Grizzly G9744 Machine Data Sheet

Customer Service #: (570) 326-3806 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
GRIZZLY MODEL G9744 METAL-CUTTING BANDSAW
Design Type......................................................................................................Floor Model
Overall Dimensions:
Crate Size ..................................................................................66" L x 29" W x 43" H
Foot Print ........................................................................................................47" x 22"
Length ......................................................................................................................67"
Width (front to back) ................................................................................................28"
Height (head in high position) ..................................................................................63"
Height (from floor to cutting area) ............................................................................23"
Weight (shipping) ..............................................................................................814 lbs.
Weight (Net) ......................................................................................................682 lbs.
Capacities:
Maximum Cutting Capacity@ 90˚................................9" Round, 5" x 16" Rectangular
Maximum Cutting Capacity@ 45˚.............................. 6" Round, 6" x 7
Bed Size ....................................................................................................22
Angle Cuts ......................................................................................................45° - 90°
Blade Size ....................................................................................................1" x 121
Blade Speeds ........................................................................115, 195, 290, 375 FPM
Construction:
Main Body ......................................................................................................Cast Iron
Stand ....................................................Formed and Welded Steel with Coolant Sump
Gear Box....................................................................Sealed & Lubricated Worm Gear
Blade Guides ........................................Adjustable Carbide Guides and Ball Bearings
Motor:
Type .................................................................... TEFC Capacitor Start Induction Run
Horsepower ........................................................................................................1
Phase ⁄ Cycle ..............................................................................Single Phase ⁄ 60 HZ
Voltage ..................................................................................................................220V
Amps ......................................................................................................................11.5
RPM ..............................................................................................................1720 RPM
Bearings ..........................................................Shielded and Lubricated Ball Bearings
Switch..............................................................................................Automatic Shut Off
Features:
.............................................................................. Control Panel on Top of Saw Bow
....................................................................................................Removable Chip Tray
..................................................................................Adjustable Hydraulic Down-Feed
..................................................................Hardened & ground Worm Gear and Shaft
............................................Quick Release Vise for Rapid Change out of Workpiece
............................................................Coolant Pump with Adjustable Coolant Nozzle
................................................................Quick Setting Blade Guide Arms with Scale
.............................................................................................................. Blade Included
351801621
Specifications, while deemed accurate, are not guaranteed.
REVISED 04/01
MACHINE DATA
SHEET
1
⁄ " Rectangular
2
1 5
⁄ " x 11 ⁄ "
4 8
5 ⁄ "
8
1 ⁄ HP
2
Form#197D
