Carrier 33CS2PPRH-02 Owner's Manual

Commercial thermostat.
Hide thumbs

®
EDGE
Pro
33CS
Commercial Thermostat
Owner's Manual
Part Numbers 33CS2PPRH-02 and 33CS2PP2S-02
• advanced programming indicators
SAFETY CONSIDERATIONS
• keypad locked or unlocked
Read and follow manufacturer instructions carefully. Fol-
• programming option (indicates which settings are being
low all local electrical codes during installation. All wiring
adjusted)
must conform to local and national electrical codes. Improper
• system is in auxiliary (supplemental) mode
wiring or installation may damage thermostat.
• cooling set point
Recognize safety information. This is the safety alert sym-
• heating set point
bol
. When the safety alert symbol is present on equipment
• year
or in the instruction manual, be alert to the potential for person-
• holiday schedule return date
al injury.
• day
• length of time for temporary temperature hold (override)
Understand the signal words DANGER, WARNING, and
• month
CAUTION. These words are used with the safety alert symbol.
• outdoor temperature
DANGER identifies the most serious hazards which will result
• leaving air temperature
in severe personal injury or death. WARNING signifies a haz-
• time period start
ard which could result in personal injury or death. CAUTION
• period of the day
is used to identify unsafe practices which would result in minor
personal injury or property damage.
GENERAL
The Edge Pro thermostat by Carrier is a wall-mounted, low-
holiday
voltage control which combines temperature and humidity
control in either a single or two-piece unit. The Edge Pro ther-
mostat can be set for 7-day, 5/2-day, or 1-day programmable
operation. Different heating and cooling set points and times
are programmable for 2 or 4 periods per day. The thermostat
holiday
can also be configured for non-programmable operation. When
operating as a non-programmable thermostat, the user will still
have both temperature and humidity control.
occ
The Edge Pro thermostat has no need for batteries to store
occ2
user-configured settings in memory. During power loss its in-
a
occ3
ternal memory saves settings for unlimited time, and the clock
continues to run for at least 24 hours. An extension of Carrier's
unocc
proven line of thermostats, the Edge Pro thermostat provides
separate set points for heating and cooling in addition to hu-
midification and dehumidification.
a33-9188
Fig. 1 — Thermostat Display
OPERATION
The thermostat display is locat-
Thermostat Display —
The thermo-
Thermostat Front Panel Buttons —
ed in the center of the thermostat. See Fig. 1. The following
stat has buttons under the front cover which are used for vari-
information can be displayed on the screen:
ous functions such as raising or lowering the desired set point
• day of the week
and changing the current mode. See Fig. 2.
• programming option (indicates which settings are being
SET BUTTON — This button enters the thermostat program-
adjusted)
ming schedule and allows the user to adjust the clock and
• filter and UV lamp service reminders
change the calendar.
• current temperature
• current program routine (follow scheduled program-
SCHEDULE BUTTON — This button allows the user to
ming, hold current settings, or run holiday program)
choose to follow a schedule, hold the current set points, or go
• fan mode (on, auto)
into holiday mode.
• current system mode (heating, cooling, emergency heat,
OCCUPIED BUTTON — This button temporarily changes
heat/cool (auto), off)
the thermostat from Unoccupied to Occupied settings.
• humidify or dehumidify settings
• Fahrenheit or Celsius display
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53330013-01
Printed in U.S.A.
Form 33CS-21SO
Pg 1
9-11
Replaces: 33CS-20SO
