G36D Zero Clearance Direct Vent Gas Fireplace
WARNING: If the information in these instructions are not followed exactly,
a fi re or explosion may result causing property damage, personal injury
or loss of life.
FOR YOUR SAFETY:
vapors and liquids in the vicinity of this or any other appliance. Installation
and service must be performed by a qualifi ed installer, service agency or
the gas supplier.
This appliance may be installed in an aftermarket, permanently located,
manufactured home (USA only) or mobile home, where not prohibited by
local codes. This appliance is only for use with the type of gas indicated on
the rating plate. This appliance is not convertible for use with other gases,
unless a certifi ed kit is used.
Tested by:
918-156b
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
MODELS:
G36D-NG Natural Gas
Do not store or use gasoline or other fl ammable
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
www.regency-fi re.com
G36D-LP Propane
Owners &
Installation Manual
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance.
Do not touch any electrical switch:
do not use any phone in your building
Immediately call your gas supplier
from a neighbour's phone. Follow the
gas supplier's instructions.
If you cannot reach your gas supplier,
call the fi re department.
01/04/06
Advertisement
Table of Contents
Related Manuals for Regency ULTRAGLOOW G36D-LP
Summary of Contents for Regency ULTRAGLOOW G36D-LP
- Page 1 Owners & G36D Zero Clearance Direct Vent Gas Fireplace Installation Manual MODELS: G36D-NG Natural Gas G36D-LP Propane WARNING: If the information in these instructions are not followed exactly, FOR YOUR SAFETY a fi re or explosion may result causing property damage, personal injury What to do if you smell gas: or loss of life.
- Page 2 As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions and the many features of your Regency Fireplace.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Page Page Safety Label Operating Instructions Safety Label ............... 4 Operating Instructions ..........32 Lighting Procedure ........... 32 Installation Shutdown Procedure ..........32 First Fire ..............32 Important Message ............. 5 Aeration Adjustment ..........32 Before You Start ............5 Normal Operating Sounds of General Safety Information ........ -
Page 4: Safety Label
SAFETY LABEL This is a copy of the label that accompanies each G36D Zero Clearance Direct Vent Gas Fireplace. We have printed a copy of the contents here for your review. The safety label is located on the front inside base of the unit, visible when the bottom louver is open. -
Page 5: Installation
INSTALLATION 14) Under no circumstances should any solid IMPORTANT: CLOTHING OR OTHER FLAMMABLE fuels (wood, paper, cardboard, coal, etc.) SAVE THESE MATERIAL SHOULD NOT BE PLACED be used in this appliance. ANCE. ON OR NEAR THE APPLI INSTRUCTIONS 15) The appliance area must be kept clear and free of combustible materials, (gases and other fl... -
Page 6: Locating Your Gas Stove
INSTALLATION This includes: MANUFACTURED 5) This appliance is Listed for bedroom instal- MOBILE HOME 1) Clocking the appliance to ensure the correct lations when used with a Listed Millivolt fi ring rate (rate noted on label 26,000 Btu/h) Thermostat. Some areas may have further ADDITIONAL after burning appliance for 15 minutes. -
Page 7: Clearances
INSTALLATION 2) Frame in the enclosure for the unit with CLEARANCES MANTEL LEG framing material. The framed opening is CLEARANCES 37-1/4" high x 36-1/4" wide x 17-3/8" deep The clearances listed below are Minimum (946mm high x 921mm wide x 441mm distances unless otherwise stated: deep). -
Page 8: Combustible Mantel Clearances
INSTALLATION COMBUSTIBLE MANTELS Because of the extreme heat this fi replace emits, the mantel clearances are critical. Combustible mantel clearances from top of unit are shown in the diagram below. Note: A non-combustible mantel may be installed at a lower height if the framing is made of metal studs covered with a non-combustible board. -
Page 9: Unit Assembly Prior To Installation
INSTALLATION 3) Attach the standoff securely to the top Top Header with 2 screws per standoff (on opposite 10"dia. h ol e corners). through w al l 1/2" fo r F le x Drywal l orfor DuraV ent "C" Screw Position: For a facing material depth of 1-1/4"... -
Page 10: Exterior Vent Termination Locations
INSTALLATION EXTERIOR VENT TERMINATION LOCATIONS UltraGlow G36D Zero Clearance Direct Vent Gas Fireplace... -
Page 11: Venting
9) screws #8 x 1-1/2" Drill Point, Stainless Steel (4) Notes: 1) Liner sections should be continuous without any joints or seams. 2) Only Flex pipe purchased from Regency may be used for Flex installations. UltraGlow G36D Zero Clearance Direct Vent Gas Fireplace... -
Page 12: Rigid Pipe Venting Components List
INSTALLATION RIGID PIPE VENTING COMPONENTS LIST All Simpson Dura-Vent components are available directly from FPI. Description Simpson Dura-Vent Selkirk Amerivent Direct VentGS Direct-Temp Direct Vent 6" Pipe Length, Galvanized 4DT-6 6" Pipe Length, Black 908B 4DT-6B 7" Pipe Length, Galvanized 7"... -
Page 13: Rigid Pipe Venting Systems
INSTALLATION RIGID PIPE VENTING SYSTEMS Horizontal or Vertical Terminations The minimum components required for a basic horizontal termination are: Flat Wall Installation Wall Thickness Vent Length Horizontal Termination Cap (inches) Required (inches) Elbow 4" 5-1/2" 6" Rigid Pipe Adaptor 7" 8-1/2"... -
Page 14: Venting - Horizontal Terminations
INSTALLATION RIGID PIPE VENTING ARRANGEMENTS - HORIZONTAL TERMINATIONS ULTRAGLOW DIRECT VENT SYSTEM (FLEX) (Propane & Natural Gas) The diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 90 elbow (two 45 elbows equal one 90 elbow). Note: Must use optional rigid pipe adaptor (Part # 510-994) when using rigid pipe vent systems. -
Page 15: Venting - Dura-Vent Horizontal Installations
INSTALLATION RIGID PIPE VENTING ARRANGEMENTS - HORIZONTAL TERMINATIONS ULTRAGLOW DIRECT VENT SYSTEM (FLEX) (Propane & Natural Gas) The diagram below shows examples of horizontal termination arrangements using two 90 elbows (two 45 elbows equal one 90 elbow). Note: A maximum of two 90 elbows are permitted. -
Page 16: Venting - Vertical Terminations
INSTALLATION RIDID PIPE VENTING ARRANGEMENTS - VERTICAL TERMINATIONS (Propane & Natural Gas) The G36D is approved for a maximum 23 ft. (7.0m) vertical, with a maximum 12 ft. (3.7m) horizontal offset using two 90 elbows (two 45 elbows equal one 90 elbow) with Rigid Pipe vent systems for Propane and Natural Gas, as per diagram 1. - Page 17 INSTALLATION The G36D is approved for a maximum 37 ft. (11.3m) straight vertical, with Rigid Pipe vent systems for Propane and Natural Gas, as per the diagram 3. The shaded area in the diagram 3 shows all allowable combinations of straight vertical and offset to vertical terminations with Rigid Pipe vent systems for Propane and Natural Gas.
-
Page 18: Vertical Terminations - Co-Linear Flex System
INSTALLATION VERTICAL TERMINATION WITH CO-LINEAR FLEX SYSTEM THE APPLIANCE MUST NOT BE Masonry chimneys may take various contours which the fl exible liner will accommodate. However, CONNECTED TO A CHIMNEY FLUE keep the fl exible liner as straight as possible, avoid unnecessary bending. SERVING A SEPARATE SOLID FUEL BURNING APPLIANCE. -
Page 19: Venting Arrangements
INSTALLATION Venting Arrangements - Vertical Terminations with Co-linear Flex System for both Residential & Manufactured Homes into Masonry Fireplaces The shaded area in the diagrams show the allowable vertical terminations. UltraGlow G36D Zero Clearance Direct Vent Gas Fireplace... -
Page 20: Horizontal Installations
INSTALLATION b) Horizontal runs of vent must be HORIZONTAL supported every three feet. Wall straps INSTALLATIONS are available for this purpose. 5) Mark the wall for a 10" x 10" square hole. Install the vent system according to the The center of the square hole should line manufacturer's instructions included with up with the centerline of the horizontal pipe. - Page 21 INSTALLATION VERTICAL 4) Assemble the desired lengths of pipe and TERMINATION elbows. Ensure that all pipes and elbow connections are in the fully twist-locked position and sealed. 1) Maintain the 1-1/2" clearances (air spaces) to combustibles 5) Cut a hole in the roof centered on the small when passing through ceilings, drilled hole placed in the roof in Step 2.
-
Page 22: System (Flex)
INSTALLATION in Diagram 5 or local codes. Note that for 4) Separate the 2 halves of the wall thimble and steep roof pitches, the vertical height must be securely fasten the one with the tabs to the increased. A poor draft, or down drafting can Note: To make the outside wall making sure that the tabs are result from high wind conditions near big trees... -
Page 23: System Data
Burner Inlet Orifi ce Sizes: label. Note: If you have an incorrect fl ame pat- tern, contact your Regency dealer Max. Input Rating 26,000 Btu/h 6) When fi nished reading manometer, turn for further instructions. -
Page 24: Conversion To Propane
INSTALLATION CONVERSION KIT FROM NATURAL GAS TO PROPANE MODEL #290-969 FOR G36D USING SIT 820 NOVA GAS VALVE THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! 8) Remove burner orifi ce with a 1/2" wrench Conversion Kit Contains: and discard. -
Page 25: Log Set Installation
INSTALLATION LOG SET INSTALLATION Read the instructions below carefully and refer to the diagrams. If logs are broken do not use the unit until they are replaced. Broken logs can interfere with the pilot operation. The gas log kit (Part # 780-930) contains the following pieces: a) 02-75 Rear Log 902-277... - Page 26 INSTALLATION 8) Place Log 02-52 between Logs 02-51 and 02-75 and on the indenta- 6) Position Log 02-54 across the cutouts in Logs 02-51 and 02-53. The tion on Log 02-54. The bottom right end sits behind the rear grate notch in the bottom right end fi...
- Page 27 INSTALLATION 10) Place the embers on the front of the burner tray in the places shown 11) Test fi re to ensure proper light off (make sure fl ame fl ows smoothly on the photos below. from one end of burner to the other). If there is any fl ame hesitation, check that area for any blockage of the burner ports.
-
Page 28: Flush Door - Standard
INSTALLATION STANDARD FLUSH Use the hook to pull the spring out until you Flush Louvers can put the hook into the slot on the bottom DOOR door bracket. Repeat for 2nd spring. 1) Install each top by clipping the louver lip diagram 3. -
Page 29: Remote Control (Optional)
INSTALLATION Option 1: Option 3: Option 2: REMOTE CONTROL WALL THERMOSTAT WALL SWITCH A wall thermostat may be installed if desired, connect the wires as per the wiring diagram. 1) Run the wire through the right or left side inlet Use the UltraGlow Remote Control Kit approved Use the table below to determine the maximum opening. -
Page 30: Wiring Diagram
INSTALLATION WIRING DIAGRAM This heater does not require a 120V A.C. supply for operation. In case of a power failure, the burner switch and the optional remote control/thermostat will continue to operate. (Do not cut the ground terminal off under any circumstances.) Caution: Ensure that the wires do not touch any hot surfaces and are away from sharp edges. -
Page 31: Fan Installation (Optional)
INSTALLATION INSTALLING THE OPTIONAL FAN 120 Volt AC power is needed for the fan switch Note: A 120 Volt AC power cord can be in- To Remove the Fan and blower. A three wire power cord is provided stalled at rough-in stage so that the to be plugged into the receptacle. -
Page 32: Operating Instructions
"OFF" position to turn off the pilot. under warranty. 3) Turn off all electric power to appliance if Note: Aeration Adjustment should only be service is to be performed. performed by an authorized Regency Installer at the time of installation or service. FIRST FIRE LIGHTING PROCEDURE The fi... -
Page 33: Normal Operating Sounds Of Gas Appliances
OPERATING INSTRUCTIONS NORMAL OPERATING Copy of the Lighting Plate Instructions SOUNDS OF GAS APPLIANCES It is possible that you will hear some sounds from your gas appliance. This is perfectly normal due to the fact that there are various gauges and types of steel used within your appliance. -
Page 34: General Vent Maintenance
MAINTENANCE 4) Make a periodic check of burner for proper Clean any fi ngerprints off before turning the WARNING: Do not operate the appliance position and condition. Visually check the unit on. If the top louvers start to discolour, with the glass panels removed, cracked fl... -
Page 35: Removing Valve
MAINTENANCE 11) Remove the 12 Phillips head screws securing REMOVING VALVE INSTALLING VALVE the valve tray assembly in place. 1) Shut off the gas supply. 1) Attach the valve to the valve bracket with the 4 (m5x8 metric) screws provided. 2) Remove louvers. -
Page 36: Parts List
PARTS LIST G36D MAIN ASSEMBLY Part # Description Part # Description 948-253 Door Handle 27) * Outer Flue Collar 510-026 Hinge Bracket - Left/Right 28) * Inner Flue Collar Assy 948-045 Chain 29) * Flue Mounting Plate 948-115 Spring 30) * Gasket for Flue Collar 34) * Firebox Tray... - Page 37 PARTS LIST G36D BURNER ASSEMBLY & LOG SET Part # Description 52) 910-190 Piezo Ignitor & Nut 53) 780-021 Gasket - Valve Access Plate NG/LP 786-574/P Valve Assy - Natural Gas 786-576/P Valve Assy - Propane 56) * Valve Tray - NG/LP 57) 910-378 Valve - S.I.T.
- Page 38 PARTS LIST G36D FLUSH FRONT ASSEMBLY Part # Description 131) 510-934 Flush Glass Trim (Set) - Brass 510-947 Flush Glass Trim (Set) - Steel 510-932 Flush Glass Trim (Set) - Gold 132) 904-196 Magnet (1" Round) 133) 780-069 Flush Louver - Top - Black 134) 786-520 Assembly - Bottom - Black 135) 940-334/P Glass - Tempered...
-
Page 39: Warranty
WARRANTY UltraGlow products, are designed with reliability and simplicity in mind. In addition, our internal Quality Assurance Team carefully inspects each unit thoroughly before it leaves our door. UltraGlow is pleased to extend this one year warranty to the original purchaser of a UltraGlow product. - Page 40 Register your UltraGlow online at http://www.regency-fi re.com Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Printed in Canada © Copyright 2006, FPI Fireplace Products International Ltd. All rights reserved.
