SMC Networks WBR14S-N3 - annexe 1 Manual

Draft 11n wireless broadband router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Barricade
TM
N
Draft 11n Wireless Broadband Router
SMCWBR14S-N3

Advertisement

Table of Contents
loading

Related Manuals for SMC Networks WBR14S-N3 - annexe 1

Summary of Contents for SMC Networks WBR14S-N3 - annexe 1

  • Page 1 Barricade Draft 11n Wireless Broadband Router SMCWBR14S-N3...

  • Page 3: User Guide

    Draft 11n Wireless Broadband Router User Guide 20 Mason September 2009 Irvine, CA 92618 Pub. # 149100000009W Phone: (949) 679-8000 E092009-AP-R01...
  • Page 4 No license is granted by implication or otherwise under any patent or patent rights of SMC. SMC reserves the right to change specifications at any time without notice.
  • Page 5 Warranty and Product Registration To register SMC products and to review the detailed warranty statement, please refer to the Support Section of the SMC Website at http://www.smc.com.

  • Page 6: Federal Communication Commission Interference Statement

    Compliances Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 7 Käesolevaga kinnitab SMC seadme Radio LAN device vastavust Eesti direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele. English Hereby, SMC, declares that this Radio LAN device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
  • Page 8 1999/5/CE. Latvian Latviski Lithuanian Maltese Malti Spanish Por medio de la presente SMC declara que el Radio LAN device Español cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE viii...

  • Page 9: Ncc Statement

    Polish Polski Portuguese SMC declara que este Radio LAN device está conforme com os Português requisitos essenciais e outras disposições da Directiva 1999/5/CE. Slovak Slovensky Slovenian Slovensko NCC Statement 低功率輻射規定 根據國家通信傳播委員會低功率電波輻射性電機管理辦法之規定，應包含下列警語： 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自 變更頻率、加大功率或變更原設計之特性及功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象 時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業 之無線電通信。低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設 備之干擾。...

  • Page 10: About This Guide

    About This Guide Purpose This guide details the hardware features of the wireless AP/Router, including its physical and performance-related characteristics, and how to install the device and use its configuration software. Audience This guide is for PC users with a working knowledge of computers. You should be familiar with Windows operating system concepts.

  • Page 11: Table Of Contents

    Table of Contents Chapter 1: Introduction Package Checklist Hardware Description Antennas LED Indicators Ethernet RJ-45 Ports Power Socket Reset Button WPS Button Hardware Installation Chapter 2: Installation Gateway Mode Bridge Mode Chapter 3: Network Planning Internet Gateway Router LAN Access Point Wireless Bridge Chapter 4: Initial Configuration Using the Setup Wizard...
  • Page 12 Contents L2TP PPTP LAN Setting 5-11 Advanced Routing 5-13 QoS Setting 5-15 5-16 Wireless Settings 5-16 Basic Settings 5-17 Advanced Wireless Settings 5-23 WLAN Security 5-28 Wi-Fi Protected Setup (WPS) 5-35 Station List 5-37 Firewall 5-37 MAC/IP/Port Filtering 5-38 Virtual Server Settings (Port Forwarding) 5-40 5-41 System Security...

  • Page 13: Chapter 1: Introduction

    Chapter 1: Introduction The SMCWBR14S-N3 wireless AP/Router is an IEEE 802.11n wireless gateway router that connects your Internet access device (cable or ADSL modem) to your PC or local area network, or to its own secure wireless network. The wireless AP/Router can be automatically configured with other Wi-Fi Protected Setup (WPS) devices by simply pressing its WPS button.

  • Page 14: Hardware Description

    Introduction Hardware Description Antennas Reset Button WPS Button Power Socket Ethernet LAN Ethernet WAN RJ-45 Ports RJ-45 Port Figure 1-1. Rear Panel Antennas The access point includes integrated MIMO antennas for wireless communications. A MIMO antenna system uses two or more identical antennas to receive and transmit signals, helping to increase data throughput and range.

  • Page 15: Led Indicators

    Hardware Description LED Indicators The wireless AP/Router includes eight status LED indicators, as described in the following figure and table. Power 802.11n Link/Activity WPS Authentication LAN Link/Activity WAN Link/Activity Figure 1-2. LED Indicators Status Description POWER On Blue Indicates that the system is working normally. WLAN On Blue Indicates the 802.11n radio is enabled.

  • Page 16: Ethernet Rj-45 Ports

    Introduction Ethernet RJ-45 Ports The wireless AP/Router has the following RJ-45 ports: • The four RJ-45 LAN ports are for connections to PCs or to a 10/100 Mbps network switch. • The RJ-45 WAN port is for connection to a DSL or cable modem, or to a LAN or other device that provides your Internet access.

  • Page 17: Hardware Installation

    Hardware Installation Hardware Installation Select a Site – Choose a proper place for the wireless AP/Router. In general, the best location is at the center of your wireless coverage area, within line of sight of all wireless devices. For optimum performance, consider these points: •...
  • Page 18 Introduction...

  • Page 19: Chapter 2: Installation

    Chapter 2: Installation The wireless AP/Router has two basic operating modes that can be set through the web-based management interface. For information on setting the mode suitable for your network environment, see “Operation Mode configuration” on page 5-4. • Gateway Mode — A gateway mode that connects a wired LAN and wireless clients to an Internet access device, such as a cable or DSL modem.

  • Page 20: Bridge Mode

    Installation To connect the wireless AP/Router in Gateway Mode for use as an Internet gateway, follow these steps: Connect an Ethernet cable from the wireless AP/Router’s WAN port to your Internet connected cable or ADSL modem. Connect an Ethernet cable from the wireless AP/Router’s LAN port to your PC. Alternatively, you can connect to a workgroup switch to support multiple users.
  • Page 21 Bridge Mode Set up wireless devices Notebook PC Connect AC power adapter to power source Connect LAN and WAN ports to an Ethernet LAN switch or PCs Figure 2-2. Bridge Mode Connection To connect the wireless AP/Router for use as an access point, follow these steps: Using Ethernet cable connect the wireless AP/Router’s LAN and WAN ports to PCs or a LAN switch.
  • Page 22 Installation...

  • Page 23: Chapter 3: Network Planning

    Chapter 3: Network Planning The wireless AP/Router is designed to be very flexible in its deployment options. It can be used as an Internet gateway for a small network, or as an access point to extend an existing wired network to support wireless users. It also supports use as a wireless bridge to connect two wired LANs.

  • Page 24: Lan Access Point

    Network Planning The private local network, connected to the LAN port or wireless interface, provides a Dynamic Host Configuration Protocol (DHCP) server for allocating IP addresses to local PCs and wireless clients, and Network Address Translation (NAT) for mapping the multiple "internal" IP addresses to one "external" IP address. The public external network, connected to the WAN port, supports DHCP client, Point-to-Point Protocol over Ethernet (PPPoE), static IP for connection, L2TP and PPTP to an Internet service provider (ISP) through a cable or DSL modem.

  • Page 25: Wireless Bridge

    Wireless Bridge Wireless Bridge The IEEE 802.11 standard defines a Wireless Distribution System (WDS) for bridge connections between access points. The wireless AP/Router can use WDS to forward traffic on links between units. A single WDS bridge link can be specified for the WLAN1 interface. One end of a link must be configured as the “WDS Parent”...
  • Page 26 Network Planning...

  • Page 27: Chapter 4: Initial Configuration

    Chapter 4: Initial Configuration The wireless AP/Router offers a user-friendly web-based management interface for the configuration of all the unit’s features. Any PC directly attached to the unit can access the management interface using a web browser, such as Internet Explorer (version 6.0 or above).

  • Page 28: Using The Setup Wizard

    Initial Configuration Using the Setup Wizard There are only a few basic steps you need to set up the wireless AP/Router and provide a connection for network access for other wireless stations. The Setup Wizard takes you through configuration procedures for the general network settings.

  • Page 29: Dhcp

    Using the Setup Wizard WAN Configuration – Specifies the Internet connection parameters for the wireless AP/Router’s WAN port. Click Next after completing the setup. WAN Connection Type — By default, the access point WAN port is configured with DHCP enabled. After you have network access to the access point, you can use the web browser interface to modify the initial IP configuration, if needed.

  • Page 30: Static Ip

    Initial Configuration Static IP Configures a static IP for the WAN port. Figure 4-5. Setup Wizard - WAN Static IP • IP Address – The IP address of the wireless AP/Router. Valid IP addresses consist of four decimal numbers, 0 to 255, separated by periods. •...

  • Page 31: Pppoe

    Using the Setup Wizard • MAC Clone Mode – Some ISPs limit Internet connections to a specified MAC address of one PC. This setting allows you to manually change the MAC address of the wireless AP/Router's WAN interface to match the PC's MAC address provided to your ISP for registration.

  • Page 32: L2Tp

    Initial Configuration L2TP Enables the Layer Two Tunneling Protocol (L2TP) for implementing virtual private networks. The service is provided in many European countries. Figure 4-7. Setup Wizard - WAN L2TP • Server IP – Sets the L2TP server IP Address. (Default: l2tp_server;...

  • Page 33: Pptp

    Using the Setup Wizard • Default Gateway – The IP address of the gateway router for the wireless AP/ Router, which is used if the requested destination address is not on the local subnet. • MAC Clone Mode – Some ISPs limit Internet connections to a specified MAC address of one PC.
  • Page 34 • Network Name (SSID) – The name of the wireless network service provided by the VAP. Clients that want to connect to the network must set their SSID to the same as that of the VAP interface. (Default: “SMC”; Range: 1-32 characters) • Security Policy – Configures the security mode used by clients.

  • Page 35: Chapter 5: System Configuration

    Chapter 5: System Configuration The wireless AP/Router offers a user-friendly web-based management interface for the configuration of all the unit’s features. Any PC directly attached to the unit can access the management interface using a web browser, such as Internet Explorer (version 6.0 or above).
  • Page 36 System Configuration The System Information page displays the System, Internet Configuration, and Local Network Settings. Figure 5-2. System Information (Gateway Mode) The information in this chapter is organized to reflect the structure of the web management screens for easy reference. The Configuration pages include the options in the table below.
  • Page 37 Table 5-1. Advanced Settings Menu Description Mode Page System Mode Operation Mode Sets the operating modes Both Network Settings Configures settings for the wide area network Gateway Sets the unit’s IP address and enables DNS Gateway 5-11 Advanced Routing Configures Static and Dynamic Routing settings Gateway 5-13 Configures Quality of Service (QoS) for wireless traffic...

  • Page 38: Operation Mode Configuration

    System Configuration Operation Mode configuration The Operation Mode Configuration pages allow you to setup the mode suitable for your network environment. Figure 5-3. System Information (Gateway Mode) • Bridge Mode – An access point mode that extends a wired LAN to wireless clients. •...

  • Page 39: Dhcp

    Network Settings DHCP Enables Dynamic Host Configuration Protocol (DHCP) for the WAN port. This setting allows the wireless AP/Router to automatically obtain an IP address from a DHCP server normally operated by the Internet Service Provider (ISP). Figure 5-4. WAN Setting - DHCP •...

  • Page 40: Static Ip

    System Configuration Static IP Configures a static IP for the WAN port. Figure 5-5. WAN Setting - Static IP • IP Address – The IP address of the wireless AP/Router. Valid IP addresses consist of four decimal numbers, 0 to 255, separated by periods. •...

  • Page 41: Pppoe

    Network Settings PPPoE Enable the wireless AP/Router IP address to be assigned automatically from an Internet service provider (ISP) through an xDSL modem using Point-to-Point Protocol over Ethernet (PPPoE). Figure 5-6. WAN Setting - PPPoE • PPPoE Username – Sets the PPPoE user name for the WAN port. (Default: pppoe_user;...

  • Page 42: L2Tp

    System Configuration L2TP Enables the Layer Two Tunneling Protocol (L2TP) for implementing virtual private networks. The service is provided in many European countries. Figure 5-7. WAN Setting - L2TP • Server IP – Sets the L2TP server IP Address. (Default: l2tp_server; Range: 1~32 characters) •...

  • Page 43: Pptp

    Network Settings • Operation Mode – Selects the operation mode as Keep Alive, On Demand or Manual. (Default: Keep Alive) - Keep Alive Mode: The wireless AP/Router will periodically check your Internet connection and automatically re-establish your connection when disconnected. (Default: 60 seconds) - On Demand Mode: The maximum length of inactive time the unit will stay connected to the DSL service provider before disconnecting.
  • Page 44 System Configuration • Server IP – Sets a PPTP server IP Address. (Default: pptp_server) • Username – Sets the PPTP user name for the WAN port. (Default: pptp_user; Range: 1~64 characters) • Password – Sets a PPTP password for the WAN port. (Default: pptp_password; Range: 1~32 characters) •...

  • Page 45: Lan Setting

    Network Settings LAN Setting The wireless AP/Router must have a valid IP address for management using a web browser and to support other features. The unit has a default IP address of 192.168.2.1. You can use this IP address or assign another address that is compatible with your existing local network.
  • Page 46 System Configuration • LAN IP Address – Valid IP addresses consist of four decimal numbers, 0 to 255, separated by periods. The default setting is 192.168.2.1. • Subnet Mask – Indicate the local subnet mask. (Default: 255.255.255.0.) • MAC Address – The shared physical layer address for the wireless AP/Router’s LAN ports.

  • Page 47: Advanced Routing

    Network Settings • DNS Proxy – Enables DNS proxy on the LAN port. DNS Proxy receives DNS queries from the local network and forwards them to an Internet DNS server. (Default: Disable) Advanced Routing Routing setup allows a manual method to set up routing between networks. The network administrator configures static routes by entering routes directly into the routing table.

  • Page 48: Routing Table

    System Configuration Routing Table This page displays the information necessary to forward a packet along the best path toward its destination. Each packet contains information about its origin and destination. When a packet is received, a network device examines the packet and matches it to the routing table entry providing the best match for its destination.

  • Page 49: Qos Setting

    Network Settings Dynamic Route The wireless AP/Router supports RIP 1 and RIP 2 dynamic routing protocol. Routing Information Protocol (RIP) is the most widely used method for dynamically maintaining routing tables. RIP uses a distance vector-based approach to routing. Routes are chosen to minimize the distance vector, or hop count, which serves as a rough estimate of transmission cost.

  • Page 50: Alg

    System Configuration The application gateway settings provide a filter for certain protocol data (such as FTP and SIP) to pass through the wireless AP/Router NAT and firewall restrictions. Figure 5-14. ALG Settings • FTP Support – Allows FTP packets to pass through the wireless AP/Router. •...

  • Page 51: Basic Settings

    Wireless Settings Traffic to specific VAPs can be segregated based on user groups or application traffic. Both VAPs can have up to 64 wireless clients, whereby the clients associate with these VAPs the same as they would with a physical access point. Note: The radio channel settings for the access point are limited by local regulations, which determine the number of channels that are available.
  • Page 52 VAP. Clients that want to connect to the network must set their SSID to the same as that of the VAP interface. (Default: “SMC”; Range: 1-32 characters) - Multiple SSID – The number of wireless network interfaces (SSIDs) supported on the device.
  • Page 53 Wireless Settings the same as that used by the wireless AP/Router to which it is linked. Selecting Auto Select enables the wireless AP/Router to automatically select an unoccupied radio channel. Wireless Distribution System (WDS) The WLAN1 radio interface can be configured to operate in a mode that allows it to forward traffic directly to other access point units.
  • Page 54 System Configuration Figure 5-16. WDS Settings WDS Setting — Configures WDS related parameters. Up to four MAC addresses can be specified for each unit in the WDS network. WDS links may either be manually configured (Bridge and Repeater modes) or auto-discovered (Lazy mode). •...
  • Page 55 Wireless Settings HT Physical Mode Settings Figure 5-17. HT Physical Mode Settings • HT Operation Mode – Packets from 802.11n clients are referred to as High Throughput (HT) Greenfield packets, in other words packets that can be transmitted at rates of up to 300 Mbps assuming that HT Channel Bandwidth is set to 20/40Mhz, see HT Channel Bandwidth next page.
  • Page 56 System Configuration • MCS – The Modulation and Coding Scheme (MCS) is a value that determines the modulation, coding and number of spatial channels. (Options: value [range] = 0~7 (1 Tx Stream), 8~15 (2 TxStream), 32 and auto (33). Default: auto) •...

  • Page 57: Advanced Wireless Settings

    Wireless Settings Advanced Wireless Settings The Advanced Setting page allows you to configure the more advanced radio settings, many of which are enabled by default. Click “Wireless Settings” followed by “Advanced”. Figure 5-19. Advanced Wireless Settings • BG Protection – Enables a backward compatible protection system for 802.11b clients.
  • Page 58 System Configuration • Beacon Interval – The rate at which beacon signals are transmitted from the access point. The beacon signals allow wireless clients to maintain contact with the access point. They may also carry power-management information. (Range: 20-999 TUs; Default: 100 TUs) •...
  • Page 59 Wireless Settings • Short Slot – Sets the basic unit of time the wireless AP/Router’s uses for calculating waiting times before data is transmitted. Enabling a short slot time can increase data throughput on the wireless AP/Router, but requires that all clients can support a short slot time (that is, 802.11g-compliant clients must support a short slot time).
  • Page 60 System Configuration • APSD Capable – Auto Power Save Delivery is used for saving power consumption. APSD allows a longer beacon interval until the traffic arrives. (Default: Disable. , See “Beacon Interval” on page 5-24 • DLS Capable – The Direct Link Setup (DLS) allows all clients transfer data more effectively.
  • Page 61 Wireless Settings Figure 5-21. WMM Parameters WMM Acknowledge Policy – By default, all wireless data transmissions require the sender to wait for an acknowledgement from the receiver. WMM allows the acknowledgement wait time to be turned off for each Access Category (AC). Although this increases data throughput, it can also result in a high number of errors when traffic levels are heavy.

  • Page 62: Wlan Security

    System Configuration • TXOP Limit (Transmit Opportunity Limit) – The maximum time an AC transmit queue has access to the wireless medium. When an AC queue is granted a transmit opportunity, it can transmit data for a time up to the TxOpLimit. This data bursting greatly improves the efficiency for high data-rate traffic.
  • Page 63 Wireless Settings Click on “Wireless Settings,” followed by “Security”. Figure 5-22. Wireless Security Settings Security Settings — The security settings determine the security mode and enable WEP keys. • Security Mode – Configures the security mode used by clients. (WLAN1/WLAN2 Defaults: Open) 5-29...
  • Page 64 System Configuration - Open: Open-system authentication accepts any client attempting to connect the wireless AP/Router without verifying its identity. In this mode the default encryption type is "None." - Shared: The shared-key approach uses Wired Equivalent Privacy (WEP) to verify client identity by distributing a shared key to clients before attempting authentication.
  • Page 65 Wireless Settings - WPA-PSK or WPA2-PSK or WPA-PSK/WPA2-PSK: The WPA or WPA2 mode uses a common password phrase, called a Pre-Shared Key, that must be manually distributed to all clients that want to connect to the network. Specify a key as an easy-to-remember form of letters and numbers. The WPA Preshared Key can be input as ASCII string (8-63 characters) or Hexadecimal format (length is 64).
  • Page 66 System Configuration - WPA or WPA1/WPA2: Defines a transitional mode of operation for networks moving from WPA security to WPA2. WPA1/WPA2 Enterprise Mode allows both WPA1 and WPA2 clients to associate to a common SSID interface. In WPA1/ WPA2 mixed mode, the unicast encryption cipher (TKIP or AES-CCMP) is negotiated for each client.
  • Page 67 Wireless Settings • Encryption Type – Selects the data encryption type to use. (Default: determined by the Security Mode selected) - None: Disables data encryption. - WEP: Selects WEP keys for data encryption. - TKIP: Uses Temporal Key Integrity Protocol (TKIP) keys for encryption. WPA specifies TKIP as the data encryption method to replace WEP.
  • Page 68 System Configuration • Key 1 ~ Key 4 – Sets WEP key values. The user must first choose between ASCII or Hexadecimal keys. At least one key must be specified. Each WEP key has an index number. The selected key is used for authentication and encryption on the VAP interface.

  • Page 69: Wi-Fi Protected Setup (Wps)

    Wireless Settings • RADIUS Server Shared Secret – A shared text string used to encrypt messages between the access point and the RADIUS server. Be sure that the same text string is specified on the RADIUS server. Do not use blank spaces in the string. (Maximum length: 20 characters) •...
  • Page 70 • WPS Configured – States if WPS for wireless clients has been configured for this device. (Default: no) • WPS SSID – The service set identifier for WLAN1. (Default: SMC) • WPS Auth Mode – The method of authentication used. (Default: Open) •...

  • Page 71: Station List

    Firewall Figure 5-25. WPS Progress Settings WPS Configuration — Configures WPS settings for the wireless AP/Router. • WPS Mode – Selects between methods of broadcasting the WPS beacon to network clients wanting to join the network: - PIN: The wireless AP/Router, along with other WPS devices, such as notebook PCs, cameras, or phones, all come with their own eight-digit PIN code.

  • Page 72: Mac/Ip/Port Filtering

    System Configuration MAC/IP/Port Filtering MAC/IP/Port filtering restricts connection parameters to limit the risk of intrusion and defends against a wide array of common hacker attacks. IP/Port filtering allows the unit to permit, deny or proxy traffic through its MAC addresses, IP addresses and ports.
  • Page 73 Firewall • Default Policy – When MAC/IP/Port Filtering is enabled, the default policy will be enabled. If you set the default policy to “Dropped”, all incoming packets that don’t match the rules will be dropped and vise versa. (Default: Disable) •...

  • Page 74: Virtual Server Settings (Port Forwarding)

    System Configuration Virtual Server Settings (Port Forwarding) Virtual Server (sometimes referred to as Port Forwarding) is the act of forwarding a network port from one network node to another. This technique can allow an external user to reach a port on a private IP address (inside a LAN) from the outside through a NAT-enabled router.

  • Page 75: Dmz

    Firewall Current Virtual Servers The Current Virtual Servers displays the entries that are allowed to forward packets through the wireless AP/Router’s firewall. • Select – Selects an entry in the Current Virtual Servers. • IP Address – Displays an IP address on the local network to allow external access •...

  • Page 76: System Security

    System Configuration System Security The wireless AP/Router includes the facility to manage it from a remote location. The unit can also be sent a ping message from a remote location. Figure 5-31. System Security Settings • Remote Management – Denies or allows a remote access via WAN. (Default: Deny) •...

  • Page 77: Content Filtering

    Firewall Content Filtering The wireless AP/Router provides a variety of options for blocking Internet access based on content, URL and host name. Figure 5-32. Filter Settings Webs Content Filter Settings — The wireless AP/Router blocks access to specific traffic such as proxies, Java Applets and ActiveX. Check the box for whichever service to be blocked then click “Apply”.

  • Page 78: Administration Settings

    System Configuration Current Web URLs Filters — By filtering inbound Uniform Resource Locators (URLs) the risk of compromising the network can be reduced. URLs are commonly used to point to websites. By specifying a URL or a keyword contained in a URL traffic from that site may be blocked.

  • Page 79: Language Settings

    Administration Settings Language Settings You can change the language displayed in web interface. Chooses the appropriate language of your choice from the drop-down list, then click “Apply”. (Options: English/Traditional Chinese/Simplified Chinese. Default: English) Administrator Settings To protect access to the management interface, you need to configure a new Administrator’s user name and password as soon as possible.

  • Page 80: Ddns Settings

    System Configuration Green AP Settings The GreenAP feature is used for reducing the wireless AP/Router's power consumption. Before setting the Green AP duration, you need to configure the Time Zone Settings first, then choose one of the options from Action drop-down list. The WiFi Tx Power indicates how much antenna power you want to use.

  • Page 81: Upgrade Firmware

    Administration Settings • Dynamic DNS Provider – Specifies the DDNS service provider, DynDns.org, Freedns.afraid.org, ZoneEdit.com or Non-IP.com. (Default: DynDns.org) • DDNS Account – Specifies your username for the DDNS service. • DDNS Password – Specifies your password for the DDNS service. •...

  • Page 82: Configuration Settings

    System Configuration Configuration Settings The Configuration Setting page allows you to save the wireless AP/Router’s current configuration or restore a previously saved configuration back to the device. Figure 5-38. Configuration Settings • Load Factory Defaults – Restores the factory defaults. •...

  • Page 83: System Status

    Administration Settings System Status The System Information page displays basic system information and the displayed settings are for status information only and are not configurable on this page. This information is split into the three sections that follow. Figure 5-39. System Information - Basic Information System Info —...
  • Page 84 System Configuration Internet Configurations — Displays the basic WAN information: • Connected Type – Displays the WAN connected mode. (Default: DHCP) • WAN IP Address – IP address of the WAN port for this device. • Subnet Mask – The mask that identifies the host address bits used for routing to the WAN port.

  • Page 85: Statistics

    Administration Settings Statistics The wireless AP/Router Traffic Statistics - Interfaces window displays received and transmitted packet statistics for all interfaces on the wireless AP/Router. Figure 5-42. Statistic The following items are displayed on this page: • Memory total – The total memory of this wireless AP/Router. •...

  • Page 86: Dhcp Clients

    System Configuration DHCP Clients Lists information about associated DHCP clients. Figure 5-43. DHCP Client List (Gateway Mode) • MAC Address – The MAC address of the DHCP client. • IP Address – The IP address of the DHCP client. • Expires in – The time after which the connection will expire and the DHCP client must request a new IP address.

  • Page 87: Reboot

    Administration Settings Reboot • Reboot – Click the button to reboot the wireless AP/Router. Figure 5-45. System Reboot 5-53...
  • Page 88 System Configuration 5-54...

  • Page 89: Appendix A: Troubleshooting

    Appendix A: Troubleshooting Check the following items before you contact local Technical Support. If wireless clients cannot access the network, check the following: • Be sure the access point and the wireless clients are configured with the same Service Set ID (SSID). •...
  • Page 90 Troubleshooting Diagnosing LED Indicators Troubleshooting Chart Symptom Action POWER LED is Off • The AC power adapter may be disconnected. Check connections between the wireless AP/Router, the power adapter, and the wall outlet. WLAN LED is Off • The wireless AP/Router’s radio has been disabled through it’s web management interface.

  • Page 91: Appendix B: Specifications

    Appendix B: Specifications Operating Frequency 802.11b/g/n: 2.412 ~ 2.462 GHz (USA, Canada Ch1- Ch11) 2.412 ~ 2.472 GHz (Europe Ch1- Ch13) 2.412 ~ 2.484 GHz (Japan Ch1- Ch14) 2.412 ~ 2.462 GHz (Taiwan Ch1-Ch11) Data Rate 802.11b: 1, 2, 5.5, 11 Mbps per channel 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps per channel Draft 802.11n (20MHz, 400ns GI): 7.2, 14.4, 21.7, 28.9, 43.3, 57.8, 65, 72.2, 14.4, 28.9, 43.3, 57.8, 86.7, 115.6, 130, 144.4 Mbps per channel...
  • Page 92 Specifications Humidity 5% to 95% (non-condensing) Compliances FCC Part 15B Class B EN 55022 EN 55024 EN61000-3-2 EN61000-3-3 Radio Signal Certification FCC Part 15C 15.247, 15.207 (2.4 GHz) EN 300 328 EN 301 489-1 EN 301 489-17 Standards IEEE 802.11b/g IEEE 802.11n draft v2.0 Physical Size 184 x 130 x 34.6 mm (7.24 x 5.11 x 1.36 in)

  • Page 93: Appendix C: License Information

    Appendix C: License Information This product includes copyrighted third-party software subject to the terms of the GNU General Public License (GPL), GNU Lesser General Public License (LGPL), or other related free software licenses. The GPL code used in this product is distributed WITHOUT ANY WARRANTY and is subject to the copyrights of one or more authors.
  • Page 94 License Information We protect your rights with two steps: (1) copyright the software, and (2) offer you this license which gives you legal permission to copy, distribute and/or modify the software. Also, for each author's protection and ours, we want to make certain that everyone understands that there is no warranty for this free software.
  • Page 95 The GNU General Public License a). You must cause the modified files to carry prominent notices stating that you changed the files and the date of any change. b). You must cause any work that you distribute or publish, that in whole or in part contains or is derived from the Program or any part thereof, to be licensed as a whole at no charge to all third parties under the terms of this License.
  • Page 96 License Information c). Accompany it with the information you received as to the offer to distribute corresponding source code. (This alternative is allowed only for noncommercial distribution and only if you received the program in object code or executable form with such an offer, in accord with Subsection b above.) The source code for a work means the preferred form of the work for making modifications to it.
  • Page 97 The GNU General Public License you may not distribute the Program at all. For example, if a patent license would not permit royalty-free redistribution of the Program by all those who receive copies directly or indirectly through you, then the only way you could satisfy both it and this License would be to refrain entirely from distribution of the Program.
  • Page 98 License Information NO WARRANTY BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM "AS IS"...
