© 2007 GN A/S. All rights reserved. Jabra® is a registered
trademark of GN A/S. All other trademarks included herein
are the property of their respective owners. The Bluetooth®
word mark and logos are owned by the Bluetooth SIG,
Inc. and any use of such marks by GN A/S is under license.
(Design and specifications subject to change without notice).
www.jabra.com
MADE IN ChINA
USER MANUAL
TOLL FREE CusTOmER COnTaCT DETaiLs:
PhOnE numbERs:
Belgique/Belgie
00800 722 52272
Danmark
702 52272
Deutschland 0800 1826756
Die Schweiz 00800 722 52272
España
900 984572
France
0800 900325
Italia
800 786532
Luxembourg 00800 722 52272
Nederland
0800 0223039
Norge
800 61272
Österreich
00800 722 52272
Portugal
00800 722 52272
Suomi
00800 722 52272
Sverige
020792522
United Kingdom 0800 0327026
International 00800 722 52272
EmaiL aDDREssEs:
Deutsch
support.de@jabra.com
English
support.uk@jabra.com
Français
support.fr@jabra.com
Italiano
support.it@jabra.com
Nederlands support.nl@jabra.com
Español
support.es@jabra.com
Scandinavian support.no@jabra.com

Advertisement

Table of Contents
loading

Summary of Contents for Jabra A7010

  • Page 1 © 2007 GN A/S. All rights reserved. Jabra® is a registered trademark of GN A/S. All other trademarks included herein are the property of their respective owners. The Bluetooth® TOLL FREE CusTOmER COnTaCT DETaiLs: word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by GN A/S is under license.
  • Page 2: Table Of Contents

    Jabra A7010 set up ..................5 Connecting your Jabra A7010 with your desk phone and power supply ....... .5 how to pair your Jabra A7010 and headset .
  • Page 3: Thank You

    What’s what ThANk yoU Thank you for purchasing the Jabra A7010 Bluetooth® hub. We hope you enjoy it! This instruction manual will help you make the most of your Bluetooth hub. 1 AboUT yoUR JAbRA A7010 What your Jabra a7010 can do The Jabra A7010 allows you to add a Bluetooth headset* to your standard desk phone. It is a ‘connectivity hub’ that enables your desk phone for wireless Bluetooth communication. once the Jabra A7010 is connected, your Bluetooth headset can be used with your desk phone. The Jabra A7010 supports MultiPoint™ headsets so that the MultiPoint™ headset can connect to two Bluetooth devices simultaneously, for example a mobile phone and a desk phone equipped with a Jabra A7010. For information on MultiPoint™ headsets, please see www.jabra.com/multipoint The Jabra A7010 also allows you to connect a GN1000 (remote handset lifter) that automatically lifts and puts down your desk phone’s handset, so you don’t have to. With this handset lifter, you can answer and end desk phone calls from your headset. a Jabra a7010 bluetooth hub Dial Tone Switch Stylishly designed, the Jabra A7010 helps organize your cords, helping keep your desk tidy. Light indicator (LED) nOTE: If there is no power to the Jabra A7010, the desk phone handset will still work, but the headset will not Pairing button work with the desk phone. once power is restored, you will find all settings (including pairing) intact. Microphone volume control AUX socket * For a complete list of Jabra headsets compatible with the Jabra A7010 please see www.jabra.com. Jabra does handset socket not warrant the compatibility of other, non-Jabra headsets not listed at www.jabra.com/multipoint...
  • Page 4: What Type Of Desk Phone Do You Have

    2 WhAT TypE of dESk phoNE do yoU hAvE? JAbRA A7010 SET Up The Jabra A7010 can connect with your desk phone in three different ways, depending on the type of phone Connecting your Jabra a7010 with your desk phone and power supply and accessory you have. · D isconnect the handset from your desk phone (by unplugging the handset from the desk phone handset port). Please use the following checklist to determine the best way to connect to your desk phone. i have a desk phone and a Gn1000 (remote handset lifter*) · Go straight to page 4 “For use with desk phone with GN1000 (remote handset lifter)”...
  • Page 5 The green LED (2) indicates that the Jabra A7010’s power is on. Please refer to the Gn1000 user manual for directions on how to set up your GN1000. in the unlikely event that the Jabra a7010 is not OK, its LED (2) will flash red. · First, try disconnecting and reconnecting the Jabra A7010 to the power source. if the LED (2) is still flashing red, you must reset your Jabra a7010.
  • Page 6: How To Pair Your Jabra A7010 And Headset

    Jabra a7010 and headset your Jabra A7010 can be paired with multiple headsets. If the Jabra A7010 has been paired with multiple imPORTanT: refer to your headset’s user manual for information about how to pair it to another device. headsets, and more than one headset is in range, the Jabra A7010 will seek to establish communication with the most recently connected headset. · Set your headset into pairing mode according to its user manual. adjusting settings with a test call from your desk phone · S et your Jabra A7010 in pairing mode by pressing and holding its pairing button (3). The LED (2) will show · Place your headset on your ear and tap the headset Answer/End button. a steady blue light and the Jabra A7010 will ‘search’ for a headset. nOTE: The Jabra A7010 will continue to ‘search’ for a headset for 5 minutes. · The handset will be lifted automatically, establishing a dial tone. · W hen your headset and Jabra A7010 have paired successfully, the Jabra A7010’s LED (2) will flash blue 10 times. your headset may also give an audible or visual indication (see its user manual).
  • Page 7: Use

    · I f you cannot hear a dial tone or it is unclear, slowly slide the Dial Tone Switch (1) from A through G until you hear a clear dial tone. The Dial Tone Switch (1) is preset to setting A, since that setting is most commonly used. · To end the call, tap the headset Answer/End button. The headset will be lowered automatically. · Dial a friend so you can test the volume of your microphone (how your voice sounds to others). making and ending a call from your desk phone · P lace the headset on your ear and tap the headset Answer/End button. The handset will lift automatically. · A djust the headset microphone volume (4) in the Jabra A7010 until your friend confirms that your voice can be heard at an appropriate level. (If you can hear your own voice in the headset, the microphone volume is probably too high.) · Wait for the dial tone and then dial the desired number. Jabra A7010 Bluetooth hub Jabra A7010 Bluetooth hub...
  • Page 8: Answering And Ending A Call To Your Desk Phone

    · Keep the desk phone handset off the hook. · Tap the headset Answer/End button. (The GN1000 will lift.) The call will be transferred to the headset. · To end the call, tap the Answer/End button. (The GN1000 will be lowered.) nOTE: remember to replace the desk phone handset after you have ended the call. staying within range The sound in your headset will deteriorate if you move beyond range of the Jabra A7010.* Move back into · To end the call, tap the headset Answer/End button. The handset will be lowered automatically. range to restore sound quality. answering and ending a call to your desk phone If you move too far from the Jabra A7010, the call will be routed to your desk phone handset. return into Both your desk phone and your headset will give an audible indication that a call is incoming. range within 60 seconds and the call will be re-routed back to the headset. If you stay out of range for more · P lace the headset on your ear and tap the headset Answer/End button. The handset will lift automatically than 60 seconds, the GN1000 will lower the handset and the call will be ended automatically.
  • Page 9: For Use With Desk Phone With Headset Port

    · y ou can use the ‘wire guide’ at the bottom of the Jabra A7010 to neatly guide the cable from the desk phone to the wall phone plug. The green LED (2) indicates that the Jabra A7010’s power is on. in the unlikely event that the Jabra a7010 is not OK, its LED (2) will flash red. · First, try disconnecting and reconnecting the Jabra A7010 to the power source. if the LED (2) is still flashing red, you must reset your Jabra a7010. · Press and hold the Jabra A7010 reset button (8).
  • Page 10: Adjusting Settings With A Test Call From Your Desk Phone

    · Place your headset on your ear and tap the headset Answer/End button. nOTE: The Jabra A7010 will continue to search for a headset for 5 minutes. · W hen your headset and Jabra A7010 have paired successfully, the Jabra A7010 LED (2) will flash blue 10 times. your headset may also give an audible or visual indication (see its user manual). · Press the appropriate button on your desk phone to establish a dial tone. nOTE: If you accidentally put the Jabra A7010 into pairing mode, tap the pairing button (3) to exit pairing · I f you cannot hear a dial tone or it is unclear, slowly slide the Dial Tone Switch (1) from A through G until you mode. hear a clear dial tone. The Dial Tone Switch (1) is preset to setting A, since that setting is most commonly used. your Jabra A7010 can be paired with multiple headsets. If the Jabra A7010 has been paired with multiple headsets, and more than one headset is in range, the Jabra A7010 will seek to establish communication with the most recently connected headset. Jabra A7010 Bluetooth hub Jabra A7010 Bluetooth hub...
  • Page 11 · Dial a friend so you can test the volume of your microphone (how your voice sounds to others). · T o end the call, press the appropriate button on the desk phone AND tap the headset Answer/End button. · A djust the headset microphone volume (4) in the Jabra A7010 until your friend confirms that your voice can be heard at an appropriate level. (If you can hear your own voice in the headset, the microphone volume is probably too high.) Jabra A7010 Bluetooth hub Jabra A7010 Bluetooth hub...
  • Page 12: Use

    · P lace the headset on your ear and tap the headset Answer/End button. · T o end the call, press the appropriate button on your desk phone AND tap the headset Answer/End button. · P ress the appropriate button on your desk phone to establish a dial tone. · D ial the desired number. Jabra A7010 Bluetooth hub Jabra A7010 Bluetooth hub...
  • Page 13: Answering And Ending A Call To Your Desk Phone

    · T ap the headset Answer/End button. The call will be transferred to your desk phone handset. switching from handset to headset you can switch from your desk phone handset to your headset during an active call. you might want to do this if, for example, the call was answered on the desk phone handset and you would prefer to use your headset. · K eep the desk phone handset off the hook. · T ap the headset Answer/End button. · I f necessary, press the appropriate button on your desk phone (see your desk phone user manual). The call will be transferred to the headset. nOTE: on some desk phones, you might hear an echo. This is because the headset and handset audio links are both open. If this happens, replace the desk phone handset. staying within range The sound in your headset will deteriorate if you move beyond range of the Jabra A7010.* Move back into range to restore sound quality. · T o end the call, press the appropriate desk phone button AND tap the headset Answer/End button. Jabra A7010 Bluetooth hub Jabra A7010 Bluetooth hub...
  • Page 14: For Use With Desk Phone Without Headset Port

    5 foR USE WiTh dESk phoNE WiThoUT hEAdSET poRT This set up will work for most desk phones (not cordless phones). nOTE: in the following pages, all references to “Tap the headset Answer/End button” refer to the action needed for most common Jabra headsets available. yours may differ – please refer to your headset’s user manual. · C onnect the desk phone handset port to the Jabra A7010’s desk phone socket (7) using the supplied connection cord (desk phone-to-Bluetooth hub (C)). JAbRA A7010 SET Up Connecting your Jabra a7010 with your desk phone and power supply · D isconnect the handset from your desk phone (by unplugging the handset from the desk phone handset port). · C onnect the power supply (B) to your Jabra A7010’s power supply socket (10). · C onnect the handset to your Jabra A7010’s handset socket (6). Jabra A7010 Bluetooth hub Jabra A7010 Bluetooth hub...
  • Page 15: How To Pair Your Jabra A7010 And Headset

    10 times. your headset may also give an audible or visual indication (see its user manual). phone to the wall phone plug. The green LED (2) indicates that the Jabra A7010’s power is on. in the unlikely event that the Jabra a7010 is not OK, its LED (2) will flash red. · F irst, try disconnecting and reconnecting the Jabra A7010 to the power source. if the LED (2) is still flashing red, you must reset your Jabra a7010. · Press and hold the Jabra A7010 reset button (8).
  • Page 16: Adjusting Settings With A Test Call From Your Desk Phone

    · P lace your headset on your ear and tap the headset Answer/End button. · D ial a friend so you can test the volume of your microphone (how your voice sounds to others). · L ift your desk phone handset and listen for a dial tone in your headset. · A djust the headset microphone volume (4) in the Jabra A7010 until your friend confirms that your voice can be heard at an appropriate level. (If you can hear your own voice in the headset, the microphone volume is probably too high.) · I f you cannot hear a dial tone or it is unclear, slowly slide the Dial Tone Switch (1) from A through G until you hear a clear dial tone. The Dial Tone Switch (1) is preset to setting A, since that setting is most commonly used. Jabra A7010 Bluetooth hub Jabra A7010 Bluetooth hub...
  • Page 17: Use

    · P lace the headset on your ear and tap the headset Answer/End button. · T o end the call, replace the desk phone handset AND tap the headset Answer/End button. · L ift the desk phone handset and listen for the dial tone. · D ial the desired number. Jabra A7010 Bluetooth hub Jabra A7010 Bluetooth hub...
  • Page 18: Answering And Ending A Call To Your Desk Phone

    · P lace the headset on your ear and tap the headset Answer/End button. · T o end the call, replace the desk phone handset AND tap the headset Answer/End button. · L ift the desk phone handset to connect the call. Jabra A7010 Bluetooth hub Jabra A7010 Bluetooth hub...
  • Page 19: Switching From Headset To Handset

    · T ap the headset Answer/End button. The call will be transferred to your desk phone handset. switching from handset to headset you can switch from your desk phone handset to your headset during an active call. you might want to do this if, for example, the call was answered on the desk phone handset and you would prefer to use your headset. · K eep the desk phone handset off the hook. · T ap the headset Answer/End button. The call will be transferred to the headset. only one color will be visible at any one time. staying within range When your Jabra a7010 LED (2) does this… it means… The sound in your headset will deteriorate if you move beyond range of the Jabra A7010.* Move back into range to restore sound quality. Green steady Jabra A7010 on Blue steady Pairing in progress Blue flash ten times Pairing successful...
  • Page 20: Troubleshooting

    Warranty that came with your Jabra A7010. · h as your headset been charged? · I s your headset turned on? · I s your headset disconnected from its charger? 9 gLoSSARy · h as the Dial Tone Switch (1) been adjusted correctly? · h as the microphone volume (4) been adjusted correctly? · I s the headset within range of the Jabra A7010? Bluetooth® is a radio technology that connects devices, such as mobile phones and headsets, without wires or · C an your headset and Jabra A7010 ‘see’ each other, or is something blocking their connection? cords over a short distance. For more information go to www.bluetooth.com · A re more than eight devices paired with the Jabra A7010? The Jabra A7010 Bluetooth hub is the ‘connectivity unit’ made by Jabra (GN Netcom) that enables your desk phone for wireless Bluetooth communication. The Jabra A7010 is compatible with several kinds of corded desk nOTE: If your Jabra A7010 LED (2) is flashing red, try disconnecting and reconnecting the power supply (B). In phones.
