SMC Networks SMC7904WBRA-N2 Specifications

SMC7904WBRA-N2
4 Ethernet Ports ADSL2+ 11n Wireless Router

Product Overview

The SMC7904WBRA-N2 is a three-in-one wireless ADSL2/2+ router designed for Internet connectivity. It includes an ADSL
modem, four Ethernet ports, and an 802.11n high-speed wireless function. The SMC7904WBRA-N2 supports the most
up-to-date ADSL2/2+ standards to provide the best DSL performance, with up to 24 Mbps* downstream and 2 Mbps*
upstream and a long-reach rate from your ISP's DSLAM site. Through its QoS and security features, the SMC7904WBRA-N2
can deliver high-quality video/audio streams without sacrificing security. The SMC7904WBRA-N2 is an ideal, cost-effective
solution for ISPs and carriers with all its value services in one small box.
*ADSL speeds vary depending on individual contracts and services offered by ISPs, and distances from the ISP DSLAM.
Key Features and Benefits
Bridge/Router Mode
The SMC7904WBRA-N2 supports both a Bridge mode and
Router mode. This means that the SMC7904WBRA-N2 can
be operated within different ISP deployment plans.
High Security
The SMC7904WBRA-N2 provides NAT/NAPT and firewall
features. The firewall in the SMC7904WBRA-N2 supports not
only IP/Port/MAC filtering functions, but also Stateful Packet
Inspection (SPI). Virtual DMZ is also supported for providing
servers for Internet users without jeopardizing private LAN
security. In addition, Day/Time Parent Control is also
supported to prevent children from accessing harmful web
sites.
300Mbps Wireless
ADSL2/2+ Router
SMC7904WBRA-N2
SMCWIPCFN-G2
Internet
ADSL2/2+ Barricade
SMCWUSB-N2
N
TM
802.11n 2.4GHz Wireless with 2x2 MIMO
The SMC7904WBRA-N2 Wi-Fi solution is compliant with
802.11n draft v2.0 specifications. As a Wi-Fi AP/router, the
SMC7904WBRA-N2 can achieve a 300 Mbps PHY rate using
11n MIMO 2x2 antennas. Compared with the 54 Mbps PHY
rate of 802.11g technology, the device provides almost six
times faster Wi-Fi throughput.
Easy Management
The SMC7904WBRA-N2 is TR-069 compliant, which allows an
ISP to monitor and provision the SMC7904WBRA-N2 remotely.
It is able to automatically upgrade firmware and other
Auto-Configuration
Server
ATM
POWER TO CONNECT
www.edge-core.com
www.smc.com
Set-top Box
SMC7904WBRA-N2
USB Storage
(Option)
