Dhcp Reservation - D-Link DIR-815 User Manual

Section 3 - Configuration
If you want a computer or device to always have the same IP address assigned, you can create a DHCP reservation. The router
will assign the IP address only to that computer or device.
Note: This IP address must be within the DHCP IP Address Range.
Checkbox:
Check this box to enable the reservation.
Computer
Enter the computer name. Alternatively, select a
Name:
computer that currently has a DHCP lease from the
drop down menu and click << to automatically
populate the Computer Name, IP Address, and MAC
Address fields.
IP Address: Enter the IP address you want to assign to the
computer or device. This IP Address must be within
the DHCP IP Address Range.
MAC Address: Enter the MAC address of the computer or device.
When you have finished configuring the new DHCP Reservation, click the Save Settings button at the top or bottom of the
window to activate your reservations.
D-Link DIR-815 User Manual
Network Settings

DHCP Reservation

47
