Pace TDC775D Quick Start Manual

Pace TDC775D

CONNECTING THE EQUIPMENT

This Quick Start Guide shows two connection setups, which show various ways of setting up your Pace TDC775D with your other equipment.The solid lines
show recommended connections, while the dashed lines show optional or alternate connections.
Choose the setup that closest matches your available equipment.
Setup 1:TDC775D with HDTV and VCR
TV / RF
OUT
ANTENNA/
RF IN
RF
cable
Component
video
cables
CABLE INPUT
Setup 2:TDC775D with home theater receiver (or audio decoder), HDTV and VCR
RF cable
V CR
VIDEO IN
TV / RF
OUT
LEFT
AUDIO IN
ANTENNA/
RIGHT
RF IN
AUDIO IN
Baseband
audio cables
DIGITAL
OPTICAL
AUDIO IN
LEFT RIGHT
AUDIO AUDIO
IN IN
RF
cable
HOME THEATER
Baseband audio
and video cables
CABLE INPUT
RF cable
VCR
COMPONENT
VIDEO IN
Y
PB/CB
PR/CR
L AUDIO
IN
R AUDIO
IN
Baseband audio
cables
Baseband video cable
VIDEO OUT
COMPONENT
LEFT
VIDEO IN
AUDIO OUT VIDEO IN
RIGHT
Y
LEFT
AUDIO OUT
AUDIO IN
PB/CB
RIGHT
AUDIO IN
PR/CR
L AUDIO
IN
R AUDIO
IN
DIGITAL
COAXIAL
AUDIO IN
Component
video cables
Coaxial/optical
digital audio cable
Quick Start Guide
In Setup 1, connect your set-top to your TV via either an HDMI
connector, or via component video connectors.
HDTV
Connect the baseband audio cables to your TV as shown.
The RF connection and VCR are optional.
ANTENNA/
RF IN
Do not connect your set-top (or any other equipment such
as a TV or VCR) to the AC power supply until you have
HDMI
properly connected all the other cables Disconnect your set-
top from the AC power supply before you disconnect any
other equipment from its rear panel.
The only way to disconnect your set-top from the AC power
supply is to remove the AC power cord (or switch the wall
HDMI cable
socket-outlet switch, if present, to its OFF position).Your
set-top must therefore be installed near to the AC power
socket-outlet, which should be easily accessible.
TDC775D
In Setup 2, connect your set-top to your TV via either an HDMI
connector, or via component video connectors.
HDTV
Connect your set-top to your home theater receiver (or audio
decoder) via either an optical digital audio cable or a coaxial
audio cable.
ANTENNA/
RF IN
Connect your VCR to your other equipment via baseband audio
and video cables as shown.
The RF connection is optional.
HDMI
The POWER OUTLET plug is designed only for connection to the AC
power cord for a TV. The maximum power it can supply is 500 watts.
Do not connect any equipment that uses more than 500 watts, or any
non-TV equipment such as a toaster or hair drier.
HDMI cable
The CABLE IN connector is designed for
connection to a cable network only.
TDC775D
You must not connect any other
equipment, such as a VCR, to this input.
WARNINGS
POWER INPUT
