Page 1 Cat. No. V083-E1-14 NS-Series Programmable Terminals SETUP MANUAL...
Page 3  OMRON, 2003 All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form, or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior written permission of OMRON.
Page 4: Table Of Contents
3-1 Installing the PT ..........................3-3 3-1-1 Installation Environment...................... 3-3 3-1-2 Installing RS-232C/RS-422A Converters ................3-4 3-1-3 Mounting the PT to the Control Panel ................. 3-4 3-1-4 Connecting the Power Supply....................3-6 3-1-5 Wiring the Ground Wire ...................... 3-7 3-1-6 Peripheral Device Connection Limitations ................3-8 3-2 Starting the PT..........................
Page 5 3-4-3 Data Format ........................3-18 3-4-4 Bar Code Input........................3-18 3-5 Connecting to Printers ........................3-19 3-5-1 Connecting to a Printer Compatible with ESC/P Raster and BJ Raster ......3-19 3-5-2 Connecting a PictBridge-compatible Printer..............3-20 3-6 Using Memory Cards........................3-22 3-6-1 Installation..........................
Page 6 6-3-14 Starting the Ladder Monitor from Alarm/Event Summary and History (NS15/12/10/8 Only)......................6-30 6-3-15 Setting the Tag Update Notification Message..............6-31 6-3-16 Time to Switch to System Menu (NS12, NS10, NS8, or NS5).......... 6-31 6-3-17 Double-touch Interval (NS15 Only)................... 6-32 6-3-18 Analog RGB Output (NS15 only)..................6-32 6-4 Project Settings..........................
Page 7 6-8-9 Memory Card Transfers ..................... 6-61 6-8-10 External Application Startup....................6-63 6-8-11 Version Display ......................... 6-64 6-8-12 PLC Data Trace (NS15, NS12, NS10, and NS8 Only) ............6-64 6-9 Hardware Check ..........................6-66 6-9-1 LCD Check ........................6-66 6-9-2 Touch Switch Check ......................6-67 6-9-3 Touch Panel Calibration (NS15 Only) ................
Page 8 Appendix 6 Preparing Cables for Computer Connection ..............A-41 A-6-1 Connecting Cable Assembly ..................... A-41 Appendix 7 Preparing Connecting Cables for Bar Code Readers ............A-43 Appendix 8 Standard Models ....................... A-44 Appendix 9 List of Optional Products ....................A-59 A-9-1 Anti-reflection Sheets: NS15-KBA04, NS12-KBA04, NS7-KBA04, NT30-KBA04 ..
Page 9: About This Manual
This section describes the methods for connecting the host to the serial port of the PT. Section 5 Connecting to Host via Ethernet or Controller Link This section describes the methods for connecting the PT to the host using the PT’s Ethernet interface and the Controller Link Interface Unit.
Page 10: Related Manuals
Related Manuals The following manuals are used for NS-series PTs. (The boxes at the end of the catalog numbers indicate the revision code.) NS Series -V1/-V2 Setup Manual ..........V083-E1-@ This manual Provides information on NS Series V1 and V2 PTs (i.e., NS15-V2, NS12-V@, NS10-V@, NS8-V@, and NS5-V@).
Page 11: Terminology
Controllers: CV500, CV1000, CV2000, CVM1 Serial Communications Unit Indicates a Serial Communications Unit for an OMRON CS/CJ-series PLC. Serial Communications Board Indicates a Serial Communications Board for an OMRON CS-series or CQM1H PLC. Communications Board Indicates a Communications Board for an OMRON C200HX/HG/HE(-Z) PLC.
Page 12: Introduction
• This manual provides information for connecting and setting up an NS-series PT. Be sure to read this manual before attempting to use the PT and keep this manual close at hand for reference during installation and operation.
Page 13 Safety Precautions Notation Used for Safety Information The following notation is used in this manual to provide precautions required to ensure safe usage of the product. The safety precautions that are provided are extremely important to safety. Always read and heed the information provided in all safety precautions.
Page 14 3. The mounting panel must be between 1.6 and 4.8 mm thick. Tighten the Mounting Brackets evenly to a torque of between 0.5 and 0.6 N⋅m to maintain water and dust resistance. Make sure the panel is not dirty or warped and that it is strong enough to hold the Units.
Page 15 43. Never connect more than two crimp terminals to one terminal. 44. Water and oil resistance will be lost if the front sheet is torn or is peeling off. Do not use the PT if the front sheet is torn or is peeling off.
Page 16 1. Do not install the Unit in the following places: • Locations subject to severe changes in temperature. • Locations subject to direct sunlight • Locations subject to temperatures or humidity outside the range specified in the specifications • Locations subject to condensation as the result of high humidity •...
Page 17 You must therefore confirm that the overall machine or equipment complies with EC Directives. • This is a class A product. It may cause radio interference in residential areas, in which case the user may be required to take adequate measures to reduce interference.
Page 18 Conformance to Shipbuilding Standards This product complies with shipping standards. Application conditions are set for compliance for individual shipping standards, and it may not be possible to use the product in some installation locations. Contact an OMRON sales representative before using the product.
Page 19 1. Zones with and without air conditioning not on the bridge or deck (e.g., boiler room) 2. Zones with and without air conditioning on the bridge (e.g., helm room) 3. Deck zone 4. Engine room zone (devices mounted on machinery that has strict vibration conditions, such as diesel engines or air compressors) 5.
Page 20 WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY. In no event shall the responsibility of OMRON for any act exceed the individual price of the product on which liability is asserted. IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS...
Page 21 The following are some examples of applications for which particular attention must be given. This is not intended to be an exhaustive list of all possible uses of the products, nor is it intended to imply that the uses listed may be suitable for the products: •...
Page 22 PERFORMANCE DATA Performance data given in this manual is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the result of OMRON's test conditions, and the users must correlate it to actual application requirements.
Page 23: Overview
Section 1 Overview This section provides an overview of the NS-series PTs, including functions, features, connection types, and communications methods. NS-series PT Functions and Operation................1-2 1-1-1 PT Functions for FA Manufacturing Sites..............1-2 1-1-2 NS-series PT Operating System ................1-3 Communications with the Host..................
Page 24: Ns-Series Pt Functions And Operation
Graphs and other indicators can be used to better represent the information and make it easy to understand. Directions for FA Site Operators The PTs can be used to inform the operators of system and device errors and assist them in taking appropriate measures.
Page 25: Ns-Series Pt Operating System
Note 1: Some models do not support Ethernet. Note 2: USB data transfer is not supported for some PT lots and system program versions. Note 3: If the serial port protocol is set to Allen-Bradley DF1, you cannot connect to the CX-Designer through that port.
Page 26 Reading Data from the Host A communications method such as NT Link Ethernet or Controller Link is used to connect the host, and the required data is automatically read from the host. Note: Some models do not support Ethernet or Controller Link.
Page 27: Communications With The Host
1-2 Communications with the Host 1-2 Communications with the Host NS-series PTs allow the user to allocate words and bits in any PLC area for use in accessing the required display contents and storing input data. Operations that can be performed include reading and writing allocated word contents and bit status directly, changing the display status of functional objects on the PT screen, and con- trolling and notifying PT status.
Page 28: What Is An Nt Link
In the rest of this manual, "NT Link" refers to NT Link communications in general, "1:1 NT Link" refers to an NT Link in a 1:1 configuration only, and "1:N NT Links" refers to NT Links in a 1:N configuration only. Where necessary, "normal 1:N NT Links" and "high-speed 1:N NT Links"...
Page 29: Memory Link Connections
When the host is a computer instead of a PLC, the Memory Link protocol can be used to connect with the computer. Use serial port A or B to connect to the host. For details, refer to the Host Connection Manual (Tem.Control, MemLink).
Page 30: System Configuration
Note 5: Refer to 3-3-2 Connecting via USB for information on connecting the PT and computer with a USB cable. A USB Relay Cable can be used to place a USB slave connector on the front of the control panel. Refer to 3-1-3 Mounting the PT to the Control Panel.
Page 31 • Video Input Unit (Refer to 3-7 Installing the Video Input Unit.) NS-CA001 NS-CA002: Refer to the NS Series RGB and Video Input Unit Operation Manual (Cat. No. V086). • Controller Link Interface Unit (Refer to 3-8 Installing the Controller Link Interface Unit.)
Page 32: Procedure For Running Ns-Series Pts
3. The system menu can be operated as required to initialize data saved in the PT. 4. For the NS15, the System Menu can be displayed by pressing one of the four corners of the touch panel twice in a row. For the NS5, NS8, NS10, and NS12, the system menu can be dis- played by simultaneously pressing two of the four corners of the touch panel.
Page 33 1-4 Procedure for Running NS-series PTs The following table lists the device and software manuals used for reference. Device/Software Manual name Catalog No. NS-series PTs Setup Manual V072 (Provides information on existing NS-series models, i.e., NS12, NS10, and NS7.) Programming Manual...
Page 34 1-4 Procedure for Running NS-series PTs 1-12...
Page 35: Before Connecting
Section 2 Before Connecting This section provides information on methods for connecting NS-series PTs that must be under- stood before connecting the host and peripheral devices. For details on connecting through host link communications, refer to the Host Connection Manual (Host Link). For details on Temperature Controller connections and Memory Link communications, refer to the Host Connection Manual (Temp.
Page 36: Connecting The Host
Note 1: A 1:N NT Link can be set for either normal or high-speed communications. Note 2: With the NS5, EXP. (Expansion) I/F on the Comm Tab Page in the System Menu settings can be set to use a communications port in the expansion interface connector. The expansion in- terface, however, is a future expansion, which cannot yet be used.
Page 37 Specified shielded twisted-pair Link (See Yes P. 5-17 cable Link note 2.) Yes: Connection is possible. No: Connection is not possible. Note 1: Possible only with the NS15-TX01@-V2. Note 2: Only when a Controller Link Interface Unit (NS-CLK21) is mounted.
Page 38 Specified shielded Controller twisted-pair cable Link (See Yes P. 5-17 Link note 2.) Yes: Connection is possible. No: Connection is not possible. Note 1: Possible only with the NS15-TX01@-V2. Note 2: Only when a Controller Link Interface Unit (NS-CLK21) is mounted.
Page 39 No P. 5-26 Host Controller Link Interface Unit Specified shielded twisted-pair cable Controller Controller Link (See Yes P. 5-17 Link note.) Host Yes: Connection is possible. No: Connection is not possible. Note: Only when a Controller Link Interface Unit (NS-CLK21) is mounted.
Page 40 No: Connection is not possible. Note: Possible only with the NS15-TX01@-V2. • The NS-AL002 is connected directly to the serial port of the PT and power is supplied from pin 6 of the port. • When there are multiple serial ports and Ethernet Units for a single host, each port can be used to communicate with separate PTs.
Page 41 No: Connection is not possible. Note: Only when a Controller Link Interface Unit (NS-CLK21) is mounted. • The NS-AL002 is connected directly to the serial port of the PT and power is supplied from pin 6 of the port. • When there are multiple serial ports and Ethernet Units for a single host, each port can be used to communicate with separate PTs.
Page 42: Part Names And Functions
A backlight error occurred abnormally. immediately after power was turned ON. • Power is not being supplied to the PT. Not lit • The fuse is broken. • The system program is damaged and the system cannot be booted.
Page 43 USB Slave Connector USB Host Connector This is a USB Type B connector. It can be used to connect to the CX-Designer. Used to connect to printers. Refer to 3-3-2 Connecting via USB. It is a USB Type A connector.
Page 44 A backlight error occurred abnormally. immediately after power was turned ON. • Power is not being supplied to the PT. Not lit • The fuse is broken. • The system program is damaged and the system cannot be booted. 2-10...
Page 45 USB Type A connector. USB Slave Connector Refer to 3-5-1 Connecting to a This is a USB Type B connector. It can be used to connect to the CX-Designer. Printer Compatible with ESC/P Refer to 3-3-2 Connecting via USB. A PictBridge-compatible printer can also be connected to the NS12-V2 or NS10-V2.
Page 46 Memory Card transfer in progress. Memory Card normally. transfer ended abnormally. • Power is not being supplied to the PT. Not lit • The fuse is broken. • The system program is damaged and the system cannot be booted. 2-12...
Page 47 It is a USB Type A connector. This is a USB Type B connector. Refer to 3-5-1 Connecting to Refer to 3-3-2 Connecting via USB. It is used to connect to CX-Designer. a Printer Compatible with A PictBridge-compatible printer can also be connected to the NS8-V2.
Page 48 Memory Card transfer in progress. Memory Card normally. transfer ended abnormally. • Power is not being supplied to the PT. Not lit • The fuse is broken. • The system program is damaged and the system cannot be booted. 2-14...
Page 49 Designer, and Bar Code Reader. Designer, and Bar Code Reader. Uses an RS-232C 9-pin connector. Uses an RS-232C 9-pin connector. Confirm system safety before turning the power ON/OFF or restarting. Other- Precautions for Safe Use wise the system may operate unpredictably.
Page 50 2-2 Part Names and Functions Touch Panel (NS15) The touch switches on the front panel of the PT are used to perform input operations. Press the touch switches to perform operations such as switching screens and sending bit status to the host.
Page 51 2-2 Part Names and Functions Touch Panel (NS12/10/8/5) The touch switches on the front panel of the PT are used to perform input operations. Press the touch switches to perform operations such as switching screens and sending bit status to the host.
Page 52 Request to send (-) Request to send (+) Functional ground A screwdriver that is thin only at the tip will not fit all the way into the hole. Use Precautions for Correct Use a small flat-blade screwdriver with a consistent thickness. The tightening torque is 0.4 to 0.5 N ⋅...
Page 53 Protection circuit BI_D − Protection circuit When using a cable with a hood (or boot), make sure that the length for connection is at least 15 mm, as shown in the following diagram. 15 mm min. Analog GRGB output connector (NS15 Only) Pin No.
Page 54 2-2 Part Names and Functions 2-20...
Page 55: Installing The Pt And Connecting Peripheral Devices
This section describes the methods used to install the PT and connect peripheral devices. For details on methods for connecting the host, refer to Section 4 Connecting the Host to Serial Port or Section 5 Connecting to Host via Ethernet or Controller Link.
Page 56 Installing the Controller Link Interface Unit ..............3-43 3-8-1 Controller Link Interface Unit Components............3-43 3-8-2 Nomenclature and Functions.................. 3-44 3-8-3 Installation Method for Controller Link Interface Unit.......... 3-47 3-8-4 Wiring ........................3-54 Connecting a Monitor ....................3-60 3-10 External Brightness Adjustment ................... 3-61...
Page 57: Installing The Pt
3-1 Installing the PT 3-1 Installing the PT The methods used to mount the PT to the control panel and connect the power supply are described here. 3-1-1 Installation Environment Always mount the PT to the control panel and perform other installation procedures accord- ing to the following precautions.
Page 58: Installing Rs-232C/Rs-422A Converters
Reference A NS-USBEXT-1M USB Relay Cable can be used to place a USB slave connector on the front of the control panel. To use a USB Relay Cable, mount the Cable connector in a panel cutout with the following dimensions.
Page 59 Secure the panel mounting brackets from the back of the panel, as shown in the following diagram. Insert the catch on each bracket into the square hole on the PT, and secure the PT to the panel by tightening the screws with a Phillips screwdriver while gently pulling in the PT.
Page 60: Connecting The Power Supply
Safe Use • Do not perform a dielectric strength test. • To conform to EC Directives, use a DC power supply that will provide a sta- ble output even if the input is momentarily interrupted for 10 ms, and that has reinforced or double insulation.
Page 61: Wiring The Ground Wire
Wire the FG terminal according to the following conditions. 1. Ground according to Figure when there is difference in potential between the PT and host. Do not ground the functional ground of the PT if it is far from the host and one-point grounding is difficult.
Page 62: Peripheral Device Connection Limitations
Select one of the following combinations when devices requiring power supply are con- nected to port A, port B, and an Expansion Interface Unit on the PT. Use a 5-V Bar Code Reader with a current consumption of 250 mA or the equivalent.
Page 63: Starting The Pt
3-2 Starting the PT 3-2 Starting the PT Check that the hardware is connected properly, turn ON the power to the PT, and then start the PT. Use the following procedure to start the PT. 3-2-1 Operation at Startup When the power is ON or the PT is reset, the PT will operate as follows: Indicator lights orange.
Page 64 Confirm the safety of the system before turning the power ON and OFF or Precautions for Safe Use pressing the reset switch. Reference If tags are used in the screen data in the NS-series PT, tags will be verified before opera- tion is started. Refer to 6-11 Verifying Tags for details. 3-10...
Page 65: Starting The Pt For The First Time
2. Set the date and time. Operate according to the following conditions. a) When the power is turned ON to the PT, the following error message will be displayed. Press the OK Button. b) The System Menu will be displayed. Press the Initialize Tab. The dialog boxes and System Menu are set for English-language displays at the factory.
Page 66 3-2 Starting the PT Example: Input March 15, 2002 as 2002.3.15. e) Press the time display area under the heading Calendar Check. A dialog box will be displayed. In- put the time using a 24-hour clock in hours/minutes/seconds format. Example: Input 06:01:01 p.m. as 18.1.1.
Page 67: Connecting The Cx-Designer
Connect the RS-232C cable from the computer to serial port A or B. The cable can be con- nected to either serial port A or B, but cables cannot be connected to both ports at the same time. Use either serial port A or B.
Page 68 Day of month, e.g., the 3rd in this example Use a USB cable that is 2 m or shorter. If a distance of longer than 2 m is required for a USB connection, use a commercially available USB Hub. Up to 2 m 2 m max.
Page 69: Connecting Via A Modem
3-3-3 Connecting via a Modem A modem can be used to connect the computer and a serial port on the PT. For details on connection methods and communications conditions, refer to Transferring Data to the PT in the CX-Designer’s Online Help.
Page 70: Connecting To Bar Code Readers
Inputting Numeral and Character Strings in the Programming Manual. 3-4-1 Connection Methods Connect the Bar Code Reader to either serial port A or B of the PT as shown in the following diagram. Bar Code Reader Serial port A or B...
Page 71: Setting Bar Code Readers
Set the settings for the Bar Code Reader according to the following table. Make sure, how- ever, that the communications conditions settings for the communications speed, parity, stop bits, and data bits, match those set for the PT. For details on setting methods, refer to the operation manual of the Bar Code Reader being used.
Page 72: Data Format
2. The Numeral Display & Input or String Display & Input object will become highlighted. 3. Read the bar code data from the Bar Code Reader. 4. Touch the command button set to either RET (Return) or ENT (Enter) to confirm the in- put.
Page 73: Connecting To Printers
Connecting to a Printer Compatible with ESC/P Raster and BJ Raster Connect the printer to the USB host connector on a NS15, NS12, NS10, or NS8 PT with a USB cable as shown in the following figure. USB host connector USB slave connector •...
Page 74: Connecting A Pictbridge-Compatible Printer
PT is turned ON. Always turn OFF the power supply to the printer and PT before connecting or disconnecting the cable. • Connect the printer directly to the PT with a cable. Connection via a USB hub is not Reference possible.
Page 75 ON in system bit memory. Depending on the printer, an error message saying that an unsupported digital camera is connected may be displayed. Even if this display ap- pears, you can still print properly by using the bits in system bit memory ($B25, 27, and 29).
Page 76: Using Memory Cards
The history data is normally saved in internal memory that is backed up in the PT, but can also be saved in CSV file format. When history data is saved as a CSV file, it is stored in the Memory Card.
Page 77: Installation
1. The Memory Card is installed in the memory card interface on the side of the PT. Eject button Front surface 2. Push the Memory Card firmly into the back of the slot. (The eject button will be pushed out when the Memory Card is installed properly.) •...
Page 78: Replacing The System Program
3-6 Using Memory Cards 3-6-2 Replacing the System Program The system program in the PT can be replaced or upgraded to a higher version. There are two methods that can be used to replace the system program. • Using a recovery/upgrade program •...
Page 79: Transferring Data With Memory Cards
When screen data is transferred and modified frequently, it is convenient to transfer the data from the System Menu. Use the DIP Switch on the back of the PT instead of the screen op- eration to save screen data when the display screen is damaged. For details on the System Menu’s Memory Card Transfer operation, refer to 6-8-9 Memory Card Transfers.
Page 80 • When data is transferred to the Memory Card using the CX-Designer. • When data is transferred (uploaded) from the PT. • When transferring data, only one bank can be specified. Set only one of pins 1 to 4 to Reference •...
Page 81 Always check carefully that the PT model and Memory Card details match before transfer- ring data automatically. When data transfer security has been set for the project data stored in the PT to protect the project data from unauthorized data transfers, an automatic download will not be performed.
Page 82 & System, or System), and banks. Use one of the following procedures to manually transfer data. 1. Turn OFF the power to the PT, turn ON pin 6 of the DIP switch, and turn ON the power to the PT.
Page 83 3-6 Using Memory Cards 7. When data transfer security has been set for the project data stored in the PT to protect the project data from unauthorized data transfers, the following password-entry screen will be displayed. Input the password and press the ENTER Button.
Page 84 • System Program Recovery/Update It may not be possible to replace the system program using a normal download if the PT sys- tem has been damaged, e.g., if the power was turned OFF while a file was being written. Use the following procedure to operate the PT if system program replacement is not possible or the system program is damaged and the PT does not start.
Page 85 Video Input Unit allows images from a video camera or vision sensor to be displayed on the PT screen. This section explains how to connect a Video Input Unit to the PT with a cable using the NS-CA001 as an example.
Page 86: Installing The Video Input Unit
Display may not be possible, however, if the input signal deviates from the stan- for Correct Use dard signal. Before operation, be sure to check the output signal of the camera to be used. If display cannot be made, take measures so that the input signal is a standard signal. Video Input Specifications...
Page 87: Installation Method For Video Input Unit
This section describes the method for mounting the Video Input Unit to the PT. A Video Input Unit can be connected to the NS8, NS10, NS12 or NS15 (except that the NS- CA001 cannot be connected to the NS15. Also, the NS15 does not support video input from the NS-CA002, but it does support analog RGB input from the NS-CA002).
Page 88 3-7 Installing the Video Input Unit 2. Secure the four corners of the Video Board with screws. 3. Insert screws in the screw holes for attaching the cover and tighten them slightly. Align the cover’s screw holes with the screws and mount the cover.
Page 89 3-7 Installing the Video Input Unit Slide the cover downward and tighten the screws. Connecting the Cable Connect the functional ground terminal of the PT and the cover with the cable to prevent malfunction due to noise. Connect with the cable provided.
Page 90 3-7 Installing the Video Input Unit Removing the Video Input Unit 1. Remove the cover from the PT as follows: Loosen the screws. Lift up on the cover and remove it. 2. Remove the screws from the four corners. 3-36...
Page 91 3-7 Installing the Video Input Unit 3. Remove the Video Board from the expansion interface connector of PT. Follow the procedure shown below. 3-37...
Page 92: Connecting To Video Input Connectors
3-7 Installing the Video Input Unit 3-7-4 Connecting to Video Input Connectors Use the following method to connect cameras to the Video Input Unit mounted to the PT. The tensile load of the cable is 30 N maximum. Do not exceed maximum load Precautions...
Page 93 3-7 Installing the Video Input Unit Removing the Video Input Connector 1. Unlock the BNC socket on the camera’s video output cable by twisting it counterclock- wise while pushing it. Push Twist counterclockwise 2. After unlocking the BNC socket, pull it out.
Page 94 3-7 Installing the Video Input Unit If the camera’s video output cable uses an RCA plug, connect it to the video input connector using a BNC-RCA connector in the way shown below. Video input connector (BNC type) BNC - RCA connector (See note.)
Page 95 Use the following method to connect the Video Board’s console port connector to the con- sole connector of an OMRON Vision Sensor (F150-C10V3, F160-C10, F180-C10, F400- C10V2, F250-C10, V530-R150V2). 1. Insert the socket of the Relay Cable (F150-VKP; see note) into the Video Board’s con- sole port connector. Note The Relay Cable (F150-VKP) is the cable used to connect the Video Board’s console connec-...
Page 96 3-7 Installing the Video Input Unit Setting the Contrast If the picture displayed on the PT screen is too bright or dark, contrast adjustment is required. Contrast adjustment is usually performed using one of the following procedures. • Select Video Configuration from the Special Screen Tab Page in the System Menu. (Refer to Video Configuration under 2-20 Special Functions in the NS-series Programmable Ter- minals Programming Manual.)
Page 97 To comply with EC Directives when mounting the Controller Link Interface Unit Precautions for Safe Use on the PT, attach the PT to a control panel that has been cut to fit to size. (Refer to 3-1-3 Mounting the PT to the Control Panel for cutout dimensions.) 3-43...
Page 98: Installing The Controller Link Interface Unit
Network. The switch must be set to OFF at other nodes. Reference To identify nonconforming Controller Link Boards, check the Model printed on the Plate. This will tell you whether it conforms with EC Directives. Model 3G8F5-CLK21: Does not conform with EC Directives...
Page 99 A Board operating error (watchdog timer error) occurred. Communica- One of the following errors occurred. • Communications error tions error • Same node address used twice (i.e., address duplica- tion error) • Hardware error Not lit Normal operation EEPROM error Red One of the following errors occurred.
Page 100 ON. Set the switch to ON to connect the terminating resistance at both end nodes in wired net- works and set the switch to OFF at all other nodes.
Page 101: Installation Method For Controller Link Interface Unit
This section explains the method for mounting a Controller Link Interface Unit to the PT. The Controller Link Interface Unit can be mounted to NS15, NS12 and NS10 PTs only. It cannot be mounted to an NS8 or NS5 PT.
Page 102 3-8 Installing the Controller Link Interface Unit Connecting and Disconnecting 1. Mount the Connector Conversion Board onto the back of the PT so that its expansion in- terface connector is inserted into the expansion interface connector on the back of the PT and the respective screw holes are aligned.
Page 103 3. Insert the Controller Link Support Board’s card edge connector into the Connector Conversion Board’s connector. Reference Follow the steps given below if it is hard to insert the card edge connector to the con- nector on the connector conversion board. 3-49...
Page 104 3-8 Installing the Controller Link Interface Unit 4. Mount the cover to the PT. Cover Controller Link Support Board (Underside view) 5. Secure the five places shown below with screws. 3-50...
Page 105 3-8 Installing the Controller Link Interface Unit Connecting the Cable Connect the functional ground terminal of the PT and the cover with the cable to prevent malfunction due to noise. Connect with the cable provided. Removing Controller Link Interface Unit 1.
Page 106 3-8 Installing the Controller Link Interface Unit 2. Disconnect the Controller Link Support Board from the connector conversion board. Hold both ends of the Controller Link Support Board and pull out straight. 3. Remove the screws from the Connector Conversion Board.
Page 107 3-8 Installing the Controller Link Interface Unit 4. Disconnect the Connector Conversion Board from the PT. To do this, follow the steps given below. Hold the four corners of the Board and detach upper side first. Then, pull out the Board completely.
Page 108: Wiring
3-8 Installing the Controller Link Interface Unit 3-8-4 Wiring This section describes the method for wiring the network communications cable to the Con- troller Link Support Board. Wiring the Communications Cable Wire the communications cable to connect identical signals. • Use the cable specified for the communications cable.
Page 109 Connect the communications cable to the connector using the following procedure. 1. Taking care not to damage the mesh of the shield, strip about 50 mm off the end of the cable. Do not strip the cable too far because it may cause a short-circuit.
Page 110 3. Strip the ends of the signal wires far enough to attach to the crimp terminals. Twist the wire strands together. 4. Cover the end of the cable at the point it was stripped to in step 1 with vinyl tape or heat- shrink tubing.
Page 111 • Marks indicate signals as listed above. • The lines can be connected to either the right or left half of the connector at the node on either end of the network. • If grounding by node, the connection method for the shield is different.
Page 112 1. Insert the connector on the communications cable into the connector on the Board as shown below. Controller Link Support Board Cable connector 2. Secure the connector to the Board by tightening the screws on the connector. The appli- cable tightening torque is 0.2 N⋅m. 3-58...
Page 113 3-8 Installing the Controller Link Interface Unit • If the connector becomes disconnected, not only will the Board be unable to Precautions perform communications with other nodes in the network, the network will be for Safe Use split into two at the point of disconnection. Take the utmost care to ensure that the connector does not become disconnected during communications.
Page 114: Connecting A Monitor
3-9 Connecting a Monitor To display images from the PT on a monitor, connect a VGA cable from the monitor to the analog RGB output connector on the NS-series PT. Only the NS15 can output images to an external monitor.
Page 115: External Brightness Adjustment
Connect a variable resistor to the external brightness adjustment connector on the NS-series PT to exter- nally adjust the brightness of the backlight in the touch panel. This allows the brightness to be set lower than the Low selection in the backlight brightness settings (High, Medium, and Low) under the operating settings for NS-series PTs.
Page 116: Rs-232C/Rs-422A Selector Dip Switch
3-11 RS-232C/RS-422A Selector DIP Switch A DIP switch on the NS15 can be used to select RS-232C or RS-422A for serial port B communications. Use the software program to see which cable is selected and use the System Menu to display the status of the connection.
Page 117: Connecting The Host To Serial Port
Section 4 Connecting the Host to Serial Port This section describes the methods for connecting the host to the serial port of the PT. For details on connecting through host link communications, refer to the Host Connection Manual (Host Link). For details on Temperature Controller connections and Memory Link communications, refer to the Host Connection Manual (Temp.
Page 118: 1:1 Host Connection
4-1 1:1 Host Connection 4-1-1 Connection Methods This section describes the methods for connecting the host to serial port A or B of the PT us- ing RS-232C or RS-422A communications. The connection methods are as follows: • Direct Connection using RS-232C This is the easiest connection method.
Page 119 • CQM1H PLCs can be connected in a 1:1 NT Link for RS-422A by adding a Serial Com- munications Board. Check the series and type of the PLC and the model of the Board that is mounted to the PLC when connecting the PT to the host.
Page 120: Unit Setting Methods
Port 2 of CQM1H (See note 2.) DM 6550 4000 Note 1. RS-422A port of Communications Board. 2. RS-422A port of Serial Communications Board. Refer to the manuals of the PLC being used for details on using the PLC Setup Area.
Page 121 Set pin 5 of the DIP switch to OFF to enable the PLC Setup Area settings. • Setting the CPM2A Front Panel DIP Switch When using a CPM2A, set the DIP switch on the front panel to enable the PLC Setup Area (Data Memory) settings, as follows: Set the communications conditions setting switch to OFF (lower position).
Page 122 When using CVM1/CV-series PLCs, always set the Execute Process (Execute Control 2) in the PLC Setup to synchronous execution. Setting the Front Panel DIP Switch Set the DIP switch on the front panel, as shown in the following diagram. Switch setting Switches between RS-232C...
Page 123: 1:N Host Connection
CS1W-SCU21/31 Serial Communications Unit. CJ-series PLCs can also be connected in 1:N NT Links by using a CJ1W-SCU31/41 Serial Communications Unit. Check the series and model of the PLC and the model of the Board or Unit that is mounted to the PLC when connecting the PTs to the host.
Page 124 • There is Communications Board for use with CQM1H where Port 1 is an RS-422A port. • When setting a 1:N NT Link in the CX-Programmer, set the baud rate to 38,400 bps. Setting the Front Panel DIP Switch • Using RS-232C...
Page 125 1. Open the project file in the CX-Programmer and select PLC - PLC Information - PLC Settings from the menus. 2. The PLC Settings Dialog Box will be displayed. Click the tab for the port to which the PT is connected and change the following three parameters. (The following screen capture is provided as an example.
Page 126 Set the mode to the 1:N NT Link Mode. NT/PLC If only one PT is connected to the port and it has a unit number of 0, set this Link Max. parameter to 1. Otherwise, set the highest unit number of all the PTs that are connected.
Page 127 Setting the Front Panel Switches • Using RS-232C Set DIP switch pin 4 or 5 of the CPU Unit according to the port to which the PT is connected, as follows: DIP switch (inside battery compartment) Turn ON pin 4 when connecting the PT to...
Page 128 Set the mode to the 1:N NT Link Mode. NT/PLC If only one PT is connected to the port and it has a unit number of 0, set this Link Max. parameter to 1. Otherwise, set the highest unit number of all the PTs that are connected.
Page 129 • Using RS-232C Set DIP switch pin 4 or 5 of the CPU Unit according to the port to which the PT is connected, as shown below. (The following figure shows a CJ1G CPU Unit. The arrangement depends on the CPU Unit, but the DIP switch settings are the same.)
Page 130 @: Largest unit number (1 to 7) of the con- nected PTs. (See note 2.) Note 1. Set the baud rate to a numeric value between 0000 to 0009 Hex. (The setting is the same for any value between 0000 and 0009 Hex.) 2.
Page 131 @: Largest unit number (1 to 7) of the connected PTs. (See note 2.) Note 1. Set the baud rate to a numeric value between 0000 to 0009 Hex. (The setting is the same for any value between 0000 and 0009 Hex.) 2.
Page 132 000@ connected PTs. (See note 2.) Note 1. Set the baud rate to a numeric value between 0000 to 0009 Hex. (The setting is the same for any value between 0000 and 0009 Hex.) 2. When using a 1:N connection, set the value for @ to 1 or higher.
Page 133 Display indicators Terminating resistance switch (TERM) Unit number setting switch Set a value between 0 and F that is not the same as these used by other Units in the system. Two-wire/four-wire switch (WIRE) For RS-422A: Set to 4 for four-wire operation (right position).
Page 134: High-Speed 1:N Nt Link
Communications Unit. Check the series and model of the PLC and the model of the Board or Unit that are mounted to the PLC when connecting the PT to the host. For details on the PLCs that can be con- nected, refer to Appendix 8 Standard Models.
Page 135: Unit Setting Methods
1. Open the project file in the CX-Programmer and select PLC - PLC Information - PLC Settings from the menus. 2. The PLC Settings Dialog Box will be displayed. Click the tab for the port to which the PT is connected and change the following three parameters. (The following screen capture is provided as an example.
Page 136 150 of the PLC Setup instead of 160, 161, 166. Setting the Front Panel Switches Using RS-232C Set DIP switch pin 4 or 5 of the CPU Unit according to the port to which the PT is connected, as follows: DIP switch (inside battery...
Page 137 3. Open the project file in the CX-Programmer and select PLC - PLC Information - PLC Settings from the menus. 4. The PLC Settings Dialog Box will be displayed. Click the tab for the port to which the PT is connected and change the following three parameters. (The following screen capture is provided as an example.
Page 138 Setting the Front Panel Switches • Using RS-232C Set DIP switch pin 4 or 5 of the CPU Unit according to the port to which the PT is connected, as shown below. (The following figure shows a CJ1G CPU Unit. The arrangement depends on the CPU Unit, but the DIP switch settings are the same.)
Page 139 000@ note.) Note: When connecting a single Unit in a 1:N connection, set the value of @ to 1 or higher. For example, to connect PTs with unit numbers 3 to 6 to Port 1 in 1:N NT Links, set DM32000 to 8200 Hex, DM32001 to 000A Hex, and DM32006 to 0006 Hex.
Page 140 @: Largest unit number (1 to 7) of the connected 000@ PTs. (See note.) Note: When connecting a single Unit in a 1:N connection, set the value of @ to 1 or higher. Reference To set high-speed 1:N NT Link communications from the CX-Programmer, set the baud rate to 115,200 bps.
Page 141 @: Largest unit number (1 to 7) of the connected PTs. (See 000@ note.) Note: When connecting a single Unit in a 1:N connection, set the value of @ to 1 or higher. Reference To set high-speed 1:N NT Link communications from the CX-Programmer, set the baud rate to 115,200 bps.
Page 142 Display indicators Terminating resistance switch (TERM) Unit number setting switch Set a value between 0 and F that is not the same as these used by other Units in the system. Two-wire/four-wire switch (WIRE) For RS-422A: Set to 4 for four-wire operation (right position).
Page 143: Recommended Connector Cables
CO-MA-VV-SB Multiconductor shielded cable 5P × 28AWG made by Hitachi Densen, Ltd. The connector’s tensile load is 30 N max. Do not subject the connectors to a Precautions for Safe Use load greater than that specified. • OMRON Cables with Connectors The following OMRON Cables with Connectors can be used.
Page 144 4-4 Recommended Connector Cables 4-28...
Page 145: Connecting To Host Via Ethernet Or Controller Link
Section 5 Connecting to Host via Ethernet or Controller Link This section describes the methods for connecting the PT to the host using the PT’s Ethernet interface and the Controller Link Interface Unit. 5-1 Connecting to Host Via Ethernet..................5-2 5-1-1 Host Types and Settings ...................
Page 146: Connecting To Host Via Ethernet
To connect to the network using Ethernet, the network number, node number, and IP ad- dress must be set. Use the CX-Designer to set the settings. For details, refer to System Set- tings and Project Properties in the CX-Designer’s Online Help.
Page 147: Host Types And Settings
Units that are used for Ethernet communications vary according to the type and series of OMRON PLC used. When connecting an Ethernet Unit, check the series and type of the PLC that it will be con- nected to and the model of the Unit that is mounted to the PLC.
Page 148 IP Address Configuration The IP address is comprised of 32 bits of binary data, consisting of the net ID and host ID. The net ID is the address that identifies the network, and the host ID is the ID that identifies the host (node).
Page 149 The system operates internally as multiple networks, but exter- nally appears as a single network. To operate a system in this way, divide the host ID field of the IP address into a subnet ID field and a host ID field.
Page 150 The automatic generation method uses the FINS node number without modification as the host ID of the IP address. The net ID of the local IP address is used as the net ID. Automatic generation uses the following type of remote IP address configured from the local IP address, subnet mask, and remote node number (FINS node number).
Page 151 This method combines automatic generation and the IP address table method. First refer to the IP address table, and if the required FINS address is included in the table, read the corresponding IP address. If the required FINS address is not included, calculate the IP address using the automatic generation method.
Page 152 The remote network table provides the node and network address corresponding to the ini- tial relay point (first point the data must pass) en route to a target network (end network) not directly connected to the local PLC. The table specifies the route from the relay point to the end network.
Page 153 Setting the Front Panel Switches Setting Unit Numbers Always set the unit numbers so that the unit numbers of other CPU Bus Units mounted to the CPU Unit are all unique. Use a small screwdriver to set the rotary switches, being careful not to damage them.
Page 154 SW7 and SW8, and set the other host ID fields to 0. The ERC indicator will flash if the value of the IP address host ID does not correspond to the node number value.
Page 155 When using automatic generation to convert addresses, set the node number to the same value as that of the rightmost byte of the local IP address. If the same values cannot be set, the IP address table method or combination method must be used to convert the addresses.
Page 156 Setting the Front Panel Switches Setting Unit Numbers Always set the unit numbers so that the unit numbers of other CPU Bus Units mounted to the same CPU Unit are all unique. Use a small screwdriver to set the rotary switches, being careful not to damage them.
Page 157 When using automatic generation to convert addresses, set the node number to the same value as that of the rightmost byte of the local IP address. If the same values cannot be set, the IP address table method or combination method must be used to convert the addresses.
Page 158 When using automatic generation to convert addresses, set the node number to the same value as that of the rightmost byte of the local IP address. If the same values cannot be set, the IP address table method or combination method must be used to convert the addresses.
Page 159 Setting Example This example is for unit number 12. • The unit number cannot be set to a value more than 15. If the unit number is set to a Reference value higher than 15, the ERH indicator in the display will light.
Page 160 Ethernet. This setting is the node number used for FINS communications. Use the left switch (SW3) to set the left digit as a hexadecimal, and the right switch (SW4) to set the right digit. The setting range is 01 to 7E hexadecimal (1 to 126 decimal).
Page 161: Connecting To The Host Using Controller Link
To connect the PT to the Controller Link, it is necessary to install a Controller Link Interface Unit on the PT. A Controller Link Interface Unit can be used only for the NS15, NS12 and NS10 NS-series PTs. Refer to 3-8 Installing the Controller Link Interface Unit for the proce- dure for installing and wire the Controller Link Interface Unit.
Page 162: Data Links
Data links can be freely created for CS-series PLCs, C200HX/HG/HE PLCs, CVM1, CV- series PLCs, CJ-series PLCs, CQM1H-series PLCs, and NS-series PTs. Two data link areas, area 1 and area 2, can be set for each node. Data links can be set in ei- ther of the following ways.
Page 163 5-2 Connecting to the Host Using Controller Link Example 2: Some nodes can Example 1: The order of send send data without receiving data. and receive nodes is free. Area 1 Area 1 Sending only Area 2 Area 2 Example 3: Some nodes can...
Page 164 Set the number of words to be transmitted The total number of words in area 1 and area 2 in each node must not exceed 1,000. The number of words in both area 1 and area 2 in each node must not be set to 0. •...
Page 165 The PT starts and stops data links according to the status of the data links when participat- ing in the network. If the data links are started when entering the network, the PT will start its data links. If network has stopped data links, the PT will not start data links. The PT cannot control starting/stopping data links independently.
Page 166 Routine tables must be set for the following items. • Local node • All relay nodes that are included for the communication path from local node to the desti- nation. Make settings for routing tables on the CX-Designer. For details on setting routing tables, re- fer to System Settings and Project Properties in the CX-Designer’s Online Help.
Page 167: Troubleshooting Using Indicators
LNK: Data link Troubleshooting with RUN, ERC, ERH, and INS Indicators The RUN, ERC, ERH, and INS indicators can be used to check whether the Controller Link Interface Unit and network participation are operating normally. • Always turn OFF the power to the PT before performing any of the following Precautions operations.
Page 168 5-2 Connecting to the Host Using Controller Link Indicators Probable cause Remedy RUN ERC ERH − − Routing table setting error. Remake and set the routing tables correctly, referring to System Settings and Project Properties in the CX- Designer’s Online Help.
Page 169 Troubleshooting with LNK Indicator - Data Links Cannot Be Started The following table describes the LNK indicator and remedies when a data link cannot be started. Starting a data link depends on the Controller Link Interface Unit operating normally and par- ticipating in the network.
Page 170: Connecting To Host Via Ethernet/Ip
NS-series PTs can communicate with CS/CJ-series EtherNet/IP Units and CJ2H-CPU@@- EIP CPU Units, which have a built-in EtherNet/IP port. Also, it is possible to perform tag mes- sage communications if an NS-series PT is connected to a CJ2H-CPU@@-EIP PLC. The...
Page 171: Setting Individual Units
Setting the Front Panel Switches Setting Unit Numbers Always set the unit numbers so that the unit numbers of other CPU Bus Units mounted to the same CPU Unit are all unique. Use a small screwdriver to set the rotary switches, being careful not to damage them.
Page 172 When using automatic generation to convert addresses, set the node number to the same value as that of the rightmost byte of the local IP address. If the same values cannot be set, the IP address table method or combination method must be used to convert the addresses.
Page 173 When using automatic generation to convert addresses, set the node number to the same value as that of the rightmost byte of the local IP address. If the same values cannot be set, the IP address table method or combination method must be used to convert the addresses.
Page 174 5-3 Connecting to Host via EtherNet/IP 5-30...
Page 175: System Menu Operations
Section 6 System Menu Operations This section describes the methods for operating the System Menu. This section also provides details on functions that are useful for NS-series PT applications and for system maintenance. Operating Modes and System Menu................6-3 6-1-1 Mode Configuration ....................6-3 6-1-2 System Menu Configuration ..................
Page 176 6-3-14 Starting the Ladder Monitor from Alarm/Event Summary and History (NS15/12/10/8 Only)....................6-30 6-3-15 Setting the Tag Update Notification Message............6-31 6-3-16 Time to Switch to System Menu (NS12, NS10, NS8, or NS5)......6-31 6-3-17 Double-touch Interval (NS15 Only)............... 6-32 6-3-18 Analog RGB Output (NS15 only) ................6-32 Project Settings ......................
Page 177: Operating Modes And System Menu
6-1 Operating Modes and System Menu 6-1 Operating Modes and System Menu The System Menu can be used to set various PT settings by operating the touch switches on the screen. The following diagram shows the menu configuration in the System Menu. Refer to 6-1-4 Using the System Menu for details on System Menu operations.
Page 178: Overview Of Menu Items
6-1 Operating Modes and System Menu 6-1-3 Overview of Menu Items The following tables show the eight menu items and provide an overview of their contents. 1. Initialize Tab Item Function Page Screen Data Area Formats project data, such as screen data.
Page 179 NS-series PT is operating. Time to Switch to System Sets the time required to switch to the System Menu when two of P. 6-31 Menu (NS12, NS10, NS8, the four screen corners are pressed. The time to switch to the Sys- or NS5) tem Menu can be set to between 0 and 5 s.
Page 180 Sets and displays whether serial port B is used, the communica- P. 6-40 tions method, and other details. Expansion Interface Sets and displays the connector used by serial port B (NS5 only). P. 6-40 Ethernet Sets and displays whether Ethernet is used and communications P. 6-42 details.
Page 181: Using The System Menu
Information on using the menus, such as displaying the System Menu, and selecting menu items, is provided here. Reference The system settings set in the project data are given priority over those set in the System Menu. Displaying the System Menu The System Menu can be displayed by using any of the following methods.
Page 182 Reference The time required to switch to the System Menu can be set in the Time to keep pressing 2 corners on the screen [sec] for Entering System Menu Field on the PT Settings Tab Page in the System Menu.
Page 183 6-1 Operating Modes and System Menu Selecting Menu Items Items in the System Menu can be displayed by simply pressing the tab of the menu item to be displayed. Example: Press the Hardware Check Tab in the System Menu to display the Hardware Check Screen.
Page 184: Initializing And Saving Data And Removing The Memory Card
6-2 Initializing and Saving Data and Removing the Memory Card 6-2 Initializing and Saving Data and Removing the Memory Card The Initialize Tab is used to initialize or save the PT data and specify the system language. Used these function whenever necessary. • Memory Card (remove) •...
Page 185: Screen Data Area Format
6-2-1 Screen Data Area Format This function formats the PT screen data. Screen data must be formatted if it is corrupted and cannot start up properly. The data recorded for the operation log, alarm history, data log, and error log is not initialized when screen data is formatted.
Page 186: Initializing Or Saving The Alarm/Event History
An error message will be displayed if the System Menu is closed while screen data is being for- matted. Always transfer the screen data from the CX-Designer or Memory Card after formatting.
Page 187 Saving Alarm/Event Histories 1. Press the Save Button. The Save Button will be lit yellow while data is being saved. 2. When the PT has completed saving the alarm/event histories, the Save Button will return to its normal color.
Page 188: Initializing And Saving Data Log
Use this function when screen data has been changed, or for initializing history data. The data log is used to record changes over time to the contents of an address that is registered in the log. Up to 50,000 events can be recorded.
Page 189: Initializing And Saving The Operation Log
• For details on how to execute Multifunction Objects that have the operation log data initialization function set, refer to the NS-series PT Programming Manual. Initialize or save the operation log by using operations from the Initialize Tab Page in the Sys- tem Menu, as follows:...
Page 190 Saving the Operation Log 1. Press the Save Button. The Save Button will be lit yellow while data is being saved. 2. When the PT has completed saving the operation log, the Save Button will return to its normal color.
Page 191: Initializing And Saving The Error Log
This function initializes the macro error history saved in the PT or saves the history in the Memory Card. Up to 100 errors can be recorded in the error log. The number of errors that can be recorded, however, also depends on the free space in the memory.
Page 192: Language Selection
Chinese (traditional or simplified). The system language will be used on the System Menu, input keypads, message dialog boxes, etc, on the PT. The system language is set from the Initialize Tab Page in the System Menu Window using the following procedure.
Page 193: Removing The Memory Card
6-2-7 Removing the Memory Card The Memory Card can be removed from the PT while the PT is ON. Use the following proce- dure from the Initialize Tab Page of the System Menu to remove the Memory Card. 1. Press the Remove Button next to Memory Card.
Page 194: Initializing Internal Holding Memories ($Hb/$Hw)
Press the OK Button. Reference The NS-series PT’s internal holding memory ($HB/$HW) can be initialized by turning ON the system memory bit $SB34 from the host. Refer to 2-4 System Memory in the NS Series Programming Manual for details. 6-20...
Page 195: Pt Settings
6-3-14 Starting the Ladder Monitor from Alarm/Event Summary and History (NS15/12/10/8 Only) 6-3-15 Setting the Tag Update Notification Message 6-3-16 Time to Switch to System Menu (NS12, NS10, NS8, or NS5) 6-3-17 Double-touch Interval (NS15 Only) 6-3-18 Analog RGB Output (NS15 only)
Page 196 6-3 PT Settings PT Tab Page for the NS10 and NS8 (Page 1) (Page 2) (Page 3) (Page 4) PT Tab Page for the NS5 (Page 1) (Page 2) 6-22...
Page 197: Start-Up Wait Time
The start-up wait time refers to the waiting time before the PT starts communicating with the host after the PT power is turned ON or the PT is reset Set the system startup waiting time when the host requires time before it starts running.
Page 198: Screen Saver
• The system startup waiting time is calculated from when initialization finishes. Therefore, if the startup waiting time is set to 0 s, the PT will not start actual communi- cations with the host immediately after the power is turned ON.
Page 199: Key Press Sound
6-3-4 Buzzer Sound The buzzer is used at times such as when a command from the host is received or an error occurs. This function is set to ON or OFF in the System Menu. Buzzer turns ON when a command is received from the host or an error occurs.
Page 200: Backlight Brightness
Backlight Brightness NS15 The brightness of the backlight can be set to any of three levels or to an external adjustment. The default setting is for High. Perform the following procedure from the PT Operation Tab Page of the System Menu to set the brightness of the backlight.
Page 201: Calendar Check
Menu, as follows: 1. The currently set date and time will be displayed in the Date and Time Setting field. 2. To change the date/time, set the date/time in the dialog box that is displayed by pressing the date and time field.
Page 202: Printer Type
• The print control method is set to PictBridge and cannot be changed for the NS5- @Q1@, NSJ5-@Q1@, NSH5-SQ@10. 6-3-8 Printing Mode If the printer control method is set to ESC/P raster or BJ raster, select the printing method of the printer that will be connected to the NS-series PT. Setting item Details Color Print Prints in color.
Page 203: Orientation
2. After setting, press the Write Button to save the setting. 6-3-9 Orientation If the printer control method is set to ESC/P raster or BJ raster, select the printing orientation of the printer that will be connected to the NS-series PT. 1. Select either Portrait or Landscape in Orientation.
Page 204: Cjk Han Unification Priority
6-3 PT Settings 1. Change the contrast setting using the left and right arrow buttons (<<, <, >, >>) for contrast ad- justment. The contrast will change as soon as the buttons are pressed. << Button: Decreases the contrast by ten degrees.
Page 205: Setting The Tag Update Notification Message
With a NS12, NS10, NS8, or NS5 PT, the time required to switch to the System Menu when two of the four screen corners are pressed can be set. A longer time can be set to help pre- vent unintentional access to the System Menu.
Page 206: Double-Touch Interval (Ns15 Only)
6-3-17 Double-touch Interval (NS15 Only) With the NS15, one corner of the screen must be touched twice in a row to move to the Sys- tem Menu. The interval between the touches is called the double-touch interval and it can be set to between 500 and 1,500 ms.
Page 207: Project Settings
6-4 Project Settings 6-4 Project Settings The Project Tab Page is used to display and set the following functions. • Project title • Number of labels • Initial screen • Initial label • Alarm/event history recording method: Method for recording log of generated and deleted alarms/events.
Page 208: Number Of Labels
Display and set the initial screen number by using operations from the Project Tab Page in the System Menu, as follows: 1. The number of the screen that is displayed when the PT is started is displayed in the initial screen field.
Page 209: Operation Log Recording Method
If the log is not saved in ring buffer format, the PT stops collecting log data when the speci- fied number of items has been reached. Initialize the operation log to reopen the record.
Page 210: Setting Passwords
Operations cannot be performed on functional objects protected with higher-level passwords. The passwords are set from the CX-Designer and up to five passwords (5 levels) can be set for a single project. The passwords can be set and changed from the System Menu.
Page 211: Setting The Password Function
Setting the Password Function Perform the following procedure from the System Menu to set a password. 1. Select the Password Tab. Press the Password mode Button. After making the required settings, press the Write Button to save the settings. 6-37...
Page 212 Reference The password settings can also be made from the CX-Designer. • When changing passwords, do not reset the PT or turn OFF the power until Precautions for Safe Use the write operation has been completed (i.e., the Write Button has returned to the status before being pressed).
Page 213: Communications Settings
Set the time before a timeout error occurs when a response is not received from the host. The timeout interval can be set to between 1 and 10 (unit: s). Input the value by using the tenkey or the Up ( ) and Down ( ) buttons that are displayed by pressing the display area.
Page 214 Supported Communications Method Combinations It is not possible to connect to a PLC via NT Link (1:N) with both serial ports A and B at the same time. It is not possible to use a Bar Code Reader with both serial ports A and B at the same time.
Page 215: Setting 1:1 Nt Link
6-6-2 Setting 1:1 NT Link Select the Comm. Tab from the System Menu, and select NT Link 1:1 (1:1 NT Link) as the communications method for serial port A or B. After setting, press the Write Button to save the setting.
Page 216: Setting High-Speed 1:N Nt Links (Standard, High-Speed)
6-6-3 Setting High-speed 1:N NT Links (Standard, High-speed) Select the Comm. Tab from the System Menu, and select NT Link 1:N (1:N NT Link) as the communications method for serial port A or B. Press the Detail Button to display the setting items for high-speed 1:N NT Links on the right side of the screen.
Page 217 This setting is used to display detailed data for hosts connected using Ethernet or Controller Link. The host type, network address, and node address for each host can also be changed. 3. Press the ETN/CLK Host Display Button. The registered hosts will be displayed in a list.
Page 218 Node address Set the node address of the host. 1 to 254 • Using EtherNet/IP The IP address of the selected host can be changed. The host type and route path are dis- played only. They cannot be changed. 6-44...
Page 219: Setting The Controller Link Network
6-6-5 Setting the Controller Link Network If using a Controller Link Network is enabled for the project, settings for the network will be displayed on the right side of window. Set the node address and baud rate (Comm. Speed). Click the Write Button after setting these items. The Controller Link is supported by the NS15, NS12, and NS10 PTs only, and is not supported by the NS8 PTs.
Page 220: Setting Bar Code Readers
Displays address where status is read (display only). Add. Note: Using the Controller Link network and the network number cannot be changed at the PT. If you change the setting, display the communications settings in the CX-Designer by selecting PT –...
Page 221: Modem Settings
Reference details on modem types and connections. • The modem can be connected to either Serial Port A or Serial Port B, but not to both at the same time. Set the communications conditions for the modem from the System Menu using the following procedure.
Page 222: Screen Data Check
At this point you can also switch between displaying or not displaying the host name by setting Show Host Name to ON or OFF. 4. Press any part of the sample screen that is displayed to return to the Screen Data Check Screen. Reference Addresses are not displayed for data block tables.
Page 223: Special Screens
Transfers screen data and the system program on the PT to a Memory Card Card. Reads the results of a data trace executed in the PLC and displays the PLC Data Trace results in a time chart. The data trace parameters can also be set.
Page 224: Alarm History
6-8 Special Screens 6-8-1 Alarm History This function displays the alarm history. The alarm history can be displayed in order of occur- rence or frequency. Display alarm history data by using operations from the Special Screen Tab Page in the Sys- tem Menu, as follows: 1.
Page 225: Operation Log
2. With the NS10, NS8, or NS5, press the Switch Item Button to change the items that are dis- played. 3. Press the Save Log Button. The operation log data will be saved to the Memory Card as a CSV file.
Page 226: Error Log
Display error log data by using operations from the Special Screen Tab Page in the System Menu, as follows: 1. Press the Error Log (Sort by Occurrence) Button or Error Log (Sort by Frequency) Button to display the error log contents.
Page 227: Device Monitor
6-8 Special Screens 6-8-4 Device Monitor The device monitor is an expansion function of the PT. This function is supported by CPM1A, CPM2A, CPM2C, CQM1, CQM1H, C200HS, C200HX/HG/HE(-Z), CS1G/CS1H, CS1D, CS1G/CS1H-H, CJ1G, CJ1M, and CJ2H PLCs. The device monitor has the following functions.
Page 228 The Device Monitor Screen is displayed by using operations from the Special Screen Tab Page from the System Menu, as follows: 1. Select Device Monitor from the Special Functions List Box, and press the START Button. 2. The Device Monitor Screen will be displayed.
Page 229: Communication Test
Display the Communication Test Screen by using operations from the Special Screen Tab Page in the System Menu, as follows: 1. Select Communication Test from the Special Functions List Box, and press the START Button. 2. Press the Communication Test Button to switch to the Communications Test Screen.
Page 230 Note 1. SID is the source process ID. 2. The FINS header is the header that precedes the FINS command. Refer to the FINS Com- mand Reference Manual (Cat. No. W227) for details on FINS commands.
Page 231: Video Configuration
6-8-6 Video Configuration A Video Input Unit can be mounted to the PT to display images by connecting video devices. The user can adjust the image and output signals to a Vision Sensor from this window. This section describes only the procedure for opening the window. For details, refer to 2-20- 10 Video Configuration in the NS Series Programming Manual.
Page 232 6-8 Special Screens the Special Screen Tab as shown below. 1. Select Video Configuration from the list under Special Function, and click the Start but- ton. The Video Configuration Window will be displayed. 2. Press the Back Button to return to the Special Window.
Page 233: Usb Device List
2. The USB Device List Window will be displayed. A list of USB devices currently connected and a list of USB devices supported by the NS Series are displayed. Press the Update Button to reconfirm the connected USB devices and refresh the display.
Page 234: Display Capture Data
6-8-8 Display Capture Data Video capture data and screen capture data stored in a Memory Card can be displayed. Perform the following procedure under Special Screen Tab on the System Menu. 1. Select Display Capture Data from the Special Function List Box and press the START Button.
Page 235: Memory Card Transfers
DIP switch on the PT. The Memory Card can be used to transfer data in the following situations. • To transfer data to or from a Memory Card already inserted to save or read data such as data logs and captured data.
Page 236 Transferring Memory Card Data Use the following procedure from the Special Screen Tab Page of the System Menu to trans- fer data to Memory Card. Press the EXIT Button at the top left of the Memory Card Transfer screen to reset the PT.
Page 237: External Application Startup
6-8 Special Screens 9. If you want to continue using the Memory Card, press the Reset Button to reset the PT. If you remove or replace the Memory Card, press the Reset Button immediately after removal or replacement to reset the PT.
Page 238: Version Display
CPU Unit’s Trace Memory. The PT reads the data stored in the PLC and displays that data on the screen as a time chart. The PLC Data Trace function can be used in the NS15, NS12, NS10, and NS8 PTs only.
Page 239 CPU Unit Stored data trace results This section only explains how to open the PLC Data Trace Screen. Refer to 2-20 Special Functions in the NS Series Programming Manual for details on the specifications and opera- tion of the data trace function.
Page 240: Hardware Check
LCD Check This function checks whether the LCD (screen display) is operating normally. Check the LCD by using operations from the Hardware Check Tab Page in the System Menu, as follows: 1. Press the LCD Check Button to switch to the LCD Check Screen.
Page 241: Touch Switch Check
Menu, as follows: 1. Press the Touch Switch Check Button to switch to the Touch Switch Check Screen. 2. Press the screen. If the part of the screen touched is shown in inverse display, the touch switch is operating normally.
Page 242: Starting Operations
Switching to RUN Mode and Starting Up Pressing the Exit Button at the top right of the screen in the System Menu will display the screen that was displayed before moving to the System Menu, change the status to RUN mode, and start running the PT.
Page 243 6-10 Starting Operations Communications Not Established with Host Use the following procedure to check communications if the PT and host are not communi- cating normally. Check the cable models and cable pins. Check cables Refer to Appendix 5 Preparing Connecting Cables.
Page 244: Verifying Tags
6-11 Verifying Tags 6-11 Verifying Tags If tags are used by projects in the NS-series PT, verification will be perform to check whether the tag settings match the host tag settings (i.e., network variables). Tags will be verified in the following cases.
Page 245 4. Check the differences, and then revise the settings for the project data or the tag. 5. To revise the settings of the host tag, click the Recompare Button to verify the tags again. 6. Click the System Menu Button to move to the System Menu. You can check the commu- nications settings for the host and transfer memory card data.
Page 246 6-11 Verifying Tags 6-72...
Page 247: Maintenance And Troubleshooting
Section 7 Maintenance and Troubleshooting This section describes the maintenance and inspection methods for preventing errors occurring, and troubleshooting measures when errors occur in the PT. 7-1 Maintenance ........................7-2 7-1-1 Replacing the Battery ....................7-2 7-2 Inspection and Cleaning ....................7-4 7-3 Troubleshooting and Maintenance ..................
Page 248: Maintenance
Unit. Spare Units Prepare a spare PT to allow quick recovery of the system at such times as when the PT mal- functions, or the service life of the backlight has expired causing poor screen visibility.
Page 249 The shape of the battery cover and the direction for installing the connector depend on the PT model. 1. After power to the PT has been turned ON and at least five minutes have lapsed, turn OFF the power. 2. Open the battery cover on the rear panel of the PT.
Page 250: Inspection And Cleaning
(approximately 2%), squeeze the cloth out, and then wipe the sur- face. • Materials such as rubber, vinyl, or tape that are attached to the Unit will leave stains if left for a long time. If such material is attached to the Unit, remove when cleaning.
Page 251 7-2 Inspection and Cleaning • Inspection Items Inspect the PT for the following items to check whether the PT is operating within the speci- fied criteria. If the PT is outside the criteria, use measures such as improving the operating environment to conform to the standards, or tightening screws.
Page 252: Troubleshooting And Maintenance
7-3 Troubleshooting and Maintenance 7-3 Troubleshooting and Maintenance When an error occurs while operating the PT, search for the symptom in the following table and take measures according to those provided. Errors during Data Transfer Symptoms at Cause Possible countermeasure...
Page 253 In the following Download the project data again. When downloading the cases, project data project data again, be sure to clear the log data saved in the was downloaded without clearing the log data saved in the NS.
Page 254 PT may be faulty. Contact your nearest OMRON representative. An attempt may have been made to transfer screens that are larger than the memory of the PT. Check the screen data at the transfer destination. The indicator The PT is faulty, Reinstall the system program.
Page 255 Memory Card transfer program, insert the Memory Card containing the recovery program in the PT and reset the PT or turn the power supply OFF and ON again. (Refer to 3-6 Using Memory Cards in the Setup Manual.) If the same prob-...
Page 256 PT do the screen.) not match. The PT is not con- Check that the type, length, and wiring of the connecting nected to the host cables meet the specifications. properly. (Refer to Section 4 Connecting the Host to Serial Port.) For 1:N NT Link con- Reset so that each Unit has a unique unit number.
Page 257 The screen saver This is not an error. Touch the screen, or operate the sys- function is operat- tem memory for switching the screen from the host to ing. switch the screen as follows: •...
Page 258 The touch panel is Test the touch panel using the hardware check in the Sys- damaged. tem Menu. If an error has occurred, contact your nearest OMRON representative. The display is The brightness set- Increase the backlight brightness in the PT Tab Page of the dark.
Page 259 Check the communications settings again. in the screen error has occurred. configuration The control flags Display the control flags for the objects set to be not dis- are not dis- set in the object played, as follows: played. include Hide Dis- Display the Expansion Tab from the functional object prop- play Flags.
Page 260: Requesting A Replacement Pt
• After replacing the PT, check to confirm that the new PT has no faults. • When returning a faulty PT for repair, include a document with the Unit that provides as many details on the fault as possible, and send to your OMRON representative.
Page 261: Appendices
A-5-4 Preparing Connecting Cables for Host Connection..........A-37 Appendix 6 Preparing Cables for Computer Connection ............ A-41 A-6-1 Connecting Cable Assembly ................. A-41 Appendix 7 Preparing Connecting Cables for Bar Code Readers........A-43 Appendix 8 Standard Models ....................A-44 Appendix 9 List of Optional Products................. A-59 A-9-1 Anti-reflection Sheets: NS15-KBA04, NS12-KBA04, NS7-KBA04, NT30-KBA04......................
Page 262 A-9-7 NS-CA001/CA002 Video Input Unit ..............A-62 A-9-8 Attachments: NS12-ATT01(B)/NS12-ATT02/NS8-ATT01/ NS8-ATT02 ..A-62 A-9-9 NS-USBEXT-1M USB Relay Cable..............A-63 Appendix 10 System Memory List..................A-64 Appendix 11 Differences between "-V1"/"-V2" Models and Other Models......A-67 Appendix 12 NS5 System Menu ................... A-69...
Page 263: Appendix 1 Specifications
The SRAM and RTC will be backed up for 5 days after the battery runs low (indicator lights orange). The SRAM and RTC will be backed up by a super capacitor for 5 minutes after removing the old bat- tery (i.e., after turning ON power after 5 minutes).
Page 264 3. When a STN LCD display device is used (NS5-SQ@-V1/-V2 or NS5-MQ@-V2), the dis- play quality will decline (e.g., the contrast ratio will be reduced) if the temperature exceeds 40°C. Also, when the temperature drops, the response speed is lowered due to character- istics of liquid crystals.
Page 265: A-1-2 Characteristics
800 dot hori- × 768 dot vertical zontal × 600 dots dot vertical Display color 256 colors (32,768 colors for BMP/JPEG images, NS5: 4,096 colors for BMP/JPEG images) Width 304.1 mm × Width 170.9 mm × Display area Width 246.0 Width 215.2 Width 162.2...
Page 266 4. Contact your nearest OMRON representative to replace the backlight. There may be some defective pixels in the display. This is not a fault as long as the num- bers of defective light and dark pixels fall within the following standard ranges.
Page 267: Appendix 1 Specifications
LCD monitor) External bright- Used to adjust ness adjustment brightness externally Note: This interface is for NS-series PTs only. Units not specified in this manual cannot be installed. Programming Device (Software for Creating Screen Data) Item Specifications Name...
Page 268: A-1-3 Communications Specifications
Conforms to EIA RS-422/RS-485 (insulated) (NS15 only) 7-pin connector Note 1: The 5-V output of serial ports A and B cannot be used at the same time. Note 2: With the NS5, the Expansion Interface on the Comm Tab Page in the System Menu set- tings can be set to use a communications port in the expansion interface connector.
Page 269 Item Specifications Conformance standards Conforms to IEEE 802.3 / Ethernet (10/100Base-T). Transmission medium 2 pair Cat 3 UTP 22 to 26AWG, Cat 5, Cat 5e, Cat 6 Transmission distance 100 m (node-to-hub and hub-to-hub) Connector 8-pin modular connector • Ethernet...
Page 270 • Watchdog timer • Error log Error correction Manchester code check CRC check (CCITT X Note: A Controller Link Interface Unit can be used only for the NS15, NS12, and NS10 NS- series PTs. • Video Input Specifications Item Specifications...
Page 271 Conforms to NS-series PT specifications. Shock resistance Conforms to NS-series PT specifications. Note: You can still use 5 V from either port A or port B on the NS-series PT after you mount a Video Unit on the PT. A-11...
Page 272: Appendix 2 Dimensions
Appendix 2 Dimensions Appendix 2 Dimensions ● NS15 (Includes Mounting Dimensions) Mounting panel Mounting bracket Note: The NS15 conforms to version-2 hardware standards. With Controller Link Interface Unit Mounted With Video Input Unit Mounted Mounting panel Mounting panel Mounting bracket Mounting bracket...
Page 273 Appendix 2 Dimensions NS15 Cable Connection Dimensions NS15 Video Board (NS-CA001) Mounted Dimensions NS15 Controller Link Interface Unit Mounted Dimensions A-13...
Page 274 With Controller Link Interface Unit Mounted With Video Input Unit Mounted M o u n tin g p a n e l M o u n tin g p a n e l M o u n tin g b ra cke t M o u n tin g b ra cke t 3 9 (m in .)
Page 275 Appendix 2 Dimensions NS12-V1/-V2, NS10-V1/-V2 Cable Connection Dimensions NS12-V1/-V2 and NS10-V1/-V2 Video Board (NS-CA001) Mounted Dimensions NS12-V1/-V2 and NS10-V1/-V2 Video Board (NS-CA002) Mounted Dimensions A-15...
Page 276 Appendix 2 Dimensions NS12-V1/-V2 and NS10-V1/-V2 Controller Link Interface Unit Mounted Dimensions NS12/NS10 (without "V1") Cable Connection Dimensions 90.2 69.5 A-16...
Page 277 Appendix 2 Dimensions NS8-V1/NS8-V2 Main Unit Dimensions (Mounted) Mounting panel Mounting bracket 15.5 39 min. 42 max. (Unit: mm) A-17...
Page 278 Appendix 2 Dimensions NS8-V1/ NS8-V2 Cable Connection Dimensions 43.2 26.6 50.1 44.1 63.4 NS8-V1/-V2 Video Board (NS-CA001) Mounted Dimensions 68.3 45.3 27.3 NS8-V1/-V2 Video Board (NS-CA002) Mounted Dimensions 59.4 19.6 23.9 1.57 A-18...
Page 279 Appendix 2 Dimensions NS7 Cable Connection Dimensions 43.2 26.6 50.1 44.1 63.4 NS5-V1/-V2 Dimensions (Includes Mounting Dimensions) Mounting panel Mounting bracket A-19...
Page 280 Appendix 2 Dimensions NS5-V1/-V2 Cable Connection Dimensions A-20...
Page 281: Appendix 3 Using Ns-Al002 Converters
B of the PT, and converts RS-232C communications to RS-422A/RS-485. Any of the Con- verters listed in Appendix 9 Standard Models can be used. A summary of the NS-AL002 external dimensions, mounting and removal methods, and specifications is provided here.
Page 282: A-3-2 Mounting And Removing
Insulation No insulation (See note 2.) Note 1: This specification is for a configuration in which all the Adapters connected on the same transmission path are NT-AL002 Link Adapters. If a CJ1W-CIF11 Conversion Adapter is used, the total length is 50 m.
Page 283: A-3-4 Dip Switch Settings
• If NT-001/NT-002 Link Adapters are used together with CJ1W-CIF11 Conversion Adapt- ers on the same transmission path, the total transmission length is also 50 m. • For details, refer to the Appendix G in the SYSMAC CJ Series Operation Manual (Cat. No. W393).
Page 284: A-3-5 Pin Arrangement
Appendix 3 Using NS-AL002 Converters A-3-5 Pin Arrangement The Adapter has a connector for RS-232C interface connection and a terminal block for RS-422A/485 interface connection. The pin arrangements for the RS-232C connector and RS-422A/485 terminal block are as follows: RS-232C Connector...
Page 285: A-3-6 Handling The Shield On Rs-422A/485 Cables
• Connect the ground terminal (GR) of the devices to the functional ground (FG: Make sure that each signal line is grounded at only one point and ground to 100 Ω max. • Short the LG terminal of the PLC to the ground terminal (GR).
Page 286 Always prepare RS-422A/485 cable shields properly. Otherwise, communications errors may occur with the host. Ground only one end of the shield when connecting the ground terminal (GR) of the de- vices to the functional ground (FG: ), and grounding each signal line at only one point and to 100 Ω...
Page 287 Appendix 3 Using NS-AL002 Converters Example of Recommended Wiring Figure (a) Figure (b) CPU Rack CPU Rack Power CPU Unit or CPU Unit or Power Communi- supply Communi- supply cations Unit Unit cations Unit Unit RS-422A/485 RS-422A/485 NS-AL002 NS-AL002 Signal line...
Page 288: A-3-7 Connection Example
Appendix 3 Using NS-AL002 Converters A-3-7 Connection Example An example of connecting a PLC and a PT using an RS-232C/RS-422A Converter is shown below. Use the wiring example as reference for correct wiring. PT (unit No. 0) CPU Rack PT (unit No. 1)
Page 289: Appendix 4 Using Nt-Al001 Converters
Mounting to a DIN Rail Latch the top part of the rear face of the converter unit (a in the figure) onto the top edge of the DIN rail, and push the unit in the direction indicated by b in the figure.
Page 290 Removal from a DIN Rail Remove the end plates at right and left of the converter unit and, as shown in the figure below, insert a flat blade screwdriver into the rail stopper at the bottom face of the con- verter unit and prize it free.
Page 291: A-4-3 Specifications
−20 to 75°C Storage ambient temperature Vibration resistance Conforms to JIS C0911 60 minutes in each of X, Y, and Z directions Shock resistance Conforms to JIS C0912 147 m/s , 3 times in each of X, Y, and Z directions...
Page 292: A-4-4 Dip Switch Settings
Before connecting the cable to the converter unit, make the DIP switch settings. When using the host link or 1:1 NT Link, set the RS-422A send mode to continual send- ing (set both SW1-5 and 6 OFF). When using the 1:N NT Link (standard or high-speed), set the RS-422A send mode to comply with CS control of RS-232C (i.e., one of SW1-5 and SW1-6 must be ON).
Page 293: A-4-5 Pin Arrangement
Appendix 4 Using NT-AL001 Converters A-4-5 Pin Arrangement The converter unit has a terminal block for an RS-422A/485 interface connection and a connector for an RS-232C interface connection. The pin arrangements for the RS-422A/485 terminal block and the RS-232C connector are as follows.
Page 294: A-4-6 Block Diagram
Appendix 4 Using NT-AL001 Converters A-4-6 Block Diagram A diagram showing the internal blocks of the converter unit is shown below. Refer to this diagram when making cables yourself, or when connecting devices with special interfaces. A-34...
Page 295: Appendix 5 Preparing Connecting Cables
3. Cut the shield using scissors. 4. Strip back to the core of each wire using a stripper. 5. Bend back the shields. 6. Wrap the section of the shields that is bent back with aluminum foil tape. (Unit: mm) Aluminum foil tape...
Page 296: A-5-2 Soldering
3. Solder each of the wires to the connector terminals. Soldering iron Heat-shrinking tube Internal diameter: 1.5 Length = 10 4. Replace the heat-shrinking tube up to the soldered section, and shrink the tube onto the wire by applying heat using a soldering gun. Heat-shrinking tube A-5-3 Hood Assembly Assemble the hood as shown in the following diagram.
Page 297: A-5-4 Preparing Connecting Cables For Host Connection
Wiring Layout between NS-AL002 and Host (RS-422A) Host NS-AL002 RS-422A cable When connecting individual signals with twisted-pair cable, connect RDA and RDB, and SDA and SDB, as pairs in the twisted-pair cable. A communications error may occur if the pairs are not combined correctly. A-37...
Page 298 PLC or PT Pin No. Signal Signal Pin No. Shield Hood +5 V +5 V 9 - pin type 9-pin type When connected to a PLC with a +5-V output, an external power supply is not required for the NT-AL001. A-38...
Page 299 CS1G-CPU45(-V1), CS1H-CPU63(-V1), CS1H-CPU64(-V1), CS1H-CPU65(-V1), CS1H-CPU66(-V1), CS1H-CPU67(-V1), C200HE-CPU32(-Z), C200HE-CPU42(-Z), C200HG-CPU33(-Z), C200HG-CPU43(-Z), C200HG-CPU53(-Z), C200HG-CPU63(-Z), C200HX-CPU34(-Z), C200HX-CPU44(-Z), C200HX-CPU54(-Z), C200HX-CPU64(-Z), C200HX-CPU65-Z, C200HX-CPU85-Z, CQM1H-CPU51, CQM1H-CPU61, CV500-LK201(COM port 2) For details on processing shielded cable, refer to A-3-6 Handling the Shield on RS- 422A/485 Cables. A-39...
Page 300 Applicable Units: CV500-CPU01-V1, CV1000-CPU01-V1, CV2000-CPU01-V1, CVM1-CPU01-V@, CVM1-CPU11-V@, CVM1-CPU21-V@ CVM1/CV Series CPU Units without the -V@ suffix cannot be connected by any commu- nications method. For details on processing shielded cable, refer to A-3-6 Handling the Shield on RS- 422A/485 Cables.
Page 301: Appendix 6 Preparing Cables For Computer Connection
Preparing Cables for Computer Connection Refer to the following information when preparing the CX-Designer connecting cables. A-6-1 Connecting Cable Assembly Wire the RS-232C connector to the DOS or 98-NX computer according to the type, as follows: • 25-pin Connector Computer PT serial port...
Page 302 Cable Multiconductor shielded cable Manufactured by Fujikura Densen. CO-MA-VV-SB 5P × 28AWG Multiconductor shielded cable Manufactured by Hitachi Densen. Note: Use a connector hood for the computer that conforms to the standards for the screws of the computer connector. A-42...
Page 303: Appendix 7 Preparing Connecting Cables For Bar Code Readers
When connecting to the 5-V output of the PT’s serial port, use a cable length of less than 2 m. If the cable is 2 m or longer, connect pins 7 and 8 of the Bar Code Reader to an ex- ternal power supply.
Page 304: Appendix 8 Standard Models
Appendix 8 Standard Models Appendix 8 Standard Models Programmable Terminals (PTs) Case Model Ethernet Type Size Color Number of dots Color 1024 × 768 NS15-TX01S-V2 15.0 inch Color 10/100Base-T Silver 800 × 600 NS12-TS01-V1 12.1 inch Color 10/100Base-T Ivory 800 × 600 NS12-TS01B-V1 12.1 inch...
Page 305 Appendix 8 Standard Models Case Model Ethernet Type Size Color Number of dots Color 320 × 240 NS5-SQ01-V1 5.7 inch Color 10/100Base-T Ivory (See note 2.) 320 × 240 NS5-SQ01B-V1 5.7 inch Color 10/100Base-T Black (See note 2.) 320 × 240 NS5-SQ00-V1 5.7 inch...
Page 306 Note 1. The capacity of the NS8-TV00/TV01(B)-V1 is 6 Mbytes and the capacity of the NS8- TV10/TV11(B)-V1 is 20 Mbytes. 2. The capacity of the NS5-SQ00/SQ01-V1 is 6 Mbytes and the capacity of the NS5-V2 is 20 Mbytes. 3. The capacity of the NS15-TX01@-V2, NS12-V2, NS10-V2, NS8-V2, NS5-SQ1@-V2, NS5- TQ1@-V2, and NS5-MQ1@-V2 is 60 MB.
Page 307 A CS1W-CN118 Conversion Cable or XW2Z-200T-2 Cable with connector must be used for the connection. • CS-series CPU Units cannot connect to 1:1 NT Links, but a 1:1 connection can be Reference made using 1:N NT Links (normal or high-speed). Refer to 4-2 1:N Host Connec- tion and 4-3 High-speed 1:N NT Link for details.
Page 308 Note 1. A C200HW-COM03-V1 or C200HW-COM06-V1 Communications Board is required. 2. A CQM1H-SCB41 Serial Communications Board is required. 3. Connection is not possible to CVM1/CV-series PLC CPU Units without "-V1" in the model number. • NS-series RS-485 (two-wire) communications are used to connect to an OMRON Reference Temperature Controller.
Page 309 Appendix 8 Standard Models CPU Units That Connect in 1:N NT Links via RS-232C to PT Serial Ports PLC Series Connecting with built-in ports Connecting via optional Communications Boards CS Series CS1G-CPU42(-V1) Same as at left (See note 1). CS1G-CPU43(-V1)
Page 310 • NS-series RS-485 (two-wire) communications are used to connect to an OMRON Reference Temperature Controller. The NS-AL002 cannot be used with the NT-series PTs or PLCs. Connect using RS-422A (4-wire). CPU Units That Connect in 1:N NT Links via RS-442A to PT Serial Ports PLC Series Unit Serial Communications Board or...
Page 311 Board CQM1H-CPU51 CQM1H-CPU61 • Both the normal 1:N NT Links and high-speed NT Links are supported for CS- Reference series PLC CPU Units with "-V1" in the model number. If the most recent Serial Communications Unit or Board is used, these connections are also supported by CPU Units without "-V1."...
Page 312 CP1E-N@@@@-@ CP1L-@@@@-@ (See note 4.) CP1H-@@@@-@ (See note 4.) Note 1. CS-series PLC CPU Units without "-V1" in the model number do not support high-speed NT Links. 2. A CS1W-SCB21/SCB41 Serial Communications Board or a CS1W-SCU21 Serial Com- munications Unit is required.
Page 313 Appendix 8 Standard Models CPU Units That Connect in 1:N NT Links via RS-442A to PT Serial Ports PLC Series Unit Serial Communications Board or Unit required for connection CS Series CS1G-CPU42(-V1) CS1W-SCB41 Serial Communica- CS1G-CPU43(-V1) tions Board CS1G-CPU44(-V1) CS1G-CPU45(-V1)
Page 314 CJ2H-CPU65-EIP (See note 1.) CJ2H-CPU66-EIP (See note 1.) CJ2H-CPU67-EIP (See note 1.) CJ2H-CPU68-EIP (See note 1.) CP Series Mount a CP1W-CIF41 Ethernet Op- CP1L-@@@@@-@ tion Board (10Base-T/100Base-T). CP1H-@@@@@-@ Note 1. The CJ2H-CPU@@-EIP CPU Unit has a built-in Ethernet connector. A-54...
Page 315 C200HW-CE001/CE002/CE012 Bus Connection Unit 2. Always set routing tables when using a CVM1/CV-series CPU Unit manufactured in April 1996 or earlier. The manufacturing date can be checked with the 4-digit lot number given on the side of the CPU Unit, as shown below.
Page 316 NS-CXDC1-V@ The CX-Designer contains a transfer program and stan- dard system program for NS-series PTs. • NEC PC98-series computers are not supported. Reference • Use the NEC PC98NX Series, however, in the same way as IBM PC/AT compatible computers. A-56...
Page 317 XW2Z-S002 DOS and 98NX computers Female 9-pin-to-male 9-pin Ethernet Cable (PT-to-Personal Computer) Particular models are not specified, but use a cable that meets the following specifications. Item Specifications Conformance standards Conforms to IEEE 802.3 / Ethernet (10/100Base-T). Transmission medium...
Page 318 Appendix 8 Standard Models Controller Link Communications Cable Use one of the twisted-pair cables listed below as the communications cable. Model Manufacturer Remarks Li2Y-FCY2x0.56qmm KROMBERG & SHUBERT, Department German company KOMTEC 1x2xAWG-20PE+Tr. DRAKA CABLES INDUSTRIAL Spanish company CUSN+PVC #9207 BELDEN American company ESVC0.5x2C...
Page 319: Appendix 9 List Of Optional Products
Appendix 9 List of Optional Products Appendix 9 List of Optional Products A-9-1 Anti-reflection Sheets: NS15-KBA04, NS12-KBA04, NS7-KBA04, NT30-KBA04 Attached to the display to prevent random reflection and dirt. The sheets are all colorless and transparent. One set contains five sheets. Dimensions Model Material...
Page 320: Appendix 9 List Of Optional Products
Appendix 9 List of Optional Products A-9-2 Protective Covers: NS12-KBA05(N), NS7-KBA05(N), NT31C-KBA05(N) This cover protects the display surface from oil, dust, and finger marks. One set contains five covers. Dimensions With Cover Mounted Note: Do not lift the product by grasping the shaded areas.
Page 321: Nt30-Kba04
Appendix 9 List of Optional Products A-9-3 NT30-KBA01 Chemical-resistant Cover This Cover on the front panel protects the Unit from chemicals. The whole sheet is opaque white and made from silicon rubber. Dimensions Model Specifications Dimensions (Unit: mm) NT30-KBA01 Chemical-resistant Cover for the -V1/-V2 196.4...
Page 322: A-9-5 Recommended Memory Cards
A-9-5 Recommended Memory Cards The Memory Card is an external memory that can save and read screen data, log data, and system programs between the PT and computer. By using the HMC-AP001, this data can be exchanged with computers that are connected to PC Cards.
Page 323: A-9-9 Ns-Usbext-1M Usb Relay Cable
Appendix 9 List of Optional Products A-9-9 NS-USBEXT-1M USB Relay Cable A NS-USBEXT-1M USB Relay Cable can be used to extend the USB slave connector on the back of the PT and place it on the front of the control panel. Model...
Page 324: Appendix 10 System Memory List
System bit memory ($SB) is used for exchanging information between the host and the PT in bit units, such as controlling the PT and notifying the host of PT status. The system bit memory contains 64 bits with predefined functions.
Page 325 System word memory ($SW) is used for exchanging information between the host and the PT in word units, such as controlling the PT and notifying the host of PT status. The system word memory contains 41 items with predefined functions.
Page 326 $SW40 Notification/control Range of initialize Alarm/Event History The notification words are not write prohibited. In addition, the system will not restore values, except when the status has changed. System word memory is allocated to PLC memory as shown below. Allocated Addresses for System Memory can be displayed by selecting PT – System Settings in the CX-Designer and clicking the Initial Tab.
Page 327: Appendix 11 Differences Between "-V1"/"-V2" Models And Other Models
Appendix 11 Differences between "-V1"/"-V2" Models and Other Models Appendix 11 Differences between "-V1"/"-V2" Models and Other Models In the NS Series, there are hardware items both with and without "-V1" and "-V2" at the end of the model number. Model...
Page 328 Appendix 11 Differences between "-V1"/"-V2" Models and Other Models The differences between "-V1" and "-V2" models and other models are shown below. For details on the differences in software functions, refer to the Programming Manual. Without "-V1" or "-V2" With "-V1"...
Page 329: Appendix 12 Ns5 System Menu
Appendix 12 NS5 System Menu Appendix 12 NS5 System Menu This section describes the NS5 System Menu screen. Some items are slightly different for the NS8, NS10, NS12, and NS15. Check all items in the table below before setting or monitoring. Setting/...
Page 330 6-5-2 Comm. Automatic Communications Recovery Setting 6-6-1 (Comms. Auto-return) Timeout Interval Setting 6-6-1 Retry Count Setting 6-6-1 Serial Port A or B Communications Settings Setting 6-6-1 Ethernet Communications Settings Setting 6-6-4 Data Check Screen Number Setting Show Address Setting A-70...
Page 331 Appendix 12 NS5 System Menu Setting/ Menu Item/settings Reference display Special Screen Error Occurrence/Frequency for All History Files Alarm History Display 6-8-1 Operations Log Display 6-8-2 Error Log Display 6-8-3 System Version Display 6-8-11 Special Functions Device Monitor Setting/ 6-8-4...
Page 332 Revision History A manual revision code appears as a suffix to the catalog number on the cover of the manual. Cat. No. V083-E1-14 Revision code The following table outlines the changes made to the manual during each revision. Page numbers refer to the previous version.
