Cat. No. I546-E1-02
0675398-6B
SETUP MANUAL
SYSDRIVE 3G3JV
Compact Simplified Inverters
Next page ->

Summary of Contents

  • Page 1

    Cat. No. I546-E1-02 0675398-6B SETUP MANUAL SYSDRIVE 3G3JV Compact Simplified Inverters...

  • Page 2

    3. This SETUP MANUAL and other related user’s manuals are to be delivered to the ac- tual end users of the products. 4. Please keep this manual close at hand for future reference. 5. If the product has been left unused for a long time, please inquire at our sales repre- sentative. NOTICE 1.

  • Page 3

    Note Indicates information of particular interest for efficient and convenient operation of the product.  OMRON, 2005 All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form, or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior written permission of OMRON.

  • Page 4

    Warranty and Limitations of Liability Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á WARRANTY Á...

  • Page 5

    Application Considerations Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á SUITABILITY FOR USE Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á...

  • Page 6

    Disclaimers Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á CHANGE IN SPECIFICATIONS Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á Á...

  • Page 7

    Operation, maintenance, or inspection must be performed after turning OFF the power supply, confirming that the CHARGE indicator (or status indicators) are OFF, and after waiting for the time specified on the front cover. Not doing so may result in electrical shock.

  • Page 8

    Transportation Precautions Caution Do not hold by front cover or panel, instead, hold by the radiation fin (heat sink) while transporting the product. Doing so may result in injury. Caution Do not pull on the cables. Doing so may result in damage to the product or malfunc- tion.

  • Page 9

    Be sure to firmly tighten the screws on the terminal block. Not doing so may result in fire, injury, or damage to the product. Caution Do not connect an AC power to the U, V, or W output. Doing so may result in damage to the product or malfunction. Caution Set the multi-function contact input parameter for NC contact terminals (e.g., 3-wire...

  • Page 10

    Maintenance or inspection must be performed only after turning OFF the power supply, confirming that the CHARGE indicator (or status indicators) is turned OFF, and after waiting for the time specified on the front cover. Not doing so may result in electrical shock.

  • Page 11

    • Do not perform a withstand voltage test on any part of the Inverter. This electronic equipment uses semiconductors and is vulnerable to high voltage. • Do not remove the Digital Operator or the blank cover unless the power supply is turned OFF. Never touch the printed control board (PCB) while the power supply is turned ON.

  • Page 12

    • Set the parameter according to the motor. • If a single Inverter is connected to more than one motor, set the parameter to 2 for no protection. The parameter is also disabled by setting n32 for rated motor current to 0.0. Provide thermal relays or other methods separately for each motor to protect equipment from overloads.

  • Page 13

    D Checking for Damage Check the overall appearance and check for damage or scratches resulting from transportation. H Checking the Accessories This manual is the only accessory provided with the 3G3JV. Set screws and other necessary parts must be provided by the user.

  • Page 14: Table Of Contents

    ..........2-2-1 Parameters Used to Copy and Verify Parameters .

  • Page 15

    Chapter 1 Design Installation Wiring Specifications...

  • Page 16: Installation, Dimensions

    Ambient temperature for operation (panel-mounting): –10°C to 50°C Humidity: 95% or less (no condensation) • Install the Inverter in a clean location free from oil mist and dust. Alternatively, install it in a totally en- closed panel that is completely protected from floating dust.

  • Page 17

    • To enhance operation reliability, the Inverter should be installed in an environment free from extreme temperature changes. • If the Inverter is installed in an enclosed environment such as a box, use a cooling fan or air conditioner to maintain the internal air temperature below 50°C.

  • Page 18: Removing And Mounting The Covers

    • Loosen the front cover mounting screws with a screwdriver. • Press the left and right sides of the front cover in the arrow 1 directions and lift the bottom of the cover in the arrow 2 direction to remove the front cover as shown in the following illustration.

  • Page 19

    Design D Removing the Optional Cover • After removing the front cover, lift the optional cover in the arrow 2 direction based on position A as a fulcrum. Note The front cover functions as a terminal cover. The Digital Operator cannot be removed.

  • Page 20: Wiring, Terminal Block

    Chapter 1 Design Wiring 1-2-1 Terminal Block Before wiring the terminal block, be sure to remove the front cover, top protection cover, and the bottom protection cover. H Position of Terminal Block Ground terminal Main circuit input terminals Control circuit terminals...

  • Page 21

    EC Directives. Note Be sure to connect the ground terminal directly to the motor frame ground. Note The maximum output voltage corresponds to the power supply input voltage of the Inverter.

  • Page 22

    Note 2. Functions in parentheses are default settings. H Selecting Input Method • Switches SW7 and SW8, both of which are located above the control circuit terminals, are used for input method selection. Remove the front cover and optional cover to use these switches.

  • Page 23

    Chapter 1 Design D Selecting Sequence Input Method • By using SW7, NPN or PNP input can be selected as shown below. D Selecting Frequency Reference Input Method Frequency reference input SW8 setting Frequency reference selection method (parameter n03) Voltage input...

  • Page 24: Standard Connections

    Note 1. The braking resistor cannot be connected because no braking transistor is incorporated. Note 2. A DC Reactor can be connected in series between the R input and L1 terminal or between the S input and L2 terminal to use it as an AC reactor.

  • Page 25: Wiring Around The Main Circuit

    Circuit Breaker Capacities • For the main circuit and ground, always use 600-V polyvinyl chloride (PVC) cables. • If any cable is long and may cause voltage drops, increase the wire size according to the cable length. D Single-phase 100-V AC Model...

  • Page 26: Optional Accessories

    Model EMC-compliant For A1001 3G3JV-PRS1010J Noise Filter For A1002 DC Reactor For A1001 3G3HV-PUZDAB5, 4A8MH For A1002 3G3HV-PUZDAB18A3MH DIN Track Mounting Bracket 3G3IV-PEZZ08122A Adapter Panel Standard installation 3G3JV-PSI232J Removable 3G3JV-PSI232JC Operator Cable 3G3IV-PCN126 3G3IV-PCN326 Digital Operator Without adjuster (with case)

  • Page 27: Specifications

    0.01 Hz (data processing resolution) Overload capacity 150% of rated output current for 1 min Switchable: 0 to 10 V DC (20 kΩ), 4 to 20 mA (250 Ω), 0 to External frequency set signal 20 mA (250 Ω), or frequency adjustment Acceleration/deceleration times 0.0 to 999 s (Acceleration and deceleration times set sepa-...

  • Page 28

    Instantaneous overcurrent Stops at approx. 250% of rated output current. protection Overload protection Stops in 1 min at approximately 150% of rated output cur- rent. Overvoltage protection Stops when main-circuit DC voltage is approximately 410 V. Undervoltage protection Stops when main-circuit DC voltage is approximately 160 V.

  • Page 29

    Chapter 2 Preparing for Operation and Monitoring Using the Digital Operator Copying and Verifying Parameters...

  • Page 30: Using The Digital Operator, Nomenclature

    Displays relevant data items, such as frequency reference, output frequency, and parameter set values. FREQ adjuster Sets the frequency reference within a range between 0 Hz and the maximum frequency. FREF indicator The frequency reference can be monitored or set while this indicator is lit.

  • Page 31

    Key. Functions as a Reset Key when an Inverter error occurs. (See note.) Note For safety’s reasons, the reset will not work while a RUN command (forward or reverse) is in ef- fect. Wait until the RUN command is OFF before resetting the Inverter.

  • Page 32: Accepting Operation Commands While Changing Parameters

    H Using the Indicators to Determine When Operation Commands Can Be Accepted The indicators on the Digital Operator can be used to determine if operation commands will be accepted or not while changing parameters. Green: Operation commands will be accepted if the indicator lights green.

  • Page 33: Outline Of Operation

    FREF indicator. The data display indicates the item corresponding to the indicator se- lected. The FOUT or IOUT indicator will be lit by turning the Inverter on again if the Inverter is turned off while the FOUT or IOUT indicator is lit. The FREF indicator will be lit by turning the Inverter on again if the Inverter is turned off while an indicator other than the FOUR or IOUT indicator is lit.

  • Page 34

    U01 will be displayed. Use the Increment or Decrement Key to select the monitor item to be displayed. Press the Enter Key so that the data of the selected monitor item will be displayed. The monitor number display will appear again by pressing the Mode Key.

  • Page 35: Copying And Verifying Parameters, Parameters Used To Copy And Verify Parameters

    The 3G3IV-PJVOP140 and 3G3IV-PJOP146 Digital Operators contain an EEPROM. All Inverter parameter settings, the Inverter capacity, and the software number are re- corded in this EEPROM. The EEPROM can be used to copy parameter settings to other Inverters. Parameter settings can be copied between Inverters with the same power supply speci- fications, but some of the parameter settings are not copied.

  • Page 36

    Verification Verifying finished Inverter capacity Software number Note The following display is an example of the capacity displayed. The values in parentheses indicate the capacities for European motors. Voltage Class Max. applicable motor capacity 1: Single-phase 100 V 0.1: 0.1 kW (0.1 kW) 0.2: 0.25 kW/0.37 kW (0.2 kW)

  • Page 37: Outline Of Copying Parameters

    EEPROM in the Digital Operator and the Inverter. H Parameters That Cannot Be Copied 1. Copying is not possible between Inverters with different power supply specifications (e.g., from a 100-V Inverter to a 400-V Inverter). 2. The recorded hold output frequency and the following parameters cannot be copied:...

  • Page 38: Procedures

    Preparing for Operation and Monitoring n64: Motor rated slip n65: Motor no-load current 2-2-3 Procedures Changing Parameters The setting of n01 is changed so that n76 and n77 can be displayed. D Setting n01 (Parameter Write-prohibit Selection/Parameter Initialization Parameter) Indicator Display Description (Display after the power supply is turned ON.)

  • Page 39

    Chapter 2 Example of Copy Function H Verifying Parameters (vFy) • The Parameter Copy and Verify Function (n76) can be set to “vFy” to compare the parameter settings in the Digital Operator with those in the Inverter. D Verifying Parameters...

  • Page 40: Error Messages For Copying And Verifying Parameters

    2-2-4 Error Messages for Copying and Verifying Parameters The errors that can be displayed when reading, writing, or verifying parameter settings are described in the following table along with corrective actions. All of these error displays will flash on the display. Display...

  • Page 41

    Chapter 3 List of Parameters...

  • Page 42

    3-wire sequence. Note Operation commands will be ig- nored in Program Mode (refer to 2-1-2) when n01 is set to 0 or 1. Normally set n01 to 0 or 1. Opera- Used to select the input method for...

  • Page 43

    No. (Reg- range setting during ister No. opera- (Hex)) tion Fre- Used to set the input method for the 0 to 4, 6 quency frequency reference in remote mode. (0103) refer- 0: Digital Operator ence 1: Frequency reference 1 (n21)

  • Page 44

    No. (Reg- range setting during ister No. opera- (Hex)) tion Maxi- Used to set the V/f pattern as the ba- 50.0 to 60.0 sic characteristic of the Inverter with (0109) frequen- output voltage per frequency set. (FMAX) Output 1 to 255...

  • Page 45

    Default Changes Memo No. (Reg- range setting during ister No. opera- (Hex)) tion S-shape Used to set S-shape acceleration/de- 0 to 3 accel- celeration characteristics. (0114) eration/ 0: No S-shape acceleration/decelera- decel- tion (trapezoidal acceleration/de- eration celeration) charac- 1: S-shape acceleration/deceleration teristic characteristic time 0.2 s...

  • Page 46

    Changes Memo No. (Reg- range setting during ister No. opera- (Hex)) tion Used to set internal frequency refer- 0.0 to max. Fre- quency ences. frequency (0115) refer- Note Frequency reference 1 is en- ence 1 abled in remote mode with...

  • Page 47

    (011E) refer- age based on the maximum frequen- cy as 100%. ence upper Note If n31 is set to a value less limit than the minimum output fre- than the minimum output fre- Fre- 0 to 110 quency (n14), the Inverter will...

  • Page 48

    0, 1 fan op- the Inverter while the Inverter is (0123) eration turned on or only while the Inverter is function in operation. 0: Rotates only while RUN command is input and for 1 minute after In- verter stops operating...

  • Page 49

    (Regis- tion ter No. (Hex)) Multi-func- Used to select the functions of multi-function 2 to 8, tion input 1 10 to input terminals S2 through S5. (0124) (0124) (Input ter- Function Description minal S2)

  • Page 50

    No. (Hex)) Multi-func- External ON: Output shut off 2 to 8, 10 to tion input 4 base block (while motor coasting to a (0127) (Input ter- command stop and “bb” flashing) 34, 35 minal S5) (NO) External OFF: Output shut off...

  • Page 51

    Up or down Up or down command command (set in n39 only) By setting n39 to 34, the set value in n38 is ig- nored and the following setting are forcibly made. S4: Up command S5: Down command...

  • Page 52

    Changes Memo eter ting setting during range opera- (Regis- tion ter No. (Hex)) Multi-func- Used to select the functions of multi-function 0 to 7, tion output output terminals. 10 to (0128) (0128) (MA/MB Function Description and MC val- output ter-...

  • Page 53

    –99 to reference Bias: The frequency of minimum analog input (012A) bias (0 V or 0 or 4 mA) in percentage based on the maximum frequency as 100%. Analog fre- Used to set the digital filter with a first-order 0.00 0.10...

  • Page 54

    7 to 9 (012E) selection 1 to 4: Carrier frequency = Set value x 2.5 kHz (fixed) 7 to 9: Carrier frequency = Output frequency ratio for 1 kHz to 2.5 kHz maximum, as fol- lows: 7: 1.0 to 2.5 kHz (12 times): Output frequency...

  • Page 55

    (Regis- tion ter No. (Hex)) Stall pre- Used to select a function to change the decel- 0, 1 vention eration time of the motor automatically so that (0137) during de- there will be no overvoltage imposed on the celeration motor during deceleration.

  • Page 56

    0.0 to compensa- tion function. (013F) tion gain The default setting does not need any changes in normal operation. Motor Used to set the rated slip value of the motor in 0.0 to Varies rated slip use. 20.0 with the (0140)

  • Page 57

    No. (Hex)) RS-422A/4 Used to set whether a communications time- 0 to 4 85 com- over (CE) is detected if there is an interval of (0144) munica- more than 2 s, and to select the method of (See tions time- processing the detected communications time- note 1.)

  • Page 58

    (014F) Note This parameter is monitored only. Note 1. The n68 to n74, n76, and n77 parameters cannot be written via RS422/485 communications. They are read-only. Note 2. Motor parameters depend on the Inverter capacity as shown in the following table.

  • Page 59

    Chapter 3 List of Parameters 100-V Class, Single-phase Power Supply Parameter No. Name Unit Default constant Inverter capacity Rated motor current Motor rated slip Motor no-load current % 3-19...

  • Page 60

    Chapter 4 Maintenance Operations Protective and Diagnostic Functions Inspection and Maintenance...

  • Page 61: Protective And Diagnostic Functions, Fault Detection (fatal Error)

    Inverter. If the operation command is being input, however, the reset signal will be ig- nored. Therefore, be sure to reset the fault with the operation command turned off. S Turn on the fault reset signal. A multi-function input (n36 to n39) must be set to 5 (Fault Reset).

  • Page 62

    Fault Fault name and meaning Probable cause and remedy display • Power supply to the Inverter has phase loss, power input Main circuit undervoltage (UV1) terminal screws are loose, or the power cable is discon- The main circuit DC voltage nected.

  • Page 63

    • The V/f setting is incorrect. → Reduce the V/f set voltage. • The value in n11 for maximum voltage frequency is low. → Check the motor nameplate and set n11 to the rated frequency. • The acceleration/deceleration time is too short.

  • Page 64

    • The internal circuitry of the Inverter has a fault. Initial memory fault (F04) → Initialize the Inverter with n01 set to 8 or 9 and turn the An error in the built-in EEPROM of the Inverter has Inverter off and on.

  • Page 65

    Fault Fault name and meaning Probable cause and remedy display • An emergency stop alarm is input to a multi-function input. Emergency stop (STP) → Remove the cause of the fault. An emergency stop alarm is input to a multi-function input.

  • Page 66: Warning Detection (nonfatal Error)

    The warning detection is a type of Inverter protective function that does not operate the fault contact output and returns the Inverter to its original status once the cause of the error has been removed. The Digital Operator flashes and display the detail of the error.

  • Page 67

    Note The Inverter stops according to the method set in n04. • An emergency stop alarm is input to a multi-func- The emergency stop alarm signal is input as multi-function input. tion input.

  • Page 68

    2-s period. • Communications circuit damage. → If the same error is detected as a result of a self-diagnostic test, change the Inverter. • The values in n36 through n39 for multi-function...

  • Page 69: Inspection And Maintenance

    These guidelines are applicable for an operating environment in which the ambient temperature is 40°C, the load rate is 80%, the operating time is 8 hours per day, and the product is installed according to the instructions in the manual.

  • Page 70

    Maintenance Operations Chapter 4 To extend the maintenance period, it is recommended to lower the ambient temperature and shorten the ON time as much as possible. Note Contact your OMRON sales representative for details on maintenance methods. 4-11...
