Intel® Desktop Board
D945GTP
Specification Update
Release Date: November 2007
Order Number: D23993-008US
The Intel
Desktop Board D945GTP may contain design defects or errors known as errata, which may cause the product to deviate
®
from published specifications. Current characterized errata are documented in this Specification Update.
Advertisement
Table of Contents
Related Manuals for Intel D945GTP
Summary of Contents for Intel D945GTP
- Page 1 Release Date: November 2007 Order Number: D23993-008US The Intel Desktop Board D945GTP may contain design defects or errors known as errata, which may cause the product to deviate ® from published specifications. Current characterized errata are documented in this Specification Update.
-
Page 2: Revision History
Desktop Board D945GTP may contain design defects or errors known as errata which may cause the product to deviate from published specifications. Current characterized errata are available on request. Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your product order. -
Page 3: Table Of Contents
Contents ® Specfication Update for the Intel Desktop Board D945GTP Terminology .................... 5 General Information ................. 5 Summary of Changes ................8 Specification Changes ................9 Errata....................10 Documentation Changes ................. 11 Intel Desktop Board D945GTP Specification Update... -
Page 4: Specfication Update For The Intel Desktop Board D945Gtp
945G/945GZ/945P/945PL Express Chipset Family Specification Update (Order Number 307503) for specification updates concerning the 82945G GMCH Controller and that may apply to the desktop board D945GTP. Unless otherwise noted in this document, it should be assumed that any GMCH errata for a given stepping are applicable to the Altered Assembly (AA) revision(s) associated with that stepping. -
Page 5: Terminology
Documentation Changes include typos, errors, or omissions from the current published specifications. These changes will be incorporated in the next release of the specifications. General Information Basic Desktop Board D945GTP Identification Information AA Revision BIOS Revision Notes C97834-301 NT94510J.86A.0980... - Page 6 C97841-304 NT94510J.86A.3239 C97841-305 NT94510J.86A.3814 C97841-306 NT94510J.86A.3996 C97841-307 NT94510J.86A.3996 C97841-308 NT94510J.86A.4076 C97841-309 NT94510J.86A.4078 C97841-310 NT94510J.86A.4089 C97844-301 NT94510J.86A.1042 C97844-302 NT94510J.86A.1616 C97844-303 NT94510J.86A.2487 C97844-304 NT94510J.86A.3814 C97844-305 NT94510J.86A.3996 C97844-306 NT94510J.86A.3996 C97844-307 NT94510J.86A.3996 C97844-308 NT94510J.86A.4076 C97844-309 NT94510J.86A.4078 C97844-310 NT94510J.86A.4089 Intel Desktop Board D945GTP Specification Update...
- Page 7 The AA number is found on a small label on the component side of the board. The 945 Chipset kit used on this AA revision consists of two components as follows: Device Stepping S-Spec Numbers 82945G GMCH SL8FU 82801GB ICH7 SL8FX 82801GR ICH7R SL8FY Intel Desktop Board D945GTP Specification Update...
-
Page 8: Summary Of Changes
Clarifications, or Documentation Changes that apply to the Intel Desktop Board D945GTP. Intel intends to fix some of the errata in a future revision of the desktop board, and to account for the other outstanding issues through documentation or specification changes as noted. -
Page 9: Specification Changes
10/100/1000 IEEE 802.3 compliant • Compliant to IEEE 802.3x flow control support • TCP, IP, UDP checksum offload • Transmit TCP segmentation • Advanced packet filtering • Full device driver compatibility • PCI Express Power Management Support Intel Desktop Board D945GTP Specification Update... -
Page 10: Errata
The Hardware Monitoring and Fan Control may only support up to 3.6V ROBLEM on its Pulse Width Modulation (PWM) outputs. The 4-pin fans used with the Intel Desktop board could have a pull up voltage as high as 5.25V, potentially causing failures in the circuit used for fan control on this Intel Desktop Board. -
Page 11: Documentation Changes
May be fixed in a later hardware revision. TATUS Documentation Changes ® The Documentation Changes listed in this section apply to the Intel Desktop Board D945GTP Technical Product Specification (Order Number D14070). All Documentation Changes will be incorporated into a future version of that specification. -
Page 12: Bios Boot Optimizations
It is possible to optimize the boot process to the point where the system boots so quickly that the Intel logo screen (or a custom logo splash screen) will not be seen. Monitors and hard disk drives with minimum initialization times can also contribute to a boot time that might be so fast that necessary logo screens and POST messages cannot be seen.
