ENTER to perform the reset. Note: Some functions may not be available depending on the type of disc. ..Preference Page..
-
Page 37: Playable Discs
Playable Discs The following discs can be played: You cannot play discs other than those listed above. You cannot play non-standardized discs, even if they may be labelled as above. The performance of CD-R or CD-RW disc depends on the way the disc was burned. In a few cases, their performance may not be consistant or may not even operate at all. -
Page 38: Disc Protection And Dvd Characteristics
Disc Protection and DVD Characteristics Compare DVD disc with other discs: Encode method Single- side Capacity single- layer 4.7G Playing Time minutes Disc diameter Horizontal resolution Picture proportion Subtitle Language Sound quality Digital/MPEG Analog Double Double- Single- -side side side single double- double-... -
Page 39: Troubleshooting Guide
Troubleshooting Guide To assist in location possible faults use help guide below Troubleshooting No picture, no sound Blank screen No sound Poor sound No picture in some channel No color for some channel program (black and white) Spots with some or all pictures Abnormal functioning Note:... -
Page 40: Specifications
Humidity Accessories NOTE Design and specifications are subject to change without notice. Dimensions quoted in this manual are approximate. HLC15B/HLC15E NTSC, ATSC, Cliar QAM 1.5W+1.5W AV input PC input S-VIDEO input PC audio input Headphone output YPbPr input Antenna input... -
Page 41: Warranty
Warranty Warranty Warranty 90 days labor and one year parts . - Page 42 V0.2 0090508051C...
