American Standard 9504 Specification Sheet

CLINIC SERVICE SINKS
MODEL NUMBERS
FLOOR MOUNT
9504.010
WALL HUNG
9512.013
FLOOR MOUNT
INLET SPUD
COVER PLATES
11'' Rim Guards
Inlet Spud 1-1/2x1-1/2
Loose Strainer
Cover Plates
FOR COMPONENT PART ORDERING SEE CURRENT PRODUCT SELECTOR AND
PRICING GUIDE.
K-4
REV. A
DESCRIPTION
DESCRIPTION
LOOSE STRAINER
INLET SPUD
RIM GUARDS
COMPONENT
7832.017
PART NUMBER
047007-0070A
037640-0020A
047202-0070A
P r o d u c t n a m e s l i s t e d h e r e i n a r e t r a d e m a r k s o f A m e r i c a n S t a n d a r d I n c .
A m e r i c a n S t a n d a r d I n c . 1 9 9 2
C
WALL HUNG
PKG QTY
1
PKG QTY
1
1
2
