Apex Digital DT502 Quick Start Manual

QUICK START GUIDE

Thank you for your purchase of the Apex Digital converter box. Remove the converter box from packaging and
proceed with the following steps for optimal connection and experience.
1
Converter Box Installation
1
Over-the-air Antenna
ANTENNA IN
TV OUT
CH 3/4 &
Analog Pass-Through
Yellow
Video Input to TV
* In order to receive digital signals, you MUST connect an over-the-air antenna to your converter box.
** If your TV does not have composite/AV inputs, please refer to the Page 9 in the User's Manual for RF connec-
tion. Your converter box and TV must be set to the same receiving channel (CH3 or CH4) in order to view digital
channels. Receiveing channels may vary between CH3 and CH4 depending on your location.
For additional questions, please visit our website www.apexdigitalinc.com or call us at (866) 427-3946 Monday-Friday, 6am-6pm PST.
Composite/AV Connection
Connect your over-the-air antenna
1
to your converter box
2
Connect Video/Audio inputs
Back of Converter Box
Yellow
VIDEO
SMART
CH 3 CH 4 S-VIDEO
L AUDIO R
ANTENNA
2
White
Red
Audio L / R Input to TV
White
Red
Easy 3 Step Installation
2
Initial Setup
Installation Guide
OSD Langauge English
OK
POWER
Change your TV input mode to
1
VIDEO/COMPOSITE.
3
Scan Channels
Installation Guide - Finish
Setup Completed
The system is configured as followed:
OSD: English
Time Zone: Pacific (-8:00)
Daylight Savings: AUTO
Detected Digital Channel: 51
Detected Digital Frequencies: 22
Press OK to complete a setup and exit to watch TV
* Channels may be deleted or added after Auto Program Channel scan. Please refer to page 14 in the User's
Manual for more information.
DT502
English
Spanish
French
Next Page
Power converter box ON. An
2
Installation Guide will automati-
cally start up. Use the arrow
buttons to select your Language,
Time Zone, Daylight Savings,
and then press "OK" to initialize
auto channel scan.
Allow the converter box to scan
until 100% for all available digital
channels. Onceinstallation scan is
complete, the first scanned chan-
nel will display.
OK
S E R I E S
