MICROSWITCH BRACKET KIT
For Holley standard-flange carburetors without choke
®
CATALOG #72282
INSTALLATION INSTRUCTIONS
NOTE: This bracket is not compatible with HP series
IMPORTANT NOTE:
carburetors and cannot be used on a carburetor that
Proper installation is the responsibility of the installer.
requires a choke.
Improper installation will void warranty and may result in
poor performance and engine or vehicle damage.
1. Mount switch to bracket so that the arm is pointed away
from the bolt holes and insert screws through switch
and bracket.
2. Thread nuts onto supplied screws, but verify switch arm
alignment before snugging them down.
3. Mount the bracket using the fine threaded holes on the
passenger side of the carburetor that would normally be
reserved for an electric choke housing.
4. Check for full throttle, microswitch operation, and
throttle return.
Catalog #72282
©2008 Edelbrock Corporation
Rev. 3/08 - AJ/mc
Brochure #63-72282
MICROSWITCH BRACKET KIT
For Holley standard-flange carburetors without choke
®
CATALOG #72282
INSTALLATION INSTRUCTIONS
NOTE: This bracket is not compatible with HP series
IMPORTANT NOTE:
carburetors and cannot be used on a carburetor that
Proper installation is the responsibility of the installer.
requires a choke.
Improper installation will void warranty and may result in
poor performance and engine or vehicle damage.
1. Mount switch to bracket so that the arm is pointed away
from the bolt holes and insert screws through switch
and bracket.
2. Thread nuts onto supplied screws, but verify switch arm
alignment before snugging them down.
3. Mount the bracket using the fine threaded holes on the
passenger side of the carburetor that would normally be
reserved for an electric choke housing.
4. Check for full throttle, microswitch operation, and
throttle return.
Catalog #72282
©2008 Edelbrock Corporation
Rev. 3/08 - AJ/mc
Brochure #63-72282
