  • Page 1 Install Manual...

  • Page 2: Introduction

    Install Manual Introduction Thank you for purchasing a Samsung SVR series digital video recorder. This manual is for SVR-3200, SVR-1680C, SVR-1660C, SVR-1645, SVR-960C, SVR-945, SVR-480. Before product installation and operation, please become thoroughly familiar with this user manual and other manuals referenced by this manual.
  • Page 3 Experience and technical skills are needed for the installation of this product as an improper installation may cause fire, electric shocks, or defects. Any installation job should be performed by the vendor you purchased this product from. This manual is authored SVR-3200, SVR-1680C, SVR-1660C, SVR-1645, SVR-960C, SVR-945, SVR-480 according to firmware version 1.8.0 The content of this manual may differ according to Firmware or Software upgrades, and the standard and appearance of the product is changeable without prior notice to users.

  • Page 4: Table Of Contents

    Install Manual Contents Introduction ..................1 Product Warranty and Limits of Responsibility ............1 Chapter 1. Safety Precautions ............4 Explaining the Symbols ................. 4 Chapter 2. Summary ............... 8 Features ....................8 Components ..................... 12 Description of product ................. 13 Front view ..................

  • Page 5: Chapter 1. Safety Precautions

    Install Manual Chapter 1. Safety Precautions 1.1 Explaining the Symbols Warning Refers to information users need to know in order to prevent serious injury or death. Before installation Verify the supplied voltage (AC100V~AC240V) before connecting to the power supply. Make sure the power supply is off before installation. Do not install in a very humid environment.
  • Page 6 Install Manual Dismantling and cleaning Do not dismantle, repair or modify the product deliberately. Doing so may cause a damage, an electric shock or an injury. Do not use water, paint thinner or organic solvent for cleaning the product exterior. Doing so may cause a malfunction or an electric shock.
  • Page 7 Install Manual Samsung Techwin cares for the environment at all product manufacturing stages, and is taking a number of steps to provide customers with more environmentally friendly products. The Eco mark represents Samsung Techwin’s will to create environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive.
  • Page 8 Install Manual Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to human health or the environment. To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them through your local, free battery return system.

  • Page 9: Chapter 2. Summary

    32/16/9 channels to its built-in hard disk. The buttons on the front of the unit as well as the mouse and GUI allow easy setup and operation. The Samsung SVR series of digital video recorders (DVRs) provide additional safety and security to banks, apartment buildings and complexes, government offices as well as other public, private and commercial facilities.

  • Page 10: Audio Recording

    SVR-3200/1680C/1600/1645 : Input - 16 channels (4 RCA in rear, 12 D-SUB), Output - 1 in rear, SVR-960C/945 : 9 channels (4 RCA in rear, 5 D-SUB), Output - 1 in rear, SVR-480 : 4 channels (4RCA), Output – 1 in rear...

  • Page 11: Data Storage

    Install Manual Each channel supports pre-emptive recording sequences up to 5 seconds prior to an actual event Search/Playback Various search and playback options are offered for the user’s convenience. Playback by time, date and channel Mouse interface increases data searchability Forward/backward search while playback is paused Playback by event log entry (sensor, video loss, motion detection and text) Remote controller and Jog/Shuttle further improve searching (The SVR-...
  • Page 12 Install Manual Networking The product supports LAN, xDSL and other networking capabilities. Combined with the PC interface client, the core features of the device can be easily remotely controlled. E-mails can be sent via TCP/IP or DHCP upon an event trigger Remote live visual feed (single or 4 section split-screen) PC playback, storage, search and DVR control functions via Network Viewer Remote recording, search and playback scheduling...

  • Page 13: Components

    Install Manual 2.1 Components Please check the included accessories as follows. AC CORD Remote Controller Program CD SATA Cable HDD Mount Screw Install Manual DVR Quickguide SNM-128S Quickguide Rackmount & Screw For the SVR-945, a switched-mode power supply (SMPS) power cord is included, while a stand is included instead of the standard rack mount.

  • Page 14: Description Of Product

    Install Manual Description of product 2.2.1 Front view 2.2.1.1 SVR-3200 Classification Function DVD-Multi for For copying recorded video and images to DVD/CD copying optical media. Channel LED Shows the data input and event operation status Jog can adjust setting values, control the STEP function, JOG/SHUTTLE navigate through the menu, and adjust the playback speed and direction.
  • Page 15 Install Manual PLAY lamp Lit when copying. Power button Turns on or off the device. ESC button The Escape button navigates up the menu tree and closes dialog windows. COPY Starts Copy mode. FUNC Starts Function mode. MONITOR Cycles through from Monitor 1 to 4. Starts or ends PTZ function.
  • Page 16 Install Manual 2.2.1.2 SVR-1680C, SVR-1660C, SVR-1645 Classification Function DVD-Multi for For copying recorded video and images to DVD/CD copying optical media. Channel LED Shows the data input and event operation status Jog can adjust setting values, control the STEP function, JOG/SHUTTLE navigate through the menu, and adjust the playback speed and direction.
  • Page 17 Install Manual closes dialog windows. COPY Starts Copy mode. FUNC Starts Function mode. MONITOR Cycles through from Monitor 1 to 4 : SVR-1680C, Switches from main and sub monitor : SVR-1660C, SVR-1645 Starts or ends PTZ function. USB ports for external devices (mouse, USB memory USB1, USB2 stick).
  • Page 18 Install Manual 2.2.1.3 SVR-960C Classification Function DVD-Multi For copying recorded video and images to DVD/CD copying optical media. Channel LED Shows the data input and event operation status Channel button Selects channel in live feed or playback AUTO Starts or stops user defined sequences.
  • Page 19 Install Manual MONITOR Switches from main and sub monitor Starts or ends PTZ function. USB ports for external devices (mouse, USB memory USB1, USB2 stick). PLAY/ENTER Start playback or select an item on the menu. Navigates or selects in the menu, or for playback, ◀/REW changes the reverse playback speed.
  • Page 20 Install Manual 2.2.1.4 SVR-945 Classification Function Channel LED Shows the data input and event operation status Channel button Selects channel in live feed or playback AUTO Starts or stops user defined sequences. MULTI Changes split-screen sections for live video feeds or playback.
  • Page 21 Install Manual Starts or ends PTZ function. USB ports for external devices (mouse, USB memory USB1, USB2 stick). PLAY/ENTER Start playback or select an item on the menu. Navigates or selects in the menu, or for playback, ◀/REW changes the reverse playback speed. Navigates or selects in the menu, or for playback, ▶/FWD changes the forward playback speed.
  • Page 22 Install Manual 2.2.1.5 SVR-480 Classification Function DVD-Multi For copying recorded video and images to DVD/CD optical copying media. Channel button Selects channel in live feed or playback Channel LED Shows the data input and event operation status AUTO Starts or stops user defined sequences. MULTI Changes split-screen sections for live video feeds or playback.
  • Page 23 Install Manual dialog windows. COPY Starts Copy mode. FUNC Starts Function mode. MONITOR Switches from main and sub monitor Starts or ends PTZ function. PLAY/ENTER Start playback or select an item on the menu. Navigates or selects in the menu, or for playback, changes ◀/REW the reverse playback speed.

  • Page 24: Rear Part

    Install Manual 2.2.2 Rear Part 2.2.2.1 SVR-3200 Input/Output Function terminal name POWER IN Socket for AC 100V ~ AC 240V power cord. CH1 ~ 32 Connection terminal for camera BNC input. MONITOR 1 ~ 4 Connection terminal for monitor BNC output. AUDIO IN(RCA) RCA audio jack for RCA input.
  • Page 25 Install Manual SENSOR IN Connection terminal for sensor input. AUDIO IN(D-SUB) Connection terminal for audio output D-SUB. D-I/O Connection terminal for DIGITAL IN/OUT.
  • Page 26 Install Manual 2.2.2.2 SVR-1680C, SVR-1660C, SVR-1645 Input/Output Function terminal name POWER IN Socket for AC 100V ~ AC 240V power cord. CH1~16 Connection terminal for camera BNC input. LOOP OUT Connection terminal for camera BNC output (loop). MONITOR 1 ~ 2 Connection terminal for monitor BNC output.
  • Page 27 Install Manual 2.2.2.3 SVR-960C Input/Output Function terminal name POWER IN Socket for AC 100V ~ AC 240V power cord. GROUND Ground terminal between DVR and external device. CH1~9 Connection terminal for camera BNC input. LOOP OUT Connection terminal for camera BNC output (loop).
  • Page 28 Install Manual 2.2.2.4 SVR-945 Input/Output Function terminal name CH1~9 Connection terminal for camera BNC input. LOOP OUT Connection terminal for camera BNC output (loop). MONITOR 1 ~ 2 Connection terminal for monitor BNC output. AUDIO IN(RCA) RCA audio jack for RCA input. AUDIO OUT Audio jack for speaker output.
  • Page 29 Install Manual 2.2.2.5 SVR-480 Input/Output Function terminal name GROUND Ground terminal between DVR and external device. CH1~4 Connection terminal for camera BNC input. LOOP OUT Connection terminal for camera BNC output (loop). MONITOR 1 ~ 2 Connection terminal for monitor BNC output. AUDIO IN(RCA) RCA audio jack for RCA input.

  • Page 30: Remote Control

    Install Manual 2.2.3 Remote control All DVR unit features can be controlled with the remote controller; 16 units can be controlled with a single remote controller. Unit IDs should be set in the DVR Menu > Communication > Remote > Remocon ID. Classification Function Selects ID.
  • Page 31 Install Manual Classification Function (◀) Moves cursor left in setup menu. Moves cursor right in (▶) setup menu. (▲) Moves cursor up in setup menu. (▼) Moves cursor down in setup menu. ENTER Saves settings and execute. Cancels settings or navigates up in menu.

  • Page 32: Chapter 3. Installation

    Install Manual Chapter 3. Installation 3.1 Installation & Connection 3.1.1 Basic connection and operation 3.1.1.1 Camera connection Connect the DVR and CCTV cameras using coaxial cable as in the following figure. - The cameras’ video input type must be one and only of NTSC or PAL. Both types should not be used together.

  • Page 33: Audio Connection

    Install Manual 3.1.1.3 Audio connection Audio equipment connects to the DVR unit using RCA audio cables or D-SUB as shown in the following figure. SVR-480 does not support D-SUB audio. Refer to the following figure when connecting D-SUB. The audio inputs are pin numbers 5 ~ 16. 3.1.1.4 Power connection &...

  • Page 34: Osd Menu Structure & Operation

    Install Manual OSD Menu structure & Operation 3.2.1 Menu structure Press the [MENU] button on the front panel to change to setup mode and display the following dialog. Main menu Sub menu Setup dialog (1) Main menu: The currently selected tab is highlighted in blue with submenus and options displayed below.

  • Page 35: Remote Control Setup & Basic Operation

    Install Manual 3.2.1.1 Character input dialog box The characters input dialog lets you input text. Character input Use the cursor [▲/▼] and [◀/▶] keys to choose characters then press [Enter] to input it. Use [ ] to backspace, and [ ] to insert a space. When finished, press [Enter] to exit the character input dialog with the newly inputted value.
  • Page 36 Install Manual Remote Control ID supports a maximum of 16 IDs. For unused remote controllers, set Remote Control ID to Off. 3.2.2.2 Selecting IDs All DVR unit features can be controlled with the remote controller; 16 units can be controlled with a single remote controller.

  • Page 37: Example Of Installation Structure

    Connect the cameras, monitors and audio. 3.2.3.2 Extended connection diagram Connect the cameras, monitors, audio, sensors, relays and other peripherals. 3.2.3.3 External storage and backup connection diagram Connect a USB memory device or a “Samsung SVS-5E external HDD (eSATA)” unit.

  • Page 38: Basic Setup

    Install Manual 3.2.3.4 Internet/Intranet connection diagram 3.2.4 Basic setup 3.2.4.1 Video check The product automatically powers on when the power cord is plugged in. Once it finishes booting up, the default 16 channel split-screen is displayed. If a password for the unit has been set, the password input dialog is displayed. Only the numeric buttons work here and all others are temporarily disabled until the correct password is entered.
  • Page 39 Install Manual Time Zone (1) Press [◀/▶] or [▲/▼] to select “Time Zone”, and then press [Enter]. (2) Press [◀/▶] to set the correct Time Zone, and then press [ESC]. Daylight Saving (1) When selecting a Daylight Saving Time zone, Daylight Saving automatically changes to On, and is Off for other time zones.
  • Page 40 Install Manual The second is for selecting a month, week, and day to define the start and end times of DST. Date Format (1) Press [◀/▶] or [▲/▼] to select “Date Format”, and then press [Enter]. Press [◀/▶] to select a date format: YYYY/MM/DD, MM/DD/YYYY, or DD/MM/YYYY. (2) Press [ESC] to exit edit mode.

  • Page 41: Record Setup

    Install Manual (1) Press [◀/▶] or [▲/▼] to select “Apply Date / Time” and then press [Enter]. A confirmation dialog is displayed as shown below. (2) Press [◀/▶] or [▲/▼] to select “YES” and then press [Enter]. Press [ESC] to cancel the new date/time and return to the original value from before.

  • Page 42: Using Input/Output Terminals

    Install Manual Schedule Setup Select the “Schedule & Event” option, and set the Day & Time options. How to check the record status If the record setup is configured correctly, [REC LED] on the front panel will light up RED. Also, record status [S] will be displayed on the video screen. [S] indicates scheduled recording.
  • Page 43 Install Manual - Stranded wire: Strip 8 ~ 10㎜ of insulation off the end of the wire and solder it together. Use AWG 22 ~ 26 wire. - Solid wire: Strip 8 ~ 10㎜ of insulation off the end of the wire. Use AWG 20 ~ 26. 3.3.2 Wire insertion/removal When inserting/removing wires to/from the terminal block, push the driver as shown below and insert or remove the wire.
  • Page 44 Install Manual Sensor input terminal connection Connect sensors to S1 ~ S16 as illustrated in the figure below. Please note that the figure shows connecting sensors with dry contacts. Refer to the section on handling wiring for more information about connecting or disconnecting sensor wires. Sensor Settings (1) Press [Menu] and select “Event”...
  • Page 45 Install Manual Individual sensor This option allows setting each of the 16 sensor input types individually. (1) Select a sensor then press [Enter]. (2) Set the input type for the selected sensor. (3) Press [ESC] to exit to the OSD menu when you are finished. Sensor setup lets you choose whether or not to use sensors and their type, and Record &...
  • Page 46 Relays can be triggered by following events; alarm sensor, motion detection, video loss, hard disk fail, hard disk full, fan fail, password fail, and DDNS registration failure. Relays can also be triggered remotely over the network using the Samsung Network Video Management software.
  • Page 47 Install Manual as Relay out, the Output can be operated with digital I/O. Also, if Input is operated, the emergency recording is started. Then the emergency recording starts to record with the Event Record value. Specification The D-I/O specifications are as follows. No.
  • Page 48 Install Manual For more information, refer to the user manual. The user manual can be downloaded from www.samsungcctv.com or on the CD provided with the product. 3.3.3.4 Serial communication terminal connections & settings Serial communication terminal connection for Pan/Tilt/Zoom PTZ cameras for the DVR unit can be connected through the COM port, and supported models configured through the OSD menu.
  • Page 49 Install Manual Serial Comm. Terminal Connection Diagram COM1 connection diagram(RS-232) COM2 connection diagram (RS-422/485) RS-422(SVR-3200, 1680C, 1660C) RS-485(All SVR series )
  • Page 50 Install Manual COM3 connection diagram (RS-232) PTZ, Keyboard Compatible List Model Manufacturer SDZ160/330, Samsung SPD SAMSUNG TECHWIN Keyboard SCC3000, Samsung SRX-100B BOSCH AutoDome, TC8560X-4 BOSCH PELCO(P), PELCO(D) PELCO Honeywell 755/655, HRX-2000, ScanDome2 HONEYWELL Sony EVI-D3x SONY VT VPT-4x AD SpeedDome SungJin SJ372R1’...
  • Page 51 Install Manual Tokina TOKINA Kodicom KRE KODICOM Nuvico NUVICO Serial Settings A total of four serial ports are available for the DVR. Two are RS-232C(Com1, Com3) and the other two are RS-422/485(Com2, Com4). The Serial Port settings are available under Communication > Remote. The following options are provided for the Serial Port settings.
  • Page 52 Install Manual Type Select a serial port. Protocol Select a connected PTZ device. Camera ID Enter the ID of the selected camera. Interface Select one from among Com2 to 4. To use RS-232, select Com3. For RS-422 or 485, select Com2 or 4. Baud rate/Parity/Stop Bit/Data Bit Enter the same settings as the ones for the PTZ device.
  • Page 53 Install Manual Type Select Coax. Protocol Select Pelco or Pelco Extended according to the coax protocol type of Pelco camera. AD Dome does not support menu control, Presets or AUX when setup with a coax protocol. Idle Time Activate or disable PTZ Home, and setup a standby duration of the device before moving to PTZ home.
  • Page 54 Install Manual Serial Settings (COM1) (1) In the OSD menu, navigate to Communication > Serial. (2) Set the “Serial Number” option to COM1 for text. (3) Set the Baud Rate/Parity/Stop bit/Data bit options identical to the Input device. Text Settings (1) On the OSD menu, select Event Setup >...
  • Page 55 The storage device should be formatted with the FAT32 file system. Supported storage devices are automatically recognized when copying. To copy video, set copying options in the Copy dialog, select the storage device, then copy the data. [CD/DVD Copy] [RE4 Copy] Select the channel to copy. [SVR-960C/945] [SVR-1680C/1660C/1645] [SVR-3200]...
  • Page 56 Install Manual [AVI Copy] Some USB storage devices may require additional software and drivers. Care should be taken in these cases as the DVR may not recognize some USB products like this. If copied files do not playback on another computer, double check that proper playback software and codecs are installed.

  • Page 57: External Storage Connections

    One eSATA external storage device can be connected through the eSATA port in the back of the DVR unit for a maximum of 8TB of storage space. The eSATA port only supports the “SVS-5E” eSATA external HDD from Samsung Techwin.
  • Page 58 Install Manual 1. Turn DVR power OFF. 2. Connect external device and eSATA interface cable. 3. Turn external device power ON. 4. Turn DVR Power ON. 3.3.4.3 Supported HDD Refer to the appendix in the back of the manual for information on supported HDDs. 3.3.4.4 Registering &...
  • Page 59 Install Manual Once the HDD is attached with the screws, insert it into an HDD bracket. For the location of HDDs, IntA is the bottom right, IntB is the upper right, IntC is the bottom left, and IntD is the upper left. The following picture shows an HDD being inserted to IntA.
  • Page 60 Install Manual After inserting the HDD, fasten the HDD fixture bracket as shown in the picture below. Now the HDD is fully attached to the product.
  • Page 61 Install Manual To enable the newly attached HDD, you must change the availability of the HDD to "Yes" under the DVR Disk menu. To access the menu, go to Menu > System Settings > Disk > Disk Manager. The newly attached HDD will display in the HDD list with No in the Availability pane. To change the availability, place the cursor on No and then press Enter.
  • Page 62 Install Manual Detaching HDD Detaching an HDD is the same as attaching it, but in reverse order. Loosen the HDD fixture bracket. Unplug the SATA and power cables. Detach the HDD. When detaching an HDD, first lift up the back part of the HDD with the SATA port, and then the front part.
  • Page 63 Install Manual Go to Menu > System Settings > Disk > Disk Manager. Select the detached HDD, and the press Enter. Select "Yes" in the dialog window and remove the HDD from the HDD list.

  • Page 64: Remote Monitoring & Control

    Install Manual 3.3.5 Remote monitoring & control Connections can be made through Internet/Intranet by using the remote computer. This connection can be used to control DVRs and monitor areas same as local spot. 3.3.5.1 Ethernet connection (1) Shut the DVR power off. (2) Connect the Ethernet cable to the DVR and hub or router.
  • Page 65 Install Manual When using Ethernet Set the type to Ethernet and fill in the IP address, Netmask, Gateway, and DNS information provided by your network administrator. Use Up/Down direction keys or the mouse wheel to select the items, and then setup with the appropriate values. When using PPPoE Change the network configuration type to xDSL then navigate to the xDSL menu.

  • Page 66: Trouble Shooting

    Install Manual Trouble Shooting 1. DVR does not boot Check power Check power cord 2. Monitor does not display camera video Check monitor power Check cable between the monitor and DVR Check monitor cable port Check that DVR power is on 3.
  • Page 67 Install Manual 8. Front buttons do not work Check DVR power Check screen lock status 9. Cannot connect to network Check that network cable is properly connected Check DVR IP address Check PC IP address Run a ping test 10. When to contact your reseller If any of the following happen, immediately turn of the DVR and contact the reseller that you purchased it from.

  • Page 68: Compatible Hdd List

    SVR-1680C/1660C/1645 : 16 composite video 0.5–2 Vpp, 75 ohm automatic termination Inputs Video SVR-960C/945 : 9 composite video 0.5–2 Vpp, 75 ohm automatic termination SVR-480 : 4 composite video 0.5–2 Vpp, 75 ohm automatic termination Resolution 704x480 NTSC...
  • Page 69 Recording SVR-3200 : 480fps@704x480, 960Cfps@704x240, Record Rate/NTSC 960Cfps@352x240 SVR-1680C : 480fps@704x480, 480fps@704x240, 480fps@352 x 240 SVR-1660C/1645 : 120fps@704x480, 240fps@704x240, 480fps@352x240 SVR-960C/945 : 120fps@704x480, 240fps@704x240, 270fps@352x240 SVR-480 : 120fps@704x480, 120fps@704x240, 120fps@352x240 SVR-3200 : 400fps@704x576, 800fps@704x288, 800fps@352x288 SVR-1680C : 400fps@704x576, 400fps@704x288, 400fps@352x288...
  • Page 70 Display switching), 1 Vp-p, 75 ohm SVR-3200 : None SVR-1680C/1660C/1645 : 16 Output, 1 Vpp, 75 Loop Outputs SVR-960C/945 : 9 Output, 1 Vpp, 75 ohm SVR-480 : 4 Output, 1 Vpp, 75 ohm SVR-3200/1680C/1660C/1645 : 16 input, 30k ohm Inputs...
  • Page 71 2 USB 2.0 ports SVR-3200/1680C/1660C : External eSATA 2 port eSATA SVR-1645/960C/945/480 : External eSATA 1 port Application Support ATM/POS, Mouse, Remote Controller Samsung Techwin, Pelco D, Pelco P, Pelco Dome Supported PTZ cameras Coaxitron, Panasonic, Bosch, SEC Protocols General Input Voltage 100 to 240 VAC ±10%;...

  • Page 72: Dimensions

    Install Manual Dimensions SVR-3200, SVR-1680C, SVR-1660C, SVR-1645...
  • Page 73 Install Manual SVR-960C...
  • Page 74 Install Manual SVR-945...
  • Page 75 Install Manual SVR-480...
  • Page 76 The program can be obtained from us for a period of three years after our last distribution of this product by sending email to help.cctv@samsung.com. If you want to obtain the complete Corresponding Source Code in the physical medium such as CD-ROM by airmail, the cost of physically performing source distribution might be charged.
  • Page 77 Install Manual Also, for each author's protection and ours, we want to make certain that everyone understands that there is no warranty for this free software. If the software is modified by someone else and passed on, we want its recipients to know that what they have is not the original, so that any problems introduced by others will not reflect on the original authors' reputations.
  • Page 78 Install Manual charge to all third parties under the terms of this License. c) If the modified program normally reads commands interactively when run, you must cause it, when started running for such interactive use in the most ordinary way, to print or display an announcement including an appropriate copyright notice and a notice that there is no warranty (or else, saying that you provide a warranty) and that users may redistribute the program under these conditions, and telling the user how to view a copy...
  • Page 79 Install Manual such an offer, in accord with Subsection b above.) The source code for a work means the preferred form of the work for making modifications to it. For an executable work, complete source code means all the source code for all modules it contains, plus any associated interface definition files, plus the scripts used to control compilation and installation of the executable.
  • Page 80 Install Manual could satisfy both it and this License would be to refrain entirely from distribution of the Program. If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the section is intended to apply and the section as a whole is intended to apply in other circumstances.
  • Page 81 Install Manual AND/OR OTHER PARTIES PROVIDE THE PROGRAM "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU.
  • Page 82 Install Manual An "Application" is any work that makes use of an interface provided by the Library, but which is not otherwise based on the Library. Defining a subclass of a class defined by the Library is deemed a mode of using an interface provided by the Library. A "Combined Work"...
  • Page 83 Install Manual The object code form of an Application may incorporate material from a header file that is part of the Library. You may convey such object code under terms of your choice, provided that, if the incorporated material is not limited to numerical parameters, data structure layouts and accessors, or small macros, inline functions and templates (ten or fewer lines in length), you do both of the following: a) Give prominent notice with each copy of the object code that the Library is used in it and...
  • Page 84 Install Manual 1) Use a suitable shared library mechanism for linking with the Library. A suitable mechanism is one that (a) uses at run time a copy of the Library already present on the user's computer system, and (b) will operate properly with a modified version of the Library that is interface-compatible with the Linked Version.
  • Page 85 Install Manual Each version is given a distinguishing version number. If the Library as you received it specifies that a certain numbered version of the GNU Lesser General Public License "or any later version" applies to it, you have the option of following the terms and conditions either of that published version or of any later version published by the Free Software Foundation.
  • Page 86 Install Manual...
  • Page 87 Install Manual...
