Summary of Contents for JVC KD-DB101

  • Page 1 CD RECEIVER KD-DB101 For canceling the display demonstration, see page 5. For installation and connections, refer to the separate manual. INSTRUCTIONS LVT1675-001A [EX]...
  • Page 2 Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. IMPORTANT FOR LASER PRODUCTS 1. CLASS 1 LASER PRODUCT 2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to qualified service personnel.
  • Page 3: Table Of Contents

    The following marks are used to indicate... CONTENTS : Indicator displayed for the Control panel ........4 corresponding operation. Getting started ........ 5 How to use the M MODE button Radio operations ......6 If you press M MODE, the unit goes into functions mode, DAB tuner operations .......
  • Page 4: Control Panel

    Control panel Parts identification Display window Control dial SSM (Strong-station Sequential Memory) button (eject) button Number buttons Loading slot RPT (repeat) button T/P (traffic programme/programme type) button RND (random) button DISP (display) button M MODE button ¢ buttons (control panel release) button Display window Disc information indicators (standby/on attenuator) button...
  • Page 5: Getting Started

    Getting started To drop the volume in a moment (ATT) Basic operations To restore the sound, press the button again. Turn on the power. To turn off the power Ÿ Basic settings • See also “General settings — PSM” on page 14. * You cannot select this source if it is not ready.
  • Page 6: Radio Operations

    When an FM stereo broadcast is hard to receive Radio operations Lights up when monaural mode is activated. Ÿ MONO Lights up when receiving an FM stereo Reception improves, but stereo effect will be lost. broadcast with sufficient signal strength. To restore the stereo effect, repeat the same 88.3 procedure.
  • Page 7: Listening To A Preset Station

    Manual presetting The following features are available only for FM Ex.: Storing FM station of 92.5 MHz into preset RDS stations. number 4 of the FM1 band. Searching for your favorite FM RDS programme You can tune in to a station broadcasting your favorite 92.5 programme by searching for a PTY code.
  • Page 8: Using The Standby Receptions

    To activate TA Standby Reception To store your favorite programme The TP (Traffic Programme) indicator types either lights up or flashes. You can store six favorite programme types. • If the TP indicator lights up, TA Standby Reception is Preset programme types in the number buttons activated.
  • Page 9: Dab Tuner Operations

    To check the current clock time while Tracking the same programme— listening to an FM RDS station Network-Tracking Reception Station name (PS) Station Frequency Programme When driving in an area where FM reception is not type (PTY) Clock (back to sufficient enough, this unit automatically tunes in to the beginning) another FM RDS station of the same network, possibly...
  • Page 10: Storing Dab Services In Memory

    To tune in to an ensemble manually Tracing the same programme— Start searching for an ensemble, as in step on page 9... Alternative Frequency Reception You can keep listening to the same programme by activating the Alternative Frequency Reception. Select a desired ensemble frequency. When shipped from the factory, Alternative Frequency Reception is activated.
  • Page 11: Disc Operations

    To locate a particular track (for CD) or folder Disc operations (for MP3 or WMA discs) directly To select a number from 01 – 06: All tracks will be played repeatedly until you change the source or eject the disc. To select a number from 07 –...
  • Page 12: Changing The Display Information

    Changing the display information Selecting the playback modes You can use only one of the following playback modes at a time. While playing an audio CD or a CD Text Select your desired playback mode. Repeat play While playing an MP3 or a WMA disc Mode Plays repeatedly When “TAG DISP”...
  • Page 13: Sound Adjustments

    Sound adjustments Adjusting the sound You can adjust the sound characteristics to your You can select a preset sound mode suitable to the preference. music genre (C-EQ: custom equalizer). Indication, [Range] Preset values BAS* (bass), [–06 to +06] BAS* TRE* S.BS* Adjust the bass.
  • Page 14: General Settings - Psm

    General settings — PSM You can change PSM (Preferred Setting Mode) items Adjust the PSM item selected. listed in the table that follows. Repeat steps to adjust other PSM Select a PSM item. items if necessary. Finish the procedure. Indications Item Selectable settings, [reference page] : Initial)
  • Page 15 Indications Item Selectable settings, [reference page] : Initial) AF-REG • AF : When the currently received signals become weak, the unit Alternative frequency/ switches to another station (the programme may differ from the regionalization one currently received), [9]. reception • The AF indicator lights up. •...
  • Page 16: Other External Component Operations

    Indications Item Selectable settings, [reference page] : Initial) AUX ADJ A.ADJ 00 : Adjust the auxiliary input level to match the FM sound level and Auxiliary input level — A.ADJ 05 store it in memory. adjustment TAG DISP • TAG ON : Shows the Tag information while playing MP3/WMA tracks, [12].
  • Page 17: Remote Controller

    Remote controller — Main elements and features RM-RK50 This unit can be remotely controlled as instructed here (with an optionally purchased remote controller). We recommend that you use remote controller RM-RK50 with your unit. Installing the lithium coin battery (CR2025) (standby/on/attenuator) button •...
  • Page 18: Maintenance

    To keep discs clean Maintenance A dirty disc may not play correctly. If a disc does become dirty, wipe it with How to clean the connectors a soft cloth in a straight line from center Frequent detachment will deteriorate the connectors. to edge.
  • Page 19: More About This Unit

    DAB tuner operations More about this unit • Only primary DAB services can be presetted even when you store a secondary service. Basic operations • A previously preset DAB service is erased when a new Turning on the power DAB service is stored in the same preset number. •...
  • Page 20 Playing an MP3/WMA disc Changing the source • This unit can play back MP3/WMA files with the • If you change the source, playback also stops extension code <.mp3> or <.wma> (regardless of (without ejecting the disc). the letter case—upper/lower). Next time you select “CD”...
  • Page 21: Troubleshooting

    Troubleshooting What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms Remedies/Causes • Sound cannot be heard from the speakers. • Adjust the volume to the optimum level. • Check the cords and connections. •...
  • Page 22 Symptoms Remedies/Causes • Disc cannot be played back. • Use a disc with MP3/WMA tracks recorded in the format compliant with ISO 9660 Level 1, Level 2, Romeo, or Joliet. • Add the extension code <.mp3> or <.wma> to the file names.
  • Page 23: Specifications

    Specifications AUDIO AMPLIFIER SECTION CD PLAYER SECTION Maximum Power Output: Type: Compact disc player Front/Rear: 50 W per channel Signal Detection Non-contact optical pickup Continuous Power Output (RMS): System: (semiconductor laser) Front/Rear: 19 W per channel into 4 Ω, Number of Channels: 2 channels (stereo) 40 Hz to 20 000 Hz at no more Frequency Response: 5 Hz to 20 000 Hz than 0.8% total harmonic...
  • Page 24 This apparatus is in conformance with the valid European directives and standards regarding electromagnetic compatibility and electrical safety. European representative of Victor Company of Japan, Limited JVC Technology Centre Europe GmbH Postfach 10 05 52 61145 Friedberg Germany © 2007 Victor Company of Japan, Limited...
