CD Stereo System
NSX-D70
U
C
OWNER'S RECORD
Record the model number and serial number of your set (found at the
rear of your set) below. Refer to them when contacting your Aiwa dealer.
Model No. _____________________________
Serial No. _____________________________
For assistance and information
(United States and Puerto Rico)
OPERATING INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MODE D'EMPLOI
En
(English)
E
(Español)
F
(Français)
8C-NF6-903-11
020201BKH-U-M

Advertisement

Table of Contents
loading

Related Manuals for Aiwa NSX-D70

Summary of Contents for Aiwa NSX-D70

  • Page 1 CD Stereo System NSX-D70 OWNER'S RECORD Record the model number and serial number of your set (found at the rear of your set) below. Refer to them when contacting your Aiwa dealer. Model No. _____________________________ Serial No. _____________________________ For assistance and information...

  • Page 2: Important Safety Instructions

    WARNING To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. Explanation of Graphical Symbols: The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...

  • Page 3: Table Of Contents

    CD OPERATIONS ... 10 RADIO OPERATIONS ... 12 TAPE OPERATIONS ... 14 SOUND ADJUSTMENTS ... 17 TIMER OPERATIONS ... 18 REFERENCE ... 20 System and accessories NSX-D70 CX-ND70 CD stereo cassette receiver SX-ND70 Front speakers Remote control FM antenna AM antenna...

  • Page 4: Preparations

    PREPARATIONS Connection Plug in the AC power cord to the AC power outlet after all other connections are made. 1 Connect the front speakers. Connect the right front speaker (marked "R" on the rear side) to the SPEAKERS R terminals and place it on the right side of the unit.

  • Page 5: Parts And Controls

    PARTS AND CONTROLS Main unit: rear 1 AM LOOP, FM 75 Ω terminals Plug in the supplied AM and FM antennas here. 2 VIDEO/AUX jacks Accepts analog sound signals from external equipment. Connect using an optional connecting cable with RCA phono plugs (red plug to R jack, white plug to L jack).

  • Page 6: Phones Jack

    Main unit: front 1 Dial Function Selects a function (TAPE, TUNER, VIDEO/AUX or CD). DECK 1/2 Selects DECK 1 or 2 in Tape function. BAND Selects a band in Tuner function. 2 POWER 6STANDBY/ON Switches the unit on and off (standby). DEMO/ECO When the unit is turned off: switches DEMO on and off.
  • Page 7 Remote control Buttons with the same or similar names with the main unit basically have the same function. 1 POWER Enters Graphic Equalizer setting mode. SOUND ENTER 2 0-9, +10 CD: selects a CD track of the specified number. Radio: tunes in to the station with the specified preset number.

  • Page 8: Adjustments Before Operations

    ADJUSTMENTS BEFORE OPERATIONS Power Turning the unit on Press POWER 6 STANDBY/ON (POWER on the remote control). Turning the unit off Press POWER 6STANDBY/ON again. The unit goes into standby. Volume Turn VOLUME (Press VOLUME +, - on the remote control).

  • Page 9: Eco Mode

    ECO mode Reduces power consumption with the following operations, etc. ECO ON mode - The unit blacks out when the unit is turned off. Only the red indicator lights up. (Only when the clock is set.) - If dimmer mode is set to on, the unit illumination brightens (for 10 seconds) only when you operate the unit.

  • Page 10: Cd Operations

    CD OPERATIONS This unit plays back finalized CD-R/RW discs as well as audio CDs. Playback 1 Turn the Dial Function to select the CD function and load disc(s). Press zCD OPEN/CLOSE to open the disc compartment and place one or two disc(s) with the labelled side up. To place three discs, press DISC CHANGE so that the trays rotate, then place the third one.

  • Page 11: Programmed Playback

    Programmed playback Plays back up to 30 selected tracks in programmed order. 1 Press SHIFT+PROGRAM on the remote control during stop. "PRGM" flashes on the display. 2 Press CD DIRECT on the remote control and then press the numbered button (1-3) within 3 seconds to select a disc.

  • Page 12: Radio Operations

    RADIO OPERATIONS Manual tuning 1 Turn the Dial Function to select the TUNER function. 2 Press BAND to select a band (FM or AM). 3 Press f or g to tune in to a station. "TUNE" is displayed when a station is tuned in. "1"...
  • Page 13 Adjustments Antennas Keep antennas away from metallic objects, electrical equipment and cords. FM antenna: Extend fully and position for the best reception. If receiving condition is poor, connect optional outdoor antenna to FM 75 Ω terminal. Be sure to connect the shield braid of the antenna to the 2 terminal.

  • Page 14: Tape Operations

    TAPE OPERATIONS Playback Use only type I (normal) tapes. 1 Turn the Dial Function to select the TAPE function. 2 Press z PUSH EJECT/CLOSE on either side (DECK 1 and DECK 2) to open the outer cassette holder and insert the tape in the deck. Insert with the exposed side down and playback side facing out from the unit.

  • Page 15: Ai Edit Recording

    2 Prepare the source. To record CD(s), select the CD function and load disc(s). To record a radio broadcast, tune in to the desired station. To record a tape, insert the source tape in DECK 1 and select the TAPE function (DECK 1). To record from connected external equipment, select the VIDEO/AUX function and prepare the equipment.
  • Page 16 Programmed Edit Recording As you program the CD tracks to record, Programmed Edit Recording displays the remaining recording time for each side of the tape, so you can easily select a set of desired tracks within the length of your tape. 1 Insert the recording tape in DECK 2.

  • Page 17: Sound Adjustments

    SOUND ADJUSTMENTS Graphic equalizer Selects a sound equalization curve to match the music type. Press MODE once and then turn MULTI JOG within 4 seconds to select one of the four equalization curves. On the remote control, press GEQ and then press PRESET N or M repeatedly within 4 seconds.

  • Page 18: Timer Operations

    TIMER OPERATIONS Sleep timer Turns off the unit automatically after a specified time. 1 Press SHIFT+SLEEP on the remote control. "SLP" appears on the display. 2 Press f or g repeatedly to set the sleep timer duration. With each press, the timer duration changes in 5-minute steps between 5 to 240 minutes.

  • Page 19: Timer Recording

    To display the timer setting Press TIMER. The timer-on time, the source and the timer-activated duration are displayed for 6 seconds. Tip: Timer setting can be displayed even while the unit is turned off, and at that time if you press ENTER or a within 6 seconds after TIMER is pressed, you can enter the timer setting mode and change the setting.

  • Page 20: Reference

    REFERENCE Care and maintenance Occasional care and maintenance of the unit and the software are needed to optimize the performance of your unit. To clean the cabinet Use a soft and dry cloth. If the unit surfaces are extremely dirty, use a soft cloth lightly moistened with mild detergent solution.

  • Page 21: Specifications

    Specifications MAIN UNIT CX-ND70 TUNER FM tuning range 87.5 MHz to 108 MHz FM usable sensitivity (IHF) 13.2 dBf FM antenna terminal 75 ohms (unbalanced) AM tuning range 530 kHz to 1710 kHz (10 kHz step) 531 kHz to 1602 kHz (9 kHz step) AM usable sensitivity 350 µV/m AM antenna...
  • Page 22 NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
