- Page 1 OWNERS HANDBOOK WET & DRY EXTRACTION VACUUM CLEANERS Welcome to the worldwide club of vacuum cleaner owners. Please read these operating instructions before operating your vacuum cleaner. PRINTED ON RECYCLED PAPER...
- Page 2 Repairs undertaken by unauthorised or inexperienced persons may cause injury and/or serious malfunctioning of the appliance. • This appliance should be serviced by authorised Electrolux personnel and only genuine Electrolux spare parts should be used. Failure to do so may render the warranty void.
- Page 3 DRY USE Fig. 1 1. Hood assembly 9. Hose intake 2. On/off switch 10. Hose 3. Valve 11. Curved handle 4. Cloth filter 12. Suction regulator 5 Bucket 13. Extension tubes 6. Castors 14. Carpet/Floor nozzle 7. Pump switch 15. Crevice nozzle 8.
-
Page 4: Wet Use
WET USE Fig. 2 16. Foam filter 19. Shampoo nozzle adaptor 17. Hose clamp 20. Wet tool 18. Flow control unit 21. Shampoo nozzle... - Page 5 SHAMPOOING Fig. 3 16. Foam filter 22. Solution tank...
-
Page 6: Operating
using the components shown in OPERATING fig. 1. INSTRUCTIONS 2. For your convenience the vacuum cleaner is supplied with WARNING. Always the cloth filter (4) fitted. This is disconnect your vacuum to be used for dry vacuuming. cleaner from the mains To fit the cloth filter (4) clip it supply before maintaining over the top rim of the bucket... - Page 7 hose intake (9). See fig. 9. socket and press the on/off switch (2) to start vacuuming. See fig. 11. Fig. 9 7. Connect the hose (10) to the Fig. 11 bucket (5) by fitting the threaded end of the hose (10) into the NOTE: You can control the amount hose intake (9) and turn in a of suction that you require by...
- Page 8 3. Fit the solution filter (8) to the extension tube (13) see fig. 3 pin on the underside of the hood assembly (1). See fig.7. NOTE: The wet tool (20) is fitted with a rubber squeegee to vacuum 4. Fit the hood assembly (1) to the spills while sweeping hard floors.
- Page 9 when operating the vacuum cleaner as a wet suction cleaner. HOW TO SET UP YOUR If the suction regulator (12) is MACHINE FOR SHAMPOOING open water can be ejected through it. 1. First vacuum or sweep the 14. Once you have completed using surface you intend shampooing.
-
Page 10: Upholstery Shampooing Setup
CARPET SHAMPOOING SETUP 1. Fit the shampoo nozzle (21) to the shampoo nozzle adaptor (19). See fig. 19. Fig. 18 7. Secure the hood assembly (1) with the latches as shown in fig. 9. Make sure that the valve (3) is aligned with the hose intake (9). -
Page 11: To Use Machine For Shampooing
5. Your vacuum cleaner is now set up to shampoo upholstery. HOW TO USE THE MACHINE FOR SHAMPOOING 1. Ensure that the suction Fig. 21 regulator (12) on the curved handle (11) is closed. 2. Fit the shampoo nozzle (21) onto the shampoo nozzle 2. - Page 12 NOTE: The surface being shampooed gets dried during the release of the solution. Further drying can take place by moving the nozzle over the surface again without pressing the trigger of the flow control unit (18). Fig. 28 5. When you have completed using •...
- Page 13 • Wash the foam filter (16) with Authorised Electrolux Service soapy water and allow it to dry. Centre for advice. IMPORTANT: Never place your vacuum cleaner in storage before...
- Page 14 ELECTROLUX for shampooing furniture and other small areas. The following accessories have been specially designed to be used with your Electrolux vacuum cleaner. They are available from your nearest Electrolux Service Agent. • Dusting brush The dusting brush can be used...
- Page 15 Cartridge Filter • Cartridge filter and reusable Part No.: EL 048 dust bag Reusable dust bag Part No.: EL 049 The cartridge filter and reusable Should you require any further assistance, dust bag can be used instead of please contact our TOLL FREE customer the cloth filter.
- Page 16 PURCHASED FROM: ............................................DATE PURCHASED: .....................MODEL NO:....................SERIAL NO. Electrolux reserves the right to make improvements or modifications to the product from time to time and consequently the details given in this book are subject to alteration without notice. PART No: 14066-002...
