Warranty Policy This camera is under warranty for one full year from the date of purchase by the original purchaser. In case of defects in materials or workmanship, we will replace or repair the camera free of charge.
FCC Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in commercial installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 4
WARNING Do not use this camera if it is emitting smoke (or an unusual odor), if it becomes unusually hot to the touch, produces a peculiar noise, or exhibits any other abnormal conditions. Operating the camera inany of these circumstances may cause a fire or an electrical shock.
Page 5
CAUTION Do not place this camera in a location affected by oil fumes or steam, such as near a cooking stove or humidifier. This may cause a fire or an electrical shock. Do not leave this camera in a location subject to extremely high temperatures, such as in a sealed vehicle or in direct sunlight.
Table of Contents Introduction Getting to Know the Camera Front View Top View Rear View Bottom View Side View Status (Information) LCD Input/Output Connectors Getting Started Power - Inserting Batteries Using an AC Power Adapter Using an SD Memory Card...
Introduction Thanks for the purchase of the digital camera. With the camera, you will live a whole new camera experience and make photo shooting more interesting and fun. Here below we will guide you through the whole picture taking process, please keep this manual on hand and enjoy your time.
Getting Started Power-Inserting Batteries 1. Slide the battery cover in the direction indicated by the arrow on the battery cover door. 2. Insert 2 AA batteries with the correct polarity as shown on the inner side of the battery cover. (Note also the decal inside the battery compartment) 3.
Using an AC Power Adapter(Optional accessory) 1. Open the i/o port cover as shown: 2. Connect one end of the power adapter to the port labelled “DC IN 3V” as illustrated: 3. Plug the other end of the power adapter into a power outlet.
Attaching the Hand Strap 1. Insert the thin end of the strap into the strap holder. 2. Pass the other end of the strap through the loop of thin cord and pull the strap tight.
Basic Operations Recording a Still Image To record a still picture, perform the following: 1. Power on the camera. 2. Toggle the Mode button to select Record Mode 3. Use the viewfinder window or image LCD display to frame the image.
Viewing Still Image/ Video Clip You can view still images /video clips stored in the camera’s internal or card memory on image LCD display. You can also connect the camera to the TV monitor in this mode to playback the still images/video clips. On Image LCD Display 1.
ERASE ONE 1. Toggle the Mode button to select Play mode arrow. 2. The last image /video clip taken will be shown on image LCD display. 3. Press Menu button to enter PLAY MENU. 4. Use the arrow button 5.
Flash Modes The Flash Mode can only be set under Record Mode. There are 4 modes available: Auto, Red- eye Reduction, Fill-in (On)and OFF. The default setting is AUTO. To change the setting, press the Flash button a number of times until the desired one is selected. Mode Icon Auto...
Thumbnail Display For quicker selection of pictures, you can display them as thumbnails on the LCD monitor. A set of nine thumbnails can be displayed per screen. 1. Power on the camera. 2. Toggle the Mode button to select Play mode 3.
Camera Modes and Menus Mode Button and Information Status LCD Display Each press of the mode button switches the status LCD display as follows: Record Still Image Record Video(Movie) Record Menu The RECORD MENU contains four items: SETUP, QUICK VIEW, WHITE BALANCE and EV COMPENSATION.
2. Highlight WHITE BALANCE by using the arrow button press OK. 3. Use the arrow button balance,press OK to confirm. EV COMPENSATION The camera will automatically adjust the camera shutter speed for the proper exposure of each scene.
EV COMPENSATION The camera will automatically adjust the camera shutter speed for the proper exposure of each scene. Occasionally, it is desirable to manually override the automatic exposure value (EV) to accommodate special scene circumstances. 1. Follow steps 1 through 2 in access MOVIE MENU section. 2.
4. Use the arrow button 5. ERASE ONE is highlighted, press OK. 6. “ERASE CURRENT ?” will be displayed in the image. 7. Press OK to delete this image/video clip. ERASE ALL 1. Follow steps 1through 4 in the preceding section.
DATE/TIME 1. Follow steps 1 through 3 in LCD BRIGHTNESS section. 2. Use the arrow button 3. Use the arrow button move to the next field. LANGUAGE Sets the OSD menu language. 1. Follow steps 1 through 3 in LCD BRIGHTNESS section. 2.
1. Follow steps 1 through 3 in LCD BRIGHTNESS section. 2. Use the arrow button 3. Use the arrow button USB CONFIGURATION This menu contains two modes, including DISK DRIVE and PC CAMERA DISK DRIVE: This mode allows to transfer pictures to PC.
Transferring Images to Your Computer Before picture transfer, please read the following guideline carefully. Operating Environments -Images recorded with the camera can be transferred to a PC using the USB cable supplied. 1. Windows MSWindows 98,98SE,2000,ME,or Windows XP Memory: 64 MB RAM Others: CD-ROM drive, USB port 2.
Connecting the Camera to Your Computer 1. Make sure to set the USB CONFIG to DISK DRIVE before connection. * Refer to SETUP MENU-USB CONFIGURATION section-DISK DRIVE. 2. Plug one end of the USB cable to the camera.
Using the Camera as a PC Camera (PC Only) The camera can also serve as a PC video camera using third-party video software such as Microsoft NetMeeting or Video maker (XP): 1. Make sure you have installed the PC camera video driver. 2.
Specifications Effective pixels Image Sensor Color Image Resolution Lens Focal length Working Distance Zoom Shutter Speed Exposure White Balance Memory Compression Method File Format Operating System PC Camera Software Language Support Flash Self-timer Connectors USB Frame Rate...
