N8LJ/US1Y 31 .5 H D T V L C D TVHD de LCD T V H D AC L © 2011 Sanyo Manufacturing Corporation Owner’s Manual Table of Contents Manual del usuario Tabla de contenido Manuel d’instructions Table des matières DP32640 Model No.
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN! CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SER- VICE PERSONNEL. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
HDMI, the HDMI Logo and High- Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. As an Energy Star® Partner, Sanyo Manufacturing determined that this product meets the Energy Star® guidelines for energy ENERGY STAR efficiency.
WARRANTY ....... . .15 CONTAINS MERCURY LAMPS, DISPOSE OF PROPERLY RECYCLING OF SANYO TELEVISIONS: SANYO television customers should contact MRM Recycling at 888-769-0149 or visit their website at www.mrmrecycling.com regarding SANYO’s waste management plan.
STAND ASSEMBLY ___________ NOTE: Skip these steps if you are wall mounting the TV. Place HDTV face down on a padded or cushioned flat surface to protect the screen and finish. Carefully insert the stand base to the bottom of the HDTV and secure the base by inserting 4 screws as indicated in the diagram below.
GETTING STARTED HDTV INPUT/OUTPUT REFERENCE HDMI (INPUT1 or INPUT2) An all digital AV interface that can accept uncompressed video signals for the very best picture possible. NOTE: A DVI conection is possible via the HDMI (DVI) INPUT1 using an appropriate adapter and connecting the audio to the Stereo Mini AUDIO jack.
GETTING STARTED AUDIO / VIDEO CONNECTIONS HDMI (DVI) INPUT1 can be used to hookup a DVI device with the use of an appropriate DVI to HDMI cable or adapter. Stereo Mini AUDIO jack needs to be hooked up to the DVI device as well NOTE: HDMI INPUT1 may also be used to hookup any digital device with an HDMI output, with- out the use of the Stereo Mini AUDIO jack.
Selects the video source to view. Holding down the key displays the Input List. Modifies the Energy Saver level (see page 10 for details.) Cycles through the available Caption modes (when available.) Pressing it twice restores your HDTV to its factory settings.
GETTING STARTED INITIAL CHANNEL SEARCH Before proceeding, please make sure to correctly hook up your antenna or cable connection and all AV equipment to your HDTV. 1. PLUG IN AC POWER CORD 120V AC, 60Hz 2. TURN ON TV (PRESS POWER BUTTON) Wait for on-screen instructions to set an Initial Energy Saving Mode, and perform an Initial Channel/Signal Search.
CHANNEL SETTING (CONTINUED) Input Setting Input Setting feature allows the removal of unused inputs from the AV input loop. Use the CURSOR LM keys to select an AV input. Press ENTER to disable (uncheck) or enable (check) the high- lighted input. NOTE: At least one input must and will remain checked.
Light Sensor This feature detects ambient room light brightness and uses that reading to control the panel brightness level and picture parameters to reduce the HDTV’s power consumption. NOTE: When room lighting is dark, the panel bright- ness and/or the picture setting parameters such as brightness and contrast are lowered.
PICTURE Display the On Screen menu and use the CURSOR LM keys to select Picture. Press ENTER. You may choose between Vivid, Mild, and Standard, which have predetermined fixed picture parameter values, or choose the Manual option for customized personal settings. NOTE: Each AV input can have its own picture mode (pre-determined or manual.) Current input’s selected option is indicated by a blue marker.
ON-SCREEN MENU OPERATION SOUND Display the On Screen menu and use the CURSOR LM keys to select Sound. Press ENTER. Choose an option for your sound settings: Auto – Sound settings are linked to the current Picture option and parameters are adjusted accordingly. Dynamic, Mild, Standard –...
NOTE: Sanyo recommends using a monitor cable that includes a Ferrite Core. Laptop Display When using your Sanyo HDTV to display a Laptop’s screen display, holding down the Fn (or FN) key while pressing the appropriate function key (F5, F7, F8, etc) should cycle through different display modes between the laptop and the HDTV.
APPLY TO PRODUCTS USED FOR INDUSTRIAL OR COMMERCIAL PURPOSES. WARRANTY APPLICATION FOR ONE YEAR from the date of original retail purchase Sanyo Manufacturing Corporation (SMC) warrants this TV to be free from manufacturing defects in materials and workmanship under normal use and conditions for parts and labor.
1-800-877-5032 We’ll be glad to Help We’ll be glad to Help Sanyo Manufacturing Corp. 3333 Sanyo Road, Forrest City, AR 72335 Printed in Mexico SMC, March 2011 Impreso en México SMC, marzo 2011 Imprimé aux. Mexique SMC, mars 2011 US1-Y / 32-N8LJ / GXBM...
