USER'S GUIDE
GUÍA DEL USUARIO
Please keep all information for future reference.
Guarde toda información para tener como referencia futura.
Safety Precautions
Before trying to use the piano, be sure to read
the separate "Safety Precautions".
Precauciones de seguridad
Antes de intentar usar el piano, asegúrese de
leer las "Precauciones de seguridad" separadas.
AP200ES1A
ES

Advertisement

Table of Contents
loading

Related Manuals for Casio CELVIANO AP-200

Summary of Contents for Casio CELVIANO AP-200

  • Page 1 USER’S GUIDE GUÍA DEL USUARIO Please keep all information for future reference. Guarde toda información para tener como referencia futura. Safety Precautions Before trying to use the piano, be sure to read the separate “Safety Precautions”. Precauciones de seguridad Antes de intentar usar el piano, asegúrese de leer las “Precauciones de seguridad”...
  • Page 2 Never let children use an AC adaptor that is seriously damaged. • The product is not intended for children under 3 years. • Use only CASIO AD-12 adaptor. • The AC adaptor is not a toy.

  • Page 3: Table Of Contents

    Contents Assembling the Stand ....................E-24 Unpacking..............E-24 To connect the pedal cord......... E-26 To assemble the stand ..........E-24 To install the music stand.......... E-26 General Guide ........E-2 Configuring Settings with the Keyboard ......... E-18 TONE/SETTING Button..........E-3 Saving Settings and Using Operation Lock ....

  • Page 4: General Guide

    General Guide Bottom Front Rear Front...

  • Page 5: Tone/Setting Button

    General Guide CAUTION • Make sure that the cover is fully open whenever you are playing on the keyboard. A partially open cover can suddenly close unexpectedly and pinch your fingers. NOTE • The names shown here are always indicated in bold when they appear within the text of this manual. 1 PHONES jack 9 LR button 2 DC 12V terminal...

  • Page 6: Power Outlet

    Power Outlet Your digital piano runs on standard household power. * Using the Clip Be sure to turn off power whenever you are not using ■ To fasten the clip the digital piano. As shown in the illustration, press down on (a) to force the tip of the clip into the slot.

  • Page 7: Connections

    Connections IMPORTANT! Audio amplifier AUX IN jack, etc. Pin plug • Whenever connecting something to the digital piano, first RIGHT use the VOLUME controller to set the volume to a low (Red) level. After connecting, you can adjust the volume to the Stereo standard plug LEFT (White)

  • Page 8: Playing With Different Tones

    Playing with Different Tones VOLUME TONE/SETTING SONG POWER METRONOME GRAND PIANO Selecting and Playing a Tone NOTE • Grand Piano Tones (MODERN, CLASSIC) This digital piano has 11 built-in tones. Your digital piano has a total of 11 built-in tones. The * You can select these tones using keyboard keys.
  • Page 9 Playing with Different Tones Selecting a Tone Using the Keyboard Keys MODERN CLASSIC VARIATION VIBRAPHONE STRINGS GRAND PIANO BASS (LOWER) ELEC PIANO HARPSICHORD PIPE ORGAN TONE/SETTING button Tone Setting Keys While holding down the TONE/SETTING button, press the keyboard key that corresponds to the tone you want to select.

  • Page 10: Adjusting The Brilliance Of A Tone

    Playing with Different Tones Adjusting the Brilliance of a Layering Two Tones Tone Use the following procedure to layer two tones, so they sound at the same time. While holding down the TONE/SETTING button, use the BRILLIANCE keys to specify While holding down the TONE/SETTING a brilliance value in the range of –3 to 3.

  • Page 11: Using Effects

    Playing with Different Tones Using Effects Using the Digital Piano’s Pedals Reverb ..Makes your notes resonate. Chorus . . . Adds more breadth to your notes. Your digital piano comes equipped with three pedals: damper, soft, and sostenuto To configure reverb and chorus effect settings While holding down the TONE/SETTING...

  • Page 12: Using The Metronome

    Playing with Different Tones Press the METRONOME button or SONG Using the Metronome / button to turn off the metronome. Press the METRONOME button. NOTE • This starts the metronome. • To return the tempo setting to the default tempo of the •...

  • Page 13: Playing A Piano Duet

    Playing with Different Tones Changing the Octaves of the Keyboards Playing a Piano Duet You can change the ranges of the left and right You can use the Duet Mode to split the piano’s keyboards in octave units from their initial default keyboard in the center so two people can play a duet.

  • Page 14: Playing Back Built-In Songs

    Playing Back Built-in Songs TONE/SETTING SONG Playing Back a Specific Music IMPORTANT! • After you select a built-in song, it can take a number of Library Song seconds for the song data to be loaded. While the data is being loaded, the keyboard keys and button operations Find the song number of the song you want to will be disabled.

  • Page 15: Practicing With A Music Library Song

    Playing Back Built-in Songs Press the SONG / button. • This starts the playback of the song. To stop playback, press the SONG button again. • Playback will stop automatically when the end of the song is reached. NOTE • Pressing the + and – keys at the same time will select song number 01.

  • Page 16: Recording And Play Back

    IMPORTANT! A track is a container of recorded data, and a song • CASIO COMPUTER CO., LTD. takes no responsibility consists of two tracks: Track 1 and Track 2. You can for any damages, lost profits, or claims by third parties...

  • Page 17: Recording Your Keyboard Play

    Recording and Play Back Start playing something on the keyboard. Recording Your Keyboard Play • Recording will start automatically. After recording to either of the tracks of a song, you can To stop recording, press the SONG record to the other track while listening to playback button again.

  • Page 18: To Play Back From Digital Piano Memory

    Recording and Play Back To record to one track of a song while To play back from digital piano listening to the playback of the other memory track Press the RECORDER button so its lamp is Press the RECORDER button so its lamp is lit.

  • Page 19: Deleting Recorded Data

    Recording and Play Back Deleting Recorded Data The following procedure deletes a specific track of a song. IMPORTANT! • The procedure below deletes all of the data of the selected track. Note that the delete operation cannot be undone. Check to make sure you really do not need the data in digital piano memory before you perform the following steps.

  • Page 20: Configuring Settings With The Keyboard

    Configuring Settings with the Keyboard TONE/SETTING In addition to selecting tones and Music Library tunes, Release the TONE/SETTING button to you also can use the TONE/SETTING button in complete the setting procedure. combination with the keyboard keys to configure effect, keyboard touch, and other settings. NOTE •...

  • Page 21: Tone Selection

    Configuring Settings with the Keyboard Keyboard Keys Used for Configuring Settings • The numbers 1 through br correspond to the same numbers in the “Parameter List” on page E-20. [Left keyboard] [Left keyboard] Tone selection Song select [Overall] [Center keyboard] Tempo Metronome beat Reverb...
  • Page 22 Configuring Settings with the Keyboard Parameter List ■ Tones Operation Parameter Settings Type Description Remarks (page E-18) Tone selection See page E-6. Assigns a tone to the Default: GRAND keyboard. PIANO (page E-6) (MODERN) Brilliance –3 to 0 to 3 Specifies the brilliance of (BRILLIANCE) Default: 0...
  • Page 23 Configuring Settings with the Keyboard ■ Keyboard Operation Parameter Settings Type Description Remarks (page E-18) Touch Response Off (OFF), 1 to 3 Specifies the relative touch (TOUCH Default: 2 of the keyboard keys. RESPONSE) Setting a smaller value causes lighter touch to produce more powerful sound.
  • Page 24 Configuring Settings with the Keyboard ■ MIDI and Other Settings Operation Parameter Settings Type Description Remarks (page E-18) Send Channel 01 to 16 Specifies one of the MIDI Default: 01 channels (1 through 16) as the Send Channel, which is used for sending MIDI messages to an external device.

  • Page 25: Connecting To The Midi Terminal

    NOTE • For details about MIDI implementation, visit: http://world.casio.com/ ■ MIDI Connections Connecting your computer or other external MIDI device to the digital piano’s MIDI OUT/IN terminals makes it possible for them to exchange MIDI messages and record and playback keyboard notes on the connected device.
  • Page 26 • Cover the screw heads with the caps J. IMPORTANT! • If anything is missing or damaged, contact your local CASIO service provider. • Note that use of any unauthorized parts or components can cause damage to the stand and/or the digital piano.
  • Page 27 Assembling the Stand Use the two screws I to secure the top left Place the piano onto the stand. and right edges of the back panel C to the brackets 5 of side panels A and B . • At location 6 , slip the G clip onto to the I screw before installing the screw.
  • Page 28 Assembling the Stand Affix the adaptor cord clip K next to the To install the music stand power terminal (DC12V). • For information about securing the cord, see “Power Install the music stand by inserting its pegs Outlet” on page E-4. into the holes in the top of the piano.

  • Page 29: Reference

    Reference Troubleshooting Problem Cause Action See Page No sound is 1. The VOLUME controller is set to 1. Rotate the VOLUME controller more produced when I “MIN”. towards “MAX”. press a keyboard 2. Headphones are connected to the 2. Unplug the headphones from the key.

  • Page 30: Product Specifications

    Reference Product Specifications Model AP-200 Keyboard 88-key piano keyboard, with Touch Response Maximum Polyphony 128 notes Tones • Layer (excluding bass tones) • Split (Low-range bass tones only) Effects Brilliance (–3 to 0 to 3), Reverb (4 types), Chorus (4 types), Acoustic Resonance Metronome •...

  • Page 31: Operating Precautions

    CASIO is prohibited under copyright laws. ■ Location • IN NO EVENT SHALL CASIO BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING, Avoid the following locations for this product. WITHOUT LIMITATION, DAMAGES FOR LOSS •...

  • Page 32: Appendix

    Appendix/Apéndice Tone List/Lista de tonos Song List/Lista de canciones Bank Select No./Nº Song Name/Nombre de canciones Program Maximum MSB/ Nocturne Op.9-2 Tone Name/ Change/ Polyphony/ MSB de Nombre de tonos Cambio de Polifonía Fantaisie-Impromptu Op.66 selección de programa máxima banco Étude Op.10-3 “Chanson de l’adieu”...

  • Page 33: Midi Implementation Chart

    • For details about footnotes 3 through 5, see MIDI Implementation at http://world.casio.com/. *5 : Mensaje exclusivo del sistema de este modelo • Si desea más información sobre los pies de página 3 a 5, vea Implementación MIDI en http://world.casio.com/. Mode 1 : OMNI ON, POLY...
  • Page 34 This recycle mark indicates that the packaging conforms to the environmental protection legislation in Germany. Esta marca de reciclaje indica que el empaquetado se ajusta a la legislación de protección ambiental en Alemania. MA0712-A Printed in China AP200ES1A...
