10/30/09
This procedure is used to update Main CPU Ver.
flash programming for the FT-950 Transceivers.
*If you already have software Ver. 11.53 it is not necessary to update the FT-950 EDSP again.
We recommend installing the Flash Programming Software on a PC computer with Windows 2000,
XP or Vista Operating System; and use the serial cable RS-232C, DB9F to DB9F straight cable.
NOTE: There are many USB adapters available; however some may not function with this software.
We recommend using the latest USB adapter driver software when available.
1. Down load the FT-950 data file [FT-950_PEP950_11-30-09.zip] from the following website:
http://www.yaesu.com/indexVS.cfm?cmd=DisplayProducts&ProdCatID=102&encProdID=292E
02F4E4D00EC99887A63E7B8ECD1B&DivisionID=65&isArchived=0
2. Save the FT-950 data file [FT-950_PEP950_11-30-09.zip] to the desktop on your computer.
3. Unzip and Extract the contents of [FT-950_PEP950_11-30-09.zip] to the desktop of your
computer.
4. You will find the PEP950_EDSP3 and PEP950_MAIN folders on your desktop.
The programmer and software are now stored on your computer on the desktop. The files designated
in the last step above are ready to update your FT-950 Transceiver.
* The PEP_950 MAIN folder includes the new software writer FWS005 V2.01. We recommend not using
the earlier version software and writer. .
* The PEP_950 EDSP folder includes a new software writer V3.01; it no longer requires the four DLL files
that were needed by V1.03. We recommend you use the V3.01 writer and remove V1.03 and the four DLL
files from you PC.
The software updates will work with all versions (AF, AS, EU, NA, OC, SA or all Countries) of the FT-950.
PEP950
Install the data file to PC
0112
and EDSP Ver.
11.53
the
Advertisement
Related Manuals for Yaesu FT-950 - UPDATE V0112 AND V11.53
Summary of Contents for Yaesu FT-950 - UPDATE V0112 AND V11.53
- Page 1 We recommend using the latest USB adapter driver software when available. Install the data file to PC 1. Down load the FT-950 data file [FT-950_PEP950_11-30-09.zip] from the following website: http://www.yaesu.com/indexVS.cfm?cmd=DisplayProducts&ProdCatID=102&encProdID=292E 02F4E4D00EC99887A63E7B8ECD1B&DivisionID=65&isArchived=0 2. Save the FT-950 data file [FT-950_PEP950_11-30-09.zip] to the desktop on your computer.
- Page 2 Ver. 0112 MAIN CPU implements improvements (also includes all previous updates): • The FH-2 [ ] keys are made to increment the frequency at 100kHz up or down. <- -> • Correct the CW Auto Mode. • DMU Band scope Display Signal Peak Frequency is centered. Ver.
- Page 3 NOTE: I f you receive a “communications error” message on your screen, click on the Configure box and choose a different COM port from the drop down menu. Then click the WRITE button again. 6. When the program opens, confirm that the file AH031_V0112.SFL is highlighted; if not, click on it to highlight it.
- Page 4 5. On your computer desk top open PEP950_EDSP folder and find the EDSP-301 icon as shown below. Double-click the EDSP-301 icon, displayed on the Program Screen. 6. Click the Update button. You will see AH031_V1153 out file displayed. If you do not see AH031_V1153 (as in the screen below), then open the “Look in:”...
- Page 5 0112 Software version 11.53 We hope this new software will increase your enjoyment of your FT-950. Thank you for choosing Yaesu radios. If you have any problems or questions please contact Vertex Standard, Amateur Tech Support. amateurtech@vxstdusa.com Best regards, Mikio Maruya, WA6F Executive Vice President Engineering &...
