Toshiba Satellite A135-S4656 Specifications

Toshiba satellite a135-s4656: specifications.


Satellite A135 Detailed Product Specification
Model Name
:A135-S4656
C1
2
Operating System
• Genuine Windows Vista™ Home Basic (32-bit version)
3
Processor and Chipset
• Intel® Celeron® M Processor 520
o 1.60GHz, 1MB L2, 533MHz FSB
• Mobile Intel® 943GML Express Chipset
4
Memory
• Configured with 512MB DDR2 SDRAM (both memory slots may be
occupied). Maximum capacity 2048MB
5
Hard Disk Drive
• 80GB (5400 RPM); Serial ATA hard disk drive
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (16x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (4x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (4x)), DVD+RW (8x), DVD-
RAM (5x)
7
Display
• 15.4" diagonal widescreen LCD display at 1280x800 native resolution
(WXGA)
8
Graphics
• Intel® Graphics Media Accelerator 950 with 8MB-64MB dynamically
allocated shared graphics memory
Sound
• Built-in stereo speakers
• Sound Volume Control Dial
Input Devices
• 85 key US keyboard
• TouchPad™ pointing device
• Control Buttons:
o Internet button to launch default browser
o CD/DVD control buttons (Play/Pause, Stop, Prev Track, Next
Track)
Communications
• Modem
9
• 10/100 Base-TX Ethernet
• Integrated Wi-Fi® compliant wireless:
o Atheros® 802.11b/g wireless-LAN
Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
• 5-in-1 Bridge Media Adapter
o Secure Digital, Memory Stick™, Memory Stick PRO™, Multi
Media Card, xD Picture Card [shared slots]
Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK(tm) IEEE-1394
o USB v2.0 – 4 ports
Physical Description
• Dimensions (WxDxH Front/H Rear): 14.2" x 10.5" x 1.47" /1.19" without
feet
• Weight: Starting at 6.0 lbs depending upon configuration
• LCD Cover Color: Mist Gray
Part Number:
6
10
11
© Copyright 2006 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A135-S4656 BTS Rev. 1.00 2007-05-10 MCL T20070420 CB1.02
This product specification is variable and subject to change prior to product launch.
1
PSAD0U-0N500N
Power
• 65W (19V x 3.42A) 100-240V AC Adapter.
o Dimensions (WxDxH): 4.25" x 1.34" x 1.85"
o Weight: starting at .67 lbs
12
Battery
• 4000mAh Lithium Ion battery pack
o Dimensions (WxDxH): 8.15" x 2.13" x 0.91"
o Weight: starting at 0.75 lbs
C1
Software
• Toshiba Software and Utilities
o TOSHIBA Value Added Package
o Electronic User's Guide
o Bluetooth Stack for Windows by Toshiba
o TOSHIBA ConfigFree®
o TOSHIBA Assist
o TOSHIBA Security Assist
o TOSHIBA Disc Creator
o TOSHIBA Extended Tiles for Windows Mobility Center
• Third-party Software
o TOSHIBA Game Console
o Microsoft Works Version 8.5
o Sun® Java™ 2 Runtime Environment
o Adobe® Acrobat® Reader
o Google™ Desktop
o Google™ Toolbar
o Yahoo! Music™ Jukebox
o Ulead® DVD MovieFactory® 5 for TOSHIBA
• Trial Software
o Microsoft Office Trial Home and Student 2007 Edition (60-day
trial)
o McAfee® Internet Security Suite (30-day trial)
• Special Offers
o EarthLink® Internet Service
o PeoplePC® Internet Service
o Toshiba Compare and Search for Broadband
o Microsoft Office Live
o Shutterfly digital photo service
o Napster® music subscription service
o eMusic MP3 music subscription service
o VONGO
o ebay®
o CNN Pipeline
o Skype Voice & Video
Environmental Specifications
14
Temperature
Thermal Gradient
Relative Humidity
(non-condensing)
Altitude
(relative to sea level)
Shock
Vibration
• This product is RoHS
SATELLITE – 1 YEAR STANDARD LIMITED
WARRANTY
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as SystemGuard®,
On-Site Repair, and ServiceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.pcsupport.toshiba.com.
Recommended Services
UPC:
13
SM
internet video download service
Operating
5° to 30°/35° C
(41° to 86°/95° F)
15° C per hour (max)
20% to 80%
-30 to 3,000 meters
10G
0.2G
15
compatible
16
032017910348
Non-operating
-20° to 65° C
(-4° to 149° F)
20° C per hour (max)
10% to 95%
-30 to 10,000 meters
60G
1.0G
Page 1 of 4
