Summary of Contents for Philips HQ7780

  • Page 1 ENGLISH 4...
  • Page 2 ENGLISH Introduction The shaver comes with two different kinds of NIVEA FOR MEN cartridges: Extra Fresh Shaving Gel for a fresh sensation during and after shaving and Moisturising Shaving Lotion for sensitive skin. This gives you the opportunity to try them out and discover which one suits your skin type best.
  • Page 3 The appliance is watertight and can be cleaned under the tap. Be careful with hot water. Always check if the water is not too hot, to prevent your hands from getting burnt. The appliance complies with the internationally approved IEC safety regulations and can be safely used in the bath or shower.
  • Page 4: Demonstration Program

    ENGLISH Demonstration program The appliance has a unique demonstration program. The demonstration will start automatically. „ Ê Shaving ± Shaving gel indication  Cleaning reminder/„ Battery capacity Ê Shaving ± Shaving gel indication „  Cleaning reminder/„ Battery low indication Œ...
  • Page 5 Indications during use All indications mentioned below are shown during every shaving session and they are always displayed in the same order, which makes it very easy for you to maintain a regular shaving ritual As a result, some symbols will light up even when you have already taken the appropriate action.
  • Page 6: Battery Fully Charged

    ENGLISH Charge indications Battery running low Battery fully charged Battery indications during shaving The three battery lights show the remaining battery capacity for 5 seconds after you switch the shaver on or off. - The lower two battery lights burn green: - The bottom battery light burns green: 33% of - The bottom battery light burns red: the battery When the battery is running low, the bottom...
  • Page 7 Charging the appliance Charge the shaver before using it for the first time and when the shaver indicates that the battery is running low. Insert the small plug into the charging stand and put the powerplug in the wall socket. Place the shaver in the charging stand.
  • Page 8: Inserting Cartridges

    ENGLISH Only use Philips NIVEA FOR MEN Cool Skin (HQ170 and HQ171) cartridges. One Philips NIVEA FOR MEN Cool Skin cartridge contains enough gel/lotion for approx. 10 shaves. For hygienic reasons, we advise you to insert a new pump when you start using a new set of five cartridges.
  • Page 9: Replacing Cartridges

    Press the release button and open the cover of the cartridge compartment. Slide the cartridge with the pump into the shaver. It only fits properly if the white side of the pump is pointing upwards. Close the cover (you will hear a click). Press the yellow pump button a few times until the NIVEA FOR MEN shaving gel/lotion appears.The shaver is now ready...
  • Page 10: Using The Appliance

    ENGLISH Storing cartridges NB:The wall holder is only suitable for storing cartridges. Never hang or place the shaver on the wall holder. If you do, the shaver may fall! Using the appliance Shaving Switching the shaver on After the battery capacity has been shown briefly, the yellow teardrop-shaped shaving gel light ±...
  • Page 11 The shaver will not perform optimally when used without shaving gel/lotion. Your skin may need 2 or 3 weeks to get accustomed to the Philips system. Switching the shaver off Switch the shaver off by pressing the on/off button once.
  • Page 12 ENGLISH After this, the remaining battery capacity is shown for 5 seconds. Rinse the shaver after each shave. Remove the cartridge if you are not going to use the appliance for more than one week. Trimming For grooming sideburns and moustache. Attaching the trimmer Clean the shaver before you attach the trimmer (see chapter 'Cleaning and maintenance').
  • Page 13: Travel Lock

    Tilt the trimmer slightly backwards. Fit the trimmer onto the shaver (you will hear a click).The trimmer is now ready for use. Activate the trimmer by pressing the on/off button once. Removing the trimmer Switch the shaver off. Remove the trimmer by pressing the release button again and pulling the trimmer off the shaver.
  • Page 14: Deactivating The Travel Lock

    ENGLISH The yellow key symbol goes out. Deactivating the travel lock The yellow key symbol goes out. Checking if the appliance is locked Cleaning and maintenance Regular cleaning guarantees better shaving performance. The travel lock indication ‰, a yellow key symbol, blinks 3-4 times and then burns continuously for 4 seconds.The travel lock has now been activated.
  • Page 15 To maintain optimal shaving performance and to keep the shaver clean, you have to thoroughly rinse the shaving unit and hair chamber with hot water after every shave. Be careful with hot water. Always check if the water is not too hot, to prevent your hands from getting burnt.
  • Page 16 ENGLISH Shaving unit: Quick Clean after every shave Never dry the shaving unit with a towel or tissue as this may damage the shaving heads. Shaving unit and hair chamber: every week We advise you to clean the appliance thoroughly at least once a week to maintain optimal shaving performance.
  • Page 17 Rinse the inside of the shaving unit. Rinse the outside of the shaving unit. Rinse the hair chamber. Make sure the inside of the shaving unit and the hair chamber have been cleaned properly. Close the shaving unit and shake off excess water.
  • Page 18 ENGLISH Trimmer The trimmer can also be cleaned by rinsing it under the tap. Storage Charging stand Always unplug the charging stand before storing the wet or dry shaver in it. Pouch Hanging cord Clean the outside of the trimmer with the brush supplied after every use.
  • Page 19 Replace the shaving heads every two years for optimal shaving results. Replace damaged or worn shaving heads with HQ177 Philips Cool Skin shaving heads only. Shaving head check indication After two years of use the red shaving unit symbol Œ will blink for 30 seconds during 7 shaves to indicate that you should check the condition of the shaving heads.This indication is...
  • Page 20 ENGLISH Accessories The following accessories are available: - HQ8000 powerplug. - HQ177 Philips Cool Skin shaving heads. - HQ170 NIVEA FOR MEN Cool Skin - HQ171 NIVEA FOR MEN Cool Skin Extra Turn the wheel anticlockwise (1) and remove the retaining frame (2).
  • Page 21 Dispose of the battery at an official collection point for batteries. If you have trouble removing the battery, you can also take the appliance to a Philips service centre, which will remove the battery for you and will dispose of it in an environmentally safe way.
  • Page 22: Troubleshooting

    Care Centre in your country (you will find its phone number in the worldwide guarantee leaflet). If there is no Customer Care Centre in your country, turn to your local Philips dealer or contact the Service Department of Philips Domestic Appliances and Personal Care BV.
  • Page 23 Clean the shaver thoroughly before you continue shaving. See chapter 'Cleaning and maintenance'. Cause 2: long hairs are obstructing the shaving heads. Press the release button to open the shaving unit. Turn the wheel anticlockwise (1) and remove the retaining frame (2). Clean the cutters and guards.
  • Page 24 ENGLISH The shaver does not work when the on/off button is pressed. Cause 1: the travel lock has been activated. Deactivate the travel lock. See chapter 'Travel lock'. Cause 2: the battery is empty. Recharge the battery. See chapter 'Charging'. Cause 3: dried-up shaving gel/lotion is blocking the shaving heads.
  • Page 25 Cause 2: the cartridge has not been pushed far enough into the shaver. Press the cartridge until it is properly seated. The NIVEA FOR MEN shaving gel/lotion has changed colour or has turned watery. Cause: the NIVEA FOR MEN shaving gel/lotion has not been stored at the right temperature.
  • Page 28 „ Ê ± Â Ê ± „  „ Œ ‰...
  • Page 34 ±...
  • Page 35 Â...
  • Page 38 ‰...
  • Page 39  Œ  Â...
  • Page 43 Œ...
  • Page 52 „ Ê ± Â Ê ± „  Œ ‰ „ „...
  • Page 58 ±...
  • Page 59 Â...
  • Page 61 ‰...
  • Page 62  Œ Â...
  • Page 63 Â...
  • Page 66 Œ...
  • Page 75 „ Ê ± Â Ê ± „  Œ ‰ „ „...
  • Page 82 ±...
  • Page 83 Â...
  • Page 85 ‰...
  • Page 86 Â...
  • Page 87 Œ  Â...
  • Page 90 Œ...
  • Page 99 „ Ê ±  „ Ê ± „  „ Œ ‰...
  • Page 105 ±...
  • Page 106 Â...
  • Page 110  Œ  Â...
  • Page 113 Œ...
  • Page 123 „ Ê ± Â Ê ± „  Œ ‰ „ „...
  • Page 130 ±...
  • Page 132 Â...
  • Page 134 ‰...
  • Page 136  Œ  Â...
  • Page 140 Œ...
  • Page 150 „ Ê ± Â Ê ± „  Œ ‰ „ „...
  • Page 156 ±...
  • Page 157 Â...
  • Page 160 ‰...
  • Page 161  Œ  Â...
  • Page 165 Œ...
  • Page 172 4222 002 45573...
