Mophie Juice Pack for Galaxy S III User Manual

Product
mophie juice pack®
Compatibility
Made for the Samsung Galaxy® S III
Box Contents mophie juice pack, Micro USB Cable, Manual
mophie juice pack
Welcome
Thank you for purchasing the mophie juice pack
for Samsung Galaxy SIII. You will now be able to
travel great distances; be the master of your own
destiny, no longer bound by the limitations of
your phone's internal battery. Let's get juiced!
Package Contains
• mophie juice pack for Samsung Galaxy SIII
• Micro USB Cable
• User Manual
Features
The mophie juice pack extends the battery life
of your Android™ phone for hours and provides
a comfortable ergonomic design with the
protection of a hard shell case.
Here's a rundown of why the juice pack air
is so fantastic:
1. (Take a breath) Ergonomic, form-fitting, fully
protective ultra-impact-resistant case-and-
battery-in-one for your Android™ phone.
2. Integrated power switch allows you to put
the juice pack into standby mode. Only use the
battery when you need it. In standby mode
(red), the juice pack still allows charge and sync
capabilities through the micro-USB port and
offers the complete protection of a case.
3. Uses breakthrough rechargeable lithium
polymer battery. (Much safer than those
troublesome lithium-Ion batteries).
4. State-of-the-art battery technology extends
the life of your Android™ phone for hours... and
you can even recharge it while it's still connected
to the phone! This battery rocks.
5. Track battery power status at a glance with
an integrated 4-light LED status indicator which
shows charging mode and current battery life.
Know before you go!
6. It's the included USB micro cable connection
that allows you to charge and sync your phone
while refilling your juice pack at the same time.
Really, you don't ever have to disconnect the
juice pack, though it's a snap when you do.
7. Rechargeable for over 500 cycles. (These are
FULL cycles. Partial cycles don't count as full. So,
you can charge your juice pack 10% of the way
ten times before you get to a complete cycle.
Don't be afraid to top it off.)
mophie juice pack Printable Manual
Made for the Samsung Galaxy
®
8. Smart battery technology actually instructs
the phone to drain out the juice pack first. When
you're done with the juice pack you can pull it
off and still have a fully charged phone.
9. The juice pack offers complete protection
from top to bottom. No more choosing between
protection and power.
10. Built-in short circuit, over-charge and
temperature protection. Safety First!
Compatibility
Though the juice pack for Samsung Galaxy SIII
comes with a standard micro USB connector, this
battery is intended solely for use with the Galaxy
SIII phone. Please do not attempt to use the
product with any other device - things could go
haywire, but contact us if they do.
Charging your juice pack
Connect the juice pack to a power source using
only the micro USB cable that came with your
juice pack. The USB cable can be plugged in
to your computer or any wall-plug style power
source with USB out including the standard USB
wall adaptor included with your phone. (The
LEDs located on the back of the device will blink
when charging, as the juice pack becomes more
charged the LEDs will indicate how full it is, but
one LED will remain blinking until completely
full.)
Important
The juice pack comes charged and ready to go,
but after the initial use, normal charging will
take only 2 to 3 hours for maximum power –
AND you can then charge it while the phone is
inserted or separated.
Charging your phone using the juice pack
If your phone is drained of power or if you want
to extend the battery life of your phone, simply
slide the phone into the juice pack. Make sure
that the connector is securely inserted into the
top of the phone and the switch is turned "On"
(green). When the phone recognizes the juice
pack, a battery symbol will appear on the screen
and you will hear a chirp from the phone; this
indicates that the phone is charging and/or
using the power from the juice pack rather than
from the phone itself.
If your phone is drained of power, the juice pack
will first charge your phone. If your phone is fully
charged, the juice pack will act as your primary
®
S III – User Manual
battery and no power will be lost from the
phone's internal battery until the juice pack is
depleted. So you keep on talkin' , rockin' , surfin'
and sendin'!
Checking the status of the juice pack
You are always in the KNOW! To check the
battery status of the juice pack, press the
button located on the back of the device.
When pressed, the LED lights will illuminate
for several seconds. Four LEDs means that the
juice pack is fully charged, and one LED means
that it is almost empty.
Switching your juice pack to standby mode
If you'd rather use your internal battery and
not the juice pack, use the switch on back of
the juice pack, to put it into standby mode. The
dot near the switch will indicate whether the
juice pack is in standby mode (red) or charging
mode (green). When your internal battery
is low, simply flick the switch "On" and your
phone will begin charging immediately.
*Note: Using the standby switch will give you
even more total battery life, as the phone uses
additional power to be on a constant charge.
Sync with your computer without removing
the juice pack
While connected to the juice pack, you can
still sync your phone with a computer. Simply
connect the included micro USB cable from
the juice pack to the computer and sync your
phone the same as if it was directly connected.
To keep your juice pack operating to its
fullest potential, make sure to do the
following:
1.
Keep your juice pack dry and away from
moisture and corrosive materials.
2. Do not wash the juice pack with harsh
chemicals, soaps or detergents. Just wipe the
case with a soft, water-dampened cloth. Wipe
the pins gently with a soft, dry cloth.
3.
Re-charge your juice pack once every three
months when not in use, and remember to
charge it for one hour before putting it away
the first time.
© mophie 2012 – 2013 www.mophie.com
