Model
AKH-TC-A
AKH-LD-A
AKH-AP-A
AKH-D-A
Water Connection Note:
All models have ¼" flare plumbing connection unless specified otherwise.
Electrical Connection Note:
All units are intended to operate on a 15 A, 120 V ac circuit unless specified otherwise. Check units serial tag.
N E W C O E N T E R P R I S E S
INSTALLATION and OPERATION MANUAL
For AKH Autofill E - SERIES BREWERS
BREWER SPECIFICATIONS
Width
8-1/2
8-1/2
8-1/2
8-1/2
Length
17-11/16
17-11/16
17-11/16
17-11/16
Prelim E Series pn 120725 iss 20091211
Height
17-1/2
21-1/16
23-5/16
27-3/16
Advertisement
Related Manuals for Newco AKH-TC-A
Summary of Contents for Newco AKH-TC-A
- Page 1 N E W C O E N T E R P R I S E S INSTALLATION and OPERATION MANUAL For AKH Autofill E - SERIES BREWERS BREWER SPECIFICATIONS Model Width Length Height AKH-TC-A 8-1/2 17-11/16 17-1/2 AKH-LD-A 8-1/2 17-11/16 21-1/16...
- Page 2 E SERIES SYSTEM ADVANTAGES The E Series/AKH Line offers several advantages over a traditional commercial brewer with a hot water reservoir. Since the water that is poured in, is the water used to brew, a fresher brewed product is produced. No energy is wasted maintaining a tank of water at a near boiling temperature.
- Page 3 Prompt disposition will be made if item proves to be defective, within warranty. Before returning any item, write or call Newco, or the dealer from whom the product was purchased, giving model number, serial number, and date of purchase, and describe nature of the defect. If damage was incurred during transit to you, file claim with the carrier.
-
Page 4: Wiring Diagram
Relay, 120 V Coil 151158 Sprayhead 102383 Valve, solenoid operated, single, fill 700902 Pitcher, 75 oz pour 201178 Adapter, 1 terminal fem to 2 male tab WIRING DIAGRAM Newco Enterprises, Inc. * 3650 Newtown Blvd * St. Charles, MO 63301...
