FS-1120D
FS-1320D
SERVICE
MANUAL
Published in June 2010
842LZ112
2LZSM062
Rev. 2

Advertisement

Table of Contents
loading

Summary of Contents for Kyocera FS-1320D

  • Page 1: Service Manual

    FS-1120D FS-1320D SERVICE MANUAL Published in June 2010 842LZ112 2LZSM062 Rev. 2...
  • Page 2 CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. It may be illegal to dispose of this battery into the municipal waste stream. Check with your local solid waste officials for details in your area for proper disposal. ATTENTION IL Y A UN RISQUE D’EXPLOSION SI LA BATTERIE EST REMPLACEE PAR UN MODELE DE TYPE INCORRECT.
  • Page 3: Revision History

    Revision history Revision Date Replaced pages Remarks March 4, 2010 1-1-2, 1-2-1 June 4, 2010 1-1-1, 1-3-1, 1-3-11, 1-3-12...
  • Page 4 This page is intentionally left blank.
  • Page 5: Safety Precautions

    Safety precautions This booklet provides safety warnings and precautions for our service personnel to ensure the safety of their customers, their machines as well as themselves during maintenance activities. Service personnel are advised to read this booklet carefully to familiarize themselves with the warnings and precautions described here before engaging in maintenance activities.
  • Page 6 Safety warnings and precautions Various symbols are used to protect our service personnel and customers from physical danger and to prevent damage to their property. These symbols are described below: DANGER: High risk of serious bodily injury or death may result from insufficient attention to or incorrect compliance with warning messages using this symbol.
  • Page 7: Installation Precautions

    1. Installation Precautions WARNING • Do not use a power supply with a voltage other than that specified. Avoid multiple connections to one outlet: they may cause fire or electric shock. When using an extension cable, always check that it is adequate for the rated current...................... •...
  • Page 8: Specifications 1

    2. Precautions for Maintenance WARNING • Always remove the power plug from the wall outlet before starting machine disassembly....• Always follow the procedures for maintenance described in the service manual and other related brochures............................• Under no circumstances attempt to bypass or disable safety features including safety mechanisms and protective circuits.
  • Page 9 • Do not remove the ozone filter, if any, from the copier except for routine replacement....... • Do not pull on the AC power cord or connector wires on high-voltage components when removing them; always hold the plug itself......................•...
  • Page 10 This page is intentionally left blank.
  • Page 11: Table Of Contents

    (1) Precautions ............................1-5-1 (2) Drum..............................1-5-1 (3) Toner container ..........................1-5-1 (4) How to tell a genuine Kyocera Mita toner container................1-5-2 1-5-2 Outer covers ............................1-5-3 (1) Detaching and refitting the top cover....................1-5-3 (2) Detaching and refitting the right and left covers ................1-5-4 1-5-3 Paper feed section ..........................1-5-6...
  • Page 12 2LY/2LZ 1-5-6 Transfer/separation section ........................1-5-14 (1) Detaching and refitting the transfer roller ..................1-5-14 1-5-7 Fuser section ............................1-5-16 (1) Detaching and refitting the fuser unit....................1-5-16 (2) Switching the fuser pressure ......................1-5-18 1-5-8 PWBs ..............................1-5-19 (1) Detaching and refitting the control PWB ..................1-5-19 (2) Detaching and refitting the power source PWB................1-5-22 (3) Detaching and refitting the operation panel PWB ................1-5-24 (4) Detaching and refitting the high voltage PWB.................1-5-25...
  • Page 13: Specifications

    2LY/2LZ-2 1-1 Specifications 1-1-1 Specifications Type ..........Desktop Printing method....... Electrophotography, laser scan Paper weight........Cassette: 60 to 120 g/m (Duplex: 60 to 105 g/m MP tray: 60 to 220 g/m Paper type ........Cassette: Plain, Preprinted, Bond, Recycled, Rough, Letterhead, Color (Colour), Prepunched, High quality, Custom 1 to 8 MP tray: Plain, Transparency, Preprinted, Labels, Bond, Recycled, Rough, Vellum,...
  • Page 14 2LY/2LZ-1 ° ° Operating environment ....Temperature: 10 to 32.5 C/50 to 90.5 Humidity: 15 to 80% Altitude: 2,500 m/8,202 ft maximum Brightness: 1,500 lux maximum Controller ........PowerPC 405F5/360 MHz Supported OS ......... Microsoft Windows 2000/XP/Vista/7, Windows Server 2003/2008, Mac OS X 10.x Interface..........
  • Page 15: Parts Names

    2LY/2LZ 1-1-2 Parts names (1) Overall Figure 1-1-1 Top cover MP tray Paper stopper Sub tray Top tray 10. Optional interface slot cover Operation panel 11. USB interface connector Right side cover 12. Rear cover Cassette 13. Power cord connector Front cover 14.
  • Page 16 2LY/2LZ (2) Operation panel Figure 1-1-2 Ready indicator Attention indicator Toner indicator Data indicator Paper indicator Jam indicator Cancel key GO key 1-1-4...
  • Page 17: Machine Cross Section

    2LY/2LZ 1-1-3 Machine cross section Light path Paper path Paper path (option) Figure 1-1-3 Cassette Laser scanner unit MP tray Transfer/separation section Paper feed/conveying section 10. Fuser section Toner container 11. Exit section Developing unit 12. Top tray Main charger unit 13.
  • Page 18 2LY/2LZ This page is intentionally left blank. 1-1-6...
  • Page 19: Installation Environment

    2LY/2LZ-1 1-2 Installation 1-2-1 Installation environment ° ° Temperature: 10 to 32.5 C/50 to 90.5 Humidity: 15 to 80%RH Power supply: 120 V AC, 8.0 A 220 - 240 V AC, 4.2 A ± ± Power source frequency: 50 Hz 0.3%/60 Hz 0.3% Installation location...
  • Page 20: Unpacking

    2LY/2LZ 1-2-2 Unpacking 220 - 240 V AC model 120 V AC model Figure 1-2-2 Printer 11. Power cord Outer case 12. Pad Bottom pad L 13. Plastic bag Bottom pad R 14. Installation guide Machine cover 15. Panel GFIS sheet Top pad L 16.
  • Page 21: Removing The Tapes

    2LY/2LZ (1) Removing the tapes Procedure 1. Remove three tapes. Tape Tape Tape Figure 1-2-3 1-2-3...
  • Page 22: Installing The Expanded Memory (Option)

    2LY/2LZ 1-2-3 Installing the expanded memory (option) Procedure 1. Turn off printer power switch. Caution: Do not insert or remove expanded memory while printer power is on. Doing so may cause damage to the printer and the expanded memory. 2. Remove the right side cover. 3.
  • Page 23: Installing The Memory Card (Option)

    2LY/2LZ 1-2-4 Installing the memory card (option) Procedure 1. Turn off printer power switch. Caution: Do not insert or remove memory card while printer power is on. Doing so may cause damage to the printer and the memory card. 2. Open the rear cover. Rear cover Figure 1-2-6 3.
  • Page 24: Installing The Network Interface Card (Option)

    2LY/2LZ 1-2-5 Installing the network interface card (option) Procedure 1. Turn off printer power switch. Caution: Do not insert or remove network interface card while printer power is on. Doing so may cause damage to the printer and the network interface card. 2.
  • Page 25: Maintenance Mode

    2LY/2LZ-2 1-3 Maintenance Mode 1-3-1 Maintenance mode The product incorporates several service modes which are activated by using the keys on the operation panel or by com- manding from a PC. (1) Executing a service mode Printing a status page for service purpose........See page 1-3-2. Printing an event log (EVENT LOG) ..........
  • Page 26: Service Status Page

    2LY/2LZ Service items Description Printing a status page Description for service purpose Prints a status page for service purpose. The status page includes various printing settings and service cumulative. Purpose To acquire the current printing environmental parameters and cumulative information. Procedure 1.
  • Page 27 2LY/2LZ Service items Description Detail of service information Service information Total page 9690 [XXXXXXXX][XXXXXXXX][01/00] /t/U00/F00/N00 (6) (7) (8) /0020/0020/1061/0811/ (10) (11) (12) (13) /0000/0000/ /00/300/81/31/81/31/ (14)(15)(16)(17)(18)(19) (20) A:1234567890123456 (21) /02870284/03028003/83030286/86000086/02000000/02020202/02020202/ (22) /03030303/03030303/03030303/03030303/03000000/03030303/03030303/ SPD1:0203040508090A0B0C0D0F101112131415161718191A1B1C1D1E1F202122235E (23) (24) /00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/ /00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/ /00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/ /00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/ /00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/ /00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/ /00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/ /00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/00000000/...
  • Page 28 1 = 0: Overseas, 1: Domestic (Japan) [First byte/Second byte bit 2, 3 (Not used) (displayed in OEM model bit 4 = 0: Kyocera, 1: OEM only)] bit 5 = 0: For Europe, 1: For US bit 6 = 0: Non MICR mode, 1: MICR mode...
  • Page 29 2LY/2LZ Service items Description Items Description (20) Fixed asset number (Maximum 16 characters) (21) Paper type attributes Paper type setting value from 1 to 28 (fuser, weight, duplex) (unused paper type are always 0x00.) (22) Paper type attributes Paper type setting value from 1 to 28 (density) (unused paper type are always 0x00.) (23) Memory SPD information (slot...
  • Page 30 2LY/2LZ Service items Description Printing an event log Description (EVENT LOG) Prints a history list of occurrences of paper jam, self-diagnostics, toner replacements, etc. Purpose To allow machine malfunction analysis based on the frequency of paper misfeeds, self diag- nostic errors and replacements. Procedure 1.
  • Page 31: Event Log

    2LY/2LZ Service items Description EVENT LOG [EB20MA001/2LZ_1000.001.019] [40.00SFLB] [01] Firmware version: 2LZ_30000.001.024 Released: 20/January/2010 Printed page(s) 12345 Paper Jam Log Service Call Log Count. Event Count. Service Code 9993 10.48.01.08.01.01 11234 01.6000 10000 01.6000 9992 10.48.01.08.01.01 9999 01.6000 9991 10.48.01.08.01.01 9998 01.6000 9990...
  • Page 32 [First byte/Second byte (dis- bit 2, 3 (Not used) played in OEM mode only)] bit 4 = 0: Kyocera, 1: OEM bit 5 = 0: For Europe, 1: For US bit 6 = 0: Non MICR mode, 1: MICR mode...
  • Page 33 2LY/2LZ Service items Description Items Description Paper Jam (a) Cause of paper jam cont. 10: Paper does not arrive at the registration sensor. (MP tray) [42] 10: Paper does not arrive at the registration sensor. (Cassette 1) [31] 10: Paper does not arrive at the registration sensor. (Cassette 2) [31] 10: Paper does not arrive at the registration sensor.
  • Page 34 2LY/2LZ Service items Description Items Description (c) Detail of paper source (Hexadecimal) Paper Jam Log cont. 00: MP tray 01: Cassette 1 (printer) 02: Cassette 2 (paper feeder 1) 03: Cassette 3 (paper feeder 2) 07: Duplex (d) Detail of paper size (Hexadecimal) 00: (Undefined) 09: B5R 20: Reply-paid postcard...
  • Page 35 2LY/2LZ-2 Service items Description Items Description (11) Unknown Toner Count. Item Remembers 1 to 5 of occur- The total page count at Unknown toner log code rence of unknown toner the time of the “Toner (1 byte, 2 categories) NOTE: detection.
  • Page 36 2LY/2LZ-2 Service items Description [REPLACE MAINTE- Description NANCE KIT] message [REPLACE MAINTENANCE KIT] message sheet is printed at the 1st power-up after the sheet page count exceeding 100,000 pages. Procedure Replace the maintenance kit. 30/32 ppm model (A4/Letter) Maintenance kit MK-162 (for 120 V specifications) Maintenance kit MK-160 (for 230 V specifications) Maintenance kit MK-164 (for 240 V specifications) 35/37 ppm model (A4/Letter)
  • Page 37: Paper Misfeed Detection

    2LY/2LZ 1-4 Troubleshooting 1-4-1 Paper misfeed detection (1) Paper misfeed indication If paper jams in the paper conveying system, or no paper sheets are fed at all, the printer automatically goes offline, and the jam indicator will flash rapidly. Status Monitor or COMMAND CENTER can indicate the location of the paper jam (the component where the paper jam has occurred).
  • Page 38: Paper Misfeed Detection Condition

    2LY/2LZ (2) Paper misfeed detection condition Printer Peper feeder 1 (Option) (1) Registration sensor (2) Paper sensor (3) MP paper sensor (4) Paper exit sensor (5) PF paper sensor (6) PF paper feed sensor Peper feeder 2 (Option) Figure 1-4-2 1-4-2...
  • Page 39: Self-Diagnostic Function

    2LY/2LZ 1-4-2 Self-diagnostic function (1) Self-diagnostic function The printer is equipped with self-diagnostic function which automatically halts the printer when an error is detected. The four indicators (Jam, Paper, Attention, Toner) are simultaneously lit, then indicate a specific error by the combination of the four indicators.
  • Page 40: Self Diagnostic Codes Indication

    2LY/2LZ (2) Self diagnostic codes indication Sequence of display Indicates the occurrence of a self diagnostics error. 1.6 s 1.6 s 0.8 s 0.8 s Example of self-diagnostic code: 2610 (Refer to the following code conversion table) 0.8 s 0.8 s 0.8 s Indication example Lit (Green)
  • Page 41: Self Diagnostic Codes

    2LY/2LZ (3) Self diagnostic codes Remarks Code Contents Causes Check procedures/corrective measures 0150 Control PWB EEPROM error Improper installation Check the installation of the EEPROM Detecting control PWB EEPROM control PWB EEPROM (U300) and remedy if necessary (See page (U300) communication error. (U300).
  • Page 42 2LY/2LZ Remarks Code Contents Causes Check procedures/corrective measures 2610 PF paper feed motor error (Paper Defective harness Reinsert the connector. Also check for conti- feeder 1) between PF paper nuity within the connector harness. If none, The PF paper feed motor of paper feed motor and PF remedy or replace the harness (Refer to the feeder 1 ready input is not given for 2...
  • Page 43 2LY/2LZ Remarks Code Contents Causes Check procedures/corrective measures 6000 Broken fuser heater lamp wire Poor contact in the Reinsert the connector (See page 1-5-16). The fuser temperature does not rise fuser thermistor con- after the fuser heater lamp has been nector terminals.
  • Page 44 2LY/2LZ Remarks Code Contents Causes Check procedures/corrective measures 7990 Waste toner full Waste toner reservoir Turn the main power switch off/on to restart The waste toner sensor has detected (drum unit) is full. the printer. If the error is not resolved, that the waste toner reservoir (drum replace the drum unit (See page 1-5-12).
  • Page 45: Image Formation Problems

    2LY/2LZ 1-4-3 Image formation problems (1)Completely blank (2)All-black printout. (3)Dropouts. (4)Black dots. (5)Black horizontal printout. streaks. See page 1-4-10 See page 1-4-10 See page 1-4-11 See page 1-4-11 See page 1-4-11 (6)Black vertical (7)Unsharpness. (8)Gray background. (9)Dirt on the top (10)Undulated print- streaks.
  • Page 46: All-Black Printout

    2LY/2LZ (1) Completely blank printout. Print example Causes Check procedures/corrective measures Defective drum unit or developing Open the top cover and check that the drum unit and develop- unit. ing unit are correctly seated. Investigate that the terminals between the main charger unit and the drum unit are not in loose contact (See page 1-5-12 and 1-5-11).
  • Page 47: Dropouts

    2LY/2LZ (3) Dropouts. Print example Causes Check procedures/corrective measures Defective developing roller (develop- If the defects occur at regular intervals of 62.8 mm/2 " (See ing unit). page 2-4-2), the problem may be the damaged developing roller (in the developing unit). Replace the developing unit (See page 1-5-11).
  • Page 48: Black Vertical Streaks

    2LY/2LZ (6) Black vertical streaks. Print example Causes Check procedures/corrective measures Adhesion of oxide to main charger Remove the drum unit (See page 1-5-12). Slide the charger wire. cleaner (green) left and right 2 or 3 times to clean the charger wire, then return it to its original position (CLEANER HOME POSITION).
  • Page 49: Dirt On The Top Edge Or Back Of The Paper

    2LY/2LZ (9) Dirt on the top edge or back of the paper. Print example Causes Check procedures/corrective measures Toner contamination in various parts. Dirty edges and back of the paper can be caused by toner accumulated on such parts as the paper chute guide, paper conveying paths, the bottom of the drum and developing unit, and the fuser unit inlet.
  • Page 50: Electric Problems

    2LY/2LZ 1-4-4 Electric problems Problem Causes Check procedures/corrective measures No electricity at the power Measure the input voltage. The machine does outlet. not operate when the The power cord is not Check the contact between the power plug and the outlet. power switch is plugged in properly.
  • Page 51 2LY/2LZ Problem Causes Check procedures/corrective measures Broken developing clutch Check for continuity across the coil. If none, replace the develop- Developing clutch coil. ing clutch. does not operate. Defective harness between Reinsert the connector. Also check for continuity within the con- developing clutch and con- nector harness.
  • Page 52: Mechanical Problems

    2LY/2LZ 1-4-5 Mechanical problems Problem Causes/check procedures Corrective measures Check if the surfaces of the paper feed roller Clean with isopropyl alcohol. No primary paper feed. is dirty with paper powder. Check if the paper feed roller is deformed. Check visually and replace any deformed paper feed roller (assembly) (See page 1-5- Defective paper feed clutch installation.
  • Page 53: Assembly And Disassembly

    2LY/2LZ 1-5 Assembly and Disassembly 1-5-1 Precautions for assembly and disassembly (1) Precautions Be sure to turn the power switch off and disconnect the power plug before starting disassembly. When handling PWBs, do not touch connectors with bare hands or damage the PWB. Do not touch any PWB containing ICs with bare hands or any object prone to static charge.
  • Page 54: How To Tell A Genuine Kyocera Mita Toner Container

    A black-colored band when seen through the left side window A shiny or gold-colored band when seen through the right side window The above will reveal that the toner container is a genuine Kyocera Mita branded toner container, otherwise, it is a coun- terfeit.
  • Page 55: Outer Covers

    2LY/2LZ 1-5-2 Outer covers (1) Detaching and refitting the top cover Procedure 1. Open the top cover. 2. Remove two screws. Top cover Screw Screw Figure 1-5-3 3. Extract the boss from the hole. 4. Unhook the A hook. Top cover 5.
  • Page 56: Detaching And Refitting The Right And Left Covers

    2LY/2LZ (2) Detaching and refitting the right and left covers Procedure 1. Remove the top cover (See page 1-5-3). 2. Remove the cassette (See page 1-5-6). 3. Open the front cover. 4. Unhook seven hooks and then remove the right cover. Hooks Right cover Figure 1-5-5...
  • Page 57 2LY/2LZ 5. Unhook seven hooks and then remove the left cover. Left cover Hooks Figure 1-5-6 1-5-5...
  • Page 58: Paper Feed Section

    2LY/2LZ 1-5-3 Paper feed section (1) Detaching and refitting the paper feed assembly (paper feed roller and pickup roller) Procedure 1. Remove the cassette. Cassette Figure 1-5-7 2. Slide the feed shaft. 3. While pressing the lever and then remove the paper feed roller assembly.
  • Page 59 2LY/2LZ 4. Check or replace the paper feed assembly and refit all the removed parts. Paper feed roller Feed shaft assembly When refitting the paper feed roller assem- bly, be sure to align the paper feed roller pivot with the slotted hole on the feed shaft. Paper feed roller assembly Feed shaft...
  • Page 60: Detaching And Refitting The Retard Roller Assembly

    2LY/2LZ (2) Detaching and refitting the retard roller assembly Procedure 1. Remove the cassette (See page 1-5-6). Retard guide 2. Push the bottom plate down until it locks. Hook 3. Unhook two hooks and then remove the retard guide. Hook Cassestte Bottom plate Cassette...
  • Page 61 2LY/2LZ 5. Check or replace the retard roller assembly and refit all the removed parts. Retard roller Caution: Before refitting the retard roller assembly assembly, firmly install the spring onto the projection of the retard roller assembly. Projection Spring Figure 1-5-12 1-5-9...
  • Page 62: Detaching And Refitting The Mp Paper Feed Roller

    2LY/2LZ (3) Detaching and refitting the MP paper feed roller Procedure 1. Open the front cover. 2. Pull the MP feed holder (lever) down (1). 3. Slide the MP feed holder (2). 4. Remove the MP paper feed roller (3). MP paper feed roller Front cover MP paper feed roller...
  • Page 63: Developing Section

    2LY/2LZ 1-5-4 Developing section (1) Detaching and refitting the developing unit Procedure 1. Open the top cover. Top cover 2. Open the front cover. 3. Remove the developing unit (with toner con- tainer). 4. Check or replace the developing unit and refit all the removed parts.
  • Page 64: Drum Section

    2LY/2LZ 1-5-5 Drum section (1) Detaching and refitting the drum unit Procedure 1. Remove the developing unit (See page 1-5- 11). 2. Remove the drum unit. 3. Check or replace the drum unit and refit all the removed parts. Drum unit Figure 1-5-16 1-5-12...
  • Page 65: Detaching And Refitting The Main Charger Unit

    2LY/2LZ (2) Detaching and refitting the main charger unit Procedure 1. Remove the drum unit (See page 1-5-12). 2. Remove the tape. 3. While pushing on the main plate (1), slide the main charger unit (2). Tape Main charger unit Drum unit Main charger unit Main plate...
  • Page 66: Transfer/Separation Section

    2LY/2LZ 1-5-6 Transfer/separation section (1) Detaching and refitting the transfer roller Procedure 1. Remove the developing unit (See page 1-5- 11). 2. Remove the drum unit (See page 1-5-12). 3. Slide the paper chute guide and unhook the hooks. 4. Remove the paper chute guide. Paper chute guide Paper chute guide Hook...
  • Page 67 2LY/2LZ 5. Remove the transfer roller’s shaft from the Shaft both transfer bushes. 6. Remove the gear Z16 from the transfer roller. Transfer roller Shaft Transfer roller Transfer roller Transfer roller Gear Z16 Figure 1-5-20 7. Check or replace the transfer roller and refit all the removed parts.
  • Page 68: Fuser Section

    2LY/2LZ 1-5-7 Fuser section (1) Detaching and refitting the fuser unit Procedure 1. Remove the outer covers (See page 1-5-3). 2. Remove two connectors. 3. Release the wires form wire clamps. Wires Wire clamps Connector (Fuser heater lamp) Connector (Fuser thermistor) Figure 1-5-22 4.
  • Page 69 2LY/2LZ 5. Remove the rear cover. Rear cover Figure 1-5-24 6. Remove two screws and then remove the fuser unit. 7. Check or replace the fuser unit and refit all the removed parts. Fuser unit Screw Screw Figure 1-5-25 1-5-17...
  • Page 70: Switching The Fuser Pressure

    2LY/2LZ (2) Switching the fuser pressure The fuser pressure may be decreased to suppress the print quality problems such as paper creases and curls. It must be cautioned that decreasing the fuser pressure could cause loose toner fusing. Procedure 1. Remove the cassette (See page 1-5-6). 2.
  • Page 71: Pwbs

    2LY/2LZ 1-5-8 PWBs (1) Detaching and refitting the control PWB Procedure 1. Remove the right cover (See page 1-5-4). 2. Remove fourteen connectors form the con- trol PWB. 3. Release the wires from the wire clamps. Control PWB Wire clamps Connectors (Thirteen) Connector...
  • Page 72 2LY/2LZ 4. Remove five screws. 5. Remove three connectors form the control PWB. Connectors (Three) 6. Unhook the hook and then remove the con- trol PWB assembly. Control PWB Hook Screw Screws Screws Control PWB assembly Figure 1-5-28 1-5-20...
  • Page 73 2LY/2LZ 7. Remove five screws and then remove the control PWB. Screw 8. Check or replace the control PWB and refit all the removed parts. Screw To replace the control PWB, remove the Screw EEPROM (U300) from the old control PWB and mount it to the new control PWB.
  • Page 74: Detaching And Refitting The Power Source Pwb

    2LY/2LZ (2) Detaching and refitting the power source PWB Procedure 1. Remove the top cover (See page 1-5-3). 2. Remove the left cover (See page 1-5-4). 3. Remove four connectors. Connector Connector Connector Connector (YC104) Figure 1-5-30 4. Remove four P tight screws, two screws and ground terminal.
  • Page 75 2LY/2LZ 6. Remove four screws and then remove the Screws power source plate from the power source PWB. 7. Check or replace the power source PWB and refit all the removed parts. Caution: The power source film must be installed in the specified position. Screws Power source PWB Power source film...
  • Page 76: Detaching And Refitting The Operation Panel Pwb

    2LY/2LZ (3) Detaching and refitting the operation panel PWB Procedure 1. Remove the top cover (See page 1-5-3). 2. Remove two screws and then remove the Screw panel cover. 3. Remove the operation panel PWB. 4. Remove the connector. Panel cover 5.
  • Page 77: Detaching And Refitting The High Voltage Pwb

    2LY/2LZ (4) Detaching and refitting the high voltage PWB Procedure 1. Remove the developing unit (See page 1-5- 11). 2. Remove the drum unit (See page 1-5-12). 3. Remove the cassette (See page 1-5-6). Stop ring 4. Remove the outer covers (See page 1-5-3). 5.
  • Page 78 2LY/2LZ 11. Remove four screws. 12. Unhook three hooks and then remove the lower base cover. Lower base cover Hook Hook Hook Screws Screws Lower base cover Figure 1-5-36 1-5-26...
  • Page 79 2LY/2LZ 13. Remove the spring. 14. Remove the cassette pin. Cassette pin Spring Figure 1-5-37 15. Remove two connectors and then remove the high voltage PWB. 16. Remove the cassette pin holder from the high voltage PWB. Cassette pin holder High voltage High voltage PWB YC202...
  • Page 80 2LY/2LZ 17. Check or replace the high voltage PWB and refit all the removed parts. When refitting the high voltage PWB, be High voltage PWB careful about following points. • Position the ground plate so that it is atop the high voltage PWB. Ground plate •...
  • Page 81: Others

    2LY/2LZ 1-5-9 Others (1) Detaching and refitting the main motor Procedure 1. Remove the right cover (See page 1-5-4). 2. Remove the connector. Connector Figure 1-5-40 3. Remove the M3 screw and two M4 screws. 4. Remove the main motor. 5.
  • Page 82: Detaching And Refitting The Laser Scanner Unit

    2LY/2LZ (2) Detaching and refitting the laser scanner unit Procedure 1. Remove the right cover (See page 1-5-4). 2. Remove the connector from the control PWB. 3. Release the wire clamp. 4. Draw in the connector inside. Connector Control PWB Clamp Connector Figure 1-5-42...
  • Page 83 2LY/2LZ 5. Remove four screws and then remove the laser scanner unit. 6. Check or replace the laser scanner unit and refit all the removed parts. Screws Screws Laser scanner unit Figure 1-5-43 1-5-31...
  • Page 84: Detaching And Refitting The Eraser Lamp

    2LY/2LZ (3) Detaching and refitting the eraser lamp Procedure 1. Remove the laser scanner unit (See page 1- 5-30). 2. Remove the connector. 3. Remove the eraser lamp. 4. Check or replace the eraser lamp and refit all the removed parts. Eraser lamp Connector Figure 1-5-44...
  • Page 85: Direction Of Installing The Left And Right Cooling Fan Motors

    2LY/2LZ (4) Direction of installing the left and right cooling fan motors When detaching or refitting the left and/or right cooling fan motors, be careful of the airflow direction (intake or exhaust). Right cooling Left cooling fan motor fan motor Intake Exhaust Figure 1-5-45...
  • Page 86 2LY/2LZ This page is intentionally left blank. 1-5-34...
  • Page 87: Firmware

    2LY/2LZ 1-6 Firmware 1-6-1 Downloading firmware Firmware files are named after the following codes: Firmware file name example Compression Software ID S 2 L Z _ 1 0 0 0 0 0 1 0 2 1 . c m p Product code Pause (period) 2LY: 30/32 ppm model (A4/Letter)
  • Page 88: Downloading The Firmware From The Memory Card

    2LY/2LZ (1) Downloading the firmware from the memory card To download data written in a memory card (CompactFlash) to the printer, proceed as explained in this section. CAUTION Downloading firmware takes several minutes. Do not turn power off during downloading. If downloading is interrupted by an accidental power failure, etc., the control PWB may have to be replaced.
  • Page 89 2LY/2LZ 5. Turn printer power on. The printer starts and finishes downloading automatically. Sequence of display Indication example Off (Amber) Downloading start Lit (Green) Lit (Amber) 4.8 s Off (Amber) Supervisor Off (Green) mode Lit (Amber) 4.8 s (Repeat) Receiving data *: 0.8 s (Repeat)
  • Page 90 2LY/2LZ 6. Confirm that downloading was finished nor- mally (See previous page). 7. Turn power off. 8. Remove the memory card. 9. Secure the optional interface slot cover by using two screws. Memory card slot 10. Close the rear cover. 11.
  • Page 91: Paper Feed/Conveying Section

    2LY/2LZ 2-1 Mechanical Construction 2-1-1 Paper feed/conveying section Paper feed/conveying section consists of the paper feed unit that feeds paper from the cassette and the MP tray paper feed unit that feeds paper from the MP tray, and the paper conveying section that conveys the fed paper to the transfer/ separation section.
  • Page 92: Mp Tray Paper Feed Section

    2LY/2LZ (2) MP tray paper feed section Figure 2-1-3 MP tray paper feed section MP paper feed roller MPF frame MPF separation pad MPF guide R/L MPF separator (10) MPF base MPF bottom plate (11) MPF middle tray MPF friction pad (12) MPF upper tray MP paper sensor (13) MPF turn guide...
  • Page 93: Paper Conveying Section

    2LY/2LZ (3) Paper conveying section Figure 2-1-5 Paper conveying section Lower registration roller Upper registration roller Registration sensor Actuator (registration sensor) Feed pulley Control PWB MMOTRDYN YC305-3 MOTCLK YC305-4 Main motor REMOTEN YC305-5 REGDRN Registration YC308-2 clutch High voltage PWB Registration REGN sensor...
  • Page 94: Drum Section

    2LY/2LZ 2-1-2 Drum section (1) Drum section The durable layer of organic photoconductor (OPC) is coated over the aluminum cylinder base. The OPC tend to reduce its own electrical conductance when exposed to light. After a cyclic process of charging, exposure, and development, the electrostatic image is constituted over the OPC layer.
  • Page 95: Main Charger Unit

    2LY/2LZ (2) Main charger unit As the drum rotates in a “clean (neutral)” state, its photoconductive layer is given a uniform, positive (+) corona charge dis- persed by the main charger wire. Due to high-voltage scorotron charging, the charging wire can get contaminated by oxi- dization after a long run.
  • Page 96: Expose Section

    2LY/2LZ 2-1-3 Expose section (1) Laser scanner unit The charged surface of the drum is then scanned by the laser beam from the laser scanner unit. The laser beam (780 nm wavelength) beam is dispersed as the polygon motor revolves to reflect the laser beam over the drum.
  • Page 97 2LY/2LZ Figure 2-1-11 Laser scanner unit Polygon motor (mirror) Laser diode (APC PWB) Collimator lens Cylindrical lens F-θ lens F-θ lens PD mirror SOS lens Pin photo diode sensor (PD PWB) (10) LSU mirror 2-1-7...
  • Page 98: Developing Section

    2LY/2LZ 2-1-4 Developing section The latent image constituted on the drum is developed into a visible image. The developing roller contains a 3-pole (S-NS) magnet roller and an aluminum cylinder rotating around the magnet roller. Toner attracts to the magnet sleeve since it is powdery ink made of black resin bound to iron particles.
  • Page 99: Transfer/Separation Section

    2LY/2LZ 2-1-5 Transfer/separation section The transfer/separation section consists of the transfer roller, discharger brush and paper chute guide. A high voltage gen- erated by the high voltage PWB is applied to the transfer roller for transfer charging. Paper after transfer is separated from the drum.
  • Page 100: Cleaning Section

    2LY/2LZ 2-1-6 Cleaning section After the transferring process, the drum needs to be physically cleaned of toner which is residual after the development process. The cleaning blade is constantly pressed against the drum and scrapes the residual toner off to the sweep roller. The waste toner is collected at the output end of the sweep roller and sent back to the toner container, into the waste toner reservoir.
  • Page 101: Fuser Section

    2LY/2LZ 2-1-7 Fuser section The toner on the paper is molten and pressed into the paper as it passes between the heat roller and the press roller in the fuser unit. The heat roller has a heater lamp inside which continuously turns on and off by the fuser thermistor to maintain the constant temperature onto the heat roller surface.
  • Page 102 2LY/2LZ Fuser unit High Power Control PWB voltage source PWB Fuser thermal cutout HEATN YC103-6 YC311-5 YC102-1 SLEEP YC103-7 YC311-6 ZCROSS YC102-3 YC103-8 YC311-3 Fuser heater lamp Fuser thermistor THERM YC311-16 Figure 2-1-19 Fuser section block diagram 2-1-12...
  • Page 103: Paper Exit Section

    2LY/2LZ 2-1-8 Paper exit section The paper exit section transports the paper which passed the fuser unit towards the top tray. The paper which passed through the fuser unit turns on the actuator (exit sensor) in the fuser unit, and is led by the guide comprised of the rear cover, frame and the FD cover guide, finally reaching the upper FD roller.
  • Page 104 2LY/2LZ Fuser unit Control PWB EXITN YC307-3 Exit sensor Figure 2-1-21 Paper exit section block diagram 2-1-14...
  • Page 105: Duplex/Conveying Section

    2LY/2LZ 2-1-9 Duplex/conveying section The duplex/conveying section consists of conveying path which sends the paper sent from the exit section to the paper feed/conveying section when duplex printing. Figure 2-1-22 Duplex/conveying section DU cover B DU holder Middle pulley B DU roller DU cover A Lower base cover...
  • Page 106 2LY/2LZ This page is intentionally left blank. 2-1-16...
  • Page 107: Electrical Parts Layout

    2LY/2LZ 2-2 Electrical Parts Layout 2-2-1 Electrical parts layout (1) PWBs Machine left Machine inside Machine right Figure 2-2-1 PWBs Control PWB ..........Main controller: Controls the software such as the print data processing and provides the interface with computers. Engine: Controls printer hardware such as high voltage/bias output con- trol, paper conveying system control, and fuser temperature control, etc.
  • Page 108: Switches And Sensors

    2LY/2LZ (2) Switches and sensors Machine left Machine inside Machine right Figure 2-2-2 Switches and sensors Power switch..........Turns ON/OFF the AC power source. Interlock switch ..........Shuts off 24 V DC power line when the top cover is opened. Cassette switch..........
  • Page 109: Other Electrical Components

    2LY/2LZ (3) Other electrical components Machine left Machine inside Machine right Figure 2-2-3 Other electrical components Main motor ............Drives the paper feed/conveying section and fuser unit. Polygon motor........... Drives the polygon mirror. Right cooling fan motor ........Cools the interior of machine. Left cooling fan motor ........
  • Page 110 2LY/2LZ This page is intentionally left blank. 2-2-4...
  • Page 111: Power Source Pwb

    2LY/2LZ 2-3 Operation of the PWBs 2-3-1 Power source PWB Power source PWB Left +24V1 cooling fan motor ZCROSS Zero cross signal circuit Power switch SLEEP AC input Switching +5V1 regulator circuit +24V2 Fuser heater Interlock lamp control switch HEATN circuit +3.3V1 THERM...
  • Page 112 2LY/2LZ YC104 YC105 YC102 YC103 YC101 Figure 2-3-2 Power source PWB silk-screen diagram Connector Pin No. Signal Voltage Description YC101 LIVE 120 V AC AC power input Connected 220 - 240 V AC to the AC NEUTRAL 120 V AC AC power input inlet 220 - 240 V AC...
  • Page 113: Feeder

    2LY/2LZ 2-3-2 Control PWB Control PWB Engine Main controller Laser scanner unit I/F Duplex solenoid Registration clutch Operation MP paper feed panel PWB I/F solenoid Paper feed clutch USB I/F +3.3 V Developing clutch Memory card I/F Paper feed sensor Engine I/F MP paper feed KUIO I/F...
  • Page 114 2LY/2LZ YC316 YC317 YC307 U300 Figure 2-3-4 Control PWB silk-screen diagram 2-3-4...
  • Page 115 2LY/2LZ Connector Pin No. Signal Voltage Description LED1 3.3/0 V DC Paper indicator display: On/Off Connected LED2 3.3/0 V DC Jam indicator display: On/Off to the opera- Analog Cancel key/GO key: On/Off tion panel SGND Ground LED3 3.3/0 V DC Ready indicator display: On/Off LED4 3.3/0 V DC...
  • Page 116 2LY/2LZ Connector Pin No. Signal Voltage Description YC311 +24V1 24 V DC 24 V DC power source Connected +3.3V2 3.3 V DC 3.3 V DC power source to the high ZCROSS 0/3.3 V DC (pulse) Zero cross signal voltage 0/24 V DC Left cooling fan motor: On/Off HEATN 0/3.3 V DC...
  • Page 117 2LY/2LZ Connector Pin No. Signal Voltage Description YC318 +24V3 24 V DC 24 V DC power source Connected PGND Ground to the PFSI 0/3.3 V DC (pulse) Serial communication data input signal optional PFSO 0/3.3 V DC (pulse) Serial communication data output signal paper feeder PFSEL 0/3.3 V DC...
  • Page 118 2LY/2LZ This page is intentionally left blank. 2-3-8...
  • Page 119: Appendixes

    2LY/2LZ 2-4 Appendixes 2-4-1 Appendixes (1) Wiring diagraml LED1 LED2 SGND LED3 LED4 LED5 LED6 +3.3V1 PFSEL PFSO PFSI PGND +24V3 connector +3.3V1 PFSEL slot DIMM Expanded slot card Memory PFSO PFSI PGND DUDR2 +24V3 COMMON DUDR1 SGND TNFULL +3.3V1 DLPDRN SGND +24V3...
  • Page 120: Repetitive Defects Gauge

    2LY/2LZ (2) Repetitive defects gauge First occurrence of defect [24.99 mm/1"] Upper registration roller [37.68 mm/1 "] Lower registration roller [45.216 mm/1 "] Transfer roller [62.8 mm/2 "] Developing roller (developing unit) [73.162 mm/2 "] Heat roller (fuser unit) [78.5 mm/3 "] Press roller (fuser unit) 1/16 [94 mm/3...
  • Page 121: Self Diagnostic Codes Indication (Animation)

    2LY/2LZ (3) Self diagnostic codes indication (Animation) Click the icon to play the animation of the indicator combinations. Right-click an indicator, then select Playback and Play to play the animation repeatedly. To play the animation, you have to install Adobe Flash Player and Adobe Reader (Version 6.01 or more) to your PC. If the animation is not displayed, you should get the latest version from Adobe site (http://www.adobe.com/downloads/).
  • Page 122 2LY/2LZ Indication Contents Broken fuser thermistor wire Zero cross signal error Control PWB checksum error Control PWB RAM checksum error Control PWB general failure Control PWB engine communication error Control PWB engine checksum error Control PWB video data control error 2-4-4...
  • Page 123: Maintenance Parts List

    2LY/2LZ (4) Maintenance parts list 30/32 ppm model (A4/Letter) Maintenance part name Alternative part Part No. Name used in service manual Name used in parts list Maintenance kit (120 V specifications) MK-162/MAINTENANCE KIT 1702LY7US0 072LY7US DK-150 DV-162(U) Maintenance kit (230 V specifications) MK-160/MAINTENANCE KIT 1702LY8NL0 072LY8NL...
  • Page 124 2LY/2LZ This page is intentionally left blank. 2-4-6...

This manual is also suitable for:

Fs-1120dPf-100

Table of Contents
