OPTIONS

D BATTERY PACK
Battery pack
Voltage
BP-230
7.4 V
7.4 V
BP-231
7.4 V
BP-232
Battery case for AAA
BP-240
(LR03)
1
*
Operating periods are calculated under the following conditions;
TX : RX : standby = 5 : 5 : 90
2
*
Operating period depends on the alkaline cells used.
D CHARGERS
•BC-119N
DESKTOP CHARGER
+ BC-145
AC ADAPTER
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions. Charging
time: approx. 2 hours when BP-231 is attached.
•BC-121N
-
MULTI
CHARGER
+ BC-157
AC ADAPTER
For rapid charging of up to 6 battery packs (six AD-106's are
required) simultaneously. An AC adapter should be pur-
chased separately. Charging time: approx. 2 hours when
BP-231 is attached.
•BC-160
DESKTOP CHARGER
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions. Charging
time: approx. 2 hours when BP-231 is attached.
46
Capacity
Battery life*
800 mAh
6 hrs.
IC-F33GT/GS
1150 mAh
IC-F43GT/GS
IC-F33GT/GS
16 hrs.
2000 mAh
IC-F43GT/GS
15 hrs.
2
—*
6 alkaline
+ AD-106
CHARGER ADAPTER
+ AD-106
CHARGER ADAPTER
+ BC-145
AC ADAPTER
D BELT CLIPS
• MB-93
SWIVEL BELT CLIP
1
• MB-94
BELT CLIP
Exclusive alligator-type belt clip. The same as supplied with
the transceiver.
9 hrs.
• MB-96N/96F
8 hrs.
D OPTIONAL UNITS
• UT-108
DTMF DECODER UNIT
Provides pager and code squelch capabilities.
• UT-109 (#02)/UT-110 (#02)
Non-rolling type (UT-109)/Rolling type (UT-110) voice
scrambler unit provides higher communication security.
• UT-113
MAN DOWN UNIT
Provides a measure of safety when working in a hazardous
environment, etc.
• UT-105
SmarTrunk II™
Provides SmarTrunk II™ capabilities.
• UT-117/117S*
Provides SmarTrunk 3G™ capabilities.
(6 pcs.)
*In addition to SmarTrunk 3G™ capabilities, UT-117S sup-
ports the voice scrambler capability.
LEATHER BELT HANGER
SCRAMBLER UNITS
LOGIC BOARD
SmarTrunk 3G™
LOGIC BOARD
