Page 1 Administrator’s Handbook ® Motorola Netopia Embedded Software Version 7.8.4 Motorola Netopia ® 2200, 3300 and 7000 Series Routers Residential models May 2009...
Page 2 (such as translation, transformation or adaptation) without written permission from Motorola, Inc. Motorola reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of Motorola to provide notification of such revision or change. Motorola provides this guide without warranty of any kind, either implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
Page 3: Table Of Contents
Table of Contents Table of Contents ® Setting up Your Motorola Netopia Gateway ..7 CHAPTER 1 What’s New in 7.8.4 ........7 Important Safety Instructions .
Page 4 Administrator’s Handbook Expert Mode ..........55 CHAPTER 3 Home Page - Expert Mode .
Page 5 Table of Contents Command Line Interface ....... 123 CHAPTER 5 Overview .
Page 6 Administrator’s Handbook Technical Specifications and Safety Information ..239 CHAPTER 6 Description ........239 Power requirements .
Page 7: Setting Up Your Motorola Netopia
Most users will ﬁnd that the basic Quickstart conﬁguration is all that they ever need to use. This sec- ® tion may be all that you ever need to conﬁgure and use your Motorola Netopia Gateway. The following instructions cover installation in Router Mode .
Page 8: Important Safety Instructions
Administrator’s Handbook Important Safety Instructions POWER SUPPLY INSTALLATION ® Connect the power supply cord to the power jack on the Motorola Netopia Gateway. Plug the power supply into an appropriate electrical outlet. ☛ CAUTION: Depending on the power supply provided with the product, either the direct plug-in power supply blades, power supply cord plug or the appliance coupler serves as the mains power disconnect.
Page 9: Wichtige Sicherheitshinweise
Wichtige Sicherheitshinweise NETZTEIL INSTALLIEREN ® Verbinden Sie das Kabel vom Netzteil mit dem Power-Anschluss an dem Motorola Netopia Gateway. Stecken Sie dann das Netzteil in eine Netzsteckdose. ☛ Achtung: Abhängig von dem mit dem Produkt gelieferten Netzteil, entweder die direkten Stecker- netzgeräte, Stecker vom Netzkabel oder der Gerätekoppler dienen als Hauptspannung-...
Page 10: Set Up Your Gateway
Set up your Gateway ® Refer to your User Manual for instructions on how to connect your Motorola Netopia Gateway to your power source, PC or local area network, and your Internet access point, whether it is a dedicated DSL ®...
Page 11: Configure Your Pc For Dynamic Addressing
Select Obtain an IP address automatically . Select Obtain DNS server address automatically , if available. Remove any previously conﬁgured gateways, if applicable. Click the OK button. Restart if prompted. Proceed to the next section “Motorola Netopia® Gateway Quickstart” on page...
Page 12 Administrator’s Handbook c. Windows Vista is set to obtain an IP address automatically by default. You may not need to conﬁgure it at all. To check, open the Networking Control Panel and select Internet Protocol Version 4 (TCP/IPv4). Click the Properties button. The Internet Protocol Version 4 (TCP/IPv4) Properties window should appear as shown.
Page 13 Menu -> follows a path System Prefer- like this: ences -> Network Then go to Step 2. Select Built-in Ethernet Select Conﬁgure Using DHCP Close and Save, if prompted. Proceed to the next section “Motorola Netopia® Gateway Quickstart” on page...
Page 14: Motorola Netopia Gateway Quickstart
Italiano Select your language from the pull-down menu and click Next. The browser displays the Welcome page. For security, you must create and enter an Administrative password for accessing the Motorola Neto- ® Gateway. • The administrative User name is admin.
Page 15 This user name and password are separate from the user name and password you will use to access the Internet. You may change them later. You will be challenged for this Admin username and ® password any time that you attempt to access the Motorola Netopia Gateway’s conﬁguration pages.
Page 16 URL in your browser’s location box or by selecting one of your favorite Internet bookmarks. Optional services that you may have contracted with your provider are also available. ® If you have any questions or encounter problems with your Motorola Netopia Gateway, refer to “Basic Troubleshooting”...
Page 17: Chapter 2 Basic Mode Features
CHAPTER 2 Basic Mode Features ® Using the Web-based user interface for the Motorola Netopia Gateway you can conﬁgure, trouble- shoot, and monitor the status of your Gateway. ◆ “The Home Page” on page 18 ◆ “Links Bar” on page 20 ◆...
Page 18: The Home Page
Administrator’s Handbook The Home Page Home Page for a PPPoE Connection Home Page Information The Home page displays information about the following categories: ◆ Connection Information ◆ (supported VoIP models only) Telephone Information ◆ Router Information ◆ Local Network Language Selection Buttons Language Selection Buttons are located at the top of every page.
Page 19 connection. For a DHCP connection, clicking this button will release and renew the DHCP lease from your service provider’s DHCP server, which assigns your local WAN IP address. ◆ Connect – Only displays if you are not connected. For a PPPoE connection, clicking this button will allow you to attempt to login using a different User ID and Password.
Page 20: Links Bar
Administrator’s Handbook Links Bar The links in the left-hand column of the Home page access a series of pages to allow you to monitor, diagnose, and update your Gateway. The following sections give brief descriptions of these pages. ◆“The Home Page” on page 18 ◆“Firewall”...
Page 21: Firewall
Firewall Firewall When you click the link, the Firewall selection page appears. In addition to the recommended Medium setting, for special circumstances, High and Low levels of ﬁrewall protection are available. You can also turn all ﬁrewall protection Off. Consider your security needs carefully before making any changes here. Save Changes If you select a different level of ﬁrewall protection, click the button.
Page 22 IP standard), hackers can identify an existing device and gain a potential opening for access to an internet-connected device. ® To protect LAN users and their network from these types of attacks, the Motorola Netopia Firewall offers three levels of increasing protection.
Page 23 This table shows how outbound trafﬁc is treated. Outbound means the trafﬁc is coming from the LAN- side computers into the LAN side of the Gateway. Gateway: LAN Side Firewall Setting >> High Low/Medium Port Session Type --------------Port State----------------------- ftp data Enabled Enabled Disabled...
Page 24: Wireless Protected Setup
Administrator’s Handbook Wireless Protected Setup Wireless Protected Setup When you click the link in the left-hand links bar, the Wireless Protected Setup conﬁguration page appears. Wireless Protected Setup (WPS) is a not a new security protocol. It is simply an easier way to use existing protocols to provide greater security for your wireless network connections.
Page 25 Start Make sure your wireless client is running and ready for WPS conﬁguration. Click the button on the webpage to begin the exchange, which may last up to two minutes, then continue the WPS push- button (PBC) installation on the client. Do not power off your Router during the exchange.
Page 26: Wireless
Administrator’s Handbook Wireless (supported models) Wireless , the Wireless LAN Settings conﬁguration page appears. When you click Enable Wireless The wireless function is automatically enabled by default. If you uncheck the Enable Wireless check- box, the Wireless Options are disabled, and the Gateway will not provide or broadcast its wireless LAN services.
Page 27: Enable Wireless Scheduler
Enable Wireless Scheduler If you check the Enable Wireless Scheduler checkbox, the screen expands to allow you to set times of day when the wireless radio will turn off and on. This makes it possible to control your wireless LAN’s hours of operation automatically.
Page 28: Advanced Configuration Options (Optional)
Administrator’s Handbook Advanced Conﬁguration Options (optional) Advanced Conﬁguration Options button, the Advanced wireless LAN set- When you click the tings screen appears. This screen varies its options depending on which form of wireless Privacy you have selected. Operating Mode The pull-down menu allows you to select and lock the Gateway into the wireless transmission mode you want.
Page 29 ◆ At Startup – the default setting – causes the Motorola Netopia® Gateway at startup to brieﬂy initial- ize on the default channel, then perform a full two- to three-second scan, and switch to the best channel it can ﬁnd, remaining on that channel until the next reboot.
Page 30 Administrator’s Handbook Wireless client cards from different manufacturers and different operating systems accomplish con- necting to a wireless LAN and enabling WEP or WPA in a variety of ways. Consult the documentation for your particular wireless card and/or operating system. Block Wireless Bridging Check the checkbox to block wireless clients from communicating with other wireless clients on the LAN side of the Gateway.
Page 31 (RADIUS) server. In conjunction with Wireless User Authentication, you can use a RADIUS server data- base to authenticate users seeking access to the wireless services, as well as the authorized user list maintained locally within the Gateway. If you select WPA-802.1x, the screen expands. Conﬁgure RADIUS Server Click the button.
Page 32 Administrator’s Handbook WPA-PSK One of the easiest ways to enable Privacy on your Wireless network is by selecting WPA-PSK (Wi-Fi Protected Access) from the pull-down menu. The screen expands to allow you to enter a Pre Shared Key. The key can be between 8 and 63 charac- ters, but for best security it should be at least 20 characters.
Page 33 WEP-Manual Alternatively, you can enable WEP (Wired Equivalent Privacy) encryption by selecting WEP-Manual from the Privacy pull-down menu. You can provide a level of data security by enabling WEP (Wired Equivalent Privacy) for encryption of net- work data. You can enable 40-, 128-, or 256-bit WEP Encryption (depending on the capability of your cli- ent wireless card) for IP trafﬁc on your LAN.
Page 34 Administrator’s Handbook Examples: ◆ 40bit: 02468ACE02 ◆ 128bit: 0123456789ABCDEF0123456789 ◆ 256bit: 592CA140F0A238B0C61AE162F592CA140F0A238B0C61AE162F21A09C Use WEP encryption key (1 – 4) #: Speciﬁes which key the Gateway will use to encrypt transmitted trafﬁc. The default is key #1. Save Changes Click the click button.
Page 35 WEP-Automatic Alternatively, you can enable WEP (Wired Equivalent Privacy) encryption by selecting WEP-Automatic from the Privacy pull-down menu. You can provide a level of data security by enabling WEP (Wired Equivalent Privacy) for encryption of net- work data. You can enable 40-, 128-, or 256-bit WEP Encryption (depending on the capability of your cli- ent wireless card) for IP trafﬁc on your LAN.
Page 36 Administrator’s Handbook Enable Multiple Wireless IDs This feature allows you to add additional network identiﬁers (SSIDs or Network Names) for your wireless network. To enable Multiple Wireless IDs, click the button. The Enable Multiple Wireless IDs screen appears to allow you to add up to three additional Wireless IDs.
Page 37 ◆ You also have the choice of applying WPA Version 1 and 2, WPA Version 1 Only, or WPA Version 2 Only from the pull-down menu. These can be applied to each SSID individually. ◆ If you choose WPA-802.1x privacy, the Conﬁgure RADIUS Server option appears, to allow you to specify your RADIUS server information.
Page 38 Administrator’s Handbook You do this in the same manner as you do to authorize MAC addresses for the primary SSID. See “Wireless MAC Authorization (optional)” on page Save Changes Click the button. The Gateway will prompt you to restart it. Click the button, and the Gateway will restart with your new settings.
Page 39: Wifi Multimedia
WiFi Multimedia WiFi Multimedia is an advanced feature that allows you to prioritize various types of data travelling over the wireless network. Certain types of data that are sensitive to delays, such as voice or video, must be prioritized ahead of other, less delay-sensitive types, such as email. WiFi Multimedia currently implements wireless Quality of Service (QoS) by transmitting data depending on Diffserv priority settings.
Page 40 Administrator’s Handbook The screen expands. Router EDCA Parameters (Enhanced Distributed Channel Access) govern wireless data from your Gateway to the client; Client EDCA Parameters govern wireless data from the client to your Gateway. ☛ NOTE: It is not recommended that you modify these settings without direct knowledge or instruc- tions to do so.
Page 41: Wireless Mac Authorization (Optional)
Wireless MAC Authorization (optional) MAC Authorization allows you to specify which client PCs are allowed to join the wireless LAN by unique Limit Wireless Access by MAC hardware (MAC) address. To enable this feature, click the Address button. The MAC Authorization screen appears. Enabled Select from the pull-down menu.
Page 42 Administrator’s Handbook Submit Click the button. Save Changes When you are ﬁnished adding MAC addresses click the button. You will be returned to the Advanced wireless LAN settings page. You can Add, Edit, or Delete any of your entries later by returning to this page.
Page 43: Gaming
Gaming Gaming , the NAT (Games and Other Services) page appears. When you click NAT (Games and Other Services) allows you to host internet applications when NAT is enabled. You can host different games and software on different PCs. From the Service Name pull-down menu, you can select any of a large number of predeﬁned games and software.
Page 44 Administrator’s Handbook List of Supported Games and Software Act of War - Direct Action Age of Empires II Age of Empires, v.1.0 Age of Empires: The Rise of Age of Mythology Age of Wonders Rome, v.1.0 AIM Talk America's Army Apache Asheron's Call Azureus...
Page 45 Microsoft Golf 2001 Edition Midtown Madness, v 1.0 mIRC Auth-IdentD mIRC Chat mIRC DCC - IRC DCC Monster Truck Madness 2, v Monster Truck Madness, v 1.0 Motocross Madness 2, v 2.0 Motocross Madness, v 1.0 MSN Game Zone MSN Game Zone DX MSN Messenger Need for Speed 3, Hot Pursuit Need for Speed, Porsche...
Page 46 Administrator’s Handbook If you chose Port Forwarding, the Port Range entry screen appears. Port Forwarding forwards a range of WAN ports to an IP address on the LAN. Enter the following infor- mation: ◆ Service Name: A unique identiﬁer for the Custom Service. ◆...
Page 47 ◆ Direct your Gateway to forward all externally initiated IP trafﬁc (TCP and UDP protocols only) to a default host on the LAN. ◆ Enable it for certain situations: – Where you cannot anticipate what port number or packet protocol an in-bound application might use.
Page 48: Expert Mode
Administrator’s Handbook Expert Mode Expert Mode allows you to conﬁgure a wide variety of speciﬁc Gateway and networking settings. Expert Mode is for advanced users and system administrators, and most users will not need to modify these Expert Mode settings. If you need to enter Expert Mode, and click the link, you will be challenged to conﬁrm your choice.
Page 49: Troubleshoot
Troubleshoot Troubleshoot When you click the link, the Links Bar expands to offer two troubleshooting sub-headings: ◆“Diagnostics” on page 50 ◆“Statistics” on page 51...
Page 50: Diagnostics
Administrator’s Handbook Diagnostics This automated multi-layer test examines the functionality of the Gateway from the physical connec- tions to the data trafﬁc being sent by users through the Gateway. Test You enter a web address URL or an IP address in the Web Address ﬁeld and click the button.
Page 51: Statistics
Statistics Statistics When you click in the left hand column of links, the links bar expands to display six statisti- cal sub-headings: ◆“DSL” on page 51 ◆“ATM” on page 52 ◆“Ethernet” on page 52 ◆“IP” on page 52 ◆“LAN” on page 52 ◆“Wireless”...
Page 52: Atm
Administrator’s Handbook When you click , the ATM Statistics page appears. The ATM Statistics page: ◆ displays your Gateway's unique hardware (MAC) address. ◆ displays detailed statistics about your WAN data trafﬁc, upstream and downstream. This information is useful for troubleshooting and when seeking technical support. Ethernet Ethernet When you click...
Page 53: Wireless
Some browsers, such as Internet Explorer for Windows XP, require that you specify the ® Motorola Netopia Gateway’s URL as a “Trusted site” in “Internet Options: Security”. This is necessary to allow the “download” of the log text ﬁle to the PC.
Page 54: Help
Administrator’s Handbook Help Help Click the link in the left-hand column of links to display a page of explanatory information. Help is available for every page in the Web interface. Here is an example:...
Page 55: Chapter 3 Expert Mode
CHAPTER 3 Expert Mode ® Using the Expert Mode Web-based user interface for the Motorola Netopia Gateway you can conﬁgure, troubleshoot, and monitor the status of your Gateway. This section covers the following topics: ◆ “Home Page - Expert Mode” on page 56 ◆...
Page 56: Home Page - Expert Mode
Administrator’s Handbook Home Page - Expert Mode ® The Home Page is the summary page for your Motorola Netopia Gateway. The toolbar on the left side provides links to controlling, conﬁguring, and monitoring pages. Critical conﬁguration and operational status is displayed in the center section.
Page 57 Supported languages in the Americas are Latin American Spanish, Brazilian Portuguese, and English. More Buttons ◆ Restart Connection – For a PPPoE connection, clicking this button will bring down any PPPoE WAN connection that is up and resend your current PPPoE login credentials and reestablish your Internet connection.
Page 58: Help
Administrator’s Handbook Help Click the Help link in the left-hand column of links to display a page of explanatory information. Help is available for every page in the Web interface. Here is an example:...
Page 59: Links Bar
Links Bar The Links Bar is the frame at the left-hand side of the page containing the major navigation links. These links are available from almost every page, allowing you to move freely about the site. The headings in the following table are hyperlinks. You can click on any heading to read about that feature. Home Conﬁgure Connection...
Page 60: Configure
Administrator’s Handbook Conﬁgure When you click Conﬁgure in the left hand column of links, the links bar expands. ◆“Connection” on page 61 ◆“LAN/WAN” on page 63 ◆“DHCP Server” on page 64 ◆“IP Passthrough” on page 66 ◆“NAT” on page 67 ◆“Router Password”...
Page 61: Connection
Connection When you click Connection, the Connection Conﬁguration page appears. This screen’s appearance will vary depending on your type of connection to the Internet. Here is an example. Here you can set up or change the way you connect to your ISP. You should only change these settings at your ISP's direction, or by agreement with your ISP.
Page 62 Gateway automatically in the “My Network Places” folder. Double-clicking this icon opens the Gateway’s web UI. PCs using UPnP can retrieve the Gateway’s WAN IP address, and automatically create NAT port maps. This means that applications that support UPnP, and are used with a UPnP-enabled Motorola ® ®...
Page 63: Lan/Wan
LAN/WAN The LAN/WAN Turnaround feature allows Ethernet port 4 to be used as the WAN interface. ◆ When you click the Enable button, the DSL interface is disabled. ◆ Disable When you click the button, the Ethernet port 4 and the DSL interface function normally.
Page 64: Dhcp Server
Administrator’s Handbook DHCP Server When you click DHCP Server, the DHCP Server Conﬁguration page appears. The Server conﬁguration determines the functionality of your DHCP Settings. This functionality enables the Gateway to assign your LAN computer(s) a “private” IP address and other parameters that allow network communication.
Page 65 The IP Subnets screen allows you to conﬁgure up to seven secondary subnets and their DHCP ranges, by entering IP address/subnet mask pairs: ☛ Note: You need not use this screen if you have only a single Ethernet IP subnet. This screen displays seven rows of editable columns.
Page 66: Ip Passthrough
Administrator’s Handbook IP Passthrough When you click Passthrough, the IP Passthrough Conﬁguration page appears. The IP passthrough feature allows a single PC on the LAN to have the Gateway’s public address assigned to it. It also provides PAT (NAPT) via the same public IP address for all other hosts on the pri- vate LAN subnet.
Page 67: Nat
When you click NAT, the NAT (Games and Other Services) page appears. NAT Conﬁguration allows you to host internet applications when NAT is enabled. You can host different games and software on different PCs. From the Service Name pull-down menu, you can select any of a large number of predeﬁned games and software.
Page 68 Administrator’s Handbook List of Supported Games and Software Act of War - Direct Action Age of Empires II Age of Empires, v.1.0 Age of Empires: The Rise of Age of Mythology Age of Wonders Rome, v.1.0 AIM Talk America's Army Apache Asheron's Call Azureus...
Page 69 Microsoft Golf 2001 Edition Midtown Madness, v 1.0 mIRC Auth-IdentD mIRC Chat mIRC DCC - IRC DCC Monster Truck Madness 2, v Monster Truck Madness, v 1.0 Motocross Madness 2, v 2.0 Motocross Madness, v 1.0 MSN Game Zone MSN Game Zone DX MSN Messenger Need for Speed 3, Hot Pursuit Need for Speed, Porsche...
Page 70 Administrator’s Handbook Deﬁne Custom Service To conﬁgure a Custom Service, choose whether to use Port Forwarding or Trigger Ports. ◆ Port Forwarding forwards a range of WAN ports to an IP address on the LAN. ◆ Trigger Ports forwards a range of ports to an IP address on the LAN only after speciﬁc outbound trafﬁc “triggers”...
Page 71 Trigger Ports forwards a range of ports to an IP address on the LAN only after speciﬁc outbound trafﬁc “triggers” the feature. Enter the following information: ◆ Service Name: A unique identiﬁer for the Custom Service. ◆ Global Port Range: Range of ports on which incoming trafﬁc will be received. ◆...
Page 72: Router Password
Administrator’s Handbook Router Password When you click Router Password, the Router Password page appears. Here you can change the administrative password that you use when logging onto the Gateway as admin. Passwords are case sensitive ﬁelds, and must be 1 to 32 characters long. Store your password in a safe place.
Page 73: Time Zone
Time Zone Time Zone link, the Time Zone page appears. When you click the You can set your local time zone by selecting the number of hours your time zone is distant from Green- wich Mean Time (GMT +12 – -12) from the pull-down menu. This allows you to set the time zone for gen- eral time stamp purposes.
Page 74: Vlan
(QoS). In effect, a single Motorola gateway acts as separate virtual gateways for each distinct service being delivered.
Page 75 - LAN-side VLAN with IP interface-to-VLAN binding - Inter-VLAN routing groups to extend VLAN segmentation up through the IP routing layer. ◆ Bridged VLANs - these VLANs are used to bridge trafﬁc from LAN to WAN ◆ Prioritization per VLAN and per port Ethernet Switching/Policy Setup Before you conﬁgure any VLANs, the unconﬁgured Gateway is set up as a router composed of a LAN switch, a WAN switch, and a router in the middle, with LAN and WAN IP interfaces connected to their...
Page 76 Administrator’s Handbook An example of multiple VLANs, using a Netopia Router with VGx managed switch technology, is shown below: To conﬁgure VLANs check the Enable checkbox. Edit To create a VLAN select a list item from the main VLAN page and click the button.
Page 77 You can create up to 8 VLANs, and you can also restrict any VLAN, and the computers on it, from admin- istering the Gateway. ◆ VLAN Name – A descriptive name for the VLAN. ◆ Type – LAN or WAN Port(s) can be enabled on the VLAN. You can choose a type designation as fol- lows: By-Port: indicating that the VLAN is port-based.
Page 78 Displayed port interfaces vary depending on the kinds of physical ports on your Gateway, for exam- ple, Ethernet. ® For Motorola Netopia VGx technology models, separate Ethernet switch ports are displayed and may be conﬁgured. To enable any of them on this VLAN, check the associated Enable checkbox(es).
Page 79 ◆ Submit Click the button. ◆ Conﬁgure If you want to create more VLANs, click the link (in the left-hand toolbar) and then the VLAN link, and repeat the process. You can Edit, Clear, Enable, or Disable your VLAN entries by returning to the VLANs page, and select- ing the appropriate entry from the displayed list.
Page 80 Administrator’s Handbook To view the settings for each VLAN, select the desired VLAN from the list and click the Details button. The screen expands to display the VLAN settings.
Page 81: Voip
Session Initiation Protocol (SIP), to transmit sound over a network or the Internet in the ® form of data packets. Certain Motorola Netopia Gateway models have two separate voice ports for connecting telephone handsets. These models support VoIP. If your Gateway is a VoIP model, you can conﬁgure the VoIP features.
Page 82 Administrator’s Handbook SIP Line Entry Registration Interval Length of time the VoIP registration will be valid before it will be (in secs) renewed. Default is 1 hour. Registrar Server Registration Server name or IP address. Registrar Port Registration Server port. Default is 5060. Proxy Server Proxy server name or IP address.
Page 83 SIP Line Entry Digit Map A set of rules used to recognize a number dialed by the user and to ensure this number matches the dial plan deﬁned by the ITSP. Call Features Settings DTMF Mode Choose the Dual Tone Multi-Frequency Mode: •...
Page 84 Administrator’s Handbook The Home page for a VoIP-enabled Gateway with both phone lines registered is shown below.
Page 85: Wireless
Wireless (supported models) Wireless , the Wireless LAN Settings conﬁguration page appears. When you click Enable Wireless The wireless function is automatically enabled by default. If you uncheck the Enable Wireless check- box, the Wireless Options are disabled, and the Gateway will not provide or broadcast its wireless LAN services.
Page 86: Enable Wireless Scheduler
Administrator’s Handbook Enable Wireless Scheduler If you check the Enable Wireless Scheduler checkbox, the screen expands to allow you to set times of day when the wireless radio will turn off and on. This makes it possible to control your wireless LAN’s hours of operation automatically.
Page 87: Advanced Configuration Options (Optional)
Advanced Conﬁguration Options (optional) Advanced Conﬁguration Options button, the Advanced Wireless LAN set- When you click the tings screen appears. This screen varies its options depending on which form of wireless Privacy you have selected. Operating Mode The pull-down menu allows you to select and lock the Gateway into the wireless transmission mode you want.
Page 88 Motorola Netopia Router. ® In addition, if you have enabled WEP or WPA encryption on the Motorola Netopia Router, your network clients must also have WEP or WPA encryption enabled, and must have the same WEP or WPA encryp- ®...
Page 89 Wireless client cards from different manufacturers and different operating systems accomplish con- necting to a wireless LAN and enabling WEP or WPA in a variety of ways. Consult the documentation for your particular wireless card and/or operating system. Block Wireless Bridging Check the checkbox to block wireless clients from communicating with other wireless clients on the LAN side of the Gateway.
Page 90 Administrator’s Handbook RADIUS Server authentication RADIUS servers allow external authentication of users by means of a remote authentication database. The remote authentication database is maintained by a Remote Authentication Dial-In User Service (RADIUS) server. In conjunction with Wireless User Authentication, you can use a RADIUS server data- base to authenticate users seeking access to the wireless services, as well as the authorized user list maintained locally within the Gateway.
Page 91 WPA-PSK One of the easiest ways to enable Privacy on your Wireless network is by selecting WPA-PSK (Wi-Fi Protected Access) from the pull-down menu. The screen expands to allow you to enter a Pre Shared Key. The key can be between 8 and 63 charac- ters, but for best security it should be at least 20 characters.
Page 92 Administrator’s Handbook WEP-Manual Alternatively, you can enable WEP (Wired Equivalent Privacy) encryption by selecting WEP-Manual from the Privacy pull-down menu. You can provide a level of data security by enabling WEP (Wired Equivalent Privacy) for encryption of net- work data. You can enable 40-, 128-, or 256-bit WEP Encryption (depending on the capability of your cli- ent wireless card) for IP trafﬁc on your LAN.
Page 93 Examples: ◆ 40bit: 02468ACE02 ◆ 128bit: 0123456789ABCDEF0123456789 ◆ 256bit: 592CA140F0A238B0C61AE162F592CA140F0A238B0C61AE162F21A09C Use WEP encryption key (1 – 4) #: Speciﬁes which key the Gateway will use to encrypt transmitted trafﬁc. The default is key #1. Save Changes Click the click button. Any WEP-enabled client must have an identical key of the same length as the Router, in order to suc- cessfully receive and decrypt the trafﬁc.
Page 94 Administrator’s Handbook WEP-Automatic Alternatively, you can enable WEP (Wired Equivalent Privacy) encryption by selecting WEP-Automatic from the Privacy pull-down menu. You can provide a level of data security by enabling WEP (Wired Equivalent Privacy) for encryption of net- work data. You can enable 40-, 128-, or 256-bit WEP Encryption (depending on the capability of your cli- ent wireless card) for IP trafﬁc on your LAN.
Page 95 Enable Multiple Wireless IDs This feature allows you to add additional network identiﬁers (SSIDs or Network Names) for your wireless network. To enable Multiple Wireless IDs, click the button. The Enable Multiple Wireless IDs screen appears to allow you to add up to three additional Wireless IDs.
Page 96 Administrator’s Handbook ◆ You also have the choice of applying WPA Version 1 and 2, WPA Version 1 Only, or WPA Version 2 Only from the pull-down menu. These can be applied to each SSID individually. ◆ If you choose WPA-802.1x privacy, the Conﬁgure RADIUS Server option appears, to allow you to specify your RADIUS server information.
Page 97 You do this in the same manner as you do to authorize MAC addresses for the primary SSID. See “Wireless MAC Authorization (optional)” on page 100. Save Changes Click the button. The Gateway will prompt you to restart it. Click the button, and the Gateway will restart with your new settings.
Page 98: Wifi Multimedia
Administrator’s Handbook WiFi Multimedia WiFi Multimedia is an advanced feature that allows you to prioritize various types of data travelling over the wireless network. Certain types of data that are sensitive to delays, such as voice or video, must be prioritized ahead of other, less delay-sensitive types, such as email.
Page 99 The screen expands. Router EDCA Parameters (Enhanced Distributed Channel Access) govern wireless data from your Gateway to the client; Client EDCA Parameters govern wireless data from the client to your Gateway. ☛ NOTE: It is not recommended that you modify these settings without direct knowledge or instruc- tions to do so.
Page 100: Wireless Mac Authorization (Optional)
Administrator’s Handbook Wireless MAC Authorization (optional) MAC Authorization allows you to specify which client PCs are allowed to join the wireless LAN by unique Limit Wireless Access by MAC hardware (MAC) address. To enable this feature, click the Address button. The MAC Authorization screen appears. Enabled Select from the pull-down menu.
Page 101 Submit Click the button. Save Changes When you are ﬁnished adding MAC addresses click the button. You will be returned to the 802.11 Wireless page. You can Add, Edit, or Delete any of your entries later by returning to this page.
Page 102: Statistics
Administrator’s Handbook Statistics When you click Statistics in the left hand column of links, the links bar expands. ☛ Note: Available Statistics links vary by platform. When you click DSL, the DSL Statistics page appears. The DSL Statistics page displays information about the Gateway's WAN connection to the Internet. ◆...
Page 103: Ethernet
The ATM Statistics page: ◆ displays detailed statistics about your WAN data trafﬁc, upstream and downstream. ◆ displays the Server MAC address for the PPPoE session (if applicable) This information is useful for troubleshooting and when seeking technical support. Ethernet When you click Ethernet, the Ethernet Statistics page appears.
Page 104: Wireless
Some browsers, such as Internet Explorer for Windows XP, require that you specify the ® Motorola Netopia Gateway’s URL as a “Trusted site” in “Internet Options: Security”. This is necessary to allow the “download” of the log text ﬁle to the PC.
Page 105: Diagnostics
Diagnostics When you click Diagnostics, the Diagnostics page appears. This automated multi-layer test examines the functionality of the Gateway from the physical connec- tions to the data trafﬁc being sent by users through the Gateway. You enter a web address URL in the Web Address ﬁeld and click the Test button.
Page 106: Remote Access
This link allows you to authorize a remotely-located person, such as a support technician, to directly ® access your Motorola Netopia Gateway. This is useful for ﬁxing conﬁguration problems when you need expert help. You can limit the amount of time such a person will have access to your Gateway. This will prevent unauthorized individuals from gaining access after the time limit has expired.
Page 107: Update Router
Update Router Update Router, the Software Upgrade page appears. When you click Operating System Software is what makes your Gateway run and occasionally it needs to be updated. Your Current Software Version is displayed at the top of the page. Check Software from Server If you want to check for an updated version without installing it, click the link.
Page 108: Reset Router
Administrator’s Handbook Reset Router You might need to reset your Gateway to its factory default state, and clear all of your previous settings. Reset Router link allows you to do that. When you click the link, you will be challenged to conﬁrm that this is what you want to do.
Page 109: Restart Router
Restart Router When the Gateway is restarted, it will disconnect all users, initialize all its interfaces, and copy the Operating System Software from its internal storage. When you make conﬁguration changes, you must restart for the changes to take effect.
Page 110: Basic Mode
Administrator’s Handbook Basic Mode When you click Basic Mode, you are returned immediately to the Basic Mode Home page...
Page 111: Chapter 4 Basic Troubleshooting
CHAPTER 4 Basic Troubleshooting This section gives some simple suggestions for troubleshooting problems with your Gateway’s initial conﬁguration. Before troubleshooting, make sure you have ◆ read the User Manual; ◆ plugged in all the necessary cables; and ◆ set your PC’s TCP/IP controls to obtain an IP address automatically.
Page 112: Status Indicator Lights
The ﬁrst step in troubleshooting is to check the status indicator lights (LEDs) in the order outlined in the following section. The ﬁrst step in troubleshooting is to check the status indicator lights (LEDs) in the order outlined below. Motorola Netopia® Router 2210 status indicator lights Power Ethernet Internet...
Page 113 Motorola Netopia® Router 2240N/2241N status indicator lights Power Ethernet Internet Action Green when power is on. if device malfunctions. Flashes Power when new embedded software is being installed. Solid green when connected. Flash green when there is activity on the Ethernet LAN.
Page 114 Administrator’s Handbook Motorola Netopia® Router 2246N status indicator lights Power Ethernet 1, 2, 3, 4 Internet Action Green when power is on. if device malfunctions. Flashes Power when new embedded software is being installed. Solid green when connected. Flash green...
Page 115 Motorola Netopia® Router 2247NWG status indicator lights Power Ethernet 1, 2, 3, 4 Wireless Internet Action Green when power is on. if device malfunctions. Flashes Power when new embedded software is being installed. Solid green when connected. Flash green when there is activity on the Ethernet 1, 2, 3, 4 LAN.
Page 116 Administrator’s Handbook Motorola Netopia® Router 2247-42 VoIP model status indicator lights Power Internet Ethernet 1, 2, 3, 4 Wireless Line Phone 1, Phone 2 Action Green when power is on. if device malfunctions. Flashes Power when new embedded software is being installed.
Page 117 Motorola Netopia® Router 3347-02 status indicator lights Wireless Ethernet 1, 2, 3, 4 Internet Power Action Green when power is on. when updating embedded Power software, or for system failure. Solid green when Internet connection is established. Solid green when Gateway is connected. Flashes...
Page 118 Administrator’s Handbook Motorola Netopia® Router 7000-series status indicator lights Power Ethernet 1, 2, 3, 4 Wireless Internet Action Green when power is on. if device malfunctions. Flashes Power when new embedded software is being installed. Solid green when connected. Flash...
Page 119 Motorola Netopia® Router 7346/56-series status indicator lights Power Ethernet 1, 2, 3, 4 Action Green when power is on. if device malfunctions. Flashes Power when new embedded software is being installed. Solid green when connected. Flash green when there is activity on the Ethernet 1, 2, 3, 4 LAN.
Page 120: Led Function Summary Matrix
Administrator’s Handbook LED Function Summary Matrix Flashing Unlit Solid Green Solid Red Flashing Red Green No power Power on System failure Installing new Power embedded software No signal USB port con- Activity on the USB Active nected to PC USB cable No signal DSL line synched Attempting to...
Page 121 Make sure you have Ethernet drivers installed on the PC. Make sure the PC’s TCP/IP Properties for the Ethernet Network Control Panel is set to obtain an IP address via DHCP. Make sure the PC has obtained an address in the 192.168.1.x range. (You may have EN Trafﬁc Unlit changed the subnet addressing.)
Page 122: Factory Reset Switch
Keep in mind that all of your settings will need to be reconﬁgured. If you don't have a password, the only way to access the Motorola Netopia® Router is the following: Referring to the following diagram, ﬁnd the round Reset Switch opening.
Page 123: Command Line Interface
The Motorola Netopia® Gateway operating software includes a command line interface (CLI) that lets you access your Motorola Netopia® Gateway over a telnet connection. You can use the command line interface to enter and update the unit’s conﬁguration settings, monitor its performance, and restart it.
Page 124 Administrator’s Handbook CONFIG Commands “Remote ATA Conﬁguration Commands” on “PPPoE with IPoE Settings” on page 183 page 144 “DSL Commands” on page 146 “Ethernet Port Settings” on page 184 “Bridging Settings” on page 147 “802.3ah Ethernet OAM Settings” on page 185 “DHCP Settings”...
Page 125: Overview
Overview The CLI has two major command modes: SHELL and CONFIG. Summary tables that list the com- mands are provided below. Details of the entire command set follow in this section. SHELL Commands Command Status and/or Description to send ARP request atmping to send ATM OAM loopback clear...
Page 126 Administrator’s Handbook CONFIG Commands Command Verbs Status and/or Description delete Delete conﬁguration list data help Help command option save Save conﬁguration data script Print conﬁguration data Set conﬁguration data validate Validate conﬁguration settings view View conﬁguration data Keywords ATA remote conﬁg options ATM options (DSL only) backup Backup gateway options...
Page 127: Starting And Ending A Cli Session
NCSA Telnet. telnet <ip_address> You must know the IP address of the Motorola Netopia® Gateway before you can make a telnet connec- tion to it. By default, your Motorola Netopia® Gateway uses 192.168.1.254 as the IP address for its LAN interface.
Page 128: About Shell Commands
SHELL Prompt When you are in SHELL mode, the CLI prompt is the name of the Motorola Netopia® Gateway followed by a right angle bracket (>). For example, if you open a CLI connection to the Motorola Netopia® Gate- Netopia-3000/9437188>...
Page 129: Shell Commands
Sends an Address Resolution Protocol (ARP) request to match the nnn.nnn.nnn.nnn IP address to an Ethernet hardware address. clear [yes] Clears the conﬁguration settings in a Motorola Netopia® Gateway. You are prompted to conﬁrm the clear command by entering yes. clear_certiﬁcate Removes an SSL certiﬁcate that has been installed.
Page 130 Adds the message in the message_string argument to the Motorola Netopia® Gateway diagnostic log. loglevel [ level ] Displays or modiﬁes the types of log messages you want the Motorola Netopia® Gateway to record. If you enter the loglevel command without the optional level argument, the command line interface displays the current log level setting.
Page 131: Reset Arp
DNS information. ping [-s size ] [-c count ] [ hostname | ip_address ] Causes the Motorola Netopia® Gateway to issue a series of ICMP Echo requests for the device with the speciﬁed name or IP address. ◆...
Page 132: Reset Wan
Restarts the heartbeat sequence. reset ipmap Clears the IPMap table (NAT). reset log Rewinds the diagnostic log display to the top of the existing Motorola Netopia® Gateway diagnostic log. reset log command does not clear the diagnostic log. The next show log command will display information from the beginning of the log ﬁle.
Page 133 [ seconds ] Restarts your Motorola Netopia® Gateway. If you include the optional seconds argument, your Motor- ola Netopia® Gateway will restart when the speciﬁed number of seconds have elapsed. You must enter the complete restart command to initiate a restart.
Page 134: Show Diffserv
Administrator’s Handbook show diffserv Displays the Differentiated Services and QoS values conﬁgured in the Motorola Netopia® Gateway. show dslf device-association Displays LAN devices that conform with the TR111 Gateway requirement. It displays - IP Address, Man- ufacture OUI and Serial number.
Page 135: Show Features
“IGMP Settings” on page 158 for detailed explanation. show ip arp Displays the Ethernet address resolution table stored in your Motorola Netopia® Gateway. show ip igmp Displays the contents of the IGMP Group Address table and the IGMP Report table maintained by your Motorola Netopia®...
Page 136: Show Log
Displays the current status of a Motorola Netopia® Gateway, the device's hardware and software revi- sion levels, a summary of errors encountered, and the length of time the Motorola Netopia® Gateway has been running since it was last restarted. Identical to the status command.
Page 137 Example: show vlan Displaying vlan segment interfaces ==== vlan mode ==== ==== segment 0 port masks ==== PortPort : 00000000-00000000 GlobalPort : 00000000-00000000 SumPort : 00000000-00000000 ==== segment 1 port masks ==== PortPort : 00001006-00000001 GlobalPort : 00000000-00000000 SumPort : 00001006-00000001 ==== segment 2 port masks ==== PortPort : 0000003c-00000000...
Page 138 Administrator’s Handbook SwitchMask : 00000004 WirelessMask : 00001000 ==== vlan active link ==== namePtr : eth-lan-uplink portType : 1 portIndex : 1 ifId : 45 ==== vlan active link ==== namePtr : ethernet0/0 portType : 3 portIndex : 2 ifId : 46 ==== vlan active link ==== namePtr...
Page 139 Traces the routing path to an IP destination. upload [ server_address ] [ ﬁlename ] [conﬁrm] Copies the current conﬁguration settings of the Motorola Netopia® Gateway to a TFTP (Trivial File Trans- fer Protocol) server. The TFTP server must be accessible on your Ethernet network. The server_address argument identiﬁes the IP address of the TFTP server on which you want to store...
Page 140: Wan Commands
Use the end-to-end argument to ping a remote end node. reset dhcp client release [ vcc-id ] ® Releases the DHCP lease the Motorola Netopia Gateway is currently using to acquire the IP settings for the speciﬁed DSL port. The vcc-id identiﬁer is an “index”...
Page 141: About Config Commands
) at the CLI SHELL prompt. CONFIG Mode Prompt When you are in CONFIG mode, the CLI prompt consists of the name of the Motorola Netopia® Gateway followed by your current node in the hierarchy and two right angle brackets (>>). For example, when you conﬁg...
Page 142: Guidelines: Config Commands
Enter IP addresses in dotted decimal notation (0 to 255). If a command is ambiguous or miskeyed, the CLI prompts you to enter additional information. For exam- ple, you must specify which virtual circuit you are conﬁguring when you are setting up a Motorola Neto- pia® Gateway.
Page 143: Validating Your Configuration
Error: Subnet mask is incorrect Global Validation did not pass inspection! You can use the validate command to verify your conﬁguration settings at any time. Your Motorola Netopia® Gateway automatically validates your conﬁguration any time you save a modiﬁed conﬁgura- tion.
Page 144: Config Commands
ATA is dis- covered, the Gateway compares the MAC address of the ATA with one of the existing proﬁles stored in ® the database. If there is a match, the conﬁguration is downloaded to the Motorola Netopia ATA, and ®...
Page 145 set ata proﬁle [ 0... 3 ] ata-static-wan-gateway ip_addr Speciﬁes a static gateway WAN IP address for the speciﬁed proﬁle. set ata proﬁle [ 0... 3 ] ata-proxy-server ip_addr Speciﬁes a SIP proxy server hostname or IP address for the speciﬁed proﬁle. set ata proﬁle [ 0...
Page 146: Dsl Commands
You can use the CLI to set up each ATM virtual circuit. set atm option {on | off } ® Enables the WAN interface of the Motorola Netopia Gateway to be conﬁgured using the Asynchronous Transfer Mode (ATM) protocol. set atm [vcc n ] option {on | off } Selects the virtual circuit for which further parameters are set.
Page 147: Bridging Settings
Bridging lets the Motorola Netopia® Gateway use MAC (Ethernet hardware) addresses to forward non- TCP/IP trafﬁc from one network to another. When bridging is enabled, the Motorola Netopia® Gateway maintains a table of up to 512 MAC addresses. Entries that are not used within 30 seconds are dropped.
Page 148 Administrator’s Handbook set bridge concurrent-bridging-routing {on | off } Enables or disables Concurrent Bridging/Routing. set bridge dhcp-ﬁlterset " string " Assigns a ﬁlterset named string to the bridge conﬁguration. ☛ NOTE: A ﬁlterset can only be conﬁgured for the bridge if the system bridge or concurrent bridging/ routing is enabled.
Page 149: Dhcp Settings
Enables or disables DHCP services in the Motorola Netopia® Gateway. You must enable DHCP services before you can enter other DHCP settings for the Motorola Netopia® Gateway. If you turn off DHCP services and save the new conﬁguration, the Motorola Netopia® Gateway clears its DHCP settings.
Page 150 Administrator’s Handbook set dhcp range [ 2... 8 ] start-address ip_address Speciﬁes the starting IP address of DHCP range n when subnet n option is on. See “Additional sub- nets” on page 164. set dhcp range [ 2... 8 ] end-address ip_address Speciﬁes the ending IP address of DHCP range n when subnet n option is on.
Page 151 Data Size Option Data Format (bytes) Conﬁgure Unsigned 4 byte integer Unsigned 2 byte integer list Multiples of 2 Unsigned 2 byte integer Flag IP address 29 - 31 Flag IP address IP address and mask list Multiples of 8 Flag Unsigned 4 byte integer Flag...
Page 152 Administrator’s Handbook Data Size Option Data Format (bytes) Conﬁgure Complex Sub-option list Complex Undeﬁned IP address list Multiples of 4 86 - 87 Unicode String Multiples of 2 Encoded DN list IP address list Multiples of 4 Complex 91 - 97 Undeﬁned/Weakly deﬁned String (up to 100 characters) 99 - 115...
Page 153 DHCP Option Filtering Beginning with Firmware Version 7.7, support for DHCP option ﬁltering is provided via the ﬁlterset set- tings. set dhcp ﬁlterset name " string " rule n type [ dhcp-option | hw-address | requested-option ] Speciﬁes a DHCP ﬁlterset named string as one of three possible types: The rule can either specify an option and option contents, dhcp-option;...
Page 154 Administrator’s Handbook set dhcp ﬁlterset name " string " rule n match-pool ip_address Speciﬁes the start IP address of the range within a DHCP pool where that range will be used to allocate an address if the wildcard matches. The value 0.0.0.0 means regular processing; 255.255.255.255 means discard. set dhcp ﬁlterset name "...
Page 155: Dmt Settings
DMT Settings DSL Commands set dmt dsl-annex-support [ off | on ] This controls whether other annex support (just as Annex M) is enabled. Default is off. set dmt type [ lite | dmt | ansi | multi | adsl2 | adsl2+ | readsl2 | adsl2anxm | adsl2+anxm ] Selects the type of Discrete Multitone (DMT) asynchronous digital subscriber line (ADSL) protocol to use for the WAN interface.
Page 156: Domain Name System Settings
Administrator’s Handbook Domain Name System Settings Domain Name System (DNS) is an information service for TCP/IP networks that uses a hierarchical naming system to identify network domains and the hosts associated with them. You can identify a pri- mary DNS server and one secondary server. Common Commands set dns domain-name domain-name Speciﬁes the default domain name for your network.
Page 157 Dynamic DNS Settings Dynamic DNS support allows you to use the free services of www.dyndns.org. Dynamic DNS automati- cally directs any public Internet request for your computer's name to your current dynamically-assigned IP address. This allows you to get to the IP address assigned to your Gateway, even though your actual IP address may change as a result of a PPPoE connection to the Internet.
Page 158: Igmp Settings
ﬁeld, or sending out company newsletters to a distribution list. ® Since a router should not be used as a passive forwarding device, Motorola Netopia Gateways use a protocol for forwarding multicasting: Internet Group Management Protocol (IGMP).
Page 159 ◆ Querier Version – select a version of the IGMP Querier: version 1, version 2, or version 3. If you know you will be communicating with other hosts that are limited to v1 or v2, for backward compati- bility, select accordingly; otherwise, allow the default v3. ☛...
Page 160: Ip Settings
If set to on, all IGMP messages on both the LAN and the WAN will be logged. Default is off. IP Settings You can use the command line interface to specify whether TCP/IP is enabled, identify a default Gate- way, and to enter TCP/IP settings for the Motorola Netopia® Gateway LAN and WAN ports. ☛ NOTE:...
Page 161 Enables or disables TCP/IP services in the Motorola Netopia® Gateway. You must enable TCP/IP ser- vices before you can enter other TCP/IP settings for the Motorola Netopia® Gateway. If you turn off TCP/IP services and save the new conﬁguration, the Motorola Netopia® Gateway clears its TCP/IP set- tings.
Page 162 (which reduces the load on hosts which do not support routing protocols. RIP-2 with MD5 authentication is an extension of RIP-2 that increases security by requiring an authentication key when routes are advertised. Depending on your network needs, you can conﬁgure your Motorola Netopia® Gateway to support RIP- 1, RIP-2, or RIP-2MD5.
Page 163 A address ip_address Assigns an IP address to the Motorola Netopia® Gateway on the local area network. The IP address you assign to the local Ethernet interface must be unique on your network. By default, the Motorola Neto- pia®...
Page 164 Default IP Gateway Settings set ip gateway option [ on | off ] Speciﬁes whether the Motorola Netopia® Gateway should send packets to a default Gateway if it does not know how to reach the destination host. set ip gateway interface [ ip_address | ppp_vccn ] ®...
Page 165 [vcc n ] option { on | off } Enables or disables IP routing through the virtual PPP interface. By default, IP routing is turned on. If you turn off IP routing and save the new conﬁguration, the Motorola Netopia® Gateway clears IP routing settings set ip ip-ppp [vcc n ] address ip_address Assigns an IP address to the virtual PPP interface.
Page 166 [ on | off ] ® Speciﬁes whether you want the Motorola Netopia Gateway to identify the source IP address of every IGMP packet transmitted from this interface as 0.0.0.0 when mcast-fwd is set to on. This complies with the requirements of TR-101, and removes the need for a publicly advertised IP address on the WAN interface.
Page 167 ARP table entries, static ARP table entries do not time out. You can conﬁgure as many as 16 static ARP table entries for a Motorola Netopia® Gateway. Use the fol- lowing commands to add static ARP entries to the Motorola Netopia® Gateway static ARP table:...
Page 168 Administrator’s Handbook RTSP Passthrough set ip rtsp-passthrough [ off | on ] Turns Real Time Streaming Protocol application layer gateway client passthrough on or off. RTSP is a protocol used for streaming media. It allows a client remotely to control a streaming media server. A typical application is Video-on-Demand (VoD).
Page 169 set diffserv custom-ﬂows name name protocol [ TCP | UDP | ICMP | other ] direction [ outbound | inbound | both ] start-port [ 0 - 65535 ] end-port [ 0 - 65535 ] inside-ip inside-ip-addr inside-ip-mask inside-ip-netmask outside-ip outside-ip-addr outside-ip-mask outside-ip-netmask qos [ off | assure | expedite | network-control ] Deﬁnes or edits a custom ﬂow.
Page 170 Administrator’s Handbook Packet Mapping Conﬁguration set diffserv qos [ network-control-queue | expedite-queue | assured-queue | best-effort-queue ] queue_name Speciﬁes the Diffserv QoS queue mapping associations. ◆ queue_name - the basic queue name to which classiﬁed packets are directed. By default the following mappings are created: set diffserv qos network-control-queue basic_q0 set diffserv qos expedite-queue basic_q1 set diffserv qos assured-queue basic_q2...
Page 171 set diffserv qos dscp-map-23 expedite set diffserv qos dscp-map-24 network-control set diffserv qos dscp-map-25 network-control set diffserv qos dscp-map-26 network-control set diffserv qos dscp-map-27 network-control set diffserv qos dscp-map-28 network-control set diffserv qos dscp-map-29 network-control set diffserv qos dscp-map-30 network-control set diffserv qos dscp-map-31 network-control...
Page 172: Queue Configuration
Administrator’s Handbook Queue Conﬁguration The Gateway’s WAN interface can now be conﬁgured for: ◆ strict priority queuing (as currently) ◆ weighted fair queuing ◆ rate-limiting funnel ☛ Note: The conﬁguration mechanism is designed to be ﬂexible enough to accommodate complex queuing requirements.
Page 173 set queue name queue_name option [ on | off ] type [ basic | wfq | priority | funnel ] Creates a queue named queue_name and assigns a type: ◆ basic – Basic Queue ◆ – Weighted Fair Queue ◆ priority –...
Page 174 Administrator’s Handbook Weighted Fair Queue set queue name wfq option [ on | off ] set queue name wf_queue_name type wfq set queue name wf_queue_name weight-type [ relative | bps ] set queue name wf_queue_name default-input queue_name Speciﬁes the attributes of the Weighted Fair Queue named wf_queue_name . ◆...
Page 175 set queue name "wfq" entry 4 weight 40000 set queue name "wfq" entry 4 share-bw off set queue name "wfq" entry 4 limit-bw off set queue name "wfq" default-input "basic_q0" Priority Queue set queue name priority_queue_name option [ off | on ] set queue name priority_queue_name type priority set queue name priority_queue_name reserve-bps reserve_bps_value set queue name priority_queue_name default-input queue_name...
Page 176 PPP, since an intermittent PPP link may make maintenance of dynamic routes problematic. You can conﬁgure as many as 32 static IP routes for a Motorola Netopia® Gateway. Use the following commands to maintain static routes to the Motorola Netopia® Gateway routing table:...
Page 177 Speciﬁes the IP address of the Gateway for the static route. The default Gateway must be located on a network connected to the Motorola Netopia® Gateway conﬁgured interface. set ip static-routes destination-network net_address metric integer Speciﬁes the metric (hop count) for the static route. The default metric is 1. Enter a number from 1 to 15 for the integer argument to indicate the number of Gateways (actual or best guess) a packet must traverse to reach the remote network.
Page 178: Ipmaps Settings
Network Address Translation (NAT) Default Settings NAT default settings let you specify whether you want your Motorola Netopia® Gateway to forward NAT trafﬁc to a default server when it doesn’t know what else to do with it. The NAT default host function is useful in situations where you cannot create a speciﬁc NAT pinhole for a trafﬁc stream because you...
Page 179: Network Address Translation (Nat) Pinhole Settings
Network Address Translation (NAT) Pinhole Settings NAT pinholes let you pass speciﬁc types of network trafﬁc through the NAT interfaces on the Motorola Netopia® Gateway. NAT pinholes allow you to route selected types of network trafﬁc, such as FTP requests or HTTP (Web) connections, to a speciﬁc host behind the Motorola Netopia® Gateway trans- parently.
Page 180: Pppoe /Pppoa Settings
[vcc n ] lcp-echo-requests { on | off } Speciﬁes whether you want your Motorola Netopia® Gateway to send LCP echo requests. You should turn off LCP echoing if you do not want the Motorola Netopia® Gateway to drop a PPP link to a nonre- sponsive peer.
Page 181 [vcc n ] connection-type { instant-on | always-on } Speciﬁes whether a PPP connection is maintained by the Motorola Netopia® Gateway when it is unused for extended periods. If you specify always-on, the Motorola Netopia® Gateway never shuts down the PPP link.
Page 182 For example, if the remote peer requires CHAP authentica- tion and has a name and CHAP secret for the Motorola Netopia® Gateway, you must enable CHAP and specify the same name and secret on the Motorola Netopia® Gateway before the link can be estab- lished.
Page 183: Pppoe With Ipoe Settings
PPPoE with IPoE Settings Ethernet WAN platforms set wan-over-ether pppoe [ on | off ] Enables or disables PPPoE on the Ethernet WAN interface. set wan-over-ether pppoe-with-ipoe [ on | off ] Enables or disables the PPPoE with IPoE support on Ethernet WAN, including VDSL, platforms when pppoe option is set to on.
Page 184: Ethernet Port Settings
Administrator’s Handbook ADSL platforms You must conﬁgure two VCCs with the same VPI/VCI to enable concurrent PPPoE and IPoE support, and you will need to conﬁgure the individual settings for each interface for proper operation. set atm vcc n encap pppoe-llc Speciﬁes that the VCC will allow a second VCC with the same VPI/VCI values as the ﬁrst.
Page 185: 802.3Ah Ethernet Oam Settings
All VDSL and Ethernet WAN Motorola Netopia Gateways support Ethernet OAM options. ® More Ethernet Packet-Transfer-Mode (PTM) enabled xDSL Motorola Netopia Gateways will support 802.3ah Ethernet OAM options in future releases. 802.3ah Ethernet OAM exchanges periodic Ethernet OAM heartbeat frames between the endpoints of the physical link being monitored, and thus discovers and keeps-alive the Link connectivity and reports faults if the link goes down.
Page 186: Command Line Interface Preference Settings
Administrator’s Handbook Command Line Interface Preference Settings You can set command line interface preferences to customize your environment. set preference verbose { on | off } Speciﬁes whether you want command help and prompting information displayed. By default, the com- mand line interface verbose preference is turned off.
Page 187: Port Renumbering Settings
Port Renumbering Settings If you use NAT pinholes to forward HTTP or telnet trafﬁc through your Motorola Netopia® Gateway to an internal host, you must change the port numbers the Motorola Netopia® Gateway uses for its own con- ﬁguration trafﬁc. For example, if you set up a NAT pinhole to forward network trafﬁc on Port 80 (HTTP) to another host, you would have to tell the Motorola Netopia®...
Page 188: Security Settings
Internet Key Exchange (IKE) is the key management pro- tocol of IPsec that establishes keys for encryption and decryption. Because this VPN software imple- mentation is built to these standards, the other side of the tunnel can be either another Motorola ®...
Page 189 set security ipsec tunnels name "123" encrypt-protocol { ESP | none } page 193 for details about SafeHarbour IPsec tunnel capability. set security ipsec tunnels name "123" auth-protocol {AH | ESP | none} page 193 for details about SafeHarbour IPsec tunnel capability. set security ipsec tunnels name "123"...
Page 190 "123" IKE-mode invalid-spi-recovery { off | on } Enables the Gateway to re-establish the tunnel if either the Motorola Netopia® Gateway or the peer gateway is rebooted. set security ipsec tunnels name "123" xauth enable {off | on } Enables or disables Xauth extensions to IPsec, when IKE-mode neg-method is set to aggressive.
Page 191 set security ipsec tunnels name "123" remote-id id_value Speciﬁes the NAT remote ID value as speciﬁed in the remote-id-type for the speciﬁed IPsec tunnel, when Aggressive Mode is set. ☛ Note: If subnet is selected, the following two values are used instead: set security ipsec tunnels name "123"...
Page 192 Administrator’s Handbook Table 1: IPSec Tunnel Details Parameter Setup Worksheet ® Motorola Netopia Parameter Peer Gateway Gateway Name Peer Internal Network Peer Internal Netmask NAT Enable On/Off PAT Address Negotiation Method Main/Aggressive Local ID Type IP Address Subnet Hostname ASCII...
Page 193: Parameter Descriptions
Parameter Descriptions The following tables describe SafeHarbour’s parameters that are used for an IPSec VPN tunnel conﬁgu- ration: Table 2: IPSec Configuration page parameters Field Description Name The Name parameter refers to the name of the conﬁgured tunnel. This is mainly used as an identiﬁer for the administrator.
Page 194 Values supported include MD5 and SHA1. N/A will display if NONE is chosen for Auth Protocol. Invalid SPI Enabling this allows the Gateway to re-establish the tunnel if either the Motorola Neto- Recovery pia® Gateway or the peer gateway is rebooted.
Page 195 Xauth Enable Extended Authentication (XAuth), an extension to the Internet Key Exchange (IKE) proto- col. The Xauth extension provides dual authentication for a remote user’s Motorola Neto- ® Gateway to establish a VPN, authorizing network access to the user’s central ofﬁce.
Page 196 Administrator’s Handbook Stateful Inspection Stateful inspection options are accessed by the security state-insp tag. set security state-insp [ ip-ppp | dsl ] vcc n option [ off | on ] set security state-insp ethernet [ A | B ] option [ off | on ] Sets the stateful inspection option off or on on the speciﬁed interface.
Page 197 Sets the exposed list address number. set security state-insp xposed-addr exposed-address# " n " start-ip ip_address Sets the exposed list range starting IP address, in dotted quad format. set security state-insp xposed-addr exposed-address# " n " end-ip ip_address Sets the exposed list range ending IP address, in dotted quad format. 32 exposed addresses can be created.
Page 198 Administrator’s Handbook Packet Filtering Settings Packet Filtering has two parts: ◆ Create/Edit/Delete Filter Sets, create/edit/delete rules to a Filter Set. ◆ Associate a created Filter Set with a WAN or LAN interface set security pkt-ﬁlter ﬁlterset ﬁlterset-name [ input_ﬁlter | output_ﬁlter ] index forward [ on | off ] Creates or edits a ﬁlter rule, specifying whether packets will be forwarded or not.
Page 199 set security pkt-ﬁlter ﬁlterset ﬁlterset-name [ input_ﬁlter | output_ﬁlter ] index dest-ip ip_addr Speciﬁes the destination IP address to match packets (where the packet is going). set security pkt-ﬁlter ﬁlterset ﬁlterset-name [ input_ﬁlter | output_ﬁlter ] index dest-mask mask Speciﬁes the destination IP mask to match packets (where the packet is going). set security pkt-ﬁlter ﬁlterset ﬁlterset-name [ input_ﬁlter | output_ﬁlter ] index tos value Speciﬁes the TOS (Type Of Service) value to match packets.
Page 200 Administrator’s Handbook set security pkt-ﬁlter ﬁlterset ﬁlterset-name [ input_ﬁlter | output_ﬁlter ] index dst-compare [ nc | ne | lt | le | eq | gt | ge ] Sets the destination compare operator action for the speciﬁed ﬁlter rule. dst-compare only displays when the protocol is TCP or UDP.
Page 201: Snmp Settings
Identiﬁes the system contact, such as the name, phone number, beeper number, or email address of the person responsible for the Motorola Netopia® Gateway. You can enter up to 255 characters for the contact_info argument. You must put the contact_info argument in double-quotes if it contains embedded spaces.
Page 202: System Settings
3000/9437188. A system name can be 1 – 255 characters long. Once you have assigned a name to your Motorola Netopia® Gateway, you can enter that name in the Address text ﬁeld of your browser to open a connection to your Motorola Netopia® Gateway.
Page 203 A password can be as many as 32 characters. Passwords are case-sensitive. Passwords go into effect immediately. You do not have to restart the Motorola Netopia® Gateway for the password to take effect. Assigning an administrator or user password to a Motorola Netopia® Gate-...
Page 204 Administrator’s Handbook set system heartbeat option { on | off } protocol [ udp | tcp ] port-client [ 1 - 65535 ] ip-server [ ip_address | dns_name ] port-server [ 1 - 65535 ] url-server (" server_name ") number [ 1 – 1073741823 ] interval (00:00:00:20) sleep (00:00:30:00) contact-email ("...
Page 205 [ on | off ] Enables or disables the Zero Touch option. Zero Touch refers to automatic conﬁguration of your Motorola Netopia® Gateway. The Motorola Neto- pia® Gateway has default settings such that initial connection to the Internet will succeed. If the zero- touch option is set to on, HTTP requests to any destination IP address except the IP address(es) of the conﬁgured redirection URL(s) will access a redirection server.
Page 206: Syslog
Administrator’s Handbook Syslog set system syslog option [ off | on ] Enables or disables system syslog feature. If syslog option is on, the following commands are avail- able: set system syslog host-nameip [ ip_address | hostname ] Speciﬁes the syslog server’s address either in dotted decimal format or as a DNS name up to 64 char- acters.
Page 207 Default syslog installation procedure Access the Gateway via telnet from the private LAN. DHCP server is enabled on the LAN by default. The product’s stateful inspection feature must be enabled in order to examine TCP, UDP and ICMP packets destined for the Gateway or the private hosts. This can be done by entering the CONFIG interface.
Page 208: Wireless Settings (Supported Models)
{ off | at-startup | continuous } Speciﬁes the wireless AutoChannel Setting for 802.11G models. AutoChannel is a feature that allows the Motorola Netopia® Gateway to determine the best channel to broadcast automatically. For details, “Advanced” on page set wireless default-channel { 1...14 }...
Page 209 set wireless scheduler end-time hh : min Speciﬁes the time to turn the wireless radio off, when wireless scheduler option is set to on. set wireless multi-ssid option { on | off } Enables or disables the multi-ssid feature which allows you to add additional network identiﬁers (SSIDs or Network Names) for your wireless network.
Page 210 Administrator’s Handbook set wireless multi-ssid second-ssid-psk { string } set wireless multi-ssid third-ssid-psk { string } set wireless multi-ssid fourth-ssid-psk { string } Speciﬁes a WPA passphrase for the multiple SSIDs, when second-, third-, or fourth-ssid-privacy is set to WPA-PSK. The Pre Shared Key is a passphrase shared between the Gateway and the clients and is used to generate dynamically changing keys.
Page 211 Wireless Multi-media (WMM) Settings Router EDCA Parameters (Enhanced Distributed Channel Access) govern wireless data from your Gateway to the client; Client EDCA Parameters govern wireless data from the client to your Gateway. set wireless wmm option [ off | on ] Enables or disables wireless multi-media settings option, which allows you to ﬁne tune WiFi Multimedia Quality of Service (QoS) by transmitting data depending on Diffserv priority settings.
Page 212 Administrator’s Handbook set wireless wmm router-edca background { aifs 1... 255 } set wireless wmm router-edca background { cwmin value } set wireless wmm router-edca background { cwmax value } Sets values for Gateway WMM background parameters. set wireless wmm client-edca voice { aifs 1... 255 } set wireless wmm client-edca voice { cwmin value } set wireless wmm client-edca voice { cwmax value } set wireless wmm client-edca voice { txoplimit 0...
Page 213 Wireless Privacy Settings set wireless network-id wps [ off | on ] Enables or disables Wireless Protected Setup. See “Wireless Protected Setup” on page set wireless network-id privacy option { off | WEP | WPA-PSK | WPA-802.1x } Speciﬁes the type of privacy enabled on the wireless LAN. off = no privacy; WEP = WEP encryption; WPA-PSK = Wireless Protected Access/Pre-Shared Key;...
Page 214 Administrator’s Handbook set wireless network-id privacy encryption-key1-length {40/64bit, 128bit, 256bit} set wireless network-id privacy encryption-key2-length {40/64bit, 128bit, 256bit} set wireless network-id privacy encryption-key3-length {40/64bit, 128bit, 256bit} set wireless network-id privacy encryption-key4-length {40/64bit, 128bit, 256bit} Selects the length of each encryption key. 40bit encryption is equivalent to 64bit encryption. The longer the key, the stronger the encryption and the more difﬁcult it is to break the encryption.
Page 215 set wireless mac-auth wrlss-MAC-list mac-address “ MAC-address_string ” allow-access-ssid2 { on | off } set wireless mac-auth wrlss-MAC-list mac-address “ MAC-address_string ” allow-access-ssid3 { on | off } set wireless mac-auth wrlss-MAC-list mac-address “ MAC-address_string ” allow-access-ssid4 { on | off } Designates whether the MAC address is enabled or not for the speciﬁed multiple SSID access.
Page 216: Vlan Settings
Administrator’s Handbook VLAN Settings You can create up to 8 VLANs, and you can also restrict any VLAN, and the computers on it, from admin- istering the Gateway. See “VLAN” on page 74 for more information. set vlan name name Sets the descriptive name for the VLAN.
Page 217 802.1p priority bit ﬁeld for tagged IP packets transmitted from this port for this VLAN. All mappings between Ethernet 802.1p and IP-TOS are made via diffserv dscp-map settings. set vlan name name ports port port-pbits [ 0 - 7 ] Speciﬁes the 802.1p priority bit for this port associated with the speciﬁed VLAN.
Page 218 Administrator’s Handbook ip-vcc1 option (off) [ off | on ]: ip-eth-a option (off) [ off | on ]: on ipsec-mgmt1 option (off) [ off | on ]: Netopia-3000/9437188 (vlan)>> Example 2: ◆ An example of a “Triple-Play” setup: set vlan name "LanPorts" type by-port set vlan name "LanPorts"...
Page 219 set vlan name "PPPoE_11" seg-pbits 0 set vlan name "PPPoE_11" ports eth0.1 option off set vlan name "PPPoE_11" ports eth0.2 option off set vlan name "PPPoE_11" ports eth0.3 option off set vlan name "PPPoE_11" ports eth0.4 option off set vlan name "PPPoE_11" ports ssid1 option off set vlan name "PPPoE_11"...
Page 220 Administrator’s Handbook set vlan name "Video_31" inter-vlan-routing group-2 off set vlan name "Video_31" inter-vlan-routing group-3 off set vlan name "Video_31" inter-vlan-routing group-4 off You must save the changes, exit from conﬁguration mode, and restart the Gateway for the changes to take effect.
Page 221: Voip Settings (Supported Models)
Session Initiation Protocol (SIP), to transmit sound over a network or the Internet in the ® form of data packets. Certain Motorola Netopia Gateway models have two separate voice ports for connecting telephone handsets. These models support VoIP. If your Gateway is a VoIP model, you can conﬁgure the VoIP features.
Page 222 Administrator’s Handbook set voip phone [ 1 | 2 ] sip-registrar-setting sip-expires-time [ 0 - 65535 ] Speciﬁes the SIP registration server time-out duration from 0 – 65535 seconds for the speciﬁed phone. Default is 3600 (1 hour). set voip phone [ 1 | 2 ] sip-out-proxy-server [ server_name | ip_address ] Speciﬁes the SIP outbound proxy server for the speciﬁed phone by fully qualiﬁed server name or IP address.
Page 223 set voip phone [ 1 | 2 ] codec G726_16 priority [ 1 | 2 | 3 | 4 | 5 | 6 | 7 | none ] Assigns a priority to the G726-16 codec, a common audio media type implementation at 16 kbit/s. set voip phone [ 1 | 2 ] codec G726_24 priority [ 1 | 2 | 3 | 4 | 5 | 6 | 7 | none ] Assigns a priority to the G726-24 codec, a common audio media type implementation at 24 kbit/s.
Page 224 Administrator’s Handbook set voip phone [ 1 | 2 ] sip-advanced-setting rtp-qos-tos-value [ 0 - 255 ] Speciﬁes the RTP Diff-Serv Type of Service (ToS) values for Quality of Service (QoS) assignment. Default is 184. set voip phone [ 1 | 2 ] sip-advanced-setting call-feature call-forwarding-all-option [ off | on ] call-forwarding-all-option –...
Page 225 set voip phone [ 1 | 2 ] sip-advanced-setting call-feature subscribe-do-not-disturb-option [ off | on ] subscribe-do-not-disturb-option – enables or disables option to prevent the phone from ringing. set voip phone [ 1 | 2 ] sip-advanced-setting call-feature subscribe-mwi-option [ off | on ] subscribe-mwi-option –...
Page 226 Administrator’s Handbook set voip phone [ 1 | 2 ] sip-advanced-setting dsp-settings vad-setting [ vad-cn | vad-std-sid | vad-suppress-sid ] When vad-option is set to on: ◆ vad-cn – enables Voice Activity Detection/Comfort Noise Generation. When speech is not present, the CNG algorithm generates a noise signal at the level sent from the transmit side.
Page 227: Upnp Settings
PCs using UPnP can retrieve the Gateway’s WAN IP address, and automatically create NAT port maps. ® This means that applications that support UPnP, and are used with a UPnP-enabled Motorola Netopia ® Gateway, will not need application layer gateway support on the Motorola Netopia Gateway to work through NAT.
Page 228 DSL Forum CPE WAN Management Protocol (TR-069) provides services similar to UPnP and TR-064. ® The communication between the Motorola Netopia Gateway and management agent in UPnP and TR- 064 is strictly over the LAN, whereas the communication in TR-069 is over the WAN link for some fea- tures and over the LAN for others.
Page 229: Remote Management Settings
Remote Management settings set remote-mgmt telnet-enable [ on | off ] Enables or disables remote management via telnet of the network speciﬁed by network- n /netmask- n . Up to 10 networks may be speciﬁed. set remote-mgmt web-enable [ on | off ] Enables or disables remote management via web UI of the network speciﬁed by network- n /netmask- n .
Page 230: Backup Ip Gateway Settings
Administrator’s Handbook Backup IP Gateway Settings The purpose of Backup is to provide a recovery mechanism in the event that the primary connection fails. A failure can be either line loss, for example by central site switch failure or physical cable break- age, or loss of end-to-end connectivity.
Page 231 set ip backup-gateway option [ on | off ] Turns the backup gateway option on or off. Default is off. set ip backup-gateway interface [ ip-address | ppp-vcc n ] Speciﬁes the backup gateway interface ip address to which you want to direct the backup connection. set ip backup-gateway default ip_address Speciﬁes the ip address of the default gateway.
Page 232: Vdsl Settings
Administrator’s Handbook VDSL Settings ☛ CAUTION! These settings are for very advanced users and lab technicians. Exercise extreme caution when modifying any of these settings. set vdsl sys-option [ 0x00 - 0xff ] sys-bandplan [ 0x00 - 0xff ] psd-mask-level [ 0x00 - 0xff ] pbo-k1_1 [ 0x00000000 - 0xffffffff ] pbo-k1_2 [ 0x00000000 - 0xffffffff ] pbo-k1_3 [ 0x00000000 - 0xffffffff ]...
Page 233 VDSL Parameter Defaults Parameter Default Meaning line-type 0x81 VDSL port line type(auto=0x80, vdsl=0x81, vdsl_etsi=0x82) us-max-inter-delay 0x04 VDSL port upstream max inter delay ds-max-inter-delay 0x04 VDSL port downstream max inter delay us-target-noise-margin 0x0C VDSL port upstream target noise margin ds-target-noise-margin 0x0C VDSL port downstream target noise margin min-noise-margin 0x0A...
Page 234 Administrator’s Handbook VDSL Parameters Accepted Values Parameter Accepted Values sys-option Bit[0]: NTR_DISABLE Bit[1]: ALW_MARGIN_ADJUST. 1: the SNR margin for the optional band is reduced by up to 2.5 dB, but never below a minimum of 4 dB. Bit[2]: SUPPORT_INI Bit[4]: TLAN Enable Bit[5]: PBO Weak mode Enable (Applicable only when PBO Bit[3]=0.
Page 235: Vdsl Parameters Accepted Values
VDSL Parameters Accepted Values Parameter Accepted Values psd-mask-level 0x00 -- default mask (old gains from before) 0x01 -- ANSI M1 CAB 0x02 -- ANSI M2 CAB 0x03 -- ETSI M1 CAB 0x04 -- ETSI M2 CAB 0x05 -- ITU-T Annex F (Japan) 0x06 - ANSI M1 Ex 0x07 - ANSI M2 Ex 0x08 -- ETSI M1 Ex...
Page 236 Administrator’s Handbook VDSL Parameters Accepted Values Parameter Accepted Values port-bandplan BP1_998_3 (0x00) BP2_998_3 (0x01) BP998_3B_8_5M (0x01) BP3_998_4 (0x02) BP998_4B_12M (0x02) BP4_997_3 (0x03) BP997_3B_7_1M (0x03) BP5_997_3 (0x04) BP6_997_4 (0x05) BP997_4B_7_1M (0x05) BP7_MXU_3 (0x06) FLEX_3B_8_5M (0x06) BP8_MXU_2 (0x07) BP9_998_2 (0x08) BP10_998_2 (0x09) BP998_2B_3_8M (0x09) BP11_998_2 (0x0A)
Page 237 VDSL Parameters Accepted Values Parameter Accepted Values band-mod Bit 0, 1: Tx Cfg band 1- All tones on 2- All tones below 640 Khz are turned off 3- All tones below 1.1 Mhz are turned off Bit 2,3: Not used Bit 4,5: Rx Cfg band 1- All tones on 2- All tones below 640 Khz are turned off...
Page 238 Administrator’s Handbook...
Page 239: Technical Specifications And Safety Information
Description Communications interfaces: The Motorola Netopia® Gateways have an RJ-11 jack for DSL line connections or an RJ-45 jack for cable/DSL modem connections and 1 or 4–port 10/100Base-T Ethernet switch for your LAN connections. Some models have a USB port that can be used to connect to your PC; in some cases, the USB port also serves as the power source.
Page 240: Agency Approvals
● EMC Compatibility, 89/336/EEC, conforming to EN 55 022 This Motorola product is in conformity with the essential requirements and other relevant requirements of the Radio Equipment and Telecommunications Terminal Equipment Directive (R&TTE) 1999/5/EC, following the provision of the Electromagnetic Compatibility Directive (EMC) No. 89/336/EEC and Low Voltage Directive (LVD) No.
Page 241: Manufacturer's Declaration Of Conformance
Company or to one of our authorized agents. Contact Us for US Technical Support for Hardware Products 1-877-466-8646 http://www.motorola.com/us/products.jsp ☛ Important This product was tested for FCC compliance under conditions that included the use of shielded cables and connectors between system components. Changes or modiﬁcations to this product not authorized by the manufacturer could void your authority to operate the equipment.
Page 242: Important Safety Instructions
Administrator’s Handbook Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. In some cases, the company’s inside wiring associated with a single line individual service may be extended by means of a certiﬁed connector assembly (telephone extension cord).
Page 243: 47 Cfr Part 68 Information
This equipment not intended to be repaired by the end user. In case of any problems, please refer to the trouble- shooting section of the Product User Manual before calling Motorola Technical Support.
Page 244: Electrical Safety Advisory
The Software is protected by copyright laws and international copyright treaties. The Software is licensed and not sold to you. This means that although you own the media (CD-ROM or the Product) on which the Software is provided or in which the Software is embedded, Motorola or its licensors retains all ownership of the Software. ●...
Page 245: Limited Warranty
Limited Warranty Motorola warrants to you, the end user, that the Product will be free from defects in materials and workmanship under normal use for a period of one (1) year from date of purchase, or two (2) years from date of purchase if you reside in a European Union country.
Page 246: Copyright Acknowledgments
Administrator’s Handbook Copyright Acknowledgments Because Motorola has included certain software source code in this product, Motorola includes the following text required by the respective copyright holders: Portions of this software are based in part on the work of the following: Copyright (c) 1998-2005 The OpenSSL Project.
Page 247 Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: 1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. 2.
Page 248: Caring For The Environment By Recycling
