Summary of Contents for Mazda B4000

Page 1 Table of Contents Table of Contents Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo AM/FM stereo with single CD AM/FM stereo tape/CD/MP3 Premium AM/FM stereo CD6/MP3 Climate Controls Heater only Manual heating and air conditioning Lights Headlamps Turn signal control Bulb replacement...
Page 2: Table Of Contents
Table of Contents Seating and Safety Restraints Seating Safety restraints Air bags Child restraints Driving Starting Brakes Transmission operation Vehicle loading Trailer towing Recreational towing Roadside Emergencies Hazard flasher switch Fuel pump shut-off switch Fuses and relays Overheating Changing tires Jump starting Wrecker towing Customer Assistance...
Page 3: Table Of Contents
Table of Contents Maintenance and Specifications Engine compartment Engine oil Battery Fuel information Refill capacities Lubricant specifications Engine data Accessories Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from MNAO.
Page 4: Introduction
The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it. For more information on Mazda and its products visit the following website: In the United States: www.mazdausa.com In Canada: www.mazda.ca...
Page 5 Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment? In this guide, answers to such questions are contained in comments highlighted by a bold WARNING statement. These comments should be read and observed.
Page 6 Introduction SPECIAL NOTICES Emission warranty The New Vehicle Limited Warranty includes Bumper to Bumper Coverage, Safety Restraint Coverage and Corrosion Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.
Page 7 Introduction Notice to owners of pickup trucks and utility type vehicles WARNING: Utility vehicles have a significantly higher rollover rate than other types of vehicles. Before you drive your vehicle, please read this Owner’s Guide carefully. Your vehicle is not a passenger car. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of vehicle control, vehicle rollover, personal injury or death.
Page 8 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Protecting the Fasten Safety Belt Environment Air Bag-Front Air Bag-Side Child Seat Installation Child Seat Warning Child Seat Lower Child Seat Tether Anchor Anchor...
Page 9 Vehicle Symbol Glossary Personal Alarm System Power Window Lockout Feature Engine Oil Engine Coolant Engine Coolant Do Not Open When Hot Temperature...
Page 11: Instrument Cluster
Instrument Cluster Audio system 4wd control* Auxiliary power point (pg. 18) (pg. 120) (pg. 45) Fog lamp control (pg. 34) Passenger air bag deactivate switch Climate control system (pg. 84) Cigar lighter (pg. 31) * if equipped...
Page 12: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 13 Instrument Cluster Check fuel cap: Illuminates when the fuel cap may not be properly installed. Check the fuel filler cap if this light remains on. Continued driving with this light on may cause the Check Engine warning light to come on. It may take a long period of time for the system to detect an improperly installed or properly re-installed fuel filler cap depending on driving and fuel tank level conditions.
Page 14 Instrument Cluster Air bag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced immediately. A chime will also sound when a malfunction in the supplemental restraint system has been detected.
Page 15 Instrument Cluster Overdrive off (if equipped): Illuminates when the overdrive function of the transmission has been turned off, refer to the Driving chapter. If the light does not come on or the light flashes steadily, have your vehicle serviced as soon as possible, damage to the transmission could occur.
Page 16: Gauges
Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened. Door ajar warning chime: Sounds when any door is opened (or not fully closed).
Page 17 WARNING: Never remove the coolant reservoir cap and/or the radiator cap while the engine is running or hot, this may result in serious burns. Odometer: Registers the total kilometers (miles) of the vehicle. Trip odometer: Registers the kilometers (miles) of individual journeys.
Page 18: Am/Fm Stereo
AM/FM STEREO (IF EQUIPPED) 1. AM/FM: Press to select AM/FM1/FM2 frequency bands. 2. CLK: Press until SELECT HOUR / SELECT MINUTE appears. Press AUDIO to adjust the hours/minutes. Press CLK to display the time when the ignition is off. 3. AUDIO: Press AUDIO to toggle through the following modes and use to make...
Page 19 4. Tune: Press to manually go down/up ( ) the radio frequency and in audio mode to select various settings. 5. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. To tune a preset station, press the desired memory preset.
Page 20: Entertainment Systems
Entertainment Systems 1. CD eject: Press to eject the 2. CLK (Clock):Press CLK until SELECT HOUR or SELECT MINUTE is displayed. Press TUNE to adjust the hours/minutes. Press CLK to display the time when the ignition is off. 3. MUTE:Press to mute the playing media.
Page 21 Entertainment Systems 6. SHUFF (Shuffle): Press to play the tracks on the current CD in random order. 7. REPEAT:Press to repeat the current CD track. 8. FF (Fast forward): Press to manually advance in a CD track. 9. REW (Rewind): Press to manually reverse in a CD track.
Page 22: Am/Fm Stereo Tape/Cd/Mp3
Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Mazda CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 23 Entertainment Systems 2. CLK (Clock): Press CLK until SELECT HOUR or SELECT MINUTE is displayed. Press MENU to adjust the hours/minutes. Press CLK to display the time of day when the ignition is off. 3. MUTE: Press to mute the playing media.
Page 24 Entertainment Systems reduction system is manufactured under license from Dolby Laboratories Licensing Corporation. Dolby and the double-D symbol are registered trademarks of Dolby Laboratories Licensing Corporation. 5. TUNE: Press to manually go down/up ( ) the radio frequency and also to select various settings in menu mode.
Page 25 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Mazda CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 26: Premium Am/Fm Stereo Cd6/Mp3
PREMIUM AM/FM STEREO CD6/MP3 1. AM/FM: Press to select AM/FM1/FM2 frequency bands. 2. CD: Press to enter CD mode. If a CD is already in the system, the disc will start playing. 3. EJ (CD eject): Press to eject the CD. Press and hold to eject all CDs.
Page 27 Entertainment Systems 6. MENU: Press MENU repeatedly to toggle through the following modes and use to make adjustment in those modes. Autoset: Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2 .
Page 28 9. SHUFF (Shuffle): Press to play the tracks on the current CD/MP3 in random order. In MP3 directory mode, press to play the tracks within the current directory in random order. 10. REPEAT: Press to repeat the current CD/MP3 track. 11.
Page 29 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Mazda CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 30 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Mazda CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 31: Climate Controls
Climate Controls Climate Controls HEATER ONLY SYSTEM (IF EQUIPPED) 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle.
Page 32: Manual Heating And Air Conditioning
Climate Controls 4. Direct the outer instrument panel vents towards the side windows To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel. WARNING: Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.
Page 33 Climate Controls OPERATING TIPS To reduce fog build up on the windshield during humid weather, place the air flow selector in the position. To reduce humidity build up inside the vehicle: do not drive with the air flow selector in the OFF position. Under normal weather conditions, do not leave the air flow selector in MAX A/C or OFF when the vehicle is parked.
Page 34: Lights
Lights Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. FOG LAMP CONTROL (IF EQUIPPED) The fog lamps can only be turned on when the headlamp control is in the low beam position.
Page 35 AIMING THE HEADLAMPS The headlamps on your vehicle are properly aimed at the assembly plant. If your vehicle has been in an accident the alignment of your headlamps should be checked by your authorized Mazda dealer.
Page 36: Turn Signal Control
Lights TURN SIGNAL CONTROL Push down to activate the left turn signal. Push up to activate the right turn signal. COURTESY/READING LAMPS (IF EQUIPPED) The courtesy lamp lights when: any door is opened. the instrument panel dimmer switch is held up until the courtesy lamps come on.
Page 37 For bulb replacement, see an authorized Mazda dealer. Replacing headlamp bulbs NOTE: The procedure can be difficult. Your Mazda dealer has the proper tools, training and parts to perform this task. If you have difficulty with this, vistit your local Mazda dealer.
Page 38 WARNING: Handling Halogen Bulbs: When a halogen bulb breaks, it is dangerous. These bulbs contain pressurized gas. If one is broken, it will explode and serious injuries could be caused by the flying glass. If the glass portion of the bulb is touched with bare hands, body oil could cause the bulb to overheat and explode when lit.
Page 39 Lights To install the new bulb: Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb only by its plastic base and do not touch the glass. The oil from your hands could cause the bulb to break the next time the headlamps are operated.
Page 40 Lights 3. Remove screw(s) from lamp assembly. 4. Disengage lamp assembly (it has a snap fit). 5. Rotate bulb socket counterclockwise and remove from lamp assembly. 6. Carefully pull bulb straight out of socket and push in the new bulb. 7.
Page 41 Lights Replacing tail lamp/backup lamp bulbs The tail lamp/backup lamp bulbs are located in the same portion of the tail lamp assembly, one just below the other. Follow the same steps to replace either bulb: 1. Open the tailgate to expose the lamp assemblies.
Page 42 Lights 4. Install the bulb socket in the fog lamp turning clockwise. Replacing high-mount brake lamp and cargo lamp bulbs The replacement of the high-mount brake lamp bulb and cargo lamp bulb is basically the same. This procedure covers the high-mount brake lamp bulb.
Page 43: Driver Controls
Driver Controls Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers (from desired interval to low or high speed position); rotate towards you to decrease the speed of the wipers. Windshield washer: Push the end of the stalk: briefly: causes a single swipe of...
Page 44 Changing the wiper blades 1. Pull the wiper arm away from the vehicle. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the arm.
Page 45: Power Windows
Driver Controls AUXILIARY POWER POINT Power outlets are designed for accessory plugs only. Do not hang any type of accessory or accessory bracket from the plugs. Improper use of the power outlets can cause damage not covered by your warranty. The auxiliary power points are located on the instrument panel.
Page 46 Driver Controls One touch down Allows the driver’s window to open fully without holding the control down. Press completely down on AUTO and release quickly. Press again to stop. AUTOMATIC DIMMING REAR VIEW MIRRORS (IF EQUIPPED) When the inside rear view mirror detects bright light from behind the vehicle, the inside rear view mirror will automatically darken to minimize glare.
Page 47 Driver Controls Outside air temperature Display operation of the mirror with the compass feature: Press the right button to toggle the display between the compass direction and no display. Display operation of mirror with temperature and compass feature: Press the right button once to display temperature °F and compass.
Page 48 Driver Controls 3. To change the zone setting, push and hold the right button until ZONE appears in the display. 4. Press the right button repeatedly until desired compass zone number is displayed. The display will change back to the compass direction after 3 seconds when the button is not activated.
Page 49: Speed Control
Driver Controls POWER MIRROR CONTROL (IF EQUIPPED) To adjust your mirrors: 1. Select to adjust the left mirror or to adjust the right mirror. 2. Move the control in the direction you wish to tilt the mirror. 3. Return to the center position to lock mirrors in place.
Page 50 Driver Controls 3. Press the SET + control and release it. 4. Take your foot off the accelerator pedal. 5. The indicator light on the instrument cluster will turn on. Note: Vehicle speed may vary momentarily when driving up and down a steep hill.
Page 51 Driver Controls Increasing speed while using speed control There are three ways to set a higher speed: Press and hold the SET + control until you get to the desired speed, then release the control. Press and release the SET + control to operate the Tap-Up function.
Page 52 Press the speed control OFF control. Turn OFF the ignition. Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased. Note: Fully depressing the clutch pedal may cause a flare in engine RPM as the throttle is returned to idle. This is normal.
Page 53 Driver Controls CENTER CONSOLE (IF EQUIPPED) Your vehicle may be equipped with a variety of console features. These include: Utility compartment with cassette/compact disc storage Cupholders Coin holder slots Flip up armrest WARNING: Use only soft cups in the cupholder. Hard objects can injure you in a collision.
Page 54 Driver Controls Note: If the red marking on the shaft is visible, the bed extender is not locked or properly secured. To stow the bed extender, follow steps one through four in reverse order. The bed extender may be used to secure a load of up to 46 kg (100 lbs.) on the tailgate.
Page 55: Locks And Security
Locks and Security Locks and Security KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from your dealer. You should always carry a second key with you in a safe place in case you require it in an emergency.
Page 56 Locks and Security Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Your vehicle is equipped with a remote entry system which allows you to: unlock the vehicle doors without a key.
Page 57 Locks and Security Power door lock disabled The UNLOCK feature on your power UNLOCK door locks will not work from inside the vehicle when: LOCK the ignition has been turned to the OFF position, and 20 seconds elapse after all vehicle doors are closed and locked using the remote entry transmitter, or the power door lock control (while the accompanying door is open).
Page 58 Locks and Security To replace the battery: 1. Twist a thin coin between the two halves of the remote entry transmitter near the key ring. DO NOT TAKE THE FRONT PART OF THE REMOTE ENTRY TRANSMITTER APART. Damage to the transmitter may result in operation failure.
Page 59 Locks and Security 3. Turn the key from the 2 (LOCK) position to 3 (OFF). 4. Cycle eight times rapidly (within 10 seconds) between the 3 (OFF) position and 4 (ON). Note: The eighth turn must end in the 4 (ON) position.
Page 60 The SecuriLock passive anti-theft system is not compatible with non-Mazda aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Your vehicle comes with two coded keys; additional coded keys may be purchased from your dealer.
Page 61 Locks and Security Automatic arming The vehicle is armed immediately after switching the ignition to the 3 (OFF) position. The theft indicator will flash every two seconds when the vehicle is armed. Automatic disarming Switching the ignition to the 4 (ON) position with a coded key disarms the vehicle.
Page 62 Locks and Security Tips: A maximum of eight keys can be coded to your vehicle. Only use Securilock keys. You must have two previously programmed coded keys (keys that already operate your vehicle’s engine) and the new unprogrammed key(s) readily accessible. If you do not have at least 2 previously programmed keys, you must take your vehicle to your dealer to have the spare key(s) programmed.
Page 63: Seating And Safety Restraints
Seating and Safety Restraints Seating and Safety Restraints SEATING Adjusting the front manual seat (if equipped) WARNING: Never adjust the driver’s seat or seatback when the vehicle is moving. WARNING: Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Lift the release bar to move seat forward or backward.
Page 64 Seating and Safety Restraints 60/40 seat (if equipped) To gain access to the storage compartment in your armrest (if equipped), lift the latch to open lid. The 60/40 seat cupholder (if equipped) is detachable for cleaning. Firmly grasp the bottom of the cup holder and pull up.
Page 65: Safety Restraints
To return seat to original position, slide the seat bottom back, then push the seatback up to lock it in place. The seat will lock, and you will have to use the release bar to move the seat back to the original position. REAR SEATS Center facing jump seat (2–door Cab Plus) (if equipped) To open, pull inboard and down on the seat handle.
Page 66 Seating and Safety Restraints WARNING: All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an air bag (SRS) is provided. WARNING: It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed.
Page 67 Seating and Safety Restraints Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.
Page 68 Seating and Safety Restraints Automatic locking mode (outboard front passenger seating position only) for use with child safety seats In this mode, the shoulder belt is automatically pre-locked. The belt will still retract to remove any slack in the shoulder belt. The automatic locking mode is not available on the driver safety belt.
Page 69 Seating and Safety Restraints WARNING: After any vehicle collision, the entire seat belt system should be checked for proper operation by a qualified technician. Verify that the automatic locking retractors” in all outboard seating positions are functioning properly. Additionally check that the automatic locking mode feature for child safety seat in the passenger outboard seating position is functioning properly.
Page 70 Seating and Safety Restraints Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. Regular Cab and 4–door Cab Plus 2–door Cab Plus To lower the shoulder belt height, push the button and slide the height adjuster down.
Page 71 WARNING: The lap belts should fit snugly and as low as possible around the hips, not around the waist. Failure to position the lap belt correctly may cause serious injury in an accident. Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from).
Page 72 20 cm (8 inches) can be added to the safety belt assembly by adding a safety belt extension assembly. Safety belt extension assemblies can be obtained from your authorized Mazda dealership. Use only extensions manufactured by the same supplier as the safety belt.
Page 73 Seating and Safety Restraints BeltMinder The BeltMinder feature is a supplemental warning to the safety belt warning function. This feature provides additional reminders to the driver that the driver’s safety belt is unbuckled by intermittently sounding a chime and illuminating the safety belt warning lamp in the instrument cluster.
Page 74 Seating and Safety Restraints Reasons given... Consider... Belts are uncomfortable Safety belts are designed to enhance comfort. If you are uncomfortable - try different positions for the safety belt upper anchorage and seatback which should be as upright as possible; this can improve comfort. I was in a hurry Prime time for an accident.
Page 75 Seating and Safety Restraints WARNING: Always wear the safety belt. Do not be tempted to sit on top of the belt to fool police or to defeat the warning system. The safety belt and safety belt warning system are there to protect your life. One time disable Any time the safety belt is buckled and then unbuckled during an ignition ON cycle, the BeltMinder will be disabled for that ignition cycle...
Page 76 NOTE:If unsure about the proper procedures, bring your vehicle to an authorized Mazda dealership for inspection. Inspect the safety belts to make sure there are no nicks, tears or cuts, replacing if necessary. Check all automatic locking retractors on all outboard seating positions as well as the automatic locking mode for child safety seats on the passenger front belt.
Page 77: Air Bags
Mazda recommends that all safety belt assemblies used in vehicles involved in a collision be replaced. However, if the collision was minor and an authorized Mazda technician finds that the belts do not show damage and continue to operate properly, they do not need to be replaced.
Page 78 Seating and Safety Restraints WARNING: Air bags DO NOT inflate slowly or gently and the risk of injury from a deploying air bag is greatest close to the trim covering the air bag module. Always wear your safety belt. WARNING: Airbags have been known to kill or injure a child in front facing child restraints.
Page 79 Do not modify the front end of the vehicle. WARNING: Additional equipment may effect the performance of the air bag sensors increasing the risk of injury. Consult your authorized Mazda dealership before installation of additional equipment.
Page 80 Seating and Safety Restraints WARNING: The front passenger air bag is not designed to offer protection to an occupant in the center front seating position. Children and air bags For additional important safety information, read all information on safety restraints in this guide. WARNING: Never place a rearward facing child safety restraint in front of an activated airbag.
Page 81 Seating and Safety Restraints WARNING: An air bag can kill or injure a child in a child seat. Child seats should never be placed in the front seats, unless passenger air bag switch is turned off. See Passenger air bag on/off switch in this chapter.
Page 82 Seating and Safety Restraints The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 83 Disposal of air bags and air bag equipped vehicles (including safety belt pretensioners) For disposal of safety belt pretensioners, air bags, or air bag equipped vehicles, see your authorized Mazda dealership or qualified technician. Air bags MUST BE disposed of by qualified personnel.
Page 84 Passenger air bag ON/OFF switch WARNING: An airbag ON/OFF switch has been installed in this vehicle. Before driving, always look at the face of the switch to be sure the switch is in the proper position in accordance with these PASSENGER AIRBAG instructions and warnings.
Page 85 OFF position and the ignition switch is in the ON position, have the passenger air bag switch serviced at your authorized Mazda dealership. WARNING: In order to avoid inadvertent activation of the switch, always remove the ignition key from the passenger air bag ON/OFF switch.
Page 86 ON/OFF switch is in the ON position and the ignition switch is ON, have the passenger air bag ON/OFF switch serviced at your authorized Mazda dealership immediately. The passenger side air bag should always be ON (the air bag OFF light should not be illuminated) except for certain vulnerable persons.
Page 87 Seating and Safety Restraints effectiveness of the safety belts, because safety belts in modern vehicles are designed to work as a safety system with the air bags. Read all air bag Warning labels in the vehicle as well as the other important air bag instructions and Warnings in this Owner’s Guide.
Page 88 Seating and Safety Restraints WARNING: This vehicle has special energy management safety belts for the driver and right front passenger. These particular belts are specifically designed to work with air bags to help reduce the risk of injury in a collision. The energy management safety belt is designed to give or release additional belt webbing in some accidents to reduce concentration of force on an occupant’s chest and reduce the risk of certain bone...
Page 89: Child Restraints
Seating and Safety Restraints WARNING: This vehicle has special energy management safety belts for the driver and/or right front passenger. These particular belts are specifically designed to work with air bags to help reduce the risk of injury in a collision. The energy management safety belt is designed to give or release additional belt webbing in some accidents to reduce concentration of force on an occupant’s chest and reduce the risk of certain bone...
Page 90 Seating and Safety Restraints WARNING: An air bag can kill or injure a child in a child seat. Child seats should never be placed in the front seats, unless passenger air bag switch is turned off, See Passenger air bag on/off switch.
Page 91 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Mazda recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
Page 92 Can the child stay seated like this for the whole trip? WARNING: Booster seats must be installed only in seating positions equipped with a combination lap/shoulder belt. Types of booster seats There are two types of belt-positioning booster seats: Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder...
Page 93 The importance of shoulder belts Using a booster without a shoulder belt increases the risk of a child’s head hitting a hard surface in a collision. For this reason, you should never use a booster seat with a lap belt only. It is best to use a booster seat with combination lap/shoulder belts.
Page 94 36 kg (80 pounds) using an upper torso harness and a belt-positioning booster. Mazda recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and tether anchors.
Page 95 Seating and Safety Restraints WARNING: Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision. Installing child safety seats with combination lap and shoulder belts (front outboard passenger seat only) 1.
Page 96 Seating and Safety Restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
Page 97 Seating and Safety Restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is extracted and a click is heard. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
Page 98 Seating and Safety Restraints 11. See Attaching child safety seats with tether straps in this chapter. Check to make sure the child seat is properly secured before each use. Attaching child safety seats with tether straps Most new forward-facing child safety seats include a tether strap which goes over the back of the seat and hooks to an anchoring point.
Page 99 Seating and Safety Restraints WARNING: This anchor information applies to child safety seats equipped with tether straps. For child safety seats equipped with LATCH anchors, refer to Attaching safety seats with LATCH (Lower Anchors and Tethers for Children) attachments for child seat anchors in this chapter. WARNING: Never attach two child safety seat tethers to a single tether anchor.
Page 100 Seating and Safety Restraints 4. Clip the tether strap to the anchor. WARNING: If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. Center seating location 60/40 seats with folding armrest When installing a child safety seat in the center position, route the tether strap over the center arm rest and clip it to the center anchor.
Page 101 Seating and Safety Restraints See next page for center seating location of vinyl 60/40 seat. WARNING: If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. WARNING: If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision.
Page 102 Seating and Safety Restraints 60/40 seats represents LATCH anchors. represents tether strap anchors. To improve child seat protection, use the tether anchor when using the LATCH to install a child safety seat. See Attaching child safety seats with tether straps in this section. WARNING: Never attach two LATCH child safety seats to the same anchor.
Page 103 The LATCH anchors are below locator symbols on the seat back. Two plastic LATCH guides may be purchased from your local Mazda dealer (part number 1F60–57–751). They snap onto the latch lower anchor in the vehicle to help attach a child seat with rigid latch attachments.
Page 104 Seating and Safety Restraints If you install a child seat with rigid LATCH attachments, do not tighten the tether strap enough to lift the child seat off the vehicle seat cushion when the child is seated in it. Keep the tether strap just snug without lifting the front of the child seat.
Page 105: Driving
Driving Driving STARTING Positions of the ignition 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. 3. OFF, shuts off the engine and all accessories without locking the steering wheel.
Page 106 Driving WARNING: Extended idling at high engine speeds can produce very high temperatures in the engine and exhaust system, creating the risk of fire or other damage. WARNING: Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire.
Page 107 If starting a vehicle with an automatic transmission: Make sure the parking brake is set. Make sure the gearshift is in P (Park). If starting a vehicle with a manual transmission: 1. Make sure the parking brake is set. 2. Push the clutch pedal to the floor.
Page 108 steering wheel is turned when getting in or out of the vehicle Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced. If the driver’s safety belt is fastened, the light may not illuminate. Refer to the Instrument Cluster chapter for more information.
Page 109 Cold starting performance can also be improved by using an engine block heater. Engine block heaters are available as an option and can be obtained from your Mazda dealer. Consult the engine block heater section for proper use of the engine block heater.
Page 110: Brakes
A brief mechanical noise may be heard during this test. This is normal. If a malfunction is found, the ABS warning light will come on. If the vehicle has continuous vibration or shudder in the steering wheel while braking, the vehicle should be inspected by an authorized Mazda dealership.
Page 111 Driving The ABS operates by detecting the onset of wheel lockup during brake applications and compensates for this tendency. The wheels are prevented from locking even when the brakes are firmly applied. The accompanying illustration depicts the advantage of an ABS equipped vehicle (on bottom) to a non-ABS equipped vehicle (on top) during hard braking with loss of front braking traction.
Page 112 Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, press the parking brake pedal down until the pedal stops. The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the ignition is turned ON) until the parking brake is released.
Page 113 Driving STEERING Your vehicle is equipped with power steering. Power steering uses energy from the engine to decrease the driver’s effort in steering the vehicle. To prevent damage to the power steering pump: Never hold the steering wheel to the extreme right or the extreme left for more than a few seconds when the engine is running.
Page 114: Transmission Operation
WARNING: Vehicles with a higher center of gravity such as utility and four-wheel drive vehicles handle differently than vehicles with a lower center of gravity. Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions.
Page 115 WARNING: If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your authorized Mazda dealership. Driving with a 5–speed automatic transmission (if equipped) Your transmission is equipped with an adaptive learning strategy found in the vehicle computer.
Page 116 Driving P (Park) This position locks the transmission and prevents the rear wheels from turning. To put your vehicle in gear: Start the engine Depress the brake pedal Move the gearshift lever into the desired gear To put your vehicle in P (Park): Come to a complete stop Move the gearshift lever and securely latch it in P (Park) WARNING: Always set the parking brake fully and make sure...
Page 117 Driving Use when driving conditions cause excessive shifting from O/D to other gears. Examples: city traffic, hilly terrain, heavy loads, trailer towing and when engine braking is required. To return to O/D (overdrive mode), press the transmission control switch. The O/D OFF lamp will not be illuminated. O/D (Overdrive) is automatically returned each time the key is turned off.
Page 118 Driving 3. Start the engine, then press the brake pedal and release the parking brake. 4. Move the gearshift lever to the desired gear, then slowly release the clutch pedal while slowly pressing on the accelerator. During each shift, the clutch pedal must be fully depressed to the floor. Failure to fully depress the clutch pedal to the floor may cause increased shift efforts and prematurely wear components in the transmission.
Page 119 Driving This is a lockout feature that protects the transmission from accidentally being shifted into R (Reverse) from 5 (Overdrive). Parking your vehicle 1. Apply the brake and shift into the neutral position. 2. Fully apply the parking brake, then shift into 1 (First). 3.
Page 120 Driving If equipped with the Electronic Shift 4WD System, and 4WD Low is selected while the vehicle is moving, the 4WD system will not engage. This is normal and should be no reason for concern. Refer to Shifting to/from 4WD Low for proper operation. 4WD system indicator lights 4x4 - Momentarily illuminates when the vehicle is started.
Page 121 Driving Shifting to/from 4X4 LOW 1. Bring the vehicle to a complete stop 2. Depress the brake 3. On vehicles equipped with an automatic transmission, place the transmission in N (Neutral); on vehicles equipped with a manual transmission, depress the clutch. 4.
Page 122 Driving WARNING: Do not spin the wheels at over 56 km/h (35 mph). The tires may fail and injure a passenger or bystander. Sand When driving over sand, try to keep all four wheels on the most solid area of the trail. Do not reduce the tire pressures but shift to a lower gear and drive steadily through the terrain.
Page 123 Driving When descending a steep hill, avoid sudden braking. Shift to a lower gear when added engine braking is desired. When speed control is on and you are driving uphill, your vehicle speed may drop considerably, especially if you are carrying a heavy load. If vehicle speed drops more than 16 km/h (10 mph), the speed control will cancel automatically.
Page 124: Vehicle Loading
Driving SPECIAL LOADING INSTRUCTIONS FOR OWNERS OF PICKUP TRUCKS AND UTILITY-TYPE VEHICLES WARNING: For important information regarding safe operation of this type of vehicle, see the Preparing to drive your vehicle section in this chapter. WARNING: Loaded vehicles may handle differently than unloaded vehicles.
Page 125 Driving GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) – including vehicle curb weight and all payload. GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the driver’s door or door pillar.
Page 126 GVWR (Gross Vehicle Weight Rating) – is the maximum allowable weight of the fully loaded vehicle (including all options, equipment, passengers and cargo). The GVWR is shown on the Safety Compliance Certification Label located on the driver’s door or door pillar. The GVW must never exceed the GVWR.
Page 127 Maximum Loaded Trailer Weight – is the highest possible weight of a fully loaded trailer the vehicle can tow. It assumes a vehicle with only mandatory options, no cargo (internal or external), a tongue load of 10–15% (conventional trailer) or king pin weight of 15–25% (fifth wheel trailer), and driver only (68 kg [150 lbs]).
Page 128: Trailer Towing
Driving TRAILER TOWING Your vehicle may tow a class I, II or III trailer provided the maximum trailer weight is less than or equal to the maximum trailer weight listed for your engine and rear axle ratio on the following charts. Your vehicle’s load capacity is designated by weight, not by volume, so you cannot necessarily use all available space when loading a vehicle.
Page 129 Driving 4x2 w/manual transmission Engine Rear axle Maximum Maximum Maximum ratio GCWR - kg trailer frontal area (lbs.) weight - kg of trailer - (lbs.) To determine maximum trailer weight designed for your particular vehicle, see Calculating the load your vehicle can carry/tow earlier in this chapter.
Page 130 Driving 4x2 w/automatic transmission Engine Rear axle Maximum Maximum Maximum ratio GCWR - kg trailer frontal area (lbs.) weight - kg of trailer - (lbs.) Regular Cab 2.3L 2,495 (5,500) 1,016 (2,240) Equal to frontal area of vehicle 3.0L 3.73 2,722 (6,000) 1,188 (2,620) 4.64 (50)
Page 131 Driving 4x4 w/automatic transmission Engine Rear axle Maximum Maximum Maximum ratio GCWR - kg trailer frontal area (lbs.) weight - kg of trailer - (lbs.) Regular Cab 3.0L 3.73 2,722 (6,000) 1,043 (2,300) 4.64 (50) 4.0L 4,309 (9,500) 2,595 (5,720) 4.64 (50) Cab Plus/Cab Plus 4 4.0L...
Page 132 Driving Hitches For towing trailers up to 907 kg (2,000 lb), use a weight carrying hitch and ball which uniformly distributes the trailer tongue loads through the underbody structure. Use a frame-mounted weight distributing hitch for trailers over 907 kg (2,000 lb). Do not install a single or multi-clamp type bumper hitch, or a hitch which attaches to the axle.
Page 133 Driving Using a step bumper The optional step bumper is equipped with an integral hitch and requires only a ball with a 19 mm (3/4 inch) shank diameter. The bumper has a 907 kg (2,000 lb.) trailer weight and 91 kg (200 lb.) tongue weight capability.
Page 134 Driving Trailer tow connector Color Function Comment 3. Tan/White Tail lamp Relay controlled circuit activated when the park lamps/headlamps are on. 4. White Ground Matching vehicle circuit returns to battery’s negative ground. Driving while you tow When towing a trailer: Turn off the speed control.
Page 135: Recreational Towing
Driving After you have traveled 80 km (50 miles), thoroughly check your hitch, electrical connections and trailer wheel lug nuts. To aid in engine/transmission cooling and A/C efficiency during hot weather while stopped in traffic, place the gearshift lever in P (Park) (automatic transmission) or N (Neutral) (manual transmissions).
Page 136 If a distance of 80 km (50 miles) or a speed of 56 km/h (35 mph) must be exceeded, you must disconnect the front (4x4 only) and rear driveshafts. Mazda recommends the driveshafts be removed/installed only by a qualified technician. See your local dealer for driveshaft removal/installation.
Page 137: Roadside Emergencies
Roadside Emergencies Roadside Emergencies HAZARD FLASHER The hazard flasher is located on the steering column, just behind the steering wheel. The hazard flashers will operate when the ignition is in any position or if the key is not in the ignition. Push in the flasher control and all front and rear direction signals will flash.
Page 138: To Reset Switch
Roadside Emergencies This switch is located under the right-hand side of the glove box, just above the carpet. To reset the switch: 1. Turn the ignition OFF. 2. Check the fuel system for leaks. 3. If no leaks are apparent, reset the switch by pushing in on the reset button.
Page 139: Passenger Compartment Fuse Panel
Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
Page 140: Coded Fuses Table
The fuses are coded as follows: Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Instrument panel dimmer switch Trailer tow park lamps Right low beam headlamp Left low beam headlamp Windshield wipers/washer Radio (RUN/ACCY) Headlamp illumination indicator Restraints Control Module (RCM), PADI (Passenger Air bag Deactivation Indicator) Cluster air bag indicator...
Page 141 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Passenger compartment fuse panel (Logic power) — Not used Horn, Interior lamps High beam headlamp, High beam indicator (cluster) — One-touch down relay 30A cartridge Power windows fuse Turn signals/Hazards —...
Page 142: Power Distribution Box
Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Brake switch (logic) Instrument cluster Power point Power locks Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads.
Page 143 Roadside Emergencies 2.3L engine (if equipped) 56 B 56 A 46 B 45 B 50 B 46 A 45 A 50 A The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 50A** Passenger compartment fuse panel —...
Page 144 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description — Not used 30A** Blower motor (climate control) — Not used 30A** Anti-lock Brake System (ABS) (solenoids) — Not used 40A** ABS (motor) — Not used 20A** Engine fan —...
Page 145 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 7.5A* Trailer tow (left turn) — Not used — Not used — Wiper HI/LO relay — Wiper Park/Run relay — Fuel pump relay — Washer pump relay — Engine fan relay —...
Page 146: Coded High-Current Fuses Table
Roadside Emergencies 3.0L and 4.0L engines (if equipped) The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 50A** Passenger compartment fuse panel — Not used 50A** Passenger compartment fuse panel — Not used 50A** Passenger compartment fuse panel...
Page 147 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description — Not used 30A** Blower motor (climate control) — Not used 30A** Anti-lock Brake System (ABS) (solenoids) — Not used 40A** ABS (motor) — Not used — Not used —...
Page 148: Overheating
Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 7.5A* Trailer tow (left turn) — Not used — Not used — Wiper HI/LO relay — Wiper Park/Run relay — A/C clutch solenoid — Washer pump relay — PCM relay —...
Page 149 If you find a leak or other damage, or if coolant is still leaking, stop the engine and call an Authorized Mazda dealer. See Adding coolant in the Maintenance and specifications section. If you find no problems, the engine is cool and no leaks are obvious, carefully add coolant as required.
Page 150 Roadside Emergencies It is not recommended that the vehicle be operated in 4WD modes with a “temporary” (i.e. dissimilar size) spare. If 4WD operation is necessary, do not operate above speeds of 16 km/h (10 mph) or for distances above 80 km (50 miles).
Page 151 Roadside Emergencies Tool Location Spare tire Under the vehicle, just forward of the rear bumper Jack, jack handle, wheel nut Regular Cab: behind seats and wrench underneath the jack and tools cover Cab Plus: stowed in the passenger side rear cab compartment or behind the jump seat in a separate tool bag Cab Plus 4–Door: stowed behind...
Page 152 2. If equipped, unlock and remove the spare tire carrier lock from the rear access hole located just above the rear bumper and below the tailgate. 3. Insert the straight end of the jack handle into the rear access hole located just above the rear bumper and below the tailgate.
Page 153 Roadside Emergencies 4. If your vehicle is equipped with P265/75 R15 AT tires, do not stow a flat or inflated full size spare tire in the spare tire carrier. The flat full size tire should be stowed and tied down in the pickup box bed until it can be repaired.
Page 154 Roadside Emergencies 3. Block the diagonally opposite wheel. 4. Insert tapered end of the lug wrench behind hub caps and twist them off. 5. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground.
Page 155 135 Nm (100 lb-ft). Note that these tightening specifications are for nut and bolt threads that are free of dirt and rust. Use only Mazda recommended (1/2–20) replacement fasteners. 11. Stow the flat tire. Refer to Stowing the spare tire.
Page 156 (rotation, flat tire, wheel removal, etc.). Bolt size Wheel lug nut torque* Lb-ft ⁄ x 20 113-153 84-114 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Mazda recommended replacement fasteners.
Page 157: Jump Starting
Roadside Emergencies WARNING: When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the front disc brake hub and rotor that contacts the wheel. Installing wheels without correct metal-to-metal contact at the wheel mounting surfaces can cause the wheel nuts to loosen and the wheel to come off while the vehicle is in motion, resulting in loss of control.
Page 158 Roadside Emergencies Connecting the jumper cables 1. Connect the positive (+) jumper cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
Page 159 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the fuel injection system.
Page 160 Roadside Emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables.
Page 161 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 162: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Mazda has not approved a slingbelt towing procedure. On 4x2 vehicles, it is acceptable to tow the vehicle with the front wheels on the ground and the rear wheels off the ground.
Page 163: Customer Assistance
Mazda vehicle in top condition. If you have any questions or recommendations for improvement regarding the service of your Mazda vehicle or servicing by Mazda Dealer personnel, we recommend that you take the following steps: STEP 1: Contact Your Mazda Dealer Discuss the matter with an Authorized Mazda Dealer.
Page 164 Customer Assistance If you live outside the U.S.A., please contact your nearest Mazda Distributor. CUSTOMER ASSISTANCE (CANADA) Your complete and permanent satisfaction is our business. We are here to serve you. All Authorized Mazda Dealers have the knowledge and the tools to keep your Mazda vehicle in top condition.
Page 165 Your complete satisfaction is the goal of Mazda Canada Inc. and our dealers. Mazda’s participation in CAMVAP makes a valuable contribution to our achieving that goal.
Page 166 Manitoba (204) 942–7166 Ontario (416) 596–8824 Atlantic Canada (902) 422–5413 Quebec (418) 649–1330 REGIONAL OFFICES Regional Offices Areas Covered Mazda Canada Inc. Western Region Alberta, 8171 Ackroyd Road British Columbia, Suite 2000 Manitoba, Richmond, B.C. Saskatchewan, V6X 3K1 Yukon (604) 303–5670 Mazda Canada Inc.
Page 167 Authorized Mazda Dealers have the knowledge and the tools to keep your Mazda vehicle in top condition. If you have any questions or recommendations for improvement regarding the service of your Mazda vehicle or servicing by Mazda Dealer personnel, we recommend that you take the following steps: STEP 1 Discuss the matter with an Authorized Mazda Dealer.
Page 168 305 Milner Avenue, Suite 400 Scarborough, Ontario M1B 3V4 Canada TEL: 1 (800) 263–4680 (in Canada) (416) 609–9909 (outside Canada) PUERTO RICO Plaza Motors Corp. (Mazda de Puerto Rico) P.O. Box 362722, San Juan, Puerto Rico 00936–2722 TEL: (787) 788–9300...
Page 169 TEL: (684) 699–1854 ADD-ON NON-GENUINE PARTS AND ACCESSORIES Non-genuine parts and accessories for Mazda vehicles can be found in stores. These may fit your vehicle, but they are not approved by the manufacturer for use with Mazda vehicles. When you install non-genuine parts or accessories, they could affect your vehicle’s performance or...
Page 170 NOT take your Mazda outside the United States. However, in the event that you are moving to Canada permanently, Mazda vehicles built for use in the United States could be eligible for exportation to Canada with specific vehicle modifications to comply with the Canadian Motor Vehicle Safety requirements.
Page 171 However NHTSA cannot become involved in individual problems between you, your dealer, or your Mazda importer/distributor). To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1 (800) 424–9393 (or 366–0123 in Washington, D.C.
Page 172 Customer Assistance If you live outside of the U.S.A., please contact the nearest Mazda Distributor. (See the Mazda Importers/Distributors section of this manual). SERVICE PUBLICATIONS Factory-authorized Mazda service publication are available for owners who wish to do some of their own maintenance and repair.
Page 173: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer or Mazda Corporation. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1–800–424–9393 (202–366–0123 in the Washington D.C.
Page 174: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral Ph shampoo, such as an approved shampoo available from your Mazda dealer. Never use strong household detergents or soap, such as dish washing or laundry liquid. These products can discolor and spot painted surfaces.
Page 175 Never spray the engine or other engine components with water. Water will damage the engine or other engine components. Spray Engine Shampoo and Degreaser, available at your authorized Mazda dealer, on all parts that require cleaning and pressure rinse clean. Cover the highlighted areas to prevent water damage when cleaning...
Page 176 2.3L Engine 3.0L Engine...
Page 177 Mazda dealer. If tar or grease spots are present, use Extra Strength Tar and Road Oil Removal, available at your authorized Mazda dealer. WINDOWS AND WIPER BLADES The windshield, rear window and wiper blades should be cleaned regularly.
Page 178 Remove light stains and soil with Extra Strength Upholstery Cleaner, available at your authorized Mazda dealer. If grease or tar is present on the material, spot-clean the area first with Spot and Stain Remover, available at your authorized Mazda dealer. Never saturate the seat covers with cleaning solution.
Page 179 MAZDA CAR CARE PRODUCTS Your Mazda dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 180: Maintenance And Specifications
Mazda workmanship, will not be honored. Any auto repair shop using parts equivalent to your Mazda’s original equipment may perform maintenance. But we recommend that it always be done by an Authorized Mazda Dealer using genuine Mazda parts.
Page 181 Maintenance and Specifications CHART SYMBOLS I: Inspect, and if necessary correct, clean or replace A: Adjust R: Replace L: Lubricate Normal driving service intervals – perform at the months or distances shown, whichever occurs first. Maintenance Interval (Number of months or Miles (km), whichever comes first) Months Maintenance Item...
Page 182 Maintenance and Specifications Maintenance Interval (Number of months or Miles (km), whichever comes first) Months Maintenance Item x 1000 miles (x 1000 km) (8) (16) (24) (32) (40) (48) (56) (64) (72) (80) (88) (96) Disc brake system Caliper slide rails Drum brake system, lines and hoses Exhaust system for leaks, damage, looseness...
Page 183 Maintenance and Specifications Schedule I continued Maintenance Interval (Number of months or Miles (km), whichever comes first) Months Maintenance Item x 1000 miles 65 (x 1000 km) (104) (112) (121) (128) (136) (144) (152) (160) (168) (176) (184) (192) ENGINE Engine oil —...
Page 184 Maintenance and Specifications Maintenance Interval (Number of months or Miles (km), whichever comes first) Months Maintenance Item x 1000 miles 65 (x 1000 km) (104) (112) (121) (128) (136) (144) (152) (160) (168) (176) (184) (192) Disc brake system Caliper slide rails Drum brake system, lines and hoses Exhaust system for leaks,...
Page 185 (door-to-door delivery, taxi, police, power/utility company trucks, or similar duty), then Mazda recommends you increase the frequency of oil and filter changes to an interval equivalent to 200 ENGINE HOURS or use. Since most vehicles are not equipped with hour-meters, it may be necessary for you to approximate your idle time and plan oil/filter changes accordingly.
Page 186 Operating in dusty conditions such as unpaved or dusty roads Off road operation For specific recommendations see your authorized Mazda dealer or qualified service professional.
Page 187 The owner or a qualified service technician should make these vehicle inspections at the indicated intervals to ensure safe and dependable operation. Bring any problem to the attention of an Authorized Mazda Dealer or qualified service technician as soon as possible. While operating your vehicle Note any changes in the sound of the exhaust or any smell or exhaust fumes in the vehicle.
Page 188 Check your “Warranty Information” to find out which parts and services are covered. Use only recommended fuels, lubricants, fluids and service parts conforming to specifications. Genuine Mazda parts are designed and built to provide the best performance in your vehicle. PRECAUTIONS WHEN SERVICING YOUR VEHICLE Do not work on a hot engine.
Page 189 Working with the engine off Automatic transmission: 1. Set the parking brake and shift to P (Park). 2. Turn off the engine and remove the key. 3. Block the wheels. Manual transmission: 1. Set the parking brake, depress the clutch and place the gearshift in 1 (First).
Page 190: Engine Compartment
IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 2.3L I4 engine 1. Windshield washer fluid reservoir 2. Engine coolant reservoir 3. Engine oil dipstick 4. Transmission fluid dipstick (automatic transmission) 5. Engine oil filler cap 6. Brake fluid reservoir 7. Power distribution box 8.
Page 191 3.0L V6 engine 1. Engine coolant reservoir 2. Windshield washer fluid reservoir 3. Engine oil filler cap 4. Transmission fluid dipstick (automatic transmission) 5. Engine oil dipstick 6. Brake fluid reservoir 7. Power distribution box 8. Clutch fluid reservoir (manual transmission) 9.
Page 192 Maintenance and Specifications 4.0L SOHC V6 engine 1. Windshield washer fluid reservoir 2. Transmission fluid dipstick (automatic transmission) 3. Engine oil filler cap 4. Engine oil dipstick 5. Brake fluid reservoir 6. Power distribution box 7. Clutch fluid reservoir (manual transmission) 8.
Page 193 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Mazda specification . Refer to Lubricant specifications in this chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive.
Page 194: Engine Oil
Maintenance and Specifications ENGINE OIL Checking the engine oil Refer to the service maintenance section for the appropriate intervals for checking the engine oil. 1. Make sure the vehicle is on level ground. 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan.
Page 195 3.0L V6 engine 4.0L SOHC V6 engine...
Page 196 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. If the oil level is between the MIN and MAX marks, the oil level is acceptable, DO NOT ADD OIL. If the oil level is below the MIN mark, add enough oil to raise the level within the MIN-MAX range.
Page 197 4.0L SOHC V6 engine SAE 5W-30 Oil levels above the MAX mark may cause engine damage. Some oil must be removed from the engine by a service technician. 7. Put the indicator back in and ensure it is fully seated. Adding engine oil 1.
Page 198 SAE 5W-20 engine oil is recommended. Only use oils “Certified For Gasoline Engines” by the American Petroleum Institute (API). Use an equivalent oil Mazda specification. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 199 Mazda production and aftermarket (Mazda) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Mazda Material and design specifications, start-up engine noises or knock may be experienced.
Page 200: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Mazda maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the service maintenance section for the service interval schedules.
Page 201 Maintenance and Specifications WARNING: When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 202 Checking engine coolant Your engine’s cooling system has been factory-filled with a 50/50 mixture of distilled water and Mazda Genuine Engine Coolant, or an equivalent premium engine coolant that meets Mazda specification. A 50/50 mixture of distilled water and Mazda Genuine Engine Coolant provides: maximum cooling system efficiency.
Page 203 Maintenance and Specifications 2.3L engine 3.0L & 4.0L engines When the engine is cold, check the level of the engine coolant in the reservoir. The engine coolant should be at the “cold fill level” or within the “cold fill range” as listed on the engine coolant reservoir (depending upon application).
Page 204 Adding engine coolant Use only Mazda Genuine Engine Coolant or a premium engine coolant that meets a Mazda specification. DO NOT USE Extended Life Engine Coolant (orange in color).
Page 205: Refill Capacities
Recycled engine coolant Not all coolant recycling processes produce coolant which meets Mazda specification. Use of a recycled engine coolant which does not meet Mazda specifications may harm engine and cooling system components.
Page 206 Maintenance and Specifications Fill your engine coolant reservoir as outlined in Adding engine coolant in this chapter. Severe climates If you drive in extremely cold climates (less than –36° C [–34° F]): It may be necessary to increase the coolant concentration above 50%.
Page 207 Maintenance and Specifications How Limp to Safety works If the engine begins to overheat: The engine coolant temperature gauge will move to the red (hot) area. symbol will illuminate. The “Service Engine Soon” indicator light will illuminate. If the engine reaches a preset over-temperature condition, the engine will automatically switch to alternating cylinder operation.
Page 208 Maintenance and Specifications 4. When the engine has cooled down, first check the coolant level. If low, then use a rag and carefully turn the cap one notch counter-clockwise carefully to avoid being burned by hot steam. When there is no steam, keep you face back as you carefully remove the cap and then replenish the coolant to the full line.
Page 209 Maintenance and Specifications Observe the following guidelines when handling automotive fuel: Extinguish all smoking materials and any open flames before fueling your vehicle. Always turn off the vehicle before fueling. Automotive fuels can be harmful or fatal if swallowed. Fuels such as gasoline and ethanol are highly toxic and if swallowed can cause death or permanent injury.
Page 210 Maintenance and Specifications Ethanol Pure ethanol is the alcohol which is the intoxicating agent in liquor, beer and wine. It is distilled from the fermentation of plants such as field corn and sugar cane. When ethanol is used in the making of motor fuels, a small amount of a bad tasting chemical is added to discourage beverage use.
Page 211 If you must replace the fuel filler cap, replace it with a fuel filler cap that is designed for your vehicle. The warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Mazda fuel filler cap is not used.
Page 212 (R+M)/2 METHOD using fuel with the recommended octane rating, see your authorized Mazda dealership to prevent any engine damage. Unleaded Gasoline engines Your vehicle is designed to use “Regular” unleaded gasoline with an (R+M)/2 octane rating of 87.
Page 213 “Regular” unleaded gasoline. “Premium” unleaded gasoline is not recommended (particularly in the United States) because it may cause these problems to become more pronounced. If the problems persist, see your authorized Mazda dealership. FFV engine (if equipped) Your FFV will operate well on ordinary “Regular”...
Page 214 “Check Engine” indicator, refer to the Instrument Cluster chapter. Fuel Filter For fuel filter replacement, see your authorized Mazda dealership. Refer to the service maintenance section for the appropriate intervals for changing the fuel filter. Replace the fuel filter with an authorized Mazda part. The customer warranty may be void for any damage to the fuel system if an authorized Mazda fuel filter is not used.
Page 215 Maintenance and Specifications The advertised capacity is the amount of the indicated capacity and the empty reserve combined. Indicated capacity is the difference in the amount of fuel in a full tank and a tank when the fuel gauge indicates empty.
Page 216 Maintenance and Specifications Keep a record for at least one month and record the type of driving (city or highway). This will provide an accurate estimate of the vehicle’s fuel economy under current driving conditions. Additionally, keeping records during summer and winter will show how temperature impacts fuel economy.
Page 217 Maintenance and Specifications Perform all regularly scheduled maintenance items. Follow the recommended maintenance schedule and owner maintenance checks found in your vehicle service maintenance section. Conditions Heavily loading a vehicle or towing a trailer may reduce fuel economy at any speed. Carrying unnecessary weight may reduce fuel economy (approximately 0.4 km/L [1 mpg] is lost for every 180 kg [400 lb] of weight carried).
Page 218 If other than Mazda authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Mazda parts should be equivalent to genuine Mazda parts in performance and durability. WARNING: Do not park, idle, or drive your vehicle in dry grass or other dry ground cover.
Page 219 Maintenance and Specifications Readiness for Inspection/Maintenance (I/M) testing In some localities, it may be a legal requirement to pass an I/M test of the on-board diagnostics system. If your “Check Engine/Service Engine Soon” light is on, refer to the description in the Warning lights and chimes section of the Instrument cluster chapter.
Page 220 Maintenance and Specifications CHECKING AND ADDING POWER STEERING FLUID 2.3L I4 engine 3.0L V6 engine 4.0L V6 engine...
Page 221 If the fluid levels are outside of the normal operating range, the performance of your brake system could be compromised, seek service from your Mazda dealer immediately. WARNING: Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes. Seek medical attention if irritation persists.
Page 222 If the fluid level drops, refill the fluid level to the step in the reservoir. Use only a DOT 3 brake fluid designed to meet Mazda specification. Refer to Lubricant Specifications in this chapter. WARNING: Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes.
Page 223: Transmission Fluid
Maintenance and Specifications TRANSMISSION FLUID Checking automatic transmission fluid (if equipped) Refer to your service maintenance section for scheduled intervals for fluid checks and changes. Your transmission does not consume fluid. However, the fluid level should be checked if the transmission is not working properly, i.e., if the transmission slips or shifts slowly or if you notice some sign of fluid leakage.
Page 224 Maintenance and Specifications 7. Remove the dipstick and inspect the fluid level. Level should be in the cross-hatched area. 8. If necessary, add fluid in 250ml (1/2 pint) increments through the filler tube until the level is correct at normal operating temperatures.
Page 225 7. Add enough fluid through the filler opening so that the fluid level is at the bottom of the opening. 8. Install and tighten the fill plug securely. Use only fluid that meets Mazda specifications. Refer to Lubricant Specifications in this chapter.
Page 226 8. Install and tighten the fill plug securely. Use only fluid that meets Mazda specifications. Refer to Lubricant Specifications in this chapter. DRIVELINE UNIVERSAL JOINT AND SLIP YOKE Your vehicle may be equipped with universal joints that require lubrication.
Page 227 8. Install and tighten the fill plug securely. Use only fluid that meets Mazda specifications. Refer to Lubricant Specifications in this chapter. INFORMATION ABOUT UNIFORM TIRE QUALITY GRADING New vehicles are fitted with tires that have a rating on them called Tire Quality Grades.
Page 228 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Mazda to give you the following information about tire grades exactly as the government has written it. Treadwear...
Page 229 Maintenance and Specifications WARNING: The temperature grade for this tire is established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. TIRES Tires are designed to give many thousands of miles of service, but they must be maintained in order to get the maximum benefit from them.
Page 230 INFORMATION CONTAINED ON THE TIRE SIDEWALL Federal law requires tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire and also provides a tire identification number for safety standard certification and in case of a recall.
Page 231 Maintenance and Specifications 7. H: Indicates the tire’s speed rating. The speed rating denotes the speed at which a tire is designed to be driven for extended periods of time under a standard condition of load and inflation pressure. The tires on your vehicle may operate at different conditions for load and inflation pressure.
Page 232 Maintenance and Specifications 10. Tire Ply Composition and Material Used: Indicates the number of plies or the number of layers of rubber-coated fabric in the tire tread and sidewall. Tire manufacturers also must indicate the ply materials in the tire and the sidewall, which include steel, nylon, polyester, and others.
Page 233 Maintenance and Specifications Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information than those of “P” type tires; these differences are described below: 1. LT: Indicates a tire, designated by the Tire and Rim Association (T&RA), that is intended for service on light trucks.
Page 234 (check the tire inflation in the spare tire every 6 months) and before long trips. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Mazda recommends the use of a digital or dial type tire pressure gauge rather than a stick...
Page 235 Maintenance and Specifications Use the recommended cold inflation pressure for optimum tire performance and wear. Under-inflation or over-inflation may cause uneven treadwear patterns. NOTE: If you are driving the vehicle at its maximum weight load, make sure the tire inflation pressure is correct for the weight load on the tires. WARNING: Under-inflation is the most common cause of tire failures and may result in severe tire cracking, tread separation or blowout , with unexpected loss of vehicle control and...
Page 236 Maintenance and Specifications 4. Replace the valve cap. 5. Repeat this procedure for each tire, including the spare. Note: Some spare tires require higher inflation pressure than the other tires. 6. Visually inspect the tires to make sure there are no nails or other objects embedded that could poke a hole in the tire and cause an air leak.
Page 237 Front Wheel Drive (FWD) vehicles (front tires at top of diagram) Rear Wheel Drive (RWD) vehicles/Four Wheel Drive (4WD) vehicles (front tires at top of diagram)
Page 238 Maintenance and Specifications Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask a qualified technician at a reputable repair facility to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation. Tire wear Measure and inspect the tire tread on all your tires periodically.
Page 239 Maintenance and Specifications Safety practices Driving habits have a great deal to do with your tire mileage and safety. Observe posted speed limits Avoid fast starts, stops and turns Avoid potholes and objects on the road Do not run over curbs or hit the tire against a curb when parking If you vehicle is stuck in snow, mud, sand, etc., do not rapidly spin the tires;...
Page 240 The tires on your vehicle have all weather treads to provide traction in rain and snow. However, in some climates, you may need to use snow tires and chains. If you need to use snow tires and chains, it is recommended that steel wheels are used of the same size and specifications as those originally installed.
Page 241: Refill Capacities
Maintenance and Specifications Fluid Mazda Part Application Capacity Name Transmission Mazda 5-speed manual 2.65L (2.8 fluid MERCON ATF quarts) Mazda 4x2 vehicles 9.4L (9.9 MERCON V with automatic quarts) and 2.3L I4 engine 4x2 vehicles 9.5L (10.0 with automatic quarts) and 3.0L or 4.0L...
Page 242 Add the coolant type originally equipped in your vehicle. DO NOT MIX different colors or types of coolant. DO NOT USE Mazda Extended Life Engine Coolant (orange in color). Refer to Adding engine coolant, in...
Page 243: Lubricant Specifications
Maintenance and Specifications Traction-Lok axles use 2.2–2.4L (4.75–5.0 pints) of rear axle lubricant. Add 118 ml (4 oz.) of Additive Friction Modifier meeting Mazda specifications for complete refill of Traction-Lok axles. Service refill capacities are determined by filling the rear axle 6 mm to 14 mm (1/4 inch to 9/16 inch) below the bottom of the filler hole.
Page 244 Maintenance and Specifications Add 118 ml (4 oz.) of Additive Friction Modifier meeting Mazda specifications for complete refill of Traction-Lok axles. If submerged in water, the rear axle lubricant should be changed. Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are indicated on the dipstick or on the dipstick handle.
Page 245 Maintenance and Specifications VEHICLE DIMENSIONS Vehicle dimensions Regular Cab SuperCab mm mm (in) (in) (1) Overall length 4 786 (188.4) 5 168 (203.4) (2) Overall width 1 785 (70.3) 1 785 (70.3) (3) Overall height 4x2/4x4 1 651 (65.0) / 1 651 (65.0) / 1 727 (68.0) 1 727 (68.0)
Page 246 Maintenance and Specifications...
Page 247 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification Label be affixed to a vehicle and prescribe where the Certification Label may be located. The Certification Label is located on the front door latch pillar on the driver’s side.
Page 248: Accessories
Accessories Accessories CELL PHONES Use of cell phones and other devices by driver: WARNING: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous. Dialing a number on a cell phone while driving also ties-up the driver’s hands.
Page 249: Index
Index Index acid, treating emergencies ..200 jumping a disabled battery ..157 ABS (see Brakes) .....110 maintenance-free ....200 Air bag supplemental restraint servicing ........200 system ..........77 Bed extender ......53 and child safety seats ....80 description ........77 BeltMinder ........73 disposal ........83 Brakes ........110 driver air bag ......81 indicator light ......83 anti-lock ......110–111...
Page 250 ....175 instrument panel ....178 Doors interior ........178 lubricant specifications ..243 interior trim ......178 Driveline universal joint and Mazda car care products ..179 slip yoke ........226 plastic parts ......177 Driving under special washing ........174 conditions ....119, 121–122 waxing ........174 mud ..........122...
Page 251 Index GAWR (Gross Axle Weight Rating) calculating .......127 Flexible Fuel Vehicle (FFV) ..208 GVWR Fluid capacities ......240 (Gross Vehicle Weight Rating) Foglamps ........34 calculating .......127 Four-Wheel Drive vehicles ..119 driving off road .......121 electronic shift ......120 indicator light ......120 Hazard flashers ......137 preparing to drive your Headlamps ........34 vehicle ........113...
Page 252 Index storage ......149–152 fluid capacities ......240 lubricant specifications ..244 Jump-starting your vehicle ..157 reverse ........118 Mirrors automatic dimming rearview mirror ........46 Keyless remote entry system - side view mirrors (power) ..49 see Remote entry system ...55 Motorcraft parts ......214 Keys positions of the ignition ..105 Octane rating ......212 Lamps...
Page 253 Index Remote entry system ...55–56 AM/FM stereo tape/CD/MP3 ..23 arming and disarming the Premium AM/FM stereo anti-theft system ......57 CD6/MP3 ........26 illuminated entry ......59 Snowplowing .........7 locking/unlocking doors ..55–56 replacement/additional Spare tire (see Changing the transmitters .......58 Tire) ........149–150 replacing the batteries .....57 Spark plugs, specifications ..245 Special notice ambulance conversions ....7...
Page 254 Index Transfer case Ventilating your vehicle ...110 fluid checking ......226 Transmission automatic operation ....114 brake-shift interlock (BSI) ..114 Warning chimes ......16 fluid, checking and adding Warning lights (see Lights) ..12 (manual) .........225 Washer fluid ......193 fluid, refill capacities ....240 lubricant specifications ..243–244 Water, Driving through .....123 manual operation ....117 Windows...

Mazda B4000 Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Driving

Roadside Emergencies

Customer Assistance

Cleaning

Maintenance and Specifications

Quick Links

Table of Contents

Related Manuals for Mazda B4000

Summary of Contents for Mazda B4000

Table of Contents
