Owner's Manual
(R;IFTSMRN"
19.0 HP
ELECTRIC START
42" MOWER
6 SPEED TRANSAXLE
LAWN TRACTOR
Model No
917.270773
• Safety
• Assembly
• Operation
• Maintenance
• Repair Parts
CAUTION:
Read and follow all
Safety Rules and Instructions
before operating this equip-
ment.
For answers to your questions
about this product, Call:
1-800-659-5917
Sears Craftsman Help Line
5 am - 5 pm, Mort - Sat
Seam, Roebuck and Co., Hoffman Estates, IL 60179
Visit our Craftsman website:www.sears.com/craftsman
