2D Code Handy Scanner
AT10Q-SM
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Denso AT10Q-SM

Summary of Contents for Denso AT10Q-SM

  • Page 1 2D Code Handy Scanner AT10Q-SM User's Manual...
  • Page 2 If it is judged by DENSO WAVE INCORPORATED that malfunction of the product is due to the product having been dropped or subjected to impact, repairs will be made at a reasonable charge even within the warranty period.

  • Page 3: Table Of Contents

    Contents Preface......................................i SAFETY PRECAUTIONS.................................ii Care and Maintenance................................vi Chapter 1 Names and Functions ..............................1 Chapter 2 Preparation ................................2 2.1 Operating Environment for the Use of USB Interface ..................2 2.2 Connecting the Interface Cable to the Scanner......................3 Chapter 3 Connection to the Host Computer ..........................4 3.1 Using the RS-232C Interface ..........................4 3.2 Using the USB Interface ............................5 3.2.1 Setting up the USB-COM interface......................6...
  • Page 4 Chapter 8 Beeper, Indicator LED, Marker Beam, and Illumination LEDs................41 8.1 Beeper...................................41 8.2 Indicator LED...............................42 8.3 Marker Beam................................44 8.4 Illumination LEDs..............................44 Chapter 9 Communication ..............................45 9.1 RS-232C Interface..............................45 9.2 USB-COM Interface ............................46 9.3 USB Keyboard Interface ............................47 9.4 Communication Format............................48 9.5 GTIN Format Conversion ............................59 Chapter 10 Image Capturing..............................64 10.1 Outline ..................................64...

  • Page 5: Preface

    Preface Please READ through this manual carefully. It will enable you to operate your scanner correctly. After you have finished reading this manual, keep it handy for speedy reference. Note: Do not use this scanner in an environment with electrical noise that can trigger malfunction. Note: Specifications described in this manual are supported by AT10Q Firmware version 1.01 or later.

  • Page 6: Safety Precautions

    SAFETY PRECAUTIONS Be sure to observe all these safety precautions. Please READ through these instructions carefully. They will enable you to use the scanner correctly. Always keep this manual nearby for speedy reference. Strict observance of these warnings and cautions is a MUST for preventing accidents that could result in bodily injury and substantial property damage.
  • Page 7 To System Designers: • When introducing the scanner in those systems that could affect human lives (e.g., medicines management system), develop applications carefully through redundancy and safety design which avoids the feasibility of affecting human lives even if a data error occurs. •...
  • Page 8 • Never disassemble or modify the scanner; doing so could result in an accident such as break or fire. Doing so could result in a fire or electrical shock. Never disassemble • Do not put the scanner on an unstable or inclined plane. The scanner may drop, creating injuries.
  • Page 9 • When disconnecting the AC adapter from the wall socket, hold the AC adapter body not the power cable. The power cable may be broken, resulting in a burnt AC adapter, electrical shock, or fire. • If the interface cable is damaged (e.g., exposed or broken lead wires), stop using it and contact your nearest dealer.

  • Page 10: Care And Maintenance

    Care and Maintenance Dust or dirt accumulating on the clear plate of the code reading window will affect reading performance. If you use the scanner in dusty areas, therefore, periodically check the clear plate and clean it if dusty. • To clean the plate, first blow the dust away with an airbrush. Then wipe the plate with a cotton swab or the similar soft one gently.

  • Page 11: Chapter 1 Names And Functions

    Chapter 1 Names and Functions Indicator LED Reading window This turns blue after a successful Point this at the code to read and flashes red if there is an read. error. (Refer to Section 8.2 for details.) Trigger switch Press this to read a code. Beep hole The following trigger switch The beeper sounds when...

  • Page 12: Chapter 2 Preparation

    * Registered users can download the configuration software (ScannerSetting_2D) from QBNet, their customer support section on the Denso Wave website at no extra charge. For further details on QBNet or to register, visit the following URL.

  • Page 13: Connecting The Interface Cable To The Scanner

    2.2 Connecting the Interface Cable to the Scanner (1) Pull the connector cover of the interface cable off its connector as shown below. (2) Plug the interface cable connector into the connector located in the bottom of the scanner. Note: As shown below, hold the scanner body, align the mark on the cable connector with that on the scanner, and fully insert the interface cable connector.

  • Page 14: Chapter 3 Connection To The Host Computer

    Chapter 3 Connection to the Host Computer 3.1 Using the RS-232C Interface (1) Connect the RS-232C interface cable to the host computer. AC adapter Scanner RS-232C interface cable (2) Plug the AC adapter into the DC power jack provided in the interface cable connector. Note: When disconnecting the interface cable or DC power jack, hold the connector housings not the cables.

  • Page 15: Using The Usb Interface

    3.2 Using the USB Interface The scanner receives and sends data from/to the host computer through the USB-COM interface or USB keyboard interface. You need to set up the device driver designed for the interface to be used. Notes for connecting the USB interface cable To use the USB-COM interface, you need to install the serial port driver to the host computer before connection of the USB interface cable.

  • Page 16: Setting Up The Usb-Com Interface

    The driver always serves as a virtual serial port even if a USB device is unplugged, so the driver always occupies a COM port number. The driver cannot coexist with conventional Denso USB-COM device drivers in a host computer. In the installation procedure, the Active USB-COM port driver requires uninstalling the conventional ones.
  • Page 17 (3) Check that the USB device (scanner) to be connected is not plugged in the computer, and then click OK. Note: When installing the serial port driver for the 2nd or the following USB devices on the same computer, check that none of those USB devices is plugged in the computer, and then click OK.
  • Page 18 (5) Wait for the caution message for driver's digital signature to appear, then click Continue Anyway to proceed. (6) After completion of installation of the driver files, click Finish. • To use two or more USB ports To use two or more USB ports, run the Setup.exe by the same number of times as the number of USB ports to be used. Running the Setup.exe once adds one COM port.
  • Page 19 (4) Select "Install the software automatically (Recommended)" and click Next. (5) Wait for the wizard to start searching for the USB driver. (6) Wait for the USB driver to be found and for the caution message for driver's digital signature to appear, then click Continue Anyway to proceed.
  • Page 20 "Safe removal of hardware" on the Windows task tray When the USB device (scanner) is being connected, Windows shows the "Unplugging DENSO WAVE USB Device (COMx) in safety" on the task tray. This is useful to view the connection status of USB devices or disconnect those devices.

  • Page 21: Setting Up The Usb Keyboard Interface

    3.2.2 Setting up the USB keyboard interface The USB keyboard interface requires the USB device class driver for HID (Human Interface Device) which is included in Windows 98 or later Operating Systems and whose setup wizard will automatically run. You do not need to install the device driver.
  • Page 22 Windows XP (1) Switch the computer on to run Windows XP. Log on as an Administrator. (2) Connect the scanner's USB interface cable to the computer or USB hub. (3) Wait for the Found New Hardware hint to pop up on the Windows task tray.
  • Page 23 Windows Vista (1) Switch the computer on to run Windows Vista. Log on as an Administrator. (2) Connect the scanner's USB interface cable to the computer or USB hub. (3) Wait for the Installing device driver software hint to pop up on the Windows task tray.

  • Page 24: Chapter 4 Scanning Codes

    Chapter 4 Scanning Codes (1) Bring the reading window to a target code and press the trigger switch. The marker beam comes on, indicating the scan range. The illumination LEDs light and the scanner reads the target code. Note: This step is not required for the continuous reading modes 1, 2 and auto sensing mode.) Scan range Scanning distance...

  • Page 25: Chapter 5 Customizing The Scanner

    RS-232C interface, USB-COM interface and USB keyboard interface. * Registered users can download the configuration software (ScannerSetting_2D) from QBNet, their customer support section on the Denso Wave website at no extra charge. For further details on QBNet or to register, visit the following URL. http://www.denso-wave.com/en/qbnet...

  • Page 26: Chapter 6 Scanning Control

    Chapter 6 Scanning Control Two types of scanning controls are available--Trigger switch control and Software control. Trigger switch control: Pressing the trigger switch readies the scanner for scanning. (Refer to Section 6.1.) Software control: Instead of pressing the trigger switch, you send control commands from the host computer via the RS-232C or USB-COM interface to ready the scanner for scanning or put the scanner on standby.

  • Page 27: Software Control

    6.2 Software Control You can control the scanner by sending scanning control commands from the host computer via the RS-232C or USB-COM interface, instead of pressing the trigger switch. Scanning control commands include R, READON, LON, Z, READOFF and LOFF and are restricted by the trigger switch operating modes, as listed below.

  • Page 28: Scanning On The Hands-Free Stand

    6.4 Scanning on the Hands-free Stand Putting the scanner on the hands-free stand (shown below) switches the scanner to the auto sensing mode automatically and temporarily, without selecting the auto sensing mode using the QR-coded parameter menu or the configuration software (ScannerSetting_2D). The automatic switching function can be disabled with the configuration software.

  • Page 29: Chapter 7 Scanning Functions

    Chapter 7 Scanning Functions 7.1 Data Verification Mode The data verification mode verifies the code data read against the master data stored in the scanner and reports the match status with data output. Data verification read is available in two types--"n-point verification" and "2-point verification," which can be selected with the configuration software (ScannerSetting_2D).
  • Page 30 2-point verification Scan master registration 1) Switch the scanner to the data verification mode and select the RS-232C or USB-COM interface. The indicator LED lights in green. 2) Use the scanner to scan a master code to be registered. (The scanner operates in the trigger switch operating mode currently set.) After the registration of master data, the indicator LED turns blue and then goes OFF.

  • Page 31: Specifying A Verification Object

    7.1.2 Specifying a verification object You can specify two types of verification objects--data string and data block. For data string verification, specify the verification start position and the number of characters to be verified. For data block verification, specify one of the data blocks delimited by commas in the CSV format.

  • Page 32: Verification Result Output

    7.1.3 Verification result output (1) Report of match/mismatch status You can select any of the following report types using the configuration software (ScannerSetting_2D). Selecting "Disable transmission" reports nothing. Setting If there is a match: If there is a mismatch: Disable transmission. Disable transmission.

  • Page 33: Editing Data

    7.2 Editing Data You can edit and output code data read, in any of the four data edit modes--"data extraction mode," "data substitution mode," "data blocksorting mode" and "ADF script mode." These data edit modes can be selected with the configuration software (ScannerSetting_2D).
  • Page 34 Extraction start and end positions "Extraction start position" "Extraction end position" Head position nth position Tail position nth position Tail position By n positions from the start position nth position The n can be 1 through 9999. Note that if the extraction start position is specified as nth position, the extraction end position should be equal to or greater than the extraction start position.

  • Page 35: Extracting Data Blocks

    7.2.1.2 Extracting data blocks If data read is in the comma-delimited CSV format, the scanner extracts data blocks specified by the data block numbers from a code specified by the "Code type" and then outputs it in the data transmission format selected in the scanner (see Chapter 9, Section 9.4).
  • Page 36 Example Code read: QR Code, Data: (See the table below.) Header: STX, Terminator: ETX, Scanner ID: Disable, Code ID mark: Disable, Transmission of the number of digits: Disable, Prefix/Suffix: None, BCC: Disable Extraction conditions Data read Data block numbers Output data "Code type": QR Code 1,23,456,7890 1, 2 and 3...

  • Page 37: Extracting Ai (Application Identifier)-Prefixed Strings

    7.2.1.3 Extracting AI (Application Identifier)-prefixed strings If the scanner reads any of EAN-128 (GS1-128), RSS (GS1 DataBar), and EAN.UCC Composite symbols (excluding linear components in a UPC/EAN Composite symbol), it edits the data according to AIs and outputs it in the data transmission format selected in the scanner (see Chapter 9, Section 9.4).
  • Page 38 Example Data read: (01)94901234567894(11)030808(13)030810(17)040208(17)040305 Header: STX, Terminator: ETX, Scanner ID: Disable, Code ID mark: Disable, Transmission of the number of digits: Disable, Prefix/Suffix: None, BCC: Disable Extraction conditions AIs specified Delimiter Output data "Data transfer 01,11,17 Comma [STX]94901234567894,030808,040208[ETX] regardless of error 17,11 [STX]040208,030808[ETX] result": Prohibit...
  • Page 39 (2) AI parenthesizing mode In this mode, the scanner parenthesizes AIs contained in data read and outputs the edited data according to the extraction conditions. Extraction conditions Extraction conditions Choices "Data transfer regardless of error result" Permit/Prohibit If the scanner fails to extract an AI-prefixed element string when the "Data transfer regardless of error result" is permitted, it outputs the data read as is without editing.
  • Page 40 (3) AI table In the AI-prefixed string extraction, the scanner edits data according to the Application Identifiers (AIs) defined below. Format Description n2+n18 Serial Shipping Container Code (SSCC) n2+n14 Global Trade Item Number (GTIN) n2+n14 GTIN of Trade Items Contained in a logistic unit (For Use with AI 37 Only) n2+n14 Reserved.
  • Page 41 Format Description 321n n4+n6 Length or 1st Dimension, Inches (***) 322n n4+n6 Length or 1st Dimension, Feet (***) 323n n4+n6 Length or 1st Dimension, Yards (***) 324n n4+n6 Width, Diameter, or 2nd Dimension, Inches (***) 325n n4+n6 Width, Diameter, or 2nd Dimension, Feet (***) 326n n4+n6 Width, Diameter, or 2nd Dimension, Yards (***)
  • Page 42 Format Description 355n n4+n6 Area, Square Yards, Logistics (***) 356n n4+n6 Net Weight, Troy Ounces (***) 357n n4+n6 Net Volume, Ounces (***) 360n n4+n6 Volume, Quarts (***) 361n n4+n6 Volume, Gallons (***) 362n n4+n6 Gross Volume, Quarts (***) 363n n4+n6 Gross Volume, Gallons (***) 364n n4+n6...
  • Page 43 Format Description n3+n15 Country of Initial Processing n3+n3 Country of Processing n3+n3 Country of Disassembly n3+n3 Country of Final Processing n2+n4+n7+an..10+n1 Carrier Assigned Tracking Number 7001 n4+n13 NATO Stock Number (NSN) 7002 n4+an..30 UN/ECE Meat Carcasses and Cuts Classification 7003 n4+n10 Effective term (YYMMDDHHMM) 7030...
  • Page 44 Format Description n2+an..30 Company Internal Information--Carrier n2+an..30 Company Internal Information--Carrier n2+an..30 Company Internal Information--Company n2+an..30 Company Internal Information--Company n2+an..30 Company Internal Information To indicate only year and month, DD must be filled with "00." (**) n indicates the length of data. (***) n indicates the decimal point position.

  • Page 45: Data Substitution Mode

    7.2.2 Data substitution mode If the scanner reads a code specified by the "Code type" in this mode, it searches the data read for the specified string (max. 16 ASCII characters), substitutes it with the specified substitution string (max. 16 ASCII characters), and outputs it in the data transmission format selected in the scanner (see Chapter 9, Section 9.4).

  • Page 46: Data Blocksorting Mode

    7.2.3 Data blocksorting mode The scanner splits code data read into a maximum of 5 blocks at the specified split positions, sorts those blocks in the specified order, and outputs it in the data transmission format selected in the scanner (see Chapter 9, Section 9.4). Note: The split position must be specified by the number of digits from the head of code data read.

  • Page 47: Adf Script Mode

    7.2.4 ADF script mode The ADF script refers to a simple program language designed for editing of data read. It enables the following functions. (1) Extracting data that is fixed or variable in length (2) Supporting Application Identifiers (AIs) in EAN-128 (GS1-128), RSS (GS1 DataBar) and EAN.UCC Composite symbols (3) Sorting data blocks into the specified order (4) Collating data for verification...

  • Page 48: Point Scan Mode

    Point Scan Mode In the point scan mode, you can aim at a target code by matching up the center spot of the marker beam with that code. If there is no code at that center spot or the scanner cannot detect the marker beam due to high levels of ambient lighting, the scanner cannot read anything.

  • Page 49: Scanning Split Qr Code Symbols

    7.6 Scanning Split QR Code Symbols QR Code symbology can split data into a maximum of 16 blocks and encode each of them into a split QR Code symbol (model 1 or 2). Split QR Code scanning is possible only with the same QR Code model. The scanner can scan split QR Code symbols and restore them to the original data string in edit mode, batch edit mode, and non-edit mode, which you can select using the QR-coded parameter menu or configuration software (ScannerSetting_2D).

  • Page 50: Multi-Line Barcode Scanning

    Multi-line Barcode Scanning The scanner can scan up to 3 lines of bar codes in the readable area at any one time. You can specify the number of lines to be scanned, the data output order and output format using the configuration software (ScannerSetting_2D).* 7.7.1 Number of lines The number of lines allowed for multi-line barcode scanning is 2 or 3.

  • Page 51: Chapter 8 Beeper, Indicator Led, Marker Beam, And Illumination Leds

    Chapter 8 Beeper, Indicator LED, Marker Beam, and Illumination LEDs 8.1 Beeper (1) Beeping The scanner emits a short or long beeps, once or a couple of times as described below. The beeper emits a short beep when: - the scanner has read a code successfully, - code data read matches the master data in the data verification mode, - the scanner has read a split QR Code symbol, - the "Start setting"...

  • Page 52: Indicator Led

    8.2 Indicator LED The indicator LED lights or flashes in blue, green, red or orange as described below. The indicator LED lights in blue when: - the scanner has read a code successfully, - the "Start setting" or "End setting" code is read from the QR-coded parameter menu (given in Chapter 12), - the scanner starts or ends a sequence of split QR Code scanning, - the scanner has read a split QR Code symbol, - the parameter values are saved by a PW command (refer to Appendix 2),...
  • Page 53 The indicator LED can be disabled with the QR-coded parameter menu or configuration software (ScannerSetting_2D). In any of the following cases, however, the indicator LED comes on regardless of the current LED setting. - When the scanner is being customized with the QR-coded parameter menu (Chapter 12), - When the scanner receives an LED-ON command (LB, LG or LR) from the host computer (refer to Appendix 2), - When the configuration software (ScannerSetting_2D) starts up or any setting is newly established, - When the scanner reads a batch-process QR Code symbol,...

  • Page 54: Marker Beam

    Marker Beam The red marker beam (semiconductor laser) comes on to indicate the scanning area as a guide. The marker provides a choice of the three modes--normal marker mode, marker-OFF mode and marker-ON mode that can be selected by using the QR-coded parameter menu or the configuration software (ScannerSetting_2D). (1) Normal marker mode When the trigger switch is in auto-off mode: Holding down the trigger switch turns on the marker beam for approx.

  • Page 55: Chapter 9 Communication

    Chapter 9 Communication 9.1 RS-232C Interface With the RS-232C interface being selected, the scanner uses asynchronous data transmission and communicates with the host computer or external equipment via the RS-232C. You can set various communications conditions using the QR-coded parameter menu or configuration software (ScannerSetting_2D). Code data read is transferred in the following format.

  • Page 56: Usb-Com Interface

    This scanner is compliant with USB 1.1 (Universal Serial Bus Specification Revision 1.1). 9.2 USB-COM Interface Installing the dedicated Active USB-COM port driver to the host computer allows the USB-COM interface to operate in communications applications using the conventional serial port. Notes for use •...

  • Page 57: Usb Keyboard Interface

    9.3 USB Keyboard Interface The USB keyboard interface requires no dedicated device driver. Data read by the scanner can be entered to the cursor position in your application. The USB keyboard interface operates in conformity with the following: - Universal Serial Bus (USB) Device Class Definition for Human Interface Devices (HID) Version 1.11 - Universal Serial Bus (USB) HID Usage Tables Version 1.11 keyboard (1) CAPS Lock state Select the CAPS Lock ON or OFF to match the state of the connected keyboard.

  • Page 58: Communication Format

    9.4 Communication Format Data transmission format Select one of the following two data transmission formats. No. of digits Scanner Code ID Header Prefix Code data Suffix Terminator mark No. of digits Scanner Code ID Header Prefix Code data Suffix Terminator mark (1) Header/Terminator The following choices are available.
  • Page 59 (5) Code ID mark This optional field specifies the code system. It offers ten combinations with five code ID marks (Type 1, Type 2, Type 3, Type 4, and user-defined) and two output modes (coupling and separating) as listed below. You can also select whether or not to transmit the code ID mark.
  • Page 60 (1/2) Code ID mark Code type Type 1 Type 2 Coupling Separating Coupling Separating Bar codes Codabar (NW-7) Code 128 EAN-128 (GS1-128) Code 93 RSS (GS1 DataBar) (Note 1) EAN.UCC CC-A (Note 1) Composite CC-B (Note 1) CC-A, CC-B None None (Note 2) (Note 2)
  • Page 61 (2/2) Code ID mark Code type Type 3 Type 4 (Note 3) Coupling Separating Coupling Separating 2D codes QR Code Split QR Code In edit mode In batch edit mode In non-edit mode (Note 4) MicroQR Code (Note 4) SQRC (Note 4) MaxiCode PDF417...
  • Page 62 (2/2) Code ID mark Code type Type 3 Type 4 (Note 3) Coupling Separating Coupling Separating Bar codes Code 93 RSS (GS1 DataBar) (Note 1) EAN.UCC CC-A (Note 1) Composite CC-B (Note 1) CC-A, CC-B None None (Note 2) symbols UPC-A CC-A, UPC-A Without add-on...
  • Page 63 (Note 1) RSS (GS1 DataBar) represents: RSS-14 (GS1 DataBar Omnidirectional), RSS-14 Truncated (GS1 DataBar Truncated), RSS-14 Limited (GS1 DataBar Limited), RSS-14 Stacked (GS1 DataBar Stacked), RSS Expanded (GS1 DataBar Expanded), RSS-14 Stacked Omnidirectional (GS1 DataBar Stacked Omnidirectional), and RSS Expanded Stacked (GS1 DataBar Expanded Stacked). (Note 2) These code ID marks are contained in code data.
  • Page 64 (6) Number of digits This optional field specifies whether or not to transmit the number of digits (2 or 4 bytes) of code data to transmit or disables the transmission (default). Note that UPC and EAN codes (except EAN-128 (GS1-128)) skip this field. n1 : thousands (0 to 9) n2 : hundreds (0 to 9) n3 : tens (0 to 9)
  • Page 65 UPC-E You can select whether or not to transmit the padding character "0," number system character "S," and a check digit to the host. Disabling the transmission of the number system character "S" automatically disables the transmission of the padding character "0." The conversion to the GTIN format or to the UPC-A are selectable.
  • Page 66 EAN-13 You can select whether or not to transmit the two prefix characters "P " and "P " and a check digit to the host. The conversion to the ISBN/ISSN format is selectable. Enabling the conversion allows EAN-13 code with prefix characters 978 or 979 to be converted into the ISBN format, and EAN-13 code with prefix characters 977, into the ISSN format.
  • Page 67 EAN-8 with add-on A code ID mark precedes add-on code data under the conditions "Code ID mark: Type 4" and "Code ID mark output mode: Separating." (For details about the code ID mark, refer to (5) Code ID mark on pages 49 to 53.) The conversion to the GTIN format is selectable.
  • Page 68 UPC/EAN Composite symbols Code data read will be transmitted as is. You can select whether or not to transmit a check digit of the linear component (UPC/EAN). Under the conditions "Code ID mark: Type 1" and "Code ID mark output mode: Separating," a separator (GS: 1Dh) and 2D code ID mark are inserted between the linear component and 2D Composite component.

  • Page 69: Gtin Format Conversion

    9.5 GTIN Format Conversion Enabling the GTIN (Global Trade Item Number) format conversion allows UPC-A, UPC-E, EAN-13, EAN-8, and Interleaved 2of5 (14-digit) data to output in the GTIN format. It also allows RSS (GS1 DataBar) and EAN-128 (GS1-128) data in the GTIN format to output in the EAN format (product code format). Note: Under any of the following conditions, the GTIN format conversion is invalid.
  • Page 70 - Conversion to 14-digit GTIN format (PI added) With 2-digit add-on: PI 0 S X C/D X With 5-digit add-on: PI 0 S X C/D X Check digits are calculated again and transferred regardless of the transmission specified. UPC-E - Data read 0: Padding character for adjustment of the data length - Conversion to 16-digit GTIN format (AI "01"...
  • Page 71 - Conversion to 14-digit GTIN format (PI added) With 2-digit add-on: =0-2 PI 0 0 X 0 0 0 0 X C/D X PI 0 0 X 0 0 0 0 0 X C/D X PI 0 0 X 0 0 0 0 0 X C/D X =5-9 PI 0 0 X...
  • Page 72 EAN-8 - Data read : Prefix characters - Conversion to 16-digit GTIN format (AI "01" and PI added) 0 1 PI 0 0 0 0 0 P Check digits are calculated again and transferred regardless of the transmission specified. - Conversion to 14-digit GTIN format (PI added) PI 0 0 0 0 0 P Check digits are calculated again and transferred regardless of the transmission specified.
  • Page 73 (2) Conversion from RSS (GS1 DataBar)/EAN-128 (GS1-128) in GTIN format to EAN format RSS (GS1 DataBar) or EAN-128 (GS1-128) data read in the GTIN format (16-digit with AI "01") can be converted to the EAN format if the conversion is enabled. The conversion provides two choices--13- or 14-digit EAN formats. The former trims the Application Identifier (AI) "01"...

  • Page 74: Chapter 10 Image Capturing

    Chapter 10 Image Capturing 10.1 Outline The scanner supports image capturing that allows you to capture a graphic as a bitmap (BMP) or JPEG image and output it to the host computer. The JPEG image offers three quality choices--standard, high, and low. The image size can be selected from standard VGA, 1/4 VGA and 1/16 VGA.
  • Page 75 n: Image output area Full image area Center portion of the image area o: Thumbnail Disable thumbnail transmission Enable thumbnail transmission of BMP images in 1/64 VGA Enable thumbnail transmission of JPEG images in 1/4 VGA (5) Image capturing operation 1) Upon receipt of an IMAGEOUT command, the scanner captures an image, beeps three times, and switches to the image transmission mode (Xmodem 1K protocol).

  • Page 76: Chapter 11 Parameters And Defaults

    Chapter 11 Parameters and Defaults The tables below list the parameters and their defaults. Those parameters can be changed with the QR-coded parameter menu or configuration software (ScannerSetting_2D), except shadowed ones only with the configuration software. When the scanner leaves the factory, all of these parameters are set to defaults. (1) Reading mode related parameters Items Parameters...
  • Page 77 (3) Communications parameters for RS-232C interface The following settings take effect when the RS-232C interface is set up. Items Parameters Defaults Refer to: √ Non-acknowledge mode Communications protocol Section 9.1 (1) ACK/NAK mode 4800 bps 9600 bps 19200 bps Transmission speed Section 9.1 (3) √...
  • Page 78 (5) Communications parameters for USB keyboard interface The following settings take effect only when the USB keyboard interface is set up. Items Parameters Defaults Refer to: √ Manual Section 9.3 (1) CAPS mode (See Note 1.) Auto √ OFF (Lowercase letter) Section 9.3 (1) Host’s CAPS LOCK status (See Note 1.)
  • Page 79 Items Parameters Defaults Refer to: Enable Special key transfer mode (See Note 4.) √ Disable 3 ms 6 ms √ 10 ms Data transmission interval 16 ms Section 9.3 (5) 30 ms 50 ms 100 ms √ Enable Remote wake-up Disable (Note 4) Special key transfer applies to the fields except header and terminator in the data transmission format.
  • Page 80 (6) Data transmission format common to all interfaces Items Parameters Defaults Refer to: Enable Transmission of code ID mark Section 9.4 √ Disable Before prefix Code ID mark position Section 9.4 √ After prefix √ Type 1 (DENSO1) Type 2 (DENSO2) Code ID mark Type 3 Section 9.4, (5)
  • Page 81 (7) Data transmission format exclusive to RS-232C interface/USB-COM interface Items Parameters Defaults Refer to: √ NONE Header User-defined NONE Section 9.4, (1) √ Terminator CR LF User-defined Enabled Transmission of BCC Section 9.4, (4) √ Disabled : Can be changed only with the configuration software.
  • Page 82 (8) Data transmission format exclusive to USB keyboard interface Items Parameters Defaults Refer to: √ NONE CR LF Header ENTER Right Ctrl ← ↑ → ↓ User-defined Section 9.4 NONE CR LF Terminator √ ENTER Right Ctrl ← ↑ → ↓...
  • Page 83 (9) 2D codes, mirror image and black-and-white inverted codes Items Parameters Defaults Refer to: Enable Reading reverse codes (mirror image) Section 7.4 √ Disable √ Black cells/bars on a white background White cell/bars on a black Reading black-and-white inverted codes Section 7.5 background Auto detection of black and white...
  • Page 84 Items Parameters Defaults Refer to: Enable (SQRC and QR Code symbols) Reading SQRC Enable (SQRC symbol only) √ Disable Permit scan data transmission only Section 7.8 Encryption key mismatch √ Transmission prohibited √ Back-up permitted Encryption key control Back-up prohibited Enabled Data transmission of undisclosed section only...
  • Page 85 Items Parameters Defaults Refer to: √ Enable Sections 9.4 and Reading EAN-8 12.2 Disable √ Enable EAN-8 transmission of check digit Disable Enable EAN-8 Conversion to the EAN-13 format √ Disable Enable Reading UPC/EAN with 2-digit add-on √ Disable Sections 9.4 and 12.2 Enable Reading UPC/EAN with 5-digit add-on...
  • Page 86 Items Parameters Defaults Refer to: √ Transmit a/b/c/d Transmission of Start/Stop codes Section 12.2 Transmit A/B/C/D for Codabar (NW-7) Disable √ MOD-16 Check digit method for Codabar (NW-7) Section 12.2 7-check method Code 39 Item Parameters Defaults Refer to: √ Enable, without a check digit Enable, with a check digit (Check digit transmission enabled)
  • Page 87 Code 93 Items Parameters Defaults Refer to: Enable Reading Code 93 Section 12.2 √ Disable Minimum number of readable digits 1 digit 1 to 99 digits for Code 93 (excluding start/stop codes and 2-digit (See Note 1.) Maximum number of readable digits check digits) 99 digits for Code 93...
  • Page 88 Multi-line barcode scanning Items Parameters Defaults Refer to: Enable Reading multi-line bar codes √ Disable √ Two lines Number of lines for multi-line barcode scanning Three lines Header/Terminator-delimited Output format for multi-line bar codes √ Comma-delimited First-line barcode Selectable from readable bar codes Not specified.
  • Page 89 (11) Trigger switch control Items Parameters Defaults Refer to: √ Auto-off mode Momentary switching mode Section 6.1 Alternate switching mode Trigger switch control mode Continuous reading mode 1 Continuous reading mode 2 Auto sense mode Section 6.3 Enable Error issue when reading fails Section 6.1 √...
  • Page 90 (12) Beeper, indicator LED, marker beam and illumination LEDs Items Parameters Defaults Refer to: √ Enable Beeper control Disable Low beeping tone (2.5 kHz) Beeping tone Medium beeping tone (2.7 kHz) √ High beeping tone (2.9 kHz) Section 8.1 Short (60 ms) √...
  • Page 91 (13) Data verification conditions and data editing conditions Items Parameters Defaults Refer to: Data block verification Data to be verified √ Data string verification Enable Preset registration √ Disable Verification start position for data string 001 to 999 positions verification (Specify with ASCII characters) Number of characters to verify for data 01 to 99 positions...
  • Page 92 Items Parameters Defaults Refer to: Search string and substitution string in data Max. 16 ASCII characters No specified. substitution mode Number of splits in data blocksorting mode 2 to 5 splits 0001 to 9999 positions, specified Single Split position in data blocksorting mode by ASCII characters character Block 1/...

  • Page 93: Chapter 12 Qr-Coded Parameter Menu

    Chapter 12 QR-Coded Parameter Menu 12.1 Parameter Setting Procedure Using the QR-coded Parameter Menu Start setting Use the scanner to scan the "Start setting" QR Code symbol. ↓ Three beeps Scan parameter setting Scan necessary parameter setting QR Code symbols. QR Code symbols.

  • Page 94: Qr-Coded Parameter Menu

    12.2 QR-coded Parameter Menu Menu control (Starting/Ending the Setting Procedure and Reverting to Defaults) Start setting Start setting (When the "White code on black background" is set)" Cancel All defaults End setting The beeper volume can be set by scanning the following QR Code symbol only. No "Start setting" or "End setting"...
  • Page 95 Communications parameters for RS-232C interface Procedure Non-acknowledge mode ACK/NAK mode (default) Transmission speed 4800 bps 9600 bps 19200 bps 38400 bps (default) 57600 bps 115200 bps Data bit 7 bits 8 bits (default)
  • Page 96 Parity None (default) Even parity Odd parity Stop bit 1 bit (default) 2 bits USB interface to the host USB-COM interface USB keyboard (default) interface...
  • Page 97 Communications parameters for USB-COM interface Communications protocol (USB-COM interface) Non-acknowledge mode ACK/NAK mode (default) Header (USB-COM interface) None (default) Terminator (USB-COM interface) None CR (default) CR LF Transmission of BCC (USB-COM interface) Disable (default) Enable...
  • Page 98 Communications parameters for USB keyboard interface Conversion to binary data No conversion (default) Binary conversion (ASCII) Kanji conversion Header (USB keyboard interface) None (default) CR LF ENTER Right Ctrl...
  • Page 99 Header (USB keyboard interface) ← ↑ → ↓ Terminator (USB keyboard interface) None CR LF ENTER (default) Right Ctrl...
  • Page 100 Header (USB keyboard interface) ← ↑ → ↓ Data transmission format Transmission of code ID mark Disable (default) Enable Transmission of the number of digits Disable (default) Enable in 2 digits Enable in 4 digits...
  • Page 101 2D codes, mirror image and black-and-white inverted codes Scanning MicroQR Code Disable Enable (default) Scanning black-and-white inverted codes Black cells/bars on a White cells/bars on white background (default) a black background Automatically identify black and white inverted codes Scanning split QR Code ("Structured Append") Edit mode (default) Non-edit mode Batch edit mode...
  • Page 102 Scanning MaxiCode Disable Enable (default) Scanning Data Matrix Disable Enable (default) Bar codes Scanning UPC-A, UPC-E, EAN-13 and EAN-8 Disable Enable (default) Scanning Interleaved 2of5 Disable Enable with a check digit (Check digit transmission disabled) Enable without Enable with a check digit a check digit (default) (Check digit transmission enabled)
  • Page 103 Scanning Code 128 (EAN-128 (GS1-128)) Disable Enable (default) Scanning Codabar (NW-7) Disable Enable without a check digit (default) Enable with a check digit Enable with a check digit (Check digit transmission enabled) (Check digit transmission disabled) Transmission of start/stop codes for Codabar (NW-7) Disable Enable (default)
  • Page 104 Scanning Code 39 Disable Enable without a check digit (default) Enable with a check digit Enable with a check digit (Check digit transmission enabled) (Check digit transmission disabled) Transmission of start/stop codes for Code 39 Disable (default) Enable Scanning Code 93 Disable (default) Enable Scanning RSS (GS1 DataBar)
  • Page 105 Scanning Composite Enable Disable (default) Other settings Trigger switch control Auto-off mode (default) Alternate switching mode Momentary switching mode Continuous reading mode 1 Continuous reading mode 2 Auto sensing mode Beeper control Disable Enable (default) Indicator LED Disable Enable (default)

  • Page 106: Chapter 13 Troubleshooting

    Chapter 13 Troubleshooting Problem 1: Low reading efficiency. Probable cause What to do: • A target code is not within the scan range of the • Bring a code within the scan range. reading window. The code may be smeared. Wipe off the dirt from the code.

  • Page 107: Appendix 1 Specifications

    2.5 x 3.7 x 6.4 inches (63 x 95 x 163 mm) Weight Approx. 165 g (excluding the cable) To use SQRC (Security QR Code), contact your Denso Wave representative. Sharp temperature change, dewing or freezing not allowed, wet-bulb temperature 30°C max.

  • Page 108: Appendix 2 Control Commands

    Appendix 2 Control Commands Control commands refer to commands that are exchanged between the host computer and the scanner via the communications line. Some of the control commands that the host computer issues are functionally equivalent to some parameters that can be set with the QR-coded parameter menu (refer to Chapter 11).
  • Page 109 Transfer Direction Control Function Commands Scanner Host Light the red indicator LED Within 100 ms from the receipt of the LR command, the red indicator (Note 3) LED lights for approx. 500 ms. Capture image IMAGEOUT Refer to Chapter 10 for details. Trigger switch control U1: Auto-off mode U2: Momentary switching mode...
  • Page 110 Transfer Direction Control Function Commands Scanner Host Verification match If code data scanned matches master data in data verification mode, the scanner sends this command as long as the OK transmission is enabled for a match. Verification mismatch If code data scanned does not match master data in data verification mode, the scanner sends this command as long as the NG transmission is enabled for a mismatch.

  • Page 111: Appendix 3 Interface Specifications

    Appendix 3 Interface Specifications RS-232C Interface Dsub 9S inch, screw connector Pin # Signal N.C. Shorted wit #6 Shorted with #4 N.C. USB Interface Type A USB connector Viewed from pin side Pin # Signal 5 VDC...
  • Page 112 2D Code Handy Scanner AT10Q-SM User's Manual First Edition, April 2008 DENSO WAVE INCORPORATED...
  • Page 113 DENSO WAVE INCORPORATED 4-2-12, Toranomon, Minato-ku, Tokyo, Japan 105-0001 http://www.denso-wave.com/ 496899-0450...
