- Page 1 CD-RECEIVER KDC-MP439 KDC-MP3039 KDC-MP339 KDC-MP239 KDC-139 INSTRUCTION MANUAL © B64-3901-00/00 (MW)
-
Page 2: Table Of Contents
Contents Before use Appendix Basic Operation Accessories/ Installation Procedure 15 General functions Connecting Wires to Terminals Tuner functions Disc play functions Installation General Operation Troubleshooting Guide Audio Control Audio Setup Specifications Speaker Setting Switching Display Tuner Operation Frequency Step Setting Music disc/Audio file Operation Direct Music Search Direct Disc Search... -
Page 3: Before Use
To prevent injury or fire, take the following • When you purchase optional accessories, check with precautions: your Kenwood dealer to make sure that they work • To prevent a short circuit, never put or leave any with your model and in your area. -
Page 4: Basic Operation
Basic Operation Release Display Disc slot Control Auxiliary input knob [VOL] [SRC] [1] [2] [3] [4] [5] [6] [AUTO] [B.BOOST] • To prevent deterioration, do not touch the terminals of the General functions unit or faceplate with your fingers. Power/Source select button [SRC] Auxiliary input Auxiliary input... -
Page 5: Tuner Functions
: Indicates the button etc. to operate. Tuner functions Disc ejection ⁄ Band select Control knob • You can eject the disc for 10 minutes after switching off the Switches between FM1, FM2, and FM3 each time the engine. top side is pressed. Switches to AM when the bottom side is pressed. -
Page 6: General Operation
General Operation Audio Control Adjust the Audio setup item Turn the [VOL] knob. Select the source to adjust Exit Audio Setup mode Press the [SRC] button. Press the [VOL] knob for at least 1 second. Enter Audio Control mode Press the [VOL] knob. Select the Audio item to adjust Speaker Setting Press the [VOL] knob. - Page 7 In CD & External disc source Information Display Disc title “D-TITLE” Track title “T-TITLE” Play time & Track number “P-TIME” Clock “CLOCK” In Audio file source Information Display Music title & Artist name “TITLE” Album name & Artist name “ALBUM” Folder name “FOLDER”...
-
Page 8: Tuner Operation
Tuner Operation Frequency Step Setting Changing the tuning frequency step. The original setting is FM band 50 kHz, and AM band 9 kHz. Turn the power OFF Press the [SRC] button for at least 1 second. Switch the frequency step While pressing the [1] and [5] buttons, press the [SRC] button. -
Page 9: Music Disc/Audio File Operation
Music disc/Audio fi le Operation Function of KDC-MP439/KDC-MP3039/KDC-MP339 Function of KDC-MP439/KDC-MP3039/KDC-MP339/ Function of remote control KDC-MP239 Function of Audio file Direct Music Search Folder Select Doing Music Search by entering the music number. Quickly selecting the folder you want to hear. Enter the music number Enter Folder Select mode Press the number buttons on the remote... -
Page 10: Menu Operation
Menu Operation ⁄ Menu System • Refer to the respective page for information on how to Setting various functions. set the items with reference page number. • Refer to the <Appendix> (page 14) for the details of the Enter Menu mode menu items. -
Page 11: Manual Clock Adjustment
Do the step 4 through 7 step operation, and Exit Clock adjustment mode reenter the security code. Press the [B.BOOST] button. “APPROVED” is displayed. The Security Code function activates. ⁄ Function of KDC-MP439/KDC-MP3039/KDC-MP339/ • If you enter a Code different from your Security Code, KDC-MP239 you have to start over from step 4. -
Page 12: Demonstration Mode Setting
Menu Operation Function of KDC-MP439/KDC-MP3039/KDC-MP339/ KDC-MP239 Demonstration mode Setting Sets the demonstration mode. Select the Demonstration mode Press the top or bottom side of the Control knob. Select the “DEMO” display. Set the Demonstration mode Press the center of the Control knob for at least 2 seconds. -
Page 13: Basic Operations Of Remote Control
Accessory of KDC-MP439/KDC-MP3039/KDC-MP339 Basic Operations of remote control In Disc source Music select [4]/[¢] Folder/Disc select [FM]/[AM] FM/AM – Pause/Play [38] DIRECT DIRECT KDC-MP439: KDC-MP3039: ⁄ KDC-MP339: 0 — 9 About [ ] (KDC-MP439) This button is used when Bluetooth HANDS FREE BOX is connected. -
Page 14: Kdc-Mp439/Kdc-Mp3039/Kdc-Mp339/Kdc-Mp239/Kdc
An online manual about audio files is put on the ON2: Activates the attenuator function when site, www.kenwood.com/audiofile/. On this online switched to AUX source. manual, detailed information and notes which are not Turn off the attenuator function when written in this manual are provided. -
Page 15: Accessories/ Installation Procedure
5. Connect the wiring harness connector to the unit. or later can be connected to this unit. 6. Install the unit in your car. Refer to the catalog or consult your Kenwood dealer 7. Reconnect the - battery. for connectable models of disc changers/ CD players. -
Page 16: Connecting Wires To Terminals
Connect to the terminal that is grounded TEL mute wire (Brown) when either the telephone rings or during MUTE conversation. ⁄ To connect the Kenwood navigation system, consult your navigation manual. Not Used (Blue) ⁄ ANT. Do not let the wire come out from the tab. -
Page 17: Installation
Installation non-Japanese cars Removing the hard rubber frame Engage the catch pins on the removal tool and Metal mounting strap remove the two locks on the upper level. (commercially available) Upper the frame and pull it forward as shown in Firewall or metal support the figure. -
Page 18: Troubleshooting Guide
Troubleshooting Guide Some functions of this unit may be disabled by The messages shown below display your systems condition. some settings made on this unit. TOC ERR/E-04: • No disc has been loaded in the disc Cannot display the user of System Q. magazine. -
Page 19: Specifications
Specifi cations FM tuner section Audio section Frequency range Maximum output power 200 kHz space : 87.9 MHz – 107.9 MHz : 50 W x 4 50 kHz space : 87.5 MHz – 108.0 MHz Full Bandwidth Power (at less than 1% THD) : 22 W x 4 Usable sensitivity (S/N = 30dB) : 9.3dBf (0.8 μV/75 Ω)
