• Motor
Two stage 120 volt, double ball bearing with tangential bypass
discharge and thermoset fan end bracket. 11.7 amps.
• Power Unit Body
Durable textured powder coated all steel body.
• Performance
CFM at 2" opening: 112
Water Lift: 107"
Air Watts: 404
• Collection
5 Gallon Bagged or Bagless collection canister with maintenance
free single ply Micro-Tex
• Recommended Home Size
Homes up to 3,000 square feet.
• Mounting
Includes metal mounting bracket and an extra utility inlet.
• Shipping Information
UPC: 0-83162-
Shipping Weight: lbs.
PROJECT
LOCATION
CONTRACTOR
FAN
MODEL
CFM
NUMBER NUMBER
C
US
Specifications subject to change without notice.
®
polyester fiber filter.
IN
RPM
WATTS
W.C.
CENTRAL VACUUM POWER UNIT
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS
SONES
QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
AKCV35
CENTRAL VACUUMS
Central Vacuums
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
Updated 4-07
