Trane DFIA Programming Manual

Direct-fired indoor and outdoor make-up air units

Advertisement

Controls Programming Guide
Direct-Fired Indoor and Outdoor Make-Up
Air Units
DFIA
DFOA
January 2007
MUA-SVP01A-EN

Advertisement

Table of Contents
loading

Summary of Contents for Trane DFIA

  • Page 1 Controls Programming Guide Direct-Fired Indoor and Outdoor Make-Up Air Units DFIA DFOA MUA-SVP01A-EN January 2007...
  • Page 2 A glossary has been provided to assist the reader in understanding distinctive terms and phrases. These terms and phrases appear in italics. Trane's Digital Control System, AdaptAire, is designed to give the user the ultimate in unit performance and operational flexibility, adaptability, and reliability in a user-friendly package.
  • Page 3: Networking

    NETWORKING AdaptAire is adaptable to a variety of different network architectures and protocols. Each controller has built-in protocol translation and can be configured for operation on ARCnet156 or EIA-485 communication networks. See Appendix IV for specific controller specifications. The AdaptAire system can be connected to most existing building automation systems.
  • Page 4 Table 1. Default settings (continued) ITEM DEFAULT RANGE Low Input Value -9999.99 – 99999.99 User Control Setpoint -9999.99 – 99999.99 Maximum User Setpoint -9999.99 – 99999.99 Minimum User Setpoint -9999.99 – 99999.99 Direct-Fired Indoor and Outdoor Units • MUA-SVP01A-EN...
  • Page 5: Table Of Contents

    Contents NETWORKING ........... . 3 ADAPTAIRE DEFAULT SETTINGS .
  • Page 6 Contents ALARM ..........HOTKEY - 1 .
  • Page 7: Unit Operating Modes

    Unit Operating Modes There are three different modes that control the supply fan and unit operation: • • Manual • Auto There are also four different methods for controlling the operating modes: • "a remote panel with two rotating knob adjustments (MDT and MRT controls) •...
  • Page 8: Mrt Controls

    Unit Operating Modes MRT Controls: MRT, modulating room temperature, is the most basic AdaptAire control for room temperature. The MRT control system includes a remote control panel equipped with 1 or 2 potentiometers, 3 or more pilot lights, and up to 2 switches. UNIT OFF MODE Off Mode is the default unit operational mode.
  • Page 9 Unit Operating Modes UNIT MANUAL MODE Manual Mode allows the unit to turn on regardless of the Time Clock or Night Setback functions. A BACview or PC is required to change to this mode. See the section related to the MRT Expert for instructions on how to use the BACview for programming.
  • Page 10: Mrt-Expert Controls

    Unit Operating Modes to be "off" and the Cooling Night Setback function turns the unit "on", the unit will be cycled "off" once the room air temperature has fallen 2° below the Cooling Night Setback setpoint. The default for this setpoint is 100°F and is fixed at 27° above the Cooling setpoint.
  • Page 11 Unit Operating Modes for up to 4 separate On/Off events with any combination of days. The normal schedule sets the typical On/Off times for the unit. The holiday schedule can be programmed for up to 12 separate On/Off events with any combination of days. The holiday schedule sets the Off times for holidays and other shutdown periods.
  • Page 12: Heating/Ventilating/Cooling Operating Modes

    Unit Operating Modes function is activated whenever a contact is closed between the appropriate terminals on the unit's terminal strip located in the unit's main control panel. Heating and cooling functions use the Night Setback Setpoints. See the Typical Wiring Schematic and Multiplexed Input sections of this manual for more information.
  • Page 13 Unit Operating Modes Setpoint. The allowable temperature range is 55°F - 130°F . This sets the highest discharge air temperature that will leave the unit. If the maximum and minimum discharge temperature setpoints are set for the same temperature, the supply air temperature will be the same as the setpoint regardless of the room temperature setpoint or actual room temperature.
  • Page 14: Ventilation Mode

    Unit Operating Modes with internal heat gain. In certain conditions it may be necessary to readjust the minimum discharge air or room temperature setpoint upward or adjust the outside/return air ratio to provide a warmer supply air temperature. Energy Savings Mode 1—Non-Recirculating Units. Energy Savings Mode 1 will automatically disable the burner if the outside air temperature is equal to or greater than the minimum discharge air temperature setpoint, and the room air temperature is 5°F above the room air temperature setpoint.
  • Page 15: Cooling Mode

    Unit Operating Modes line downward. If the room temperature falls to a temperature that is 2°F below the heating setpoint, the heating will be enabled, and the unit will be in the heating mode. Continue following the solid line in a clockwise direction to the heating setpoint.
  • Page 16: Damper Control Modes

    Unit Operating Modes To change the desired cooling room temperature of an MRT-Pro control system, depress the Warmer button to increase the desired room temperature setpoint or depress the Cooler button to decrease the desired room temperature setpoint. Each push of a button changes the temperature setpoint by 1°F . The setpoint can be changed a maximum of ±10°F from the default of 72°F .
  • Page 17 Unit Operating Modes operating in the heating mode, the unit will automatically keep the minimum outside air at 20%. If the outside air drops below 20%, the burner will cycle off. See Minimum Ventilation. MRT-Pro Controls. To change the damper mode on an MRT-Pro control system requires the use of a BACview or PC.
  • Page 18 Unit Operating Modes Building Pressure Mode The Building Pressure mode varies the percentages of outside air and return air to maintain a constant pressure within the space. A pressure transducer compares the pressure outside the space to the pressure inside the space and transmits a corresponding signal to the AdaptAire controller.
  • Page 19: Functions

    Functions 100% Outside Air The 100% Outside Air function automatically opens the outside air dampers and closes the return air dampers. This function is activated whenever a contact is closed between the appropriate terminals on the unit's terminal strip located in the unit's main control panel.
  • Page 20: User Configured Pid Control

    Functions User Configured PID Control This function is applicable to non-recirculating units only. The User Configured PID Control function allows the user to control an analog output based on a user defined analog input and setpoint. See the Typical Wiring and Unit Controller Specification sections of this manual for more information regarding the inputs and outputs.
  • Page 21 Functions to the Max User setpoint. In this situation the output value is the greater of the PID output or the override output. If the input variable is below the User Control setpoint, the output could decrease from 100% to 0% as the input variable decreases from the User Control setpoint to the Min User setpoint.
  • Page 22: Reverse Acting

    Functions Figure 2. Direct acting Max User SP 100% 80ºF override scaler 75ºF > 0-100% User Ctrl SP 75ºF PID 0-100% Output < 75ºF 100% override scaler Min User SP 70ºF REVERSE ACTING The controller output AO-1 is modulated by a PID loop from 0% to 100% based on the User Control setpoint and the input signal to IN-9.
  • Page 23 Functions pressure to be+0.03" but does not want it to drop below 0.0" or go above +0.05". The parameters entered on the keypad display will be: PID Select Reverse (as input increases output decreases) High Input Val Low Input Val -0.10 User Ctrl SP 0.03...
  • Page 24: Unit Resets

    Functions Unit Resets This section should assist the user in resetting alarms and cycle counters which have been displayed on the BACview. ALARM. To reset an alarm scroll through the menu tree, locate the Unit Resets branch and select Alarm. Press the Enter key. The word OFF should flash. Now press the INC key and the word ON should flash on the display.
  • Page 25: Clock Set

    Functions input. A switch is used in conjunction with each resistor. When a switch is closed, the resistance at the controller input changes. This allows the controller to identify which switch has closed. The controller is programmed to associate each different resistance with a specific function.
  • Page 26: Diagnostics

    Diagnostics Critical Fault Codes This section should assist the user in troubleshooting critical fault codes messages that have been displayed on the local user interface. These faults require the operator to correct the condition and reset the alarm before normal unit operation resumes.
  • Page 27 Diagnostics valve closest to the burner and measure the discharge air temperature. Is it less than 130°F? – Yes. There is a problem with the controller program or controller itself. Contact the factory. – No. The outside air temperature is too hot to determine the actual cause of the problem.
  • Page 28 Diagnostics SOLUTION: If burner was not operating prior to shutdown (check prior alarm log) Is there a prior alarm such as Safety Ckt., Airflow Sw., or Flame Failure? – Yes. See the Diagnostic section for the previous alarm. – No. Continue. 2.
  • Page 29 Diagnostics – Yes. This signal is fed to the signal conditioner. Disconnect the wires from the signal conditioner's input signal terminals and measure the voltage on the wires. Is it the same as the voltage coming from the controller? – No. There is an open in the wiring from the controller output. Correct wiring and reconnect the wires to the terminals on the signal conditioner.
  • Page 30 Diagnostics – No. See the Diagnostic section for Unit On/Fan Off. – Yes. Continue. SOLUTION:If fan is running (check prior alarm log) Is the high temperature limit tripped? – Yes. Determine cause and rectify. – No. Continue. 2. Is the low gas pressure switch closed? –...
  • Page 31: Fault Code: Burner Hand

    Diagnostics – No. Continue. 2. Is the burner enable relay energized? – No. There is an open in the 24VAC circuit. Determine cause and rectify. – Yes. Continue. 3. Is the burner enable relay's normally open contact closed? – No. Replace relay. –...
  • Page 32: Fault Code

    Diagnostics 2. Are the main automatic gas shutoff valves energized? – No. The main automatic gas shutoff valves are leaking. Turn off unit and close manual gas valves. Determine cause of valve failure and rectify. – Yes. Continue. 3. Is the flame relay energized? –...
  • Page 33 Diagnostics FAULT CODE: Unit off/Fan on PROBLEM: The controller has not activated the unit enable output to start the fan, but the fan status input, is receiving a signal that the fan is running. This fault will automatically clear about 15 seconds after the fault is corrected. SOLUTION: If fan is running Is controller unit enable output LED for lit? –...
  • Page 34 Diagnostics – Yes. There is a short in the wiring between these terminals. Determine cause and rectify. – No. Replace controller. FAULT CODE:Unit on/Fan off PROBLEM:The controller has activated the unit enable output to start the fan, but the fan status input, is not receiving a signal that the fan is running. This fault will automatically clear about 60 seconds after the fault is corrected.
  • Page 35 Diagnostics – Yes. Continue. 3. Is the unit enable relay energized? – No. There is an open in the wiring between these terminals. Determine cause and rectify. – Yes. Continue. 4. Is the unit enable relay's normally open contact, closed? –...
  • Page 36 Diagnostics SOLUTION:If low airflow switch is opening. Do not adjust the switch setpoints Does low airflow switch open when the burner is off – No. Disconnect both pressure sensing tubes from one of the airflow switches and measure the differential pressure by connecting the high sensing port of a manometer to one of the airflow sensing tubes and the low sensing port to the other.
  • Page 37 Diagnostics – Yes. Clear and continue. – No. Continue. 3. Is the airflow switch setpoint properly adjusted? – No. Adjust setpoint. – Yes. Continue. 4. Are the wires connected to the air pressure switch's normally open contact? – No. Rewire switch and continue. –...
  • Page 38 Diagnostics – No. Continue. SOLUTION:If setpoints are not misadjusted Is there a prior alarm such as Insufficient OA? – Yes. See the Diagnostic section for the previous alarm. – No. Continue. 2. Is the discharge air temperature (DA Temp), displayed on the BACview remote, reading 150°F or more? –...
  • Page 39 Diagnostics equal to the %OA setpoint. However, at 20% OA the dampers should be at least ½" open. – Yes. Continue. – No. Check the damper motor and linkage connections. When 24VAC is powering the damper actuator and the control signal is 0VDC, the outside air damper should be close to a "rattle tight"...
  • Page 40 Diagnostics SOLUTION: If OAT, RoomT or DAT are such that heat is required Is the outside air temperature (OA Temp), displayed on the BACview remote, reading 150°F or more? – Yes. The outside air sensor circuit or the sensor itself is shorted. Unplug the input jack from the AdaptAire controller.
  • Page 41 Diagnostics 4. Do the dampers track with a change in the %OA setpoint? The dampers utilized on the unit are not linear with respect to airflow and openness, and as such, the proportion of outside air damper movement will not be exactly equal to the %OA setpoint.
  • Page 42 Diagnostics – Yes. The AdaptAire control system must be in the Heating mode. In this mode the smallest allowable amount of outside air is 20%. Verify the system is in the Heating mode and the MIN VENT SP is set for 20%. See Heating/Cooling Mode and Minimum Ventilation Sections of this manual.
  • Page 43: Menu Selection

    Menu Selection Menu Selection Tree for BACview This section will assist the user in navigating the menu functions of the control program. For convenience Hotkeys are provided to allow the user to jump directly to a specific menu heading. Simply press and hold the FN key. While holding the FN key, press the number key of the desired menu, and it will appear.
  • Page 44: Set Points Hotkey - 3

    Menu Selection Status Alarm SET POINTS HOTKEY - 3 Htg Occupied °F range 55-90 Htg Setback °F range 40-80 Htg Min DA °F range 40-130 Htg Max DA °F range 55-130 Clg Occupied °F range 61-96 Clg Setback °F range 75-130 Clg Min DA °F range 40-130...
  • Page 45: Status Menu

    Menu Selection STATUS MENU HOTKEY - 4 Note: The Status Menu always displays the current status of the fan, burner and cooling. Room Temp °F OA Temp °F DA Temp °F MA Temp °F Outside Air Bldg Pres "wc Fan Cycles Fan Hours Bnr Cycles Bnr Hours...
  • Page 46: Schedules Hotkey

    Menu Selection Home Schedules Clock Set Help SCHEDULES HOTKEY- 7 Daily – Schedule1 (typical 1 through 4) – Use — yes/no – Start Time — hr:min – Stop Time— hr:min – DAYS — SUN, MON, TUE, WED, THU, FRI, SAT –...
  • Page 47: Clockset - 0

    Menu Selection Low Output Value User Control Setpoint Maximum User Setpoint Minimum User Setpoint Previous Home Setpoints Help CLOCKSET HOTKEY - 0 Time hh:mm:ss Date dd-mm-yy Previous – Enable No/Yes – Sou Hem No/Yes – 06Beg Apr /02 – 06End Oct /29 –...
  • Page 48: Fuel Select Hotkey

    Menu Selection Alarm Fuel Select FUEL SELECT HOTKEY - 9 Fuel Type Natural Gas/Propane Login Home Previous Unit Modes Direct-Fired Indoor and Outdoor Units • MUA-SVP01A-EN...
  • Page 49: Thermostat Output Curve

    Thermostat Output Curve 10 K Ohms Thermistor Output Curve Figure 5. Uses FG.figure# Typical 10,000 Ohm Thermistor Output Curve 180000 170000 160000 150000 140000 130000 120000 110000 100000 90000 80000 70000 60000 50000 40000 30000 20000 10000 104 113 122 131 140 149 Temperature in Degrees F Figure 6.
  • Page 50: Airflow Station Layout

    Airflow Station Layout Figure 7. Airflow station layout MUA-SVP01A-EN • Direct-Fired Indoor and Outdoor Units...
  • Page 51: I/O Zone 583 Controller Specifications

    I/O Zone 583 Controller Specifications POWER REQUIREMENTS. 24VAC ± 10%, 20VA NETWORK COMMUNICATION BACnet (native), Modbus RTU, or N2 bus at up to 76.8K baud or 156K baud over ARCnet. LonWorks using plug-in communications board. USER INTERFACE MDT: modulating discharge temperature control with manually adjusted potentiometer at remote panel.
  • Page 52 I/O Zone 583 Controller Specifications – LED indication • 3 Analog Outputs – 0 - 10 VDC OUTPUT ASSIGNMENTS - ANALOG AO1 Burner firing rate (to signal conditioner) 0 - 10 VDC AO2 RA or Mixing Damper Control/ User Configured 0 - 10VDC AO3 Unassigned OUTPUT ASSIGNMENTS - DIGITAL DO1 Unit Enable...
  • Page 53: Typical Wiring Schematic

    Typical Wiring Schematic Figure 8. Non-recirculating with evap DFOA and DFIA model diagram MUA-SVP01A-EN • Direct-Fired Indoor and Outdoor Units...
  • Page 54 Typical Wiring Schematic Figure 9. Non-recirculating with evap DFOA and DFIA model diagram Direct-Fired Indoor and Outdoor Units • MUA-SVP01A-EN...
  • Page 55 Typical Wiring Schematic Figure 10. Recirculating DFOA and DFIA model diagrams MUA-SVP01A-EN • Direct-Fired Indoor and Outdoor Units...
  • Page 56 Typical Wiring Schematic Figure 11. Recirculating DFOA and DFIA model diagram Direct-Fired Indoor and Outdoor Units • MUA-SVP01A-EN...
  • Page 57 Typical Wiring Schematic MUA-SVP01A-EN • Direct-Fired Indoor and Outdoor Units...
