EC - Declaration of Conformity
We, ModeLabs Technologies Ltd of
31/F China Online Centre,
333 Lockhart Road,
Wan Chai, Hong Kong
declare under our sole responsibility that our product
BLUETREK sugar
to which this declaration refers is in conformity with the appropriate standards
EN300 328-02
EN301 489-17
EN301 489-01
EN50371
EN60950
Following the provisions of Radio and Telecommunications Terminal Equipment directive
1999/5/EC.
September 2007
Guillaume Ponticelli, Director of Development
Advertisement
Table of Contents
Related Manuals for BlueTrek SUGAR
Summary of Contents for BlueTrek SUGAR
- Page 1 We, ModeLabs Technologies Ltd of 31/F China Online Centre, 333 Lockhart Road, Wan Chai, Hong Kong declare under our sole responsibility that our product BLUETREK sugar to which this declaration refers is in conformity with the appropriate standards EN300 328-02 EN301 489-17 EN301 489-01...
- Page 2 FCC/ Industry Canada Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. In compliance with Industry Canada regulations, technical specifications have been provided in a declaration of conformity.
- Page 3 -You must charge it continuously for about 4 hours, until the red indicator light turns off. Please refer to the “Charging the BLUETREK® SUGAR” section of this manual. -Pair the headset with a mobile phone. Please refer to the “Pairing the BLUETREK® SUGAR” section of this manual.
-
Page 4: Charging
Charging the BLUETREK® SUGAR Please connect the charger to the headset and to the main. During the charge, the indicator light is red. The indicator light will turn off when the charge is complete. During subsequent charges, the charging should take approximately 3 hours. - Page 5 Pairing is the process of linking 2 Bluetooth® devices, so that they can communicate. To initiate pairing: Place the BLUETREK® SUGAR and your mobile phone within 0.3 meter (1 foot) from each other. Switch on your phone and select its Bluetooth®...
- Page 6 Once the mobile phone detects the headset, a “BLUETREK SUGAR” message will be displayed. Follow the phone instructions to accept the pairing. The PIN code (or passkey) is 0000, then press “yes” or “ok” . BLUETREK SUGAR BLUETREK SUGAR BLUETREK SUGAR “0000”...
- Page 7 Fitting lanyard Wearing the BLUETREK® SUGAR Two different sizes of ear hooks are included in the pack to suit your ear size. 5 I BLUETREK SUGAR...
-
Page 8: Making A Call
Switching the BLUETREK® SUGAR ON and OFF Switching BLUETREK® SUGAR ON When your headset is off, press and hold the TALK button for about 5 seconds until the blue indicator light is on. A beep (2 tones) can be heard in the speaker. Release the TALK button. -
Page 9: Answering A Call
This function may not be available on some phones, please refer to the trouble shooting frequent asked questions in our website: www.bluetrek.com. to find out more. Answering a call When the headset rings, press once on the TALK button to take the call. -
Page 10: Muting The Microphone
In the Headset profile, you can simply turn off your headset. Transferring a call from the mobile phone to the BLUETREK® SUGAR During an active call on the mobile phone, press once on the TALK button to transfer the call. - Page 11 Ergobud position that you feel the most comfortable. To replace the Ergobud*, remove the speaker cover by pulling gently out from the speaker. Place the Ergobud* back onto the speaker by inserting the bottom part first. * Registered trademark pending 9 I BLUETREK SUGAR...
- Page 12 Pre-registered numbers feature -This feature allows you to store your 2 favourite numbers in your BLUETREK® SUGAR headset and to dial these numbers directly from your headset. (Important: This feature is only available in the Hands-free profile). Storing your favourite numbers 1) Ensure your BLUETREK®...
- Page 13 3) Press and hold the “Vol-“ button on your BLUETREK® SUGAR headset for approx. 3 seconds, until the purple indicator light is on. (A beep can be heard in the speaker). 4) If the number is correct and have stored in the headset, you will hear: 1 beep in the speaker and the blue indicator light will flash once if the number has been stored in position 1.
-
Page 14: Call Waiting
To end the active call and take the hold call, press once on the TALK button. This function may not be available, depending on your phone. However, you can always answer the second call from your phone keypad. BLUETREK SUGAR I 12... -
Page 15: Troubleshooting Guide
The first thing you should do when encountering a problem that you cannot solve with this manual, is to switch off your headset and your mobile phone, and switch them on again. To find out more, please refer to the trouble shooting frequent asked questions in our website: www.bluetrek.com. 13 I BLUETREK SUGAR... -
Page 16: Guidelines For Safe Use
- Check the regulation in your area if you plan to use your headset while driving. - Turn off your headset before boarding an airplane. CAUTION : Danger of explosion if battery is incorrectly replaced. Dispose of batteries according to local regulations. Do not dispose as household waste. BLUETREK SUGAR I 14...
