Dimension One Spas Diplomat Specifications

2005 Diplomat Specifications
General
Shape
Shell Material
Height
Width
Length
Corner Radii
Seating Capacity
Water Capacity
Dry Weight
Shipping Weight
Full Weight
Skirt Material
Poly Floor
Water System
Motor Size – Peak (Continuous) HP
# Pumps/Speed
Plumbing Systems
Pump Returns
Typhoon Jets
VCR Jet ® - Air Adjustable/Directional
VCR Jet ® - Rotator
VCR Jet ® - Mini Rotator
VCR Jet ® - Mini Directional
VCR Jet ® - Mini Directional in NFJ
VCR Jet ® - Euro Directional
Ozone Jet
Heater Return Jet
Filters/Coverage
Water Treatment System
Gate Valves
Diverter Valves
Floor Drains
Skimmer
Electrical System
Voltage
Amperage
Heater
Thermostat
Light
Control System
Upper Control
Auxiliary Upper Control
Programmable
Special Features
Dynamic Massage Sequencer
w/ control panel
NeckFlex ® Jet Pillows
Headrest Pillows
Cup Holders
Tactile Therapy
Note: 1. Subject to change without notice.
2. Reference DOC-1334 REV A.
Doc-1212 Rev -B
Domestic (60Hz)
Square
Ultralife™ / Granitex™
/ Geloy®
35 ½ in.
91 ½ in.
91 ½ in.
16 in.
5
325 Gallons
900 lbs
900 lbs
3610 lbs
Wood or Synthetic
Yes
4.0 (2.5) HP
Two / Dual
4
4
1
8
12
4
10
8
0
1
1
2 / 75 sq. ft.
Ultra Pure™
4
2
1
8" Weir
240
50/40/30
FastFlo 2.7,4.0,5.5 kW
Electronic
1 with optional LED
MSPA-MP-D12
Scrolling Message Center
Yes
Yes
No
2
1
2
Foot & hand
Rev Date: 1/31/04
Part #
01562-23A/B
01510-559
01510-436
01510-418
01510-415
01510-445
01510-444
01510-595
01510-201
01510-275
(2) 01561-00
01522-30
01522-50
01510-231
01510-137
01781-20
01512-003 (O)
01710-1008
01580-0001
01510-598
01510-593
Specification, 2005, Diplomat

Dimension One Spas

Export (50Hz)
Square
Ultralife™ / Granitex™
/ Geloy®
90 cm
232 cm
232 cm
41 cm
5
1230 Liters
408 kg
431 kg
1638 kg
Wood or Synthetic
Yes
3.6 (2.0) HP
Two / single
4
4
1
8
12
4
10
8
0
1
1
2 / 6.97 sq. meters
Ultra Pure™
4
2
1
20 cm Weir
240
1X16 / 2X16 / 1X32
FastFlo 2.9 kW
Electronic
1 with optional LED
MSPA-MP-D11-CE
Scrolling Message Center
Yes
Yes
No
2
1
2
Foot & hand
Part #
01562-29A/B
01510-559G
01510-436G
01510-418G
01510-415G
01510-445G
01510-444G
01510-595G
01510-201G
01510-275G
(2) 01561-00
01522-30
01522-50G
01510-231G
01510-137G
01781-20
01512-003 (O)
01710-1008E
01580-0001
01510-598
01510-593
