Summary of Contents for Dynacord PowerMate Powered Mixer
- Page 1 ENGLISH...
- Page 2 The PowerMate The PowerMate has long been regarded as the epito- me of a powered mixer, offering uncompromised pro- fessional quality in every department: professional components, professional features, professional relia- bility. With well over 80,000 units already sold, the PowerMate is one of the most important products in the pro audio sector —...
- Page 3 2 x 700 watts into 4 ohms and an absolutely safe 2 x 870 watts into 2.66 ohms with comparatively little heat build-up. All the protective circuits with which the Dynacord 19” amplfiers are equipped are present here, including protections against overheating, short-circuits and DC voltage and HF and back EMF protection.
- Page 4 SYSTEM DETAILS & FEATU MIC / LINE CHANNELS The MIC/LINE channels of the PowerMate are outstand- ingly well-equipped and offer a multitude of useful extras. To allow the use of condenser microphones, phantom power can be switched to the channels in groups of six. Inserts in each mono channel permit the external process- ing of the microphone signals.
- Page 5 Special pole zero com- pensators — Dynacord’s patented LPN filter — eliminate transient response distortion typ- ically introduced by PA speakers and provide a degree of punch and impulse-fidelity in the bass...
-
Page 6: Rack Mounting
specs PowerMate 1000/1600 Maximum Midband Output Power, 1 kHz, THD=1%, Dual Channel into 4 Ohms into 8 Ohms Maximum Midband Output Power, 1 kHz, THD=1%, Single Channel into 4 Ohms into 8 Ohms Rated Output Power, THD=0.1%, Single Channel into 4 Ohms into 8 Ohms Maximum Output Voltage of power amplifier, no load THD at 1kHz, MBW=80kHz... - Page 7 Safe and easy to carry, fast and simple to set up, intuitive and uncomplicated to operate, the smallest member of the PowerMate family delivers Dynacord quality in a compact, elegant frame. pro-power Despite its compact dimensions,...
- Page 8 EVI Audio GmbH · Hirschberger Ring 45 · D-94315 Straubing Phone: + 49 9421-706 0 · Fax: + 49 9421-706 265 Art.Nr. 163077 · Printed in Germany (DOPF/DR) · 4000/06/08 Internet: http://www.dynacord.com SUBJECT TO CHANGE WITHOUT PRIOR NOTICE! 6 MIC/LINE + 2 STEREO LINE...
