HOME THEATER SYSTEM

DHT-500SD

OPERATING INSTRUCTIONS

BEDIENUNGSANLEITUNG
MODE D'EMPLOI
ISTRUZIONI PER L'USO
ON/STANDBY
DVD SURROUND RECEIVER ADV-500SD
PHONES
SYS-500SD
(SC-A500SD) (SC-C500SD)
INSTRUCCIONES DE OPERACION
GEBRUIKSAANWIJZING
BRUKSANVISNING
RC-973
ADV-500SD
SLEEP
CLEAR
PROG/DIRECT
MODE
TV
1
BAND
MEMORY
FM MODE
TUNING
FUNCTION
SURROUND MODE
PROGRESSIVE SCAN
TONE
4
MASTER VOLUME
7
TITLE
CHP
STANDBY
DVD
D
P.SCAN
EX
CALL
TEST TONE
A / V
SETUP
CH SELECT
RETURN
(DSW-500SD) (SC-A500SD)
OFF
ON
NTSC/PAL
VCR
PWR
TV IN
TV
PWR
A-B REPEAT
ZOOM
-
+
TV CH
TV CH
RDS
PTY
CT
RT
REPEAT
RANDOM
MEMO
BAND
VIDEO 1
VIDEO 2
TUNING /
TV VOL
+
2
3
DVD
TUNER
-
5
6
TUNER
+
8
9
CH
-
0
+10
/10
INPUT MODE
SURROUND
FUNCTION
TUNER
TV / VCR
DVD
AV AMP
+
DVD
-
STATUS
MUTING
TONE /DIMMER
ENTER
SURROUND
PARAMETER
+
-
VCR CH
DISPLAY
MENU
TOP MENU
PBC
ANGLE
AUDIO
SUB TITLE
RC-973
FOR ENGLISH READERS
FÜR DEUTSCHE LESER
POUR LES LECTEURS FRANCAIS
PER IL LETTORE ITALIANO
PARA LECTORES DE ESPAÑOL
VOOR NEDERLANDSTALIGE LEZERS
FOR SVENSKA LÄSARE
PAGE
003 ~ PAGE
035
SEITE
036 ~ SEITE
068
PAGE
069 ~ PAGE
101
PAGINA 102 ~ PAGINA 134
PAGINA 135 ~ PAGINA 167
PAGINA 168 ~ PAGINA 200
SIDA
201 ~ SIDA
233

Advertisement

Table of Contents
loading

Related Manuals for Denon DHT-500SD

Summary of Contents for Denon DHT-500SD

  • Page 1: Operating Instructions

    HOME THEATER SYSTEM DHT-500SD OPERATING INSTRUCTIONS INSTRUCCIONES DE OPERACION BEDIENUNGSANLEITUNG GEBRUIKSAANWIJZING MODE D’EMPLOI BRUKSANVISNING ISTRUZIONI PER L’USO RC-973 ADV-500SD SLEEP NTSC/PAL TV IN CLEAR A-B REPEAT ZOOM TV CH TV CH PROG/DIRECT REPEAT RANDOM MODE MEMO BAND VIDEO 1 VIDEO 2...

  • Page 2: R6P/Aa Batteries

    ENGLISH ENGLISH DEUTSCH FRANCAIS ITALIANO ESPAÑOL NEDERLANDS SVENSKA NOTE ON USE / HINWEISE ZUM GEBRAUCH / • DECLARATION OF CONFORMITY CAUTION OBSERVATIONS RELATIVES A L’UTILISATION / NOTE SULL’USO We declare under our sole responsibility that this product, to which this declaration relates, is in RISK OF ELECTRIC SHOCK NOTAS SOBRE EL USO / ALVORENS TE GEBRUIKEN / OBSERVERA conformity with the following standards:...

  • Page 3: Table Of Contents

    INTRODUCTION BEFORE USING Thank you for choosing the DENON DHT-500SD Home Theater System. This remarkable component has been Pay attention to the following before using this unit: engineered to provide superb surround sound listening with home theater sources such as DVD, as well as providing outstanding high fidelity reproduction of your favorite music sources.

  • Page 4: Speaker Cord B

    When using a stand, brackets, etc., follow the instructions included with the stand or brackets and check for magnet or an object generating magnetic force nearby. safety before installing and using. Denon will accept no responsibility for damages or accidents caused by the Examples: (a) When there are magnets on the door of the rack, stand, etc.

  • Page 5: Features

    ENGLISH FEATURES DISCS 1. Slim body wide) half 9. DTS-ES Extended Surround and DTS Neo:6 • The types of discs listed on the table below can be 2 Disc terminology mirror/aluminum panel (ADV-500SD) The ADV-500SD can be decoded with DTS-ES used on the ADV-500SD.

  • Page 6: Cautions On Handling Discs

    ENGLISH CAUTIONS ON HANDLING DISCS CONNECTIONS Discs Cautions on Handling Discs CAUTION: • Switch off the power to all equipment before making connections. Only the discs including the marks shown on page 5 Do not get fingerprints, grease or dirt on discs. •...
  • Page 7 ENGLISH S-VIDEO or VIDEO jacks DIGITAL IN/OUT jacks S-VIDEO connection is your second choice and is superior to the standard composite video connection. Connect the component with optional coaxial cables or optical cables. If the component has a S-VIDEO jack, connect them with a high quality S-VIDEO cable. DIGITAL IN DIGITAL OUT(CD, etc.) S-VIDEO OUT...
  • Page 8 ENGLISH SURR. BACK PRE OUT jack How to connect Surround speakers (SC-A500SD) Use SURR. BACK PRE OUT jack to connect additional POWER AMPLIFIER and two speaker systems. Press the lever, insert the stripped and twisted end Install these speakers above the level of the You can enjoy 7.1ch surround system.

  • Page 9: Part Names And Function

    ENGLISH PART NAMES AND FUNCTION (3) Connecting Antennas AM Indoor Loop Antenna FM Indoor Antenna (1) Front Panel Connect the lead-type FM antenna to the FM 75 Ω The high-performance AM loop antenna provided with this unit is sufficient for good reception in most socket, extend the lead and fix it to a window frame areas.
  • Page 10 ENGLISH (2) Display (3) Remote control unit • For details on the functions of these parts, refer to the pages given in parentheses ( ). • Some of the buttons on the remote control unit have some functions. The functions are switched using the remote control mode selector switches. REPEAT button..........(28) Number buttons (0~9, +10)....(13, 15, 26) CALL button ............(29)
  • Page 11 ENGLISH (4) Names and functions of remote control unit buttons on the ADV-500SD Operate the ADV-500SD. [2] DVD system buttons [1] Surround amplifier system buttons (Operated with mode switch 2 set to • Buttons in sections q ~ e can be operated regardless of the position of mode switches 1 and 2. (Operated with mode switch 2 set to “DVD”) “AV AMP”)

  • Page 12: Remote Control Unit

    “TUNER”) • The included remote control unit (RC-973) can be used to operate not only this unit but other remote control compatible DENON components as well. In addition, the memory contains the control signals for other remote : Press this...
  • Page 13 ENGLISH Combinations of preset codes for different brands (3) TV and video deck preset memories • Components of other brands can be operated with Admiral 045, 121 Fortress Press the TV PWR button to preset a TV, the the included remote control unit by storing their Adventura Fujitsu 004, 062...
  • Page 14 ENGLISH Motorola 121, 147 Admiral Hitachi 009, 013, 023, 026, 058, 108, 031, 034, 039, 048, 095 Schneider Aiko 109, 110, 111 008, 075, 076, 128 Scott Aiwa JC Penny 004, 005, 007, 023, 028, 049, National 002, 036, 061, 147 Sears 008, 014, 021, 022, 023, 024, Akai...
  • Page 15 ENGLISH (4) Operating the TV/video deck after storing its remote control signals in the preset memory Pioneer 005, 013, 029, 036, 037, 038, Sentra 045, 085 Sharp 001, 002, 021, 097 Monitor TV (TV) and video deck (VCR) system Portland 025, 055, 090 Shogun buttons...

  • Page 16: Setting Up The System

    ENGLISH SETTING UP THE SYSTEM (1) System setup items • Once all connections with other AV components have been completed as described in “CONNECTIONS” (see pages 6 to 9), make the various settings described below on the monitor screen using the ADV-500SD’s on-screen display function.
  • Page 17 ENGLISH (2) Before setting up the system (3) Quick system settings • This section describes surround-related setup operations. • The ADV-500SD is preset with Quick System settings for a 5.1-channel surround system using specified 5.1ch For DVD-related setup operations, see page 30. speakers (SYS-500SD).
  • Page 18 ENGLISH (4) System setting changes • The quick system settings and factory default settings are changed at the system setting change menu. • The settings are stored in the memory until they are next changed, even when the power is turned off. NOTE: Subwoofer frequency (SW FREQ.) •...
  • Page 19 ENGLISH [2] Setting the speaker distance [3] Setting the channel level Adjusting the channel levels in the “test tone” • Input the distances from the listening position to the speakers and set the surround delay time. • Use this setting to adjust so that the playback level mode •...
  • Page 20 ENGLISH After the above settings are completed, press the NOTES: ENTER button. Channel level setting by Remote Control unit. (TEST TONE, CH SELECT button) • The “SYSTEM SETUP MENU” screen • This section describes channel level setting by Remote Control unit. reappears.

  • Page 21: Basic Operation

    ENGLISH 11 BASIC OPERATION “Tone Control” and “DIMMER” Press the TONE/DIMMER button to select Press the POWER switch to turn the unit on. “BASS”, “TREBLE” or “DIMMER”. TONE /DIMMER ON/STAND BAND MEMORY FM MODE TUNING BAND MEMORY FM MODE TUNING ON/STAND FUNCTION SURROUND...
  • Page 22 ENGLISH Muting Sleep Timer The power can be switched to the standby To mute the sound temporarily, press the mode after a specified amount of time. MUTING button. Press the MUTING button STATUS MUTING again to restore the sound. If you change the Press the SLEEP button repeatedly until SLEEP NTSC/PAL...

  • Page 23: Surround Mode

    ENGLISH 12 SURROUND MODE DTS MODE(Dts, Neo:6 Cinema, Neo:6 Music) DOLBY PRO LOGIC II (PRO LOGIC IIx) SURROUND This mode is for DTS encoded source materials such Each time the SURROUND button is pressed, the as LASER DISC, CD, and DVD. Neo:6 is to some 2 DOLBY PRO LOGIC II brings the excitement of surround mode is changed as follows : channel signal source.

  • Page 24: Playback

    ENGLISH 13 PLAYBACK OTHER SURROUND HALL 2 To check the currently surround settings, etc. When playing recordings of live music, this mode (1) DVD/CD/VCD Press the STATUS button on the remote control provides a feeling similar to actually being in a concert unit.
  • Page 25 ENGLISH (3) Resume Playback (6) Forward / Reverse Searching (2) MP3/WMA DVD/CD/MP3/WMA MP3/WMA To suspend playback temporarily (pause When an MP3/WMA disc is loaded, the recorded During playback, press one of the 6 / 7 buttons mode) directories will be shown on the screen. STANDBY/ON OPEN/CLOSE STOP on the remote control unit.

  • Page 26: Onscreen Display

    ENGLISH 14 ONSCREEN DISPLAY (7) Slow-Motion Playback PROG/DIRECT REPEAT RANDOM MODE MEMO BAND VIDEO 1 VIDEO 2 TUNING / TV VOL A / V AV AMP DVD only 2 Use this function to display and change information on the disc (titles, TUNER To play a disc in slow-motion, press the 6, 7 chapters, time, etc.).

  • Page 27: Using The Onscreen Display

    ENGLISH 15 USING THE ONSCREEN DISPLAY (3) Change the Angle When a scene recorded with multiple angles is SETUP TONE /DIMMER (1) Select an Audio Language played, the angle icon appears on the screen. Each time you press the ANGLE button while ENTER SURROUND the angle icon is displayed, the camera angle...

  • Page 28: Special Playback

    ENGLISH 16 SPECIAL PLAYBACK (2) Shuffle Playback Tracks of a disc can be played randomly. (1) Repeat Playback SLEEP NTSC/PAL TV IN Press the RANDOM button during the CLEAR A-B REPEAT ZOOM Repeat Playback of DVD Repeat Playback of a Designated Section TV CH TV CH playback.
  • Page 29 ENGLISH Checking the programmed content (3) Program Playback (CD) In the stop mode, press the CALL buttons Up to 20 tracks can be programmed in the desired order. repeatedly. SLEEP NTSC/PAL • This function does not work when PBC is turned on with Video CDs. Press the TOP MENU button to turn PBC TV IN Track number, program number and the total CLEAR...

  • Page 30: Changing The Default Settings (Dvd)

    ENGLISH q Selecting SET UP Languages 17 CHANGING THE DEFAULT SETTINGS (DVD) (ENGLISH, FRENCH, SPANISH, GERMAN) D V D S E T U P You can select the language for OSD (On Screen LANGUAGE ENGLISH This chapter describes how to use the DVD SETUP Display).(See page 26.) SUBTITLE TV ASPECT...
  • Page 31 ENGLISH t WALL PAPER i MIDNIGHT MODE Dynamic Range Compression BLUE D V D S E T U P DVD SETUP In many listening situations, you may find loud Select this to display a blue background on the TV LANGUAGE ENGLISH LANGUAGE ENGLISH...

  • Page 32: Listen To The Radio

    ENGLISH !0 How to set and change the password for 18 LISTEN TO THE RADIO Rating D V D S E T U P 1.Press the ENTER button. LANGUAGE ENGLISH SUBTITLE (1) Tuning to the Radio 2.Use the number buttons to input the previously TV ASPECT 4:3 PS TV TYPE...
  • Page 33 ENGLISH (2) Preset Tuning (3) RDS (Radio Data System) You can store Preset stations from Channel 1 to 30 respectively. RDS (works only on the FM band) is a broadcasting service which allows station to send additional information along with the regular radio program signal. The following three types of RDS information can be received on this unit: Automatic Memory Presetting (ONLY FM STATIONS)

  • Page 34: Troubleshooting

    In case you experience any problem with this unit, please take the time to look through this chart and see if you For a description of each program type, refer to “Program Type (PTY)”. can solve the problem yourself before you call your dealer or a nearest DENON sales office. Press the TUNING + (UP) or –...

  • Page 35: Specifications

    ENGLISH SPECIFICATIONS (1) DVD Surround Receiver (ADV-500SD) 2 General 2 Audio section Power supply ..........AC 230 V, 50 Hz • Power amplifier Power consumption ........155 W (Standby 1 W) Output power (6 Ω/ohms, 1 kHz, 10% THD, 100W) Maximum external dimensions ....434 (width) x 80 (height) x 368 (depth) mm - TStereo ..........2 x 100 W Mass ............5.4 kg Output power (6 Ω/ohms, 1 kHz, 10% THD, 100W)
  • Page 36 MEMO:...
  • Page 37 16-11, YUSHIMA 3-CHOME, BUNKYO-KU, TOKYO 113-0034, JAPAN Telephone: (03) 3837-5321 Printed in China 511 4197 105...
