MVX Plus 128 VGA A
Computer video (VGA) and Audio Matrix Switcher
68-521-30 Rev. B
04 07

Advertisement

Table of Contents
loading

Related Manuals for Extron electronics MVX Plus 128 VGA A

Summary of Contents for Extron electronics MVX Plus 128 VGA A

  • Page 1 MVX Plus 128 VGA A Computer video (VGA) and Audio Matrix Switcher 68-521-30 Rev. B 04 07...
  • Page 2 Precautions Safety Instructions • English This symbol is intended to alert the user of important operating and maintenance (servicing) instructions in the literature provided with the equipment. This symbol is intended to alert the user of the presence of uninsulated dangerous voltage within the product’s enclosure that may present a risk of electric shock.

  • Page 3: Fcc Class A Notice

    FCC Class A Notice N This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense. N This unit was tested with shielded cables on the peripheral devices. Shielded cables must be used with the unit to ensure compliance. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation...
  • Page 5 Quick Start — MVX Plus 128 VGA A Matrix Switcher Installation Step 1 Turn off power to the input and output devices, and disconnect the power cords. Step 2 — Inputs a. Connect up to 12 high resolution video inputs to the 15-pin HD input connectors. b. Connect up to 12 stereo or mono audio inputs to the 5-pin captive screw connectors. Sleeve Ring Sleeve (s) Sleeve Ring Unbalanced Input (high impedance) Step 3 — Outputs a. Connect up to 8 high resolution...

  • Page 6: Quick Start

    Red indicates audio only tie. ENTER Green indicates the need to confirm the change. 4. Press and release the Enter button. QS-2 MVX Plus 128 VGA A Matrix Switcher • Quick Start Quick Start — Saving or recalling a preset 1. Save a preset — Press and hold the Preset button for 2 seconds. Recall a preset — Press and release the Preset button.

  • Page 7: Table Of Contents

    Using.presets ..3-26 Example.7:.Saving.a.preset... 3-27 Example.8:.Recalling.a.preset... 3-28 Muting.and.unmuting.video.and/or.audio.outputs Example.9:.Muting.and.unmuting.an.output... 3-29 MVX Plus 128 VGA A Matrix Switcher • Table of Contents ..1-1 ..2-1 ... 2-2 ... 2-3 ..2-5 ... 2-6 ...
  • Page 8 Command/Response Table for IP SIS Commands Symbol.definitions..4-17 Command/response.table.for.IP.SIS.commands. Special Characters ... 4-19 MVX Plus 128 VGA A Matrix Switcher • Table of Contents ... 3-32 ..3-36 ..3-41 ... 3-42 ... 3-43 .
  • Page 9 Master-Reset.selection..5-22 Using.Emulation.mode Using.the.help.system ... 5-22 Special Characters ... 5-22 Button-Label Generator Program Using.the.Button-Label.Generator.software. MVX Plus 128 VGA A Matrix Switcher • Table of Contents ... 5-1 ... 5-2 ... 5-2 ..5-3 ... 5-4 ... 5-6 ... 5-18 .
  • Page 10 Changing.the.output.volume.level... 6-17 Global.Presets.page ... 6-19 Saving.a.preset... 6-19 Recalling.a.preset... 6-19 Special Characters ... 6-20 MVX Plus 128 VGA A Matrix Switcher • Table of Contents ... 5-25 ... 6-2 ..6-5 ... 6-7 ... 6-10 ... 6-11 ..6-12...
  • Page 11 ..B-6 Button Labels ..B-7 Installing.labels.in.the.matrix.switcher’s.buttons. Button.label.blanks..B-9 MVX Plus 128 VGA A Matrix Switcher • Table of Contents ..A-1 ... A-4 ..A-6 ..A-6 ..A-6 .
  • Page 12 Table of Contents, cont’d 68-521-30.B 04.07 All trademarks mentioned in this manual are the properties of their respective owners. MVX Plus 128 VGA A Matrix Switcher • Table of Contents...

  • Page 13: Chapter One • Introduction

    MVX Plus 128 VGA A Matrix Switcher Chapter One Introduction About.this.Manual About.the.MVX.Plus.128.VGA.A.Matrix.Switcher Definitions Features...
  • Page 14 ,Y,B /R-Y DVS 304 100-2 50/60 Digital Video Scaler Figure 1-1 — Typical MVX Plus 128 VGA A matrix switcher application MVX Plus 128 VGA A Matrix Switcher • Introduction N/ SIZ IN P Audio Out IN P LI ST...

  • Page 15: Definitions

    Tie — An input-to-output connection. Set of ties — An input tied to two or more outputs. (An output can never be tied to more than one input.) Configuration — One or more ties or one or more sets of ties. Current configuration — The configuration that is currently active in the switcher (also called configuration 0) Global memory preset — A configuration that has been stored. Up to 32 global memory presets can be stored in memory. Preset locations are assigned to the input buttons and output buttons. When a preset is retrieved from memory, it becomes the current configuration. The switcher has 32 presets. Up to 20 presets can be selected from the front panel for either saving or retrieving. Preset numbers larger than 20 are accessible via serial port or Ethernet control. MVX Plus 128 VGA A Matrix Switcher • Introduction -based Matrix Switchers Control Program or the Simple ® ). The SIS is a set of basic ASCII code commands that provide...

  • Page 16: Features

    48.01 61.55 61.55 61.55 61.55 61.55 Figure 1-2 — DSVP data display MVX Plus 128 VGA A Matrix Switcher • Introduction Input # 01 Signal: PRESENT MATRIX INPUT STATUS Sync Type: H&V Vertical Freq.: 60 Hz Input # 01 Input # 02...
  • Page 17 • Simple Instruction Set (SIS™) — The remote control protocol uses Extron’s SIS for easy programming and operation. • Remote control panels and keypads — The matrix switchers are remote controllable, using the optional MKP 2000 and MKP 3000 remote control keypads. The remote control devices are easy to use and provide tactile buttons for quick selection. Each MKP can be used for input-to-output switching, one-touch switching for a particular output. The MKP 3000 also can be used for selection of global presets. Upgradeable firmware — The firmware that controls all switcher operation can be upgraded in the field via RS-232/RS-422 or Ethernet, without taking the switcher out of service. Firmware upgrades are available for download on the Extron Web site, www.extron.com, and can be installed using the Windows-based control program or the built-in HTML pages. Labeling — Extron’s included button label software lets you create labels to place in the front panel I/O buttons, with names, alphanumeric characters, or color bitmaps for easy and intuitive input and output selection. Alternatively, labels can be made with any Brother™ P-Touch™ or comparable labeler. MVX Plus 128 VGA A Matrix Switcher • Introduction...
  • Page 18 MVX Plus 128 VGA A, 20 global memory presets are available from the front panel; the remaining presets are available via serial port control. Rack mounting — Rack mountable in any conventional 19" wide rack Three front panel security lockout modes (Executive modes) — If a matrix switcher is installed in an open area, where operation by unauthorized personnel may be a problem, either of two security lockout modes can be implemented (the third mode is unlocked). When a front panel locked mode is enabled, a special button combination or SIS command is required to unlock the front panel controller and make the front panel fully operational. I/O grouping — This feature allows the matrix to be virtually divided into smaller sub-switchers, making installation and control easier. I/O grouping allows specific inputs and outputs, such as those designated for a specific purpose, to be grouped together. I/O grouping limits the selection of inputs and outputs to members of the same group. Power — The matrix switcher’s 100 VAC to 240 VAC, autoswitchable, internal power supply provides worldwide power compatibility. MVX Plus 128 VGA A Matrix Switcher • Introduction...

  • Page 19: Chapter Two • Installation

    MVX Plus 128 VGA A Matrix Switcher Chapter Two Installation Mounting.the.Switcher Rear.Panel.Cabling.and.Views Front.Panel.Configuration.Port...

  • Page 20: Ul.requirements

    Elevated operating ambient temperature — If the equipment installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient temperature. Therefore, install the MVX Plus in an environment compatible with the maximum ambient temperature (Tma = +122 °F, +50 °C) specified by Extron. Reduced air flow — Install the equipment in a rack so that the amount of air flow required for safe operation of the equipment is not compromised. Mechanical loading — Mount the equipment in the rack so that a hazardous condition is not achieved due to uneven mechanical loading. Circuit overloading — Connect the equipment to the supply circuit and consider the effect that circuit overloading might have on overcurrent protection and supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern. Reliable earthing (grounding) — Maintain reliable grounding of rack- mounted equipment. Pay particular attention to supply connections other than direct connections to the branch circuit (e.g. use of power strips). Mounting instructions The matrix switcher is housed in rack-mountable, 2U high metal enclosure with mounting flanges for a standard 19" rack. If desired, rack mount the switcher as follows: Insert the switcher into the rack, aligning the holes in the mounting bracket with those in the rack. Secure the switcher to the rack using the supplied bolts. MVX Plus 128 VGA A Matrix Switcher • Installation...

  • Page 21: Rear Panel Cabling And Views

    LISTED 1T23 I.T.E. Figure 2-1 — MVX Plus 128 VGA A video and audio matrix switcher Use Electrostatic discharge precautions (be electrically grounded) when making connections. Electrostatic discharge (ESD) can damage equipment, even if you cannot feel, see, or hear it.

  • Page 22: Audio.connections

    Figure 2-3 — Typical audio connectors The audio level for each input can be individually set via the front panel or Ethernet or RS-232/RS-422 control to ensure that the level on the output does not vary from input to input. See chapter 3, “Operation”, chapter 4, “Programmer’s Guide”, chapter 5, “Matrix Software”, and chapter 6, “HTML Operation” for details. MVX Plus 128 VGA A Matrix Switcher • Installation Sleeve Sleeve Unbalanced Stereo Input (high impedance) The length of the exposed (stripped) portion of the copper wires is important.

  • Page 23: Rs-232/Rs-422.Connection

    See “Selecting the rear panel Remote port protocol and baud rate” in chapter 3, “Operation”, to configure the RS-232/RS-422 port from the front panel. If desired, connect an MKP 2000 or MKP 3000 remote control panel to the switcher’s RS-232/RS-422 connector. Refer to the MKP 2000 Remote Control Panel User’s Manual and the MKP 3000 User’s Manual for details. MVX Plus 128 VGA A Matrix Switcher • Installation Ring NO GROUND HERE. Sleeve(s) Sleeve(s) Ring NO GROUND HERE.

  • Page 24: Ethernet.connection

    The cable used depends on your network speed. The switcher supports both 10 Mbps (10Base-T — Ethernet) and 100 Mbps (100Base-T — Fast Ethernet), half-duplex and full-duplex Ethernet connections. • 10Base-T Ethernet requires CAT 3 UTP or STP cable at minimum. • 100Base-T Fast Ethernet requires CAT 5e UTP or STP cable at minimum. The Ethernet cable can be terminated as a straight-through cable or a crossover cable and must be properly terminated for your application (figure 2-6). • Crossover cable — Direct connection between the computer and the MVX Plus 128 VGA A switcher • Patch (straight) cable — Connection of the MVX Plus 128 VGA A switcher to an Ethernet LAN MVX Plus 128 VGA A Matrix Switcher • Installation switcher to a PC or to an Ethernet LAN, via this RJ-45 connector. You can use a PC to control the networked switcher with SIS commands from anywhere in the world. You can also control the switcher from a PC that is running Extron’s Windows-based control program or has downloaded HTML pages from the switcher. Ethernet connection indicators — The Link and Act LEDs indicate the status of the Ethernet connection. The Link LED indicates that the switcher is properly connected to an Ethernet LAN. This LED should light steadily. The Act LED indicates transmission of data packets on the RJ-45 connector. This LED...

  • Page 25: Reset Button

    • Hard reset — Hold Reset while powering up the switcher to restore the switcher to the default factory conditions. Hard reset does not clear the current configuration. Power connection AC power connector — Plug a standard IEC power cord into this connector to connect the switcher to a 100 VAC to 240 VAC, 50 or 60 Hz power source. MVX Plus 128 VGA A Matrix Switcher • Installation Patch (straight) cable Side 1 Wire color White-orange Orange RJ-45 White-green...

  • Page 26: Front Panel Configuration Port

    Distances of about 50 feet (15 m) are typically not a problem. In some cases the matrix switcher may be capable of serial communications via RS-232 up to 250 feet (76 m) away. MVX Plus 128 VGA A Matrix Switcher • Installation VIEW VIDEO...

  • Page 27: Chapter Three • Operation

    MVX Plus 128 VGA A Matrix Switcher Chapter Three Operation Front.Panel.Controls.and.Indicators Front.Panel.Operations Rear.Panel.Operations Optimizing.the.Audio Troubleshooting Configuration.Worksheets...

  • Page 28: Front Panel Controls And Indicators

    The front panel controls (figure 3-1) are grouped into two sets. The input and output buttons are grouped on the left side of the control panel. The control buttons and video/audio (I/O) selection buttons are grouped on the right side of the panel. 1 2 3 4 5 6 7 8 9 10 11 12 1 2 3 4 5 6 7 8 Figure 3-1 — Front panel, MVX Plus 128 VGA A The large, illuminated pushbuttons can be labeled with text and/or graphics. The buttons can be set to provide amber background illumination all the time or the background illumination can be turned off (see “Background illumination”, on page 3-43. The buttons blink or are lit at full intensity (depending on the operation) when selected. Definitions...

  • Page 29: Input.and.output.buttons

    ❏ Select a preset. See “Using presets” on page 3-26. ❏ Display the RGB delay. See “Setting RGB delay” on page 3-23. ❏ Display the output volume level. See “Viewing and adjusting the output volume” on page 3-36. ❏ (Input 1 and Input 2 only) Toggle background illumination of the buttons on and off. See “Background illumination” on page 3-43. Output buttons — The output buttons have two primary functions (•) and four secondary functions (❏): • Select output(s). • Identify the selected output(s). ❏ (Output 1 only) With the Input 1 button, select I/O Group mode. See “I/O grouping” on page 3-19. ❏ Select a preset. See “Using presets” on page 3-26. ❏ Mute the output. See “Muting and unmuting video and/or audio outputs” on page 3-29. ❏ Display the audio level of the selected input. See “Viewing and adjusting the input audio level” on page 3-32. MVX Plus 128 VGA A Matrix Switcher • Operation...

  • Page 30: Control.buttons

    Blinks when Save Preset mode is active and lights steadily when Recall Preset mode is active. ❏ In the I/O Group mode, select group 2. See “I/O grouping” on page 3-19. ❏ In the I/O Group mode, indicate that group 2 is selected. See “I/O grouping” on page 3-19. ❏ With the Enter, View, and Esc buttons, select Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-43. ❏ Select 19200 baud for the RS-232/RS-422 port in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-43. ❏ Indicate that the RS-232/RS-422 port is set to 19200 baud in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-43. MVX Plus 128 VGA A Matrix Switcher • Operation Specify RGBHV, audio, or both (see I/O selection buttons [ Press the desired input button ( Press the desired output button(s) ( Press the Enter button. ] and...
  • Page 31 ❏ In the I/O Group mode, indicate that group 3 is selected. See “I/O grouping” on page 3-19. ❏ Decrease the RGB delay of switches to the selected output. See “Setting RGB delay” on page 3-23. ❏ Decrease the audio level of the selected input. See “Viewing and adjusting the input audio level” on page 3-32. ❏ Decrease the volume of the selected output. See “Viewing and adjusting the output volume” on page 3-36. ❏ With the Enter, Preset, and Esc buttons, select Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-43. ❏ Select 38400 baud for the RS-232/RS-422 port in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-43. ❏ Indicate that the RS-232/RS-422 port is set to 38400 baud in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-43. MVX Plus 128 VGA A Matrix Switcher • Operation < ) button has two primary functions (•) and...
  • Page 32 ❏ With the Enter, Preset, and View buttons, select Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-43. ❏ Select 115200 baud for the RS-232/RS-422 port in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-43. ❏ Indicate that the RS-232/RS-422 port is set to 115200 baud in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-43. MVX Plus 128 VGA A Matrix Switcher • Operation > ) button has two primary functions (•) and eight > ) button does not reset the current configuration, the RGBHV button...

  • Page 33: I/O.controls

    Lights to indicate that audio is available for configuration or viewing. ❏ Selects the Audio mode, in which you can adjust the input audio level and the output audio volume. See “Viewing and adjusting the input audio level” on page 3-32 and “Viewing and adjusting the output volume” on page 3-36. ❏ With the Enter button and RGBHV button, selects between front panel locks (Lock mode 2 and Lock mode 0). See “Setting the front panel locks (Executive modes)” on page 3-41. ❏ With the RGBHV button, selects between front panel locks (Lock mode 2 and Lock mode 1). See “Setting the front panel locks (Executive modes)” on page 3-41. ❏ With the RGBHV button, commands the front panel system reset. See “Performing a system reset from the front panel” on page 3-42. ❏ Select the RS-422 protocol for the RS-232/RS-422 port in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-43. ❏ Indicate that the RS-232/RS-422 port is set to the RS-422 protocol in Serial Port Configuration mode. See “Selecting the rear panel Remote port protocol and baud rate” on page 3-43. MVX Plus 128 VGA A Matrix Switcher • Operation ) and Audio ( ) buttons.

  • Page 34: Button.icons

    • Lock mode 1 — All changes are locked from the front panel. Some functions can be viewed. • Lock mode 2 — Advanced features are locked and can be viewed only. Basic functions are unlocked. N The switcher is shipped from the factory in Lock mode 2. See “Setting the front panel locks (Executive modes)” on page 3-41 for a detailed list of basic and advanced functions and the procedure to set the various front panel locks. Power Apply power by connecting the power cord to an AC source. The switcher performs a self-test that flashes the front panel button indicators red, green, and amber and then turns them off. An error-free power up self-test sequence leaves all I/O and control buttons either unlit or showing background illumination. The lit/unlit status RGBHV or Video button and the Audio button is the same as when the switcher was powered off. MVX Plus 128 VGA A Matrix Switcher • Operation Computer Computer VTG 200...

  • Page 35: Creating.a.configuration

    If you press the input button for an I/O grouped input and then try to select an output in a different group, you cannot select the associated output button. The associated input button remains lit. MVX Plus 128 VGA A Matrix Switcher • Operation Sales & Technical Support...

  • Page 36: Example 1: Creating A Set Of Video And Audio Ties

    N You can cancel the entire set of ties at this point by pressing and releasing the Esc button. The Esc button flashes red once. 3-10 MVX Plus 128 VGA A Matrix Switcher • Operation VIEW The button flashes once.
  • Page 37 Figure 3-7 — Press the Enter button The current configuration (figure 3-8) is now: • Input 5 video and audio is tied to output 3, output 4, and output 8 Input 5 (video/audio) tied to outputs 3, 4, and 8 Input Output Figure 3-8 — Example 1, final configuration MVX Plus 128 VGA A Matrix Switcher • Operation Video Audio 3-11...

  • Page 38: Example 2: Adding A Tie To A Set Of Video And Audio Ties

    RGBHV input will be tied to this output. 1 2 3 4 5 6 7 8 9 Figure 3-12 — Select the output 3-12 MVX Plus 128 VGA A Matrix Switcher • Operation VIEW The button flashes once. I / O RGBHV AUDIO Press the Audio button to toggle on and off.
  • Page 39 Input 5 video tied to outputs 1, 3, 4, and 8 Input 5 audio tied to outputs 3, 4, and 8 Input Output Figure 3-14 — Example 2, final configuration MVX Plus 128 VGA A Matrix Switcher • Operation Video Audio 3-13...

  • Page 40: Example 3: Removing A Tie From A Set Of Video And Audio Ties

    The button blinks red to indicate the pending change: audio input will be untied. 1 2 3 4 5 6 7 8 = Blinking button Figure 3-18 — Deselect the output 3-14 MVX Plus 128 VGA A Matrix Switcher • Operation VIEW The button flashes once. I / O RGBHV AUDIO Press the Audio button to toggle on and off.
  • Page 41 Input 5 video tied to outputs 1, 3, 4, and 8 Input 5 audio tied to outputs 3 and 8 Input Output Figure 3-20 — Example 3, final configuration, audio switcher MVX Plus 128 VGA A Matrix Switcher • Operation Video Audio 3-15...

  • Page 42: Viewing.a.configuration

    • • 3-16 MVX Plus 128 VGA A Matrix Switcher • Operation When you enter View-only mode, the output buttons light for all outputs without ties. Likewise, when you press an output button for which there are no ties, the output buttons light for all outputs without ties.

  • Page 43: Example.4:.Viewing.video.and.audio,.Audio.only,.And.video.only.ties

    1 2 3 4 5 6 7 8 9 Figure 3-23 — Select an input MVX Plus 128 VGA A Matrix Switcher • Operation Until you select an input, the buttons for all untied outputs light amber if no inputs are tied, green if no video inputs are tied (only audio is tied), or red if no audio inputs are tied (only video is tied).
  • Page 44 Figure 3-26 — Press the View button to exit View-only mode 3-18 MVX Plus 128 VGA A Matrix Switcher • Operation I / O The output buttons for outputs that are tied to input 5 light red to indicate audio ties (audio breakaway).

  • Page 45: I/O.grouping

    Computer #1 Computer #3 3 input, 2 output S-video matrix Document Camera Input 5 6 7 Output Group 2 MVX Plus 128 VGA A Matrix Switcher • Operation VSC 700 SCAN CONVERTER FREEZE RESET MENU NEXT SIZE MIN/MAX CENTER/PAN/SIZE...
  • Page 46 • • 3-20 MVX Plus 128 VGA A Matrix Switcher • Operation Ties between groups (an input in group 1 tied to an output in group 2) can be created under RS-232/RS-422 or Ethernet control. Presets can be created under RS-232/RS-422 or Ethernet control that tie inputs and outputs across group boundaries.

  • Page 47: Example 5: Grouping Inputs And Outputs

    If front panel lock mode 2 is selected and you try to perform step 4, the actions are ignored and the Enter, RGBHV, and Audio buttons flash. MVX Plus 128 VGA A Matrix Switcher • Operation Release the Input 1 button and Output 1 button.
  • Page 48 N Or, do nothing for approximately 30 seconds. The front panel times out and the switcher exits I/O Group mode. • Group 1 consists of inputs 1 through 4 and outputs 1 through 4. • Group 2 consists of inputs 5 through 8 and outputs 5 through 8. 3-22 MVX Plus 128 VGA A Matrix Switcher • Operation INPUTS OUTPUTS C O N T R O L VIEW ENTER PRESET The selected buttons light.

  • Page 49: Setting.rgb.delay

    • Exiting RGB Delay mode by pressing the RGBHV button always returns the I/O configuration to audio only selected for configuration. MVX Plus 128 VGA A Matrix Switcher • Operation > ) and View ( <...

  • Page 50: Example.6:.Setting.the.rgb.delay.for.an.output

    If front panel lock mode 2 is selected and you try to perform steps 4, the actions are ignored and the Enter, RGBHV, and Audio buttons flash. 3-24 MVX Plus 128 VGA A Matrix Switcher • Operation VIEW The button flashes once.
  • Page 51 The RGBHV button stops blinking and goes out or becomes background illuminated. The Audio button lights red. Figure 3-38 — Deselect RGB Delay mode MVX Plus 128 VGA A Matrix Switcher • Operation > ) button a total of three INPUTS 9 10 = Lit button...

  • Page 52: Using Presets

    Figure 3-39 — Preset locations 3-26 MVX Plus 128 VGA A Matrix Switcher • Operation Only the audio and video ties are stored and recalled; audio gain settings are not saved, and they do not change when a preset is recalled.

  • Page 53: Example 7: Saving A Preset

    The Enter and Preset background illumination. buttons return to unlit or background illumination. Figure 3-43 — Press the Enter button MVX Plus 128 VGA A Matrix Switcher • Operation (Preset Assigned) 1 2 3 Unlit (No Preset Assigned) C O N T R O L...

  • Page 54: Example 8: Recalling A Preset

    The Enter and Preset buttons return to unlit or background illumination. Figure 3-47 — Press the Enter button 3-28 MVX Plus 128 VGA A Matrix Switcher • Operation VIEW The button flashes once. (Preset Assigned) 1 2 3 All input buttons with assigned presets light red.

  • Page 55: Muting.and.unmuting.video.and/Or.audio.outputs

    Press the Esc button to clear all selections. C O N T R O L VIEW ENTER PRESET The button flashes once. Figure 3-48 — Clear all selections Press and release the View button to enter View-only mode. The View button lights red. MVX Plus 128 VGA A Matrix Switcher • Operation 3-29...
  • Page 56 N If both RGBHV and audio are selected and only video is muted, the output button flashes between green and amber. If only audio is selected, the output button flashes between red and amber. 3-30 MVX Plus 128 VGA A Matrix Switcher • Operation I / O VIDEO AUDIO Press the Audio button to toggle on and off.
  • Page 57 The View button returns to unlit or background illumination. Figure 3-52 — Press the View button to exit View-only mode MVX Plus 128 VGA A Matrix Switcher • Operation the RGBHV output is not muted. 3-31...

  • Page 58: Viewing And Adjusting The Input Audio Level

    N • • • • 3-32 MVX Plus 128 VGA A Matrix Switcher • Operation Output Level INPUTS 1 2 3 4 5 6 7 8 9 10 11 12 CONTROL 1 2 3 4 5 6 7 8...
  • Page 59 Input audio level adjustment displays MVX Plus 128 VGA A MVX Plus 128 VGA A Matrix Switcher • Operation = Unlit button = Slow blinking button = Fast blinking button = Lit button Green indicates a positive (gain) level, red indicates a negative (attenuation) level.

  • Page 60: Example 10: Viewing And Adjusting An Input Audio Level

    When the output buttons are lit red, they indicate an attenuation (-) level. In this example, the output buttons display an audio gain level of +8 dB. Figure 3-56 — Select an input 3-34 MVX Plus 128 VGA A Matrix Switcher • Operation VIEW The button flashes once. 2 seconds...
  • Page 61 RGBHV AUDIO return to unlit or background illumination. The Audio button stops blinking and lights red. The RGBHV button lights green. Figure 3-58 — Deselect Audio mode MVX Plus 128 VGA A Matrix Switcher • Operation < ) button is pressed. < ) button a total of nine...

  • Page 62: Viewing And Adjusting The Output Volume

    Audio mode. The Audio button stops blinking. N • • • • 3-36 MVX Plus 128 VGA A Matrix Switcher • Operation > ) and View ( < ) buttons to increase and decrease There is one audio volume level setting per output. The audio level setting is shared by the left and right audio inputs.

  • Page 63: Reading The Displayed Volume

    Another way to view the volume level is to think in terms of the attenuation that is applied to the output. Attenuation reduction is indicated by the lit or blinking input buttons: when fewer input buttons are lit, attenuation is greater (and the volume is quieter). • At minimum volume, all input buttons are unlit or background illuminated and 85 dB of attenuation is applied to the output. The audio output is effectively muted. • The first step of volume increase causes the Input 1 button to blink slowly. Attenuation is reduced by 22 dB (63 dB of attenuation is applied to the output). There is no change in the volume indication. • The second step of volume increase reduces the attenuation by an additional 1 dB (62 dB of attenuation is applied to the output). The front panel display is unchanged. • Successive steps of volume increase cause consecutive input buttons to first blink slowly, then quickly, and then light steadily. For example: When lit steadily, the Input 3 button indicates 47 dB of attenuation when compared to the Input 3 button blinking quickly (48 dB to 50 dB of attenuation). The blinking Input 4 button (45 dB to 46 dB of attenuation) is at least 2 dB less than the fast blinking Input 3 button (48 dB – 46 dB) and at most 5 dB less (50 dB – 45 dB). See the table on page 3-38 to read the volume display. MVX Plus 128 VGA A Matrix Switcher • Operation > ) button push > ) push applies 3-37...
  • Page 64 Slow blink Fast blink Slow blink Fast blink Slow blink Fast blink 3-38 MVX Plus 128 VGA A Matrix Switcher • Operation Highest dB of Output number input attenuation volume button lit Fast 5.5% blink 8.5% Slow blink 11.5%...

  • Page 65: Example 11: Viewing And Adjusting An Output Volume Level

    Output 1 button. The button lights green. = Unlit button = Slow blinking button Figure 3-61 — Select output 1 MVX Plus 128 VGA A Matrix Switcher • Operation AUDIO –39 dB attenuation, 41.5% volume INPUTS 1 2 3 4 5...
  • Page 66 I / O RGBHV AUDIO The Audio button stops blinking and lights red. The RGBHV button lights green. Figure 3-63 — Deselect Audio mode 3-40 MVX Plus 128 VGA A Matrix Switcher • Operation > ) button once (figure 3-62) to increase the volume > ) button several more times (figure 3-62) to > ) or View ( –26 dB attenuation,...

  • Page 67: Setting The Front Panel Locks (Executive Modes)

    2 seconds ENTER RGBHV AUDIO Figure 3-64 — Toggle front panel lock between mode 2 and mode 0 MVX Plus 128 VGA A Matrix Switcher • Operation The Enter, RGBHV, and I / O Audio buttons blink twice to indicate the mode...

  • Page 68: Selecting.lock.mode.2.Or.toggling.between.mode.2.And.mode.1

    The switcher flashes the button indicators green, red, and amber and then turns them off. Figure 3-66 — System reset 3-42 MVX Plus 128 VGA A Matrix Switcher • Operation The RGBHV and I / O Audio buttons blink twice to indicate the...

  • Page 69: Background.illumination

    VIEW ENTER PRESET = Blinking button Figure 3-68 — RS-232/RS-422 and baud rate display Release the Control buttons. MVX Plus 128 VGA A Matrix Switcher • Operation C O N T R O L 2 seconds VIEW ENTER PRESET All Control buttons light with one flashing.

  • Page 70: Rear Panel Operations

    Figure 3-70 — Exit Serial Port Configuration mode Rear Panel Operations The rear panel has a Reset button that initiates four levels of matrix switcher resets. For different reset levels, press and hold the button while the switcher is running or press and hold the button while you apply power to the switcher. 3-44 MVX Plus 128 VGA A Matrix Switcher • Operation Preset — 19200 Esc — 115200 Audio — RS-422/RS-485 I / O C O N T R O L...

  • Page 71: Performing Soft System Resets

    IP Settings Reset Press and hold the Reset button. Absolute Reset Figure 3-71 — Whole switcher and absolute resets MVX Plus 128 VGA A Matrix Switcher • Operation ZQQQ SIS command Release, then immediately press and release again. I / O...

  • Page 72: Performing A Hard Reset

    RGBHV or Video and Audio buttons turn on. Release the Reset button. Figure 3-72 — Hard reset 3-46 MVX Plus 128 VGA A Matrix Switcher • Operation Power...

  • Page 73: Optimizing The Audio

    Optimizing the Audio Each individual input audio level can be adjusted within a range of -18 dB to +24 dB, so there are no noticeable volume differences between sources and for the best headroom and signal-to-noise ratio. Adjust the audio gain and attenuation as follows: Connect audio sources to all desired inputs and connect the audio outputs to output devices such as audio players. See “Audio connections”, in chapter 2, “Installation”. For best results, wire all of the inputs and the outputs balanced. Power on the audio sources, the switcher, and the audio players. Switch among the inputs (see “Creating a configuration”, in this chapter), listening to the audio with a critical ear or measuring the output audio level with test equipment, such as a VU meter. As necessary, adjust the input audio level of each input (see “Viewing and adjusting the input audio level”, in this chapter) so that the approximate output level is the same for all selected inputs. As necessary, adjust the output audio level of each input (see “Viewing and adjusting the output volume”, in this chapter). Troubleshooting This section gives recommendations on what to do if you have problems operating the switcher and it describes an actual image problem that Extron has encountered. Ensure that all devices are plugged in and powered on. The switcher is receiving power if one of the front panel Power Supply LEDs is lit green. Check to see if one or more outputs are muted. Ensure an active input is selected for output on the switcher. Ensure that the proper signal format is supplied. Check the cabling and make corrections as necessary. Call the Extron S MVX Plus 128 VGA A Matrix Switcher • Operation Sales & Technical Support Hotline if necessary. 3-47...

  • Page 74: Configuration Worksheets

    Indicate if the configuration is for video, audio, or both. Figure 3-73 — Worksheet example 1: System equipment Inputs include PCs, an audio CD player, cameras, and an Extron VTG 300. Output devices include monitors, front and rear projectors, a stereo, and a VCR for recording presentations. The VTG 300 video test generator connected to input 12 enables a video test pattern to be sent to one, several, or all output devices for problem isolation or adjustment purposes. An audio test tape or CD could be used in a similar manner to check out the audio components. 3-48 MVX Plus 128 VGA A Matrix Switcher • Operation Input sources PC 2 Audio Classroom Classroom Laptop RGB 202 #1 VCR #2 VCR...

  • Page 75: Worksheet Example 2: Daily Configuration

    Played in the hall (output 1)  Played in the conference room (output 4)  Sent to the VCR (output 6)  • Classical music from the CD player (input 5) is: Played in the background in the main hall on sound system #2 (output 5)  Played in the lobby (output 8)  MVX Plus 128 VGA A Matrix Switcher • Operation Input sources Classroom Classroom Laptop Rack DVD #1 VCR #2 VCR RGB 202 (USP 405) USP 405 USP 405...

  • Page 76: Worksheet Example 3: Test Configuration

    Fill in the preset number and use colors, or dashes, etc., to make connecting lines. Indicate if the configuration is for video, audio, or both. Figure 3-75 — Worksheet example 3: Test configuration 3-50 MVX Plus 128 VGA A Matrix Switcher • Operation Input sources PC 2 Audio...
  • Page 77 MVX Plus 128 VGA A Matrix Switcher • Operation 3-51...
  • Page 78 Operation, cont’d 3-52 MVX Plus 128 VGA A Matrix Switcher • Operation...

  • Page 79: Chapter Four • Programmer's Guide

    MVX Plus 128 VGA A Matrix Switcher Chapter Four Programmer’s Guide Serial.Ports Ethernet.Link Host-to-Switcher.Instructions Switcher-Initiated.Messages Switcher.Error.Responses Using.the.Command/Response.Tables Command/Response.Table.for.SIS .Commands ™ Command.Response.Table.for.IP.SIS.Commands Special.Characters...

  • Page 80: Serial Ports

    See “Selecting the rear panel Remote port protocol and baud rate” in chapter 3, “Operation”, to configure the rear panel Remote port from the front panel. MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide • no parity • 8-bit • no flow control...

  • Page 81: Front.panel.configuration.port

    This front panel port’s protocol can be changed via SIS command control only. See the Command/Response table for IP SIS commands, later in this chapter, to configure both ports under SIS control. MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide 6 feet (1.8 m)

  • Page 82: Ethernet Link

    Default IP addresses To access the MVX Plus 128 switcher via the LAN port, you need the Extron IP address, and may need the subnet mask and the gateway address. If the IP address has been changed to an address comprised of words and characters, you can determine the actual numeric IP address using the ping (ICMP) utility (see appendix A, “Ethernet Connection”, for more details). If the addresses have not been changed, the factory-specified defaults are: • IP address • Gateway address 0.0.0.0 MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide White-orange Clip Down Orange 2 3 4 5 6 7 8 RJ-45 White-green connector Blue White-blue...

  • Page 83: Host-To-Switcher Instructions

    N {Day, date, time} are only reported if the connection is via the LAN port. Password: The switcher initiates the password message immediately after the copyright message when the controlling system is connected using TCP/IP or Telnet and the switcher is password protected. This message means that the switcher requires an administrator or user level password before it will perform the commands entered via this link. The switcher repeats the password message response for every entry other than a valid password until a valid password is entered. Login Administrator Login User The switcher initiates the login message when a correct administrator or user password has been entered. If the user and administrator passwords are the same, the switcher defaults to administrator privileges. The switcher initiates the Qik message when a front panel switching or preset recall operation has occurred. Sprnn The switcher initiates the Spr message when a memory preset has been saved from the front panel. nn is the preset number. Rprnn The switcher initiates the Rpr message when a memory preset has been recalled from the front panel. nn is the preset number. Innn Audxx The switcher initiates the Aud message when a front panel input audio level change has occurred. nn is the input number and xx is the dB level. Outnn Volxx The switcher initiates the Vol message when a front panel output audio volume change has occurred. nn is the output number and “xx” is the volume level. MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide ), which signals the end of the...

  • Page 84: Switcher Error Responses

    When the switcher receives an SIS command and determines that it is valid, it performs the command and sends a response to the host device. If the switcher is unable to perform the command because the command is invalid or contains invalid parameters, the switcher returns an error response to the host. The error response codes are: E01 — Invalid input channel number (too large) E10 — Invalid command E11 — Invalid preset number E12 — Invalid output number (too large) E13 — Invalid value (out of range) E14 — Illegal command for this configuration E17 — Timeout (caused only by direct write of global presets) E21 — Invalid room number E24 — Privilege violation (Ethernet, Extron software only) Using the Command/Response Tables The command/response tables begin on page 4-8. Lower-case letters are acceptable in the command field except where indicated for the gain and attenuation commands. The table below shows the hexadecimal equivalent of each ASCII character used in the command/response table. ASCII to HEX Conversion Table Space Symbols are used throughout the table to represent variables in the command/ response fields. Command and response examples are shown throughout the table. MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide...

  • Page 85: Symbol.definitions

    N The following characters are invalid in the name: {space} ~ , @ = ‘ [ ] { } < > ’ “ ; : | \ and ?. = Voltage = Temperature MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide Commands ™...

  • Page 86: Command/Response Table For Sis Commands

    N The & read tie command for RGB and the % read tie command for video can be used interchangeably on the matrix switchers. Read audio output tie MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide Response (switcher to host) •...

  • Page 87: Command/ResPonsE.table.for.sis.commands

    Set the audio volume to a specific value Example: 1*50v Increment volume Example: Decrement volume Read output volume MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide Response (switcher to host) X1% , X1%] 031.50 060.00 000.00 if there is no connection or sync frequencies are not applicable. •...•...
  • Page 88 5.5% 8.5% 11.5% 14.5% 17.5% 20.5% 23.5% 26.5% 29.5% 32.5% 35.5% 4-10 MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide dB of Output value attenuation volume 38.5% 41.5% 44.5% 47.5% 50.5% 53.5% 56.5% 59.5% 62.5% 65.5%...
  • Page 89 EX! , X2@ Write input name Example: Podium camNI Read input name EX! , X2@ Write output name Example: 1,Main PJ1NO Read output name MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide Response (switcher to host) Amt1 Amt0 X1! , X2#] Nmg01 Security 1 X2@] Security 2 X* , X2@]...
  • Page 90 Clear a global preset’s ties 4-12 MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide Response (switcher to host) See below.
  • Page 91 N See “Setting the front panel locks (Executive modes)” in chapter 3, “Operation”, for more information on the Lock modes. Lock all front panel functions Lock advanced front panel functions Unlock all front panel functions View lock status MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide Response (switcher to host) $ ... & X1!] Spr27 Spr27 , ...
  • Page 92 & Example: 15& View video output tie Example: View audio output tie Example: View input gain Example: View output volume Example: View output mutes Example: 4-14 MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide Response (switcher to host) X1!] X1@] X&] X1$] , ... 02301000 Additional description Clear all global presets and their names. Clear global preset Reset all RGB delays to 0.0 seconds.
  • Page 93 Response description: input # (I#) tied to O#1 View audio room preset configuration Command description: room #*room preset #*starting output # (O# - should always be 1)*2(=audio)VC Response description: input # (I#) tied to O#1 MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide Response (switcher to host) •X@ • •X@ • input 8 tied to output 4 input 12 tied to output 3...
  • Page 94 Ethernet protocol MVX firmware version firmware Request system status Response description: +3.3V•+5V•-5V•+15V•-15V•temperature (degrees fahrenheit) Example: 3.3V power system at 3.29V 4-16 MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide Response (switcher to host) filename1,date/time,length filename2,date/time,length filename3,date/time,length • • • •...

  • Page 95: Command/Response Table For Ip Sis Commands

    N If tagged responses is enabled, all read commands return the constant string and the value as the set command does (for example, the read matrix name command = RAM status MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide (Up to 240 alphanumeric characters) CP-300-450-MAV-- + last 3 pairs of MAC address In the format: MM/DD/YY•HH:MM:SS where:...

  • Page 96: Command/Response Table For Ip Sis Commands

    Set mail server, EX3^ , X4) , X3( domainname Read mail server, domainname EX4! Set e-mail recipient Example: 72,Jsmith@folklore.netCR EX4! Read e-mail recipient 4-18 MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide Response (switcher to host) X3)] Ipn• X3)] X3)] Ipn• X3@] X3#] X3$] Ipz+08:00 X3%]...

  • Page 97: Special Characters

    Check RAM Special Characters The HTML language reserves certain characters for specific functions. The switcher does not accept these characters as part of preset names, the switcher’s name, passwords, or locally created file names. The switcher rejects the following characters: {space (spaces are ok for names)} + ~ , @ = ‘ [ ] { } < > ’ “ semicolon (;) colon (:) | \ and ?. MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide Response (switcher to host) ... X4# , X4$] See below 17EM Notify failed and fixed E-mail input 8 status 3, 1 1 0 0 0 0 0 1 0 0 0 0 0 0 0 0 1...
  • Page 98 Programmer’s Guide, cont’d 4-20 MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide...

  • Page 99: Matrix Switchers Control Program

    MVX Plus 128 VGA A Matrix Switcher Chapter Five Matrix Software Matrix.Switchers.Control.Program Special.Characters Button.Label.Generator.Program.

  • Page 100: Installing The Software

    N For full functionality, install both of the following programs: • • Insert the CD-ROM into the drive. The installation program should start automatically. If it does not self-start, run Launch.exe from the CD. The Extron software CD window appears (figure 5-1). Figure 5-1 — Software CD window Click the Software tab (figure 5-1). Scroll to the desired program and click Install (figure 5-2). Figure 5-2 — Software installation MVX Plus 128 VGA A Matrix Switcher • Matrix Software -based Extron Matrix Switchers Control Program communicates ® The Matrix Switchers Control Program The Firmware Loader...

  • Page 101: Software.operation.via.ethernet

    Set serial port parameters command on page 4-19 to configure either port using an SIS command. Software operation via Ethernet When an MVX Plus VGA A switcher is connected to an Ethernet WAN or LAN, any number of users can operate it, locally or remotely, using the Matrix Switchers Control Program. See “Ethernet connection” in chapter 2, “Installation”, for installation details. Connection to the switcher via the Ethernet is password protected. There are two levels of password protection: administrator and user. Administrators have full access to all MVX Plus VGA A switching capabilities and editing functions. Users can select inputs and outputs, set and recall presets, and view all settings with the exception of passwords. If the same password or no password is required for logging on, all personnel log on with administrator privileges. Fields and functions that exceed user privileges are grayed out in the Matrix Switchers Control Program when the operator is logged on as a user. Ethernet protocol settings The IP Settings/Options screen (figure 5-7 on page 5-7) provides a location for viewing and, if connected via the RS-232 link or if logged on via the LAN port as an administrator, editing settings unique to the Ethernet interface. See “IP Settings/ Options window”, later in this chapter, for more details. MVX Plus 128 VGA A Matrix Switcher • Matrix Software...

  • Page 102: Using The Matrix Switcher Control Software

    If you selected Emulate, click OK and see “Using Emulation mode” on  page 5-22. If you selected IP [LAN] in step 2, the IP Connection window appears (figure 5-4). Figure 5-4 — Address and password entry a. Examine the Extron IP Address field in the IP Connection window. The field displays the last Extron IP address entered. If the IP address is correct: Proceed to step 3b. MVX Plus 128 VGA A Matrix Switcher • Matrix Software...
  • Page 103 192.168.254.254, is the correct value for this field. b. If the switcher is password protected, click in the Password field and enter the enter the appropriate administrator or user password. Click Connect. If you logged on using the administrator password, the Windows program connects you to the MVX Plus 128 VGA A switcher with all of the administrator rights and privileges. If you logged on using the user password, the Windows program connects you to the MVX Plus 128 VGA A switcher with only user capabilities. If an incorrect password was entered, the program beeps and returns to the password entry display. The Extron Matrix Switchers Control Program window (figure 5-5 and figure 5-6) appears. The window displays the current configuration of the attached matrix. Figure 5-5 — Extron Matrix Switchers Control Program window (no ties) MVX Plus 128 VGA A Matrix Switcher • Matrix Software...

  • Page 104: Ip Settings/Options Window

    RS-232 link and protecting the Ethernet access to this screen by assigning an administrator’s password to qualified and knowledgeable personnel only. MVX Plus 128 VGA A Matrix Switcher • Matrix Software...

  • Page 105: Matrix Ip Address Field

    RS-232/RS-422 link and protecting the Ethernet access to this screen by assigning an administrator’s password to qualified and knowledgeable personnel only. Edit this field as follows: Click in the Matrix IP address field. The graphic cursor becomes a text cursor. Edit the address as desired. Press the Tab key on the keyboard or click in another field to exit the Matrix IP Address field. Click the Take button to make the address change take affect. MVX Plus 128 VGA A Matrix Switcher • Matrix Software...

  • Page 106: Extron Name/Descriptor Field

    Valid IP addresses consist of four 1-, 2-, or 3-digit numeric octets separated by dots (periods). Each field can be numbered from 000 through 255. Leading zeroes, up to 3 digits total per field, are optional. Values of 256 and above are invalid. Edit this field as follows: Click in the Gateway IP Address field. The graphic cursor becomes a text cursor. Edit the address as desired. Press the Tab key on the keyboard or click in another field to exit the Gateway IP Address field. Click the Take button to make the address change take affect. Subnet Mask field The Subnet Mask field is used to determine whether the MVX Plus switcher is on the same subnet as the controlling PC or the mail server when you are subnetting. For more information, see “Subnetting — A Primer”, in Appendix A, “Ethernet Connection”. Edit this field as follows: Click in the Subnet Mask field. The graphic cursor becomes a text cursor. Edit the mask as desired. Press the Tab key on the keyboard or click in another field to exit the Subnet Mask field. Click the Take button to make the mask take affect. Hardware Address field The hardware address is hardcoded in the MVX Plus switcher and cannot be changed. MVX Plus 128 VGA A Matrix Switcher • Matrix Software...

  • Page 107: Use Dhcp Checkbox

    Edit the field as desired to set the proper time. Remember to use 24-hour time. Leading zeroes are optional. Press the Tab key on the keyboard or click in another field to exit the set time field. Click the Take button to make the time change take affect. Sync Time to PC button Clicking the mouse on the Sync Time to PC button causes the computer you are operating to send its internal time to the switcher in a set time command. GMT (offset) field The GMT field displays the amount of time, in hours and minutes, that the local time varies from the GMT international time reference. If necessary, adjust the offset as follows: Click in the GMT field. A set offset field appears with the offset in the format ±HH:MM (–12:00 to +14:00). The graphic cursor becomes a text cursor in the set offset field. Edit the field as desired to set the proper offset. Leading zeroes are optional. Some time zones are on the half-hour (30 minutes). Press the Tab key on the keyboard or click in another field to exit the Set Offset field. Click the Take button to make the offset change take affect. MVX Plus 128 VGA A Matrix Switcher • Matrix Software...

  • Page 108: Use Daylight Savings Checkbox

    N The following characters are invalid in passwords: {space} + ~ , @ = ‘ [ ] { } < > ’ “ ; : | \ and ?. Edit this field as follows: Click in the User Password field. The graphic cursor becomes a text cursor. Edit the case-sensitive password as desired. Press the Tab key on the keyboard or click in another field to exit the User Password field. Click the Take button to make the password change take affect. 5-10 MVX Plus 128 VGA A Matrix Switcher • Matrix Software...

  • Page 109: Mail Server Ip Address Field

    {space} + ~ , = ‘ [ ] { } < > ’ “ ; : | \ and ?. The @ character is only acceptable as the lead-in to the domain name (such as @folklore.net). Edit this field as follows: Click in the Mail Server Domain Name field. The graphic cursor becomes a text cursor. Edit the name as desired. Press the Tab key on the keyboard or click in another field to exit the Mail Server Domain Name field. Click the Take button to make the name change take affect. MVX Plus 128 VGA A Matrix Switcher • Matrix Software 5-11...

  • Page 110: E-Mail Addressee Fields

    Press the Tab key on the keyboard or click in another field to exit the e-mail addressee field. In the square check boxes associated with each addressee, select the options about which the addressee is to be e-mailed: missing input(s), fans, and/or power supply. In the floating box that contains the input numbers, select the inputs that need monitoring. In the round radio buttons associated with each addressee, select whether the addressee is to be e-mailed of failures, fixes, both, or not be notified. The None radio button is useful for temporarily removing personnel from the e-mail list when they are unavailable, such as on travel or vacation. If desired, click on the Send test E-mail button to test the e-mail function. Click the Take button to make the e-mail address changes take affect. 5-12 MVX Plus 128 VGA A Matrix Switcher • Matrix Software Crosspoint/MAV/Matrix-FF-FF-09@folklore.net Tuesday, November 15, 2005 10:05 AM Miles Standish Crosspoint/MAV/Matrix-FF-FF-09 - Input #10 Signal Available...

  • Page 111: Updating.firmware

    Ethernet connection rather than the serial port for firmware uploads. Click Tools > Update firmware. If you are connected via the LAN port, the select file window appears (figure 5-10). See “Ethernet-connected firmware upload”, on page 5-14. If you are connected via either serial port, the Extron Firmware Loader appears (figure 5-11). See “Serial-port-connected firmware upload”, on page 5-15. MVX Plus 128 VGA A Matrix Switcher • Matrix Software 5-13...

  • Page 112: Ethernet-Connected.firmware.upload

    N Valid firmware files must have the file extension .S19. Any other file extension is not a firmware upgrade. N The original factory-installed firmware is permanently available on the MVX Plus 128 VGA A switcher. If the attempted firmware upload fails for any reason, the switcher reverts to the factory-installed firmware. Click the Open button. The software advises you that you are about to reprogram the switcher’s firmware. Click OK to continue.

  • Page 113: Serial-Port-Connected.firmware.upload

    Figure 5-11 — Firmware loading Click Browse. The open file window appears. Navigate to the folder where you saved the firmware upgrade file. Select the file and click Open. The Firmware Loader returns to the top. N Valid firmware files must have the file extension “.S19”. Any other file extension is not a firmware upgrade for your matrix switcher. MVX Plus 128 VGA A Matrix Switcher • Matrix Software 5-15...
  • Page 114 ...“, and then “Transfer complete!“. N Firmware upgrades using either serial port can take several minutes. 10. When the Firmware Loader reports, “Transfer complete!”, click the Exit button on the Firmware Loader and then again on the port configuration window. The Firmware Loader and the Matrix Switchers Control Program exit. 5-16 MVX Plus 128 VGA A Matrix Switcher • Matrix Software...

  • Page 115: Uploading.html.files

    N If you want one of the custom HTML files that you created to be the default start-up page, name the file “index.html”. The MVX Plus 128 VGA A switcher looks for that file name when you first connect to it using an Internet browser.

  • Page 116: Windows Buttons, Drop Boxes, And Trashcan

    N A Room is a subset of outputs that are logically related to each other, as determined by the operator. The MVX Plus 128 VGA A switcher supports up to 10 rooms, each of which can consist of from 1 to 16 outputs.

  • Page 117: Tools Menu

    Mute-Output settings — Displays the RGB Delay, Volume, and Mute Adjust screen, which allows you to mute and unmute individual or all video and audio outputs. View input frequencies — (DSVP) Displays the input horizontal and vertical frequencies for each input. Update firmware — Allows you to replace the firmware that is coded on the switcher’s control board without taking the switcher out of service, opening the switcher enclosure, and replacing the firmware chip set. See “Updating firmware” on page 5-13. IP options — Allows you to set IP options. See “IP Settings/Options window” on page 5-6. HTML file manager — Displays a list of HTML files installed on the switcher and allows you to upload custom files from a connected PC to the switcher. See “Uploading HTML files” on page 5-14. MVX Plus 128 VGA A Matrix Switcher • Matrix Software 5-19...

  • Page 118: Preferences Menu

    N A Room is a subset of outputs that are logically related to each other, as determined by the operator. The MVX Plus 128 VGA A switcher supports up to 10 rooms, each of which can consist of from 1 to 16 outputs.
  • Page 119 Limit ties to same group — Allows you to limit the creation of ties using the program to inputs and outputs that are in the same group (similar to front panel operation). Icons in I/O boxes — Erases any numbers in the I/O boxes in the Control Program window (figure 5-6). You can place icons in the boxes. Numbers in I/O boxes — Erases any icons in the I/O boxes in the Control Program window and fills each box with the associated input or output number. Catch FPC/others changes — When checked, sets the switcher to report all configuration and setting changes to the Remote RS-232/RS-422 or Ethernet connection that turned this selection on. These reports allow the Matrix Switchers Control Program to track the changes that occur in the switcher’s configuration and settings, whether commanded via the front panel, the RS-232/RS-422 port, or the LAN port. MVX Plus 128 VGA A Matrix Switcher • Matrix Software 5-21...

  • Page 120: Master-Reset Selection

    Enter the file name under which you want to save any changes to the file, and click OK. Select the number of video boards, audio boards, and matrix model for which you are preparing a configuration, and click OK. Continue using the program as described on page 5-6. Using the help system For information about program features, you can access the help program in any of the following ways: • From the Extron Electronics program folder or group, double- click on the MATRIX Switchers Help icon (shown at right). • From within the Matrix Switcher Control Program, click on the Help menu on the main screen. • From within the Matrix Switcher Control Program, press the F1 key. Special Characters The HTML language reserves certain characters for specific functions. The switcher does not accept these characters as part of preset names, the switcher’s name, passwords, or locally created file names. The switcher rejects the following characters: {space (spaces are ok for names)} + ~ , @ = ‘ [ ] { } < > ’ “ semicolon (;) colon (:) | \ and ?. 5-22 MVX Plus 128 VGA A Matrix Switcher • Matrix Software...

  • Page 121: Button-Label Generator Program

    Figure 5-17 — Location of software on the web site N The Button Label Generator software is also included on the Extron Software Products CD-ROM that accompanied the switcher. By default, the Windows installation creates a C:\Program Files\Extron\ ButtonLabelGenerator directory and places the Button Label Generator icon into a group or folder named “Extron Electronics”. MVX Plus 128 VGA A Matrix Switcher • Matrix Software 5-23...

  • Page 122: Using The Button-Label Generator Software

    Using the Button-Label Generator software To run the Button-Label Generator program, click Start > Programs > Extron Electronics > Button Label Generator > Button Label Generator. The Button-Label Generator window appears (figure 5-18). Figure 5-18 — Extron’s Button-Label Generator window Under System selection, choose the Matrix Switchers 1616 Series option to match the button size for your MVX Plus 128 VGA A switcher. Using normal Windows controls, you can create and print labels that can be placed in the label windows on the front panel of the switcher. Click the Clear All Buttons button and create new labels as many times as necessary to make all of the button labels that you need. To access the help program, click the Help menu. 5-24 MVX Plus 128 VGA A Matrix Switcher • Matrix Software...

  • Page 123: Download The Startup Page

    MVX Plus 128 VGA A Matrix Switcher C hapter 6 HTML Operation Download.the.Startup.Page System.Status.Page System.Configuration.Page File.Management.Page Set.and.View.Ties.Page Special.Characters...
  • Page 124 {space} + ~ , @ = ‘ [ ] { } < > ’ “ ; : | \ and ?. Press the keyboard Enter key. The switcher checks to see if it is password protected. If the switcher is not password protected, it checks and downloads the HTML pages (proceed to step 7). If the switcher is password protected, the switcher downloads the Enter Network Password page (figure 6-1). Figure 6-1 — Enter Network Password page N A User name entry is not required. Click in the Password field and type in the appropriate administrator or user password. Click the OK button. MVX Plus 128 VGA A Matrix Switcher • HTML Operation...

  • Page 125: System Status Page

    If neither of the above conditions is true, the switcher downloads the factory-installed default startup page, “nortxe_index.html” (figure 6-2), also known as the System Status page. System Status Page The System Status page (figure 6-2) provides an overall view of the status of the matrix switcher, including individual voltages, and the serial port status (if applicable). The System Status page is the default page that the switcher downloads when you connect to the switcher. Access the System Status page from other pages by clicking the Status tab. Refresh. Select DSVP. Figure 6-2 — System Status page The status web page periodically updates itself to reflect the latest status of the switcher components. If a variable changes, the display shows the change in status the next time it updates. MVX Plus 128 VGA A Matrix Switcher • HTML Operation...

  • Page 126: Dsvp.page

    HTML Operation, cont’d DSVP page You can view a snapshot-in-time of the input frequencies of connected inputs on the Digital Sync Validation Processing (DSVP) page (figure 6-3). Click the DSVP link to the left of the Status page to download the DSVP page. The DSVP page automatically updates itself every 30 seconds to show the latest input frequencies changes or if an input has been disconnected. Select System Status. Refresh. Figure 6-3 — DSVP page MVX Plus 128 VGA A Matrix Switcher • HTML Operation...

  • Page 127: System Configuration Page

    System Configuration Page The MVX Plus 128 VGA A switcher downloads the System Configuration page (figure 6-4) when you click the Configuration tab. The screen consists of fields in which you can view and edit IP administration and system settings. You can access the Email Settings and Passwords pages clicking the appropriate link. See appendix A, “Ethernet Connection”, for basic information about IP addresses and subnetting. Refresh. Select Passwords. Select Email Settings. Select Firmware Upgrade. Figure 6-4 — System Configuration page On password-protected connections, there are two levels of protection: administrator and user. Administrators have full access to all switching capabilities and editing functions. Users can create ties, create and recall presets, set RGB and audio mutes, and view all settings with the exception of passwords. MVX Plus 128 VGA A Matrix Switcher • HTML Operation...

  • Page 128: Ip Settings Fields

    IP addresses. Gateway IP Address field The Gateway IP Address field identifies the address of the gateway to the mail server to be used if the switcher and the mail server are not on the same subnet. The gateway IP address has the same validity rules as the system IP address. Subnet Mask field The Subnet Mask field is used to determine whether the switcher is on the same subnet as the mail server when you are subnetting. For more information, see “Subnetting — A Primer”, in appendix A, “Ethernet Connection”. MAC Address field The Media Access Control (MAC) Address is hardcoded in the switcher and cannot be changed. Firmware field The Firmware field identifies the installed firmware version. This field is hardcoded in the switcher and cannot be changed. Model field The Model field identifies the number of video and audio inputs and outputs. This field is hardcoded in the switcher and cannot be changed. MVX Plus 128 VGA A Matrix Switcher • HTML Operation...

  • Page 129: Part.number.field

    When Daylight Savings Time is turned off, the switcher does not adjust its time reference. Click the Submit button. MVX Plus 128 VGA A Matrix Switcher • HTML Operation...

  • Page 130: Passwords Page

    Select Firmware Upgrade. Figure 6-6 — Passwords page The fields on the Passwords page are for entering and verifying administrator and user passwords. Passwords are case sensitive and are limited to 12 upper-case and lower-case alphanumeric characters. Each password must be entered twice; once in the Password field and then again in the Re-enter Password field. Characters in these fields are masked by asterisks (*****). If you do not want to password protect an access level, leave the Password field and the Re-Enter password field blank. After entering the desired password in both fields, click the Submit button. N An administrator password must be created before a user password can be created. To clear an existing password so that no password is required, clear any existing password, enter a single space character in the Password and Re-enter Password fields, and click the Submit button. MVX Plus 128 VGA A Matrix Switcher • HTML Operation...

  • Page 131: Email Settings Page

    {space} + ~ , = ‘ [ ] { } < > ’ “ ; : | \ and ?. The @ character is acceptable only as the lead-in to the domain name (such as @folklore.net). MVX Plus 128 VGA A Matrix Switcher • HTML Operation...

  • Page 132: Email Address Fields

    N The Firmware Upgrade page is only for replacing the firmware that controls all switcher operation. To insert your own custom HTML pages, see “File Management Page”, on page 6-11. Visit the Extron Web site, www.extron.com, select the CrossPoint/MAV Plus product category, select the latest the switcher, and download the file firmware file. 6-10 MVX Plus 128 VGA A Matrix Switcher • HTML Operation firmware installation package (*.exe file) for . Note the folder to which you save the...

  • Page 133: File Management Page

    N The original factory-installed firmware is permanently available on the MVX Plus 128 VGA A switcher. If the attempted firmware upload fails for any reason, the switcher automatically reverts to the factory-installed firmware. Click the Open button.

  • Page 134: Set And View Ties Page

    N If you lose track of the input and output associated with a specific button, let the mouse pointer rest over a button for a moment. As shown on figure 6-10, a field pops up that identifies the input and output for that button. 6-12 MVX Plus 128 VGA A Matrix Switcher • HTML Operation...

  • Page 135: Creating.a.tie

    RGB and Audio Settings page The RGB and Audio Settings page provides a way to set the input audio gain and attenuation, set the output volume, mute and unmute all video and audio outputs, and set the RGB delay (switching interval). Access the RGB and Audio Settings page (figure 6-11) by clicking the RGB & Audio Settings link on the Control page. Select Set & View Ties. Refresh. Select Global Presets. Figure 6-11 — RGB and Audio Settings page MVX Plus 128 VGA A Matrix Switcher • HTML Operation 6-13...

  • Page 136: Changing.the.input.gain.and.attenuation

    Changing the input gain and attenuation Users can set each input’s level of audio gain or attenuation (-18 dB to +24 dB) from the RGB and Audio Settings page. Audio levels can be adjusted so there are no noticeable volume differences between sources. Change an input’s audio level setting as follows: Click the Input drop box. A drop-down scroll box appears (figure 6-12). Figure 6-12 — Input selection drop box Click and drag the slider or click on the scroll up button or the scroll down button until the desired input is visible. Click the desired input. Click the Input Audio Level (dB) drop box. A drop-down scroll box appears (figure 6-13). Figure 6-13 — Gain drop box Click and drag the slider or click on the scroll up button or scroll down button until the desired input is visible. Click the desired gain or attenuation value. 6-14 MVX Plus 128 VGA A Matrix Switcher • HTML Operation...

  • Page 137: Muting.and.unmuting.one.or.all.outputs

    To select an individual output to mute or unmute, click the Output drop box. A drop down scroll box appears (figure 6-14). Figure 6-14 — Output selection drop box Click and drag the slider or click the scroll up button or the scroll down button until the desired output is visible. Click the desired output. Click the Video, Audio, or Follow button to select video, audio, or both for muting or unmuting. Each mouse click on a button toggles the other two buttons off. Click the Mute or UnMute button to mute or unmute the selected output. Click the Mute All or UnMute All to mute or unmute all of the outputs. Observe the Mute status indications on the page (figure 6-15). Unmuted is displayed in green and muted is displayed in red. Figure 6-15 — Mute status indications MVX Plus 128 VGA A Matrix Switcher • HTML Operation 6-15...

  • Page 138: Changing.the.rgb.delay

    HTML Operation, cont’d Changing the RGB delay The RGB delay interval defines how long the screen is blanked when switching to a new input for the selected output. Change the RGB delay as follows: Click the Output drop box. A drop-down scroll box appears (figure 6-16). Figure 6-16 — Output selection drop box Click and drag the slider or click on the scroll up button or the scroll down button until the desired output is visible. Click the desired output. Click the RGB delay drop box. A drop-down scroll box appears (figure 6-17). Figure 6-17 — RGB delay drop box Click the desired RGB delay. 6-16 MVX Plus 128 VGA A Matrix Switcher • HTML Operation...

  • Page 139: Changing.the.output.volume.level

    Figure 6-18 — Output selection drop box Click and drag the slider or click the scroll up button or the scroll down button until the desired output is visible. Click the desired output. Click the Volume Steps (64 Max) drop box. A drop-down scroll box appears (figure 6-19). Figure 6-19 — Volume drop box Click the desired output volume step value. N The table on the next page defines the value of each audio volume step. MVX Plus 128 VGA A Matrix Switcher • HTML Operation 6-17...
  • Page 140 5.5% 8.5% 11.5% 14.5% 17.5% 20.5% 23.5% 26.5% 29.5% 32.5% 35.5% 6-18 MVX Plus 128 VGA A Matrix Switcher • HTML Operation Number dB of Output Number of steps attenuation volume of steps 38.5% 41.5% 44.5% 47.5% 50.5% 53.5%...

  • Page 141: Global Presets Page

    + ~ , @ = ‘ [ ] { } < > ’ “ ; : | \ and ?. If you do not rename an unassigned button, the MVX Plus 128 VGA A switcher names the preset as Preset {next available number}. If you do not rename an existing preset when it is overwritten, the MVX Plus 128 VGA A switcher retains the same name. Click the Accept button. Recalling a preset To recall a global preset to be the current configuration, click the button associated with the desired preset. MVX Plus 128 VGA A Matrix Switcher • HTML Operation 6-19...

  • Page 142: Special Characters

    HTML Operation, cont’d Special Characters The HTML language reserves certain characters for specific functions. The switcher does not accept these characters as part of preset names, the switcher’s name, passwords, or locally created file names. The switcher rejects the following characters: {space} + ~ , @ = ‘ [ ] { } < > ’ “ semicolon (;) colon (:) | \ and ?. 6-20 MVX Plus 128 VGA A Matrix Switcher • HTML Operation...

  • Page 143: Appendix A • Ethernet Connection

    MVX Plus 128 VGA A Matrix Switcher A ppendix A Ethernet Connection Ethernet.Link Subnetting.—.A.Primer...

  • Page 144: Ethernet.connection

    Figure A-1 — RJ-45 connector pinout tables Default address To access the MVX Plus 128 VGA A switcher via the LAN port, you need the switcher’s IP address. If the address has been changed to an address comprised of words and characters, you can determine the actual numeric IP address using the Ping utility. If the address has not been changed, the factory-specified default is 192.168.254.254. Ping can also be used to test the Ethernet link to the MVX Plus 128 VGA A switcher. MVX Plus 128 VGA A Matrix Switcher • Ethernet Connection White-orange Clip Down Orange 2 3 4 5 6 7 8 RJ-45 White-green connector Blue...

  • Page 145: Pinging To Determine Extron Ip Address

    Minimum = 0ms, Maximum = 0ms, Average = 0ms Figure A-2 — Ping response Pinging to determine Web IP address The Ping utility has a modifier, -a, that directs the command to return the Web address rather than the numeric IP address. At the DOS prompt, type ping -a {IP address} and then press [Enter]. The computer’s return display is similar to the Ping response shown in figure A-2, except that when you specify the -a modifier, the line Pinging mail... reports the web IP address rather than the numeric IP address, regardless of whether you entered the actual numeric IP address or an alias name. MVX Plus 128 VGA A Matrix Switcher • Ethernet Connection...

  • Page 146: Connecting As A Telnet Client

    Connect to the MVX Plus 128 VGA A switcher as follows: At the Telnet prompt, type open {IP address} and then press [Enter]. If the switcher is not password protected, no further prompts are displayed until you break or disconnect the connection to the MVX Plus 128 VGA A switcher. If the switcher is password protected, Telnet displays the password prompt. If necessary, at the password prompt, type {password} and then press [Enter]. Connection to the switcher via the Ethernet can be password protected. There are two levels of password protection: administrator and user. A person logged on as an administrator has full access to all MVX Plus 128 VGA A switching capabilities and editing functions. Users can select video and/or audio for output, select test patterns, set RGB and audio mutes, select a blue screen, and view all settings with the exception of passwords. By default, the MVX Plus 128 VGA A switcher ships with both passwords set to {carriage return}. MVX Plus 128 VGA A Matrix Switcher • Ethernet Connection...

  • Page 147: Escape Character And Esc Key

    Set carriage return-line feed Unless commanded otherwise, Telnet transmits a line feed character only (no carriage return) to the connected switcher when you press the the correct setting for SIS communication with the switcher. The Telnet set crlf command forces Telnet to transmit carriage return and line feed characters when is pressed, but if crlf is set, the SIS link with the switcher does not function Enter properly. Close To close the link to the switcher, access the Telnet prompt by typing the Escape character ( ). At the Telnet prompt, type close and then press [Enter]. Ctrl Help For Telnet command definitions, at the Telnet prompt, type ? and then press [Enter]. Quit Exit the Telnet utility by typing quit and then pressing [Enter] at the Telnet prompt. If you are connected to the MVX Plus 128 VGA A switcher, access the Telnet prompt by typing the Escape character ( Ctrl MVX Plus 128 VGA A Matrix Switcher • Ethernet Connection key. Consequently, some confusion key and the Ctrl key. This is Enter key...

  • Page 148: Subnetting - A Primer

    255 indicates that this octet will be compared between two IP addresses. Typical Subnet Mask: Figure A-5 — Subnet mask and octets MVX Plus 128 VGA A Matrix Switcher • Ethernet Connection 192.168.254.254 Octets 0 indicates that this octet will not be compared between two IP addresses.

  • Page 149: Determining Whether Devices Are On The Same Subnet

    255.255.0.0 (?.?.X.X) Remote IP Address: 192.168.2.25 Match?: =.=.X.X — Match (Same subnet) Figure A-6 — Comparing the IP addresses MVX Plus 128 VGA A Matrix Switcher • Ethernet Connection Example 2 Example 3 192.168.254.254 192.168.254.254 255.255.0.0 (?.?.X.X) 255.255.0.0 (?.?.X.X) 190.190.2.25 192.190.2.25...
  • Page 150 Ethernet Connection, cont’d MVX Plus 128 VGA A Matrix Switcher • Ethernet Connection...
  • Page 151 MVX Plus 128 VGA A Matrix Switcher Appendix B Specifications, Part Numbers, Accessories Specifications Part.Numbers.and.Accessories Button.Labels...

  • Page 152: Appendix B • Specifications, Part Numbers, Accessories

    DC offset .. ±10 mV with input at 0 offset Sync Input type .. RGBHV, RGBS, RGsB, RsGsBs Output type .. RGBHV, RGBS, RGsB, RsGsBs (follows input) Input level ... 0.5 V to 5.0 Vp-p, 4.0 Vp-p normal Output level ... AGC to TTL: 4.0 V to 5.0 Vp-p, unterminated Input impedance ... 510 ohms Output impedance ... 75 ohms Max input voltage ... 5.0 Vp-p Max. propagation delay ... 30 ns Max. rise/fall time ... 4 ns Polarity... Positive or negative (follows input) MVX Plus 128 VGA A Matrix Switcher • Specifications, Part Numbers, Accessories...

  • Page 153: Audio Input

    RS-232 ... RS-232: 2 = TX, 3 = RX, 5 = GND RS-422 ... RS-422: 2 = TX-, 3 = RX-, 5 = GND, 7 = RX+, 8 = Tx+ Mini stereo jack (RS-232 only) tip = TX, ring = RX, sleeve = GND Ethernet control port... 1 RJ-45 female connector Ethernet data rate .. 10/100Base-T, half/full duplex with autodetect Ethernet protocol .. ARP, DHCP, ICMP (ping), TCP/IP, Telnet, HTTP Program control .. Extron’s control/configuration program for Windows Extron’s Simple Instruction Set (SIS Microsoft MVX Plus 128 VGA A Matrix Switcher • Specifications, Part Numbers, Accessories 2 dBu ™ Internet Explorer, Telnet ® ®...
  • Page 154 Vibration .. ISTA 1A in carton (International Safe Transit Association) Listings... UL, CUL Compliances .. CE, FCC Class A, VCCI, AS/NZS, ICES MTBF .. 30,000 hours Warranty .. 3 years parts and labor All nominal levels are at ±10%. Specifications are subject to change without notice. MVX Plus 128 VGA A Matrix Switcher • Specifications, Part Numbers, Accessories...

  • Page 155: Part Numbers And Accessories

    WT (water-tight), white MCP 1000M (master) MCP 1000S (slave) MKP 2000 matrix switcher X-Y remote control panel Black White RAL9010 white MKP 3000 Black White RAL9010 white MKP 3000 L Button cap and diffuser kit (set of 3 button cap assemblies) MVX Plus 128 VGA A Matrix Switcher • Specifications, Part Numbers, Accessories Replacement part number 60-788-01 Part number 60-239-01 60-239-02 60-239-03 60-239-05 60-239-52 60-239-53 60-298-01 60-298-02 60-682-02...

  • Page 156: Cables

    VGA M-M MD/100, 100' (30.4 m) Male-to-male VGA molded connector cables VGA M-M BK/3, 3' (0.9 m) VGA M-M BK/6, 6' (1.8 m) VGA M-M BK/10, 10' (3.0 m) VGA M-M BK/15, 15' (4.5 m) VGA M-M BK/25, 25' (7.6 m) VGA M-M BK/35, 35' (10.6 m) VGA M-M BK/50, 50' (15.2 m) VGA M-M BK/75, 75' (22.8 m) VGA M-M BK/100, 100' (30.4 m) MVX Plus 128 VGA A Matrix Switcher • Specifications, Part Numbers, Accessories Part number 26-112-17 26-112-15 26-112-01 26-112-05 26-112-28 26-112-29 26-112-30 26-112-31 Part number 26-112-35...

  • Page 157: Button Labels

    Separating the two- piece button here at the corner. Figure B-1 — Illuminated button label replacement Use a small screwdriver or Extron Tweeker to gently lever the button cap off of the white backing plate. Insert a button label into the cap and gently but firmly press the cap onto the white backing plate. Press the button into place in the matrix switcher. MVX Plus 128 VGA A Matrix Switcher • Specifications, Part Numbers, Accessories Base Diffuser Button Label Pry the two pieces apart.
  • Page 158 Specifications, Part Numbers, Accessories, cont’d MVX Plus 128 VGA A Matrix Switcher • Specifications, Part Numbers, Accessories...
  • Page 159 MVX Plus 128 VGA A Matrix Switcher • Specifications, Part Numbers, Accessories...
  • Page 160 Specifications, Part Numbers, Accessories, cont’d B-10 MVX Plus 128 VGA A Matrix Switcher • Specifications, Part Numbers, Accessories...
  • Page 161 Extron Electronics warrants this product against defects in materials and workmanship for a period of three years from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty workmanship and/or materials, Extron Electronics will, at its option, repair or replace said products or components, to whatever extent it shall deem necessary to restore said product to proper operating condition, provided that it is returned within the warranty period, with proof of purchase and description of malfunction to:...
  • Page 162 Extron Electronics, USA 1230 South Lewis Street Anaheim, CA 92805 800.633.9876 714.491.1500 FAX 714.491.1517 www.extron.com Extron Electronics, Asia Extron Electronics, Europe 135 Joo Seng Rd. #04-01 Beeldschermweg 6C PM Industrial Bldg., Singapore 368363 3821 AH Amersfoort, The Netherlands +800.7339.8766 +65.6383.4400 +800.3987.6673 +31.33.453.4040 FAX +65.6383.4664 FAX +31.33.453.4050...

Table of Contents
