FACSIMILE EQUIPMENT
PARTS REFERENCE LIST
MODEL: MFC9760 / MFC9860 / MFC9880
( For Germany / United Kingdom / France /
Norway / Belgium / Netherlands /
Switzerland / Ireland / Denmark /
Austria / Spain / Italy / Sweden /
Euro Generic )
( For Australia / New Zealand / Asia )
Advertisement
Related Manuals for Brother MFC9760
Summary of Contents for Brother MFC9760
- Page 1 FACSIMILE EQUIPMENT PARTS REFERENCE LIST MODEL: MFC9760 / MFC9860 / MFC9880 ( For Germany / United Kingdom / France / Norway / Belgium / Netherlands / Switzerland / Ireland / Denmark / Austria / Spain / Italy / Sweden / Euro Generic ) ( For Australia / New Zealand / Asia )
- Page 2 © Copyright Brother 2001 All rights reserved No part of this publication may be reproduced in any form or by any means without permission in writing from the publisher. Specifications are subject to change without prior notice.
- Page 3 NOTES FOR USING THIS PARTS REFERENCE LIST 1. In the case of ordering parts, it needs mentioning the following items: (1) Code (2) Q' ty (3) Description Note: No orders without Parts Code or Tool No. can be accepted. [Example] REF.NO.
- Page 5 LIST1(MAIN FRAME) ORDER REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK TO BIUK LE1744001 MAIN MOTOR ASSY 087320616 TAPTITE, CUP S M3X6 LJ5701001 SOLENOID ASSY 000300415 SCREW, BIND M3X4 UL8984001 FRONT COVER LINK LJ5704001 TONER SENSOR (LED) PCB 087320616 TAPTITE, CUP S M3X6 LE1166001 THERMISTOR FILM LG2423001...
- Page 7 LIST2(LASER UNIT) ORDER REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK TO BIUK LJ5828001 LASER UNIT(SP) 087321615 TAPTITE, CUP S M3X16 MFC9760, MFC9860, MFC9880...
- Page 9 LIST3(PAPER TRANSPORT) ORDER REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK TO BIUK UL9059001 JOINT UL9060001 PAPER FEED ROLLER ASSY UL9062001 PAWLED BUSHING UL9066001 PAPER PICK-UP ROLLER UL9062001 PAWLED BUSHING UL9069001 CONDUCTOR BUSHING LJ4499001 ELECTRODE SPRING LJ4843001 OUTER CHUTE 1 (SP) PICKUP ROLLER PLANETARY GEAR ASSY (SP) LJ5591001 UL9070001...
- Page 11 LIST4(PAPER TRAY) ORDER REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK TO BIUK LJ4181001 PAPER TRAY ASSY (SP) UL9078001 SIDE GUIDE L, BLUE(6155) UL9079001 SIDE GUIDE R, BLUE(6155) U73515001 SCREW, CUP B M2.6X5 UL9083001 PAPER REAR GUIDE, BLUE(6155) UL9084001 SEPARATION PAD SUPPORT ASSY UL9090001 SEPARATION PAD SPRING MFC9760, MFC9860, MFC9880...
- Page 13 LIST5(HEAT FIXING UNIT) ORDER REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK TO BIUK LJ7162001 FIXING UNIT, 230V (SP) LJ5682001 CLEANER ASSY UH3635001 CLEANER SPRING 30 LJ5684001 HEAT ROLLER 25 UL8908001 HR BEARING 25 LJ5695001 HALOGEN LAMP, 230V LJ5276001 EJECT PINCH ROLLER HOLDER L LJ5277001 EJECT PINCH ROLLER HOLDER R LJ5278001...
- Page 15 LIST6(COVER) ORDER REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK TO BIUK LJ5751001 MAIN COVER ASSY, GRAY(1495) UL9122001 PINCH ROLLER ASSY UL9125001 PINCH ROLLER SPRING LJ5763001 OUTER CHUTE, GRAY(1495) UL9127001 CHUTE SPRING L UL9128001 CHUTE SPRING R UU2102003 FRONT COVER ASSY, GRAY(1495) UU2094001 FRONT SUB COVER, GRAY(1495) 087310815...
- Page 17 LIST7(DOCUMENT SCANNER) ORDER REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK TO BIUK LE7574001 SCANNER UNIT (SP) LE3338001 CCD MOTOR (INCLUDING HARNESS) 0A4300605 SCREW, PAN (S/P WASHER) M3X6 LG2025001 PANEL HARNESS LE3417001 PULLEY ASSY LE7777001 CCD UNIT ASSY (SP) LE8487001 CCD FLAT CABLE ZLE LE3423001 CCD DRIVE BELT LE2082001...
- Page 19 LIST8(ADF&TRAY) ORDER REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK TO BIUK LE1525001 ADF UNIT(SP) UG6609001 DOCUMENT SENSOR PCB LG2014001 DOCUMENT SENSOR HARNESS UF7026001 DOCUMENT FRONT SENSOR ACTUATOR LE2008001 DOCUMENT REAR SENSOR ACTUATOR LE2011001 COMPRESSION SPRING LE2551001 RUBBER HOLDER A UU2055001 SEPARATION RUBBER LE2550001 SPRING PLATE A ASSY...
- Page 21 LIST9A(CONTROL PANEL MFC9760) ORDER REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK TO BIUK LE1685001 CONTROL PANEL ASSY LE1336001 PANEL COVER LJ4283001 KEY, FUNCTION LJ4231002 KEY, STOP, PINK(2205) LJ4284001 KEY, TEN LJ4285001 KEY, COPY, GREEN(5159) LG2326001 PANEL PCB ASSY UG4552000 LG2381001 FPC KEY 087270815 TAPTITE, CUP B M2.6X8...
- Page 23 LIST9B(CONT PANEL MFC9860-9880) ORDER REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK TO BIUK LE7080001 CONTROL PANEL ASSY, MFC9880, GRAY(1495) LE8092001 CONTROL PANEL ASSY, MFC9860, GRAY(1495) LE2273001 PANEL COVER, GRAY(1495) UF4393007 KEY, TEN, MFC9880, GRAY(1495) LE1537007 KEY, TEN, MFC9860, GRAY(1495) LE2274001 KEY COPY/FAX AREA, GRAY(1495) ---- NOT USED...
- Page 25 LIST10(PCB) ORDER REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK TO BIUK LG3487002 MAIN PCB, MFC9760 LG3518001 MAIN PCB, MFC9860/MFC9880 FOR ARL/NZ/ASA LG3518002 MAIN PCB, MFC9880 EXCEPT FOR ARL/NZ/ASA LG2295061 NCU PCB, MFC9860/9880 FOR GER/UK/FRA/NOR/BEL/ NLD/CHE/IRE/DEN/AUS/SPA/ITA/SWE/GNR LG2819002 NCU PCB, MFC9880 FOR ARL/NZ LG2821002 NCU PCB, MFC9880 FOR ASA LG4016001...
- Page 27 LIST11(ACCESSORIES) ORDER REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK TO BIUK LG2358001 AC CORD ASSY, MFC9880 FOR GER/FRA/NOR/BEL/NLD/AUS/SPA/ITA/SWE/GNR (VDE) LG2085001 AC CORD ASSY, MFC9860 FOR GER (VDE) LG2359001 AC CORD ASSY FOR UK/IRE (BS) LG2360001 AC CORD ASSY FOR CHE (SEV) LG2361001 AC CORD ASSY FOR DEN (DEMCO) LG2162001...
- Page 28 LIST12(PRINTED MATERIAL) ORDER REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK TO BIUK LE7431001 OWNER'S MANUAL ASSY, MFC9760 FOR GER (INCLUDING OWNER'S MANUAL, LICENSE AGREEMENT SHEET, PAN EURO WARRANTY LEAFLET) LE8098001 OWNER'S MANUAL ASSY, MFC9860 FOR GER (INCLUDING OWNER'S MANUAL, LICENSE AGREEMENT SHEET, PAN EURO WARRANTY LEAFLET) LE7455001 OWNER'S MANUAL ASSY, MFC9880 FOR GER...
- Page 29 LIST12(PRINTED MATERIAL) ORDER REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK TO BIUK LE7990001 OWNER'S MANUAL ASSY, MFC9880 FOR DEN (INCLUDING OWNER'S MANUAL, LICENSE AGREEMENT SHEET, PAN EURO WARRANTY LEAFLET) LE7995001 OWNER'S MANUAL ASSY, MFC9880 FOR SPA (INCLUDING OWNER'S MANUAL, LICENSE AGREEMENT SHEET, PAN EURO WARRANTY LEAFLET, WARRANTY CARD) LE8026001 OWNER'S MANUAL ASSY, MFC9760 FOR ITA...
- Page 30 RECOMMEND REMARK TO BIUK LE7260001 CARTON, BROTHER, MFC9760 LE7261001 CARTON, BROTHER, MFC9860 LE7262001 CARTON, BROTHER, MFC9880 LE8113001 CARTON, BROTHER, MFC9880 FOR ARL/NZ/ASA LE1232001 STYROFOAM ASSY UE1688001 BAG, 1000X1000H UE3122001 CARTON FOR MANUAL LE1481001 SCANNER LOCK SHEET(PROTECTION FOR ADF) LE7433001 START CARD, MFC9760 FOR GER...
- Page 31 8C5581 PL-FAX020 Ver. Q-2...
