Introduction
To the owner or user: This product manual is a
source of information about the installation, start
up, cleaning, maintenance and repair of the
product.
The SLD150 is a Slim Line® brand hotel/motel ice
dispenser. It is designed to use a Scotsman Slim
Line SLE300 or SLE400 ice machine as the
source for ice.
Ice from the cuber falls into the insulated hopper,
where it is stored until needed. When a user
pushes the dispense button a rotating wheel
scoops the ice up to the top front of the hopper
where there is an outlet to the ice chute.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Final Check List/Initial Start Up/Electrical Sequence . . . . . . . . . . . . . . . . .
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removal and Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts lists and wiring diagrams are located in the
center of this manual, printed on yellow paper.
Note the warning symbol where it appears in this
manual. It is an alert for important safety
information on a hazard that might cause serious
injury.
Keep this manual for future reference.
This manual was printed on recycled paper.

Table of Contents

. . . . . . . . . . . . . . . . . . . . . . . . . . .
October 1996
Page 1
SLD150
page 2
page 3
page 5
page 7
page 8
page 9
page 10

Advertisement

loading

Summary of Contents for Scotsman SLD150

  • Page 1: Table Of Contents

    The SLD150 is a Slim Line® brand hotel/motel ice dispenser. It is designed to use a Scotsman Slim Line SLE300 or SLE400 ice machine as the source for ice.
  • Page 2: Specifications

    F. air maximum. Must be installed indoors. Must allow space to the right for air intake when using air cooled ice machine. Compatible only with Scotsman SLE300 or SLE400 Slim Line® brand models. Must allow space for utility connections at the back.
  • Page 3: Installation

    Check that gasket tape is on the top outside edge of Thread the legs into the base of the dispenser. Be the dispenser where the ice machine will rest. sure that the legs are screwed in all the way. Turn the leg levelers in all the way.
  • Page 4 Locate bin thermostat bracket entrance hole, its found at the right side of the hole in the top of the dispenser. Make sure the hole is open. Place the ice machine onto the dispenser. The ice machine is heavy, use of a mechanical hoist is recommended.
  • Page 5: Kits

    A kit is available to install a coin mechanism, and another kit is available to install a room key mechanism. Both come with detailed instructions, summarized here: Coin Mechanism, install after ice machine has been operating: 1. Disconnect electrical power. Electrical Shock Hazard.
  • Page 6 SLD150 Key Kit Installation: (KSLDK2) 1. Disconnect electrical power Electrical Shock Hazard. Disconnect electrical power before beginning procedures. 2. Remove sink and drain pan. 3. Remove cover. 4. Remove control box cover 5. From kit, locate brass fitting. Obtain typical door lock cylinder from the motel/hotel.
  • Page 7: Electrical Sequence

    Pushing the vend button closes a contact to the gear motor (and to the ice door solenoid of SLD150-1B models). SLD150-1 model: When the gearmotor begins to turn, the cam switch on the gearmotor closes, so that the vend switch may be released without interrupting the vending, until the cam has moved 1/4 turn.
  • Page 8 SLD150 Operational Schematic Ice Machine Bin Thermostat Ice Chute Gear Motor Sink Storage Bin Drain Pan Drain Condensate Pan October 1996 Page 8...
  • Page 9: Cleaning

    3. Locate key and remove sink. 4. Remove top front panel (in front of ice machine). 5. Remove the front top panel (above ice chute). 6. Reach into the opening, locate the large nut securing the wheel to the drive shaft. Remove the nut.
  • Page 10: Service Diagnosis

    Vend switch open Sink interlock switch open Ice jams in chute Front panel not on all the way Gearmotor open Cam switch open (SLD150-1) Ice door does not open (SLD150-1B) Drive shaft broken Does not vend, no ice Bin drain leaks...
  • Page 11: Removal And Replacement

    2. Disconnect electrical power 3. Locate key and remove sink. 4. Remove top front panel (in front of ice machine). 5. Remove the front top panel (above ice chute). 6. Reach into the opening, locate the large nut securing the wheel to the drive shaft.

This manual is also suitable for:

Sle300Sle400
