Coleman 8350 Series Assembly Manual

Gas barbecue with grill lighting instructions
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Use, Care & Assembly Manual
Read all instructions and keep in a safe place for future reference.
www.coleman.com
NOTE:
1) AA Battery is included.
2) A flexible natural gas line is not
included with Coleman® grills.
3) See your dealer for a Rotisserie Kit
that is purchased separately (the
bracket shown in the photo is
provided with the Rotisserie Kit).
Gas Barbecue
With Grill Lighting Instructions
Model No. 9992-648 (Natural Gas)
ASSEMBLER/INSTALLER:
Leave these instructions with the consumer.
CONSUMER/USER:
Read this manual carefully before assembling,
using or servicing this grill. Keep this manual for
future reference. If you have questions about
assembly, operation, servicing or repair of this
grill, please call Coleman at 1-800-356-3612 or
TDD: 316-832-8707. In Canada call
1 800 387-6161.
8350 Series
IMPORTANT
For Outdoor Use Only
®

Advertisement

Table of Contents
loading

Related Manuals for Coleman 8350 Series

Summary of Contents for Coleman 8350 Series

  • Page 1 Keep this manual for future reference. If you have questions about assembly, operation, servicing or repair of this grill, please call Coleman at 1-800-356-3612 or TDD: 316-832-8707. In Canada call 1 800 387-6161. For Outdoor Use Only...

  • Page 2: Table Of Contents

    Contents General Safety Information ........2 General Installation .

  • Page 3: General Installation

    • DO NOT vent propane vapor from the cylinder before taking it to be refilled. • DO NOT use gas grill indoors or store any propane cylinder(s) indoors, including in the garage, breezeways, sheds or enclosed areas. • Under some circumstances, propane may lose the distinctive odor that was added.

  • Page 4: Electrical Attachments

    Electrical Attachments When using an electric attachment with the grill, follow the specification and warning statements accompanying the attachment. IMPORTANT: If using an external electrical source, the installed appliance must be electrically grounded according to local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70 or the Canadian Electrical Code CSA C22.1.

  • Page 5: Grill Features

    NOTE: See your dealer for a Rotisserie Kit that is purchased separately (the bracket shown in the photo is provided with the Rotisserie Kit). Grill Features — 8350 Series 6. Control Knobs: Main Burners 7. Control Knob: Rear Infrared Burner 8.

  • Page 6: Replacement Parts List

    Replacement Parts List — 8350 Series Parts Not Shown 9992-1101 9992-1121 Grill Rotisserie Kit (not shown) Grill Gas Conversion Kit (not shown) Universal Igniter Wire (60") Hood Bumper Pads 9992-539 8350 Series Grill Rotisserie Kit 9992-258 8350 Series NG to LP Conversion Kit...

  • Page 7: Built-In Instructions

    The 8350 Series grill can be installed as a built-in grill. If installed as a built-in grill, the outdoor cooking center must be constructed of non-combustible material. PLANNING AND DESIGN Start by identifying the number and size of components you want to include in your outdoor cooking center. Countertops must be constructed of non-combustible, outdoor-safe materials.
  • Page 8 3” minimum for non-combustible construction. • The side vents on this unit can be covered for built in installations without danger of fire or without impairing the operation of the grill. Built-In Instructions — 8350 Series Built-In Instructions w/o Trim Kit 35.5"...

  • Page 9: Natural Gas Installation

    NOTE: Your 8350 Series grill is set up from the factory to use NATURAL GAS. If you want to use LP GAS, you must purchase the LP GAS CONVERSION KIT (sold separately). Please skip to the section titled “LP Cylinder Conversion - 8350 Series ”.

  • Page 10: Grill Assembly

    A spark should appear at electrode tips. If the spark does not appear: -Check the wire connections to the electrode module. -Check the proper assembly of a fresh AA battery. Grill Assembly — 8350 Series Fig. 1 Fig. 2 Fig. 3 Fig.

  • Page 11: Lp Cylinder Conversion

    NOTE: This step applies to you only if you are converting your 8350 Series grill to use LP GAS. If you will be using your grill with NATURAL GAS, this section does not apply to you. Please skip back to the section titled “Natural Gas Installation - 8350 Series ”.

  • Page 12: Portable L.p. Gas Barbecue Cylinders

    L.P. gas is heavier than air and tends to collect in low areas. It is important that there are no leaking connections on your gas grill that could cause a fire or explosion (see the section titled “LEAK TESTING”).

  • Page 13: Hose And Regulator

    Do not use another hose and regulator assembly other than the one supplied with the grill or a Coleman® replacement pressure regulator assembly. The pressure regulator and hose assembly provided is factory set at an outlet pressure of 11 inches water column (1/2 psi).

  • Page 14: Purging And Evacuating Devices For L.p. Gas Cylinders With Type 1 Cylinder Valves

    Filling and Purging Type 1 L.P. Gas Cylinders (continued) Fig. 11 CGA-510 POL Purging and Evacuating Devices for L.P. Gas Cylinders with Type 1 Cylinder Valves CAUTION After purging or filling an L.P. Gas cylinder, DO NOT insert a POL plug into the valve outlet. Insertion of the plug will prevent the back-check from closing.

  • Page 15: Leak Testing

    Coleman. DO NOT attempt to repair the cylinder valve if it should become damaged; the cylinder MUST be replaced.

  • Page 16: Start-Up Check List

    Start-Up Check List WARNING Failure to follow these safety steps before using the grill each time could result in a fire that could be hazardous to you, your appliance or property. It is especially important to observe these steps after the grill has been stored, moved or cleaned. 1.

  • Page 17: Lighting Main Burners

    Lighting Main Burners 1. Push and turn one of the main burner control knobs counterclockwise to the “HIGH” position. Wait 5 seconds. (Fig. 17 and 18) 2. Press and hold the electronic igniter button. You will hear a snapping sound. (Fig. 19) 3.

  • Page 18: Using The Rotisserie

    NOTE: Your 8350 Series grill is set up from the factory with a Back Infrared Burner. An optional ROTISSERIE KIT to use with the back infrared burner must be purchased separately. The grill rotisserie system is designed to cook items from the back using infrared heat. The rotisserie burner is an infrared type which provides intense searing radiant heat.

  • Page 19: Lighting The Rotisserie Burner

    Lighting the Rotisserie Burner 1. Push and turn on the control knob for the ROTISSERIE BURNER counterclockwise to the “HIGH” position (Fig. 17 and 22). Wait 5 seconds. 2. Press and hold the electronic igniter button (Fig. 23). You will hear a snapping sound. 3.

  • Page 20: General Use And Correct Burner Flames

    General Use and Correct Burner Flames WARNING • Keep the grill area clean and free from combustible materials, gasoline and other flammable vapors, liquids, and spare L.P. cylinders. • DO NOT obstruct the flow of combustion and ventilation air. • Keep the ventilation opening(s) of the L.P. cylinder enclosure free and clear of debris.

  • Page 21: In Case Of Grease Fire

    L.P. cylinder, cylinder valve, regulator, gas supply hose, burner valve(s) and burner(s). 5. If any of the above mentioned components are damaged, seek replacement from Coleman before operating the grill again. Locate your nearest service center by calling 1-800-356-3612. Note: •...
  • Page 22 Care, Maintenance and Cleaning Cleaning the Venturi WARNING Spider’s nests or wasp’s mud inside the venturi may cause fire at the valve. If a fire occurs, immediately turn off the gas supply at the L.P. cylinder valve (see representative illustration in Fig.
  • Page 23 Care, Maintenance and Cleaning Replacing the Electrode Module Steps For Replacing the Electrode Module: 1. Remove the cooking grates and the heat tents and set aside. 2. Using a 1/4” hex nut driver, remove the self-tapping screws holding the front heat shield (Fig. 33 and 34). Set the front heat shield aside.

  • Page 24: Moving And Storage

    Moving and Storage (continued) A collision with the grill, as with any metal object, could cause injury. Use care when moving a portable gas grill. Moving the grill: • Move the grill slowly. DO NOT run with or pull the grill behind you;...

  • Page 25: Registration Card

    ¨ warranty. PROTECT YOUR PRODUCT: We will keep the model number and date of purchase of your new Coleman you refer to this information in the event of an insurance claim such as fire or theft. PROMOTE BETTER PRODUCTS: We value your input. Your responses will help us develop products designed to best meet your needs.
  • Page 26 Stainless steel material (if applies) Porcelain or stainless steel cooking grates Thank you for filling out this questionnaire. Your answers are important to us. Please check here [ ] if you prefer not to learn more about Coleman ® Outdoor Cooking Products or www.coleman.com.

  • Page 27: For Your Additional Safety

    O.P.D. feature. For Your Additional Safety YOUR NEW GAS GRILL IS EQUIPPED WITH A TYPE 1 CONNECTION DEVICE WHICH HAS 3 SAFETY FEATURES (FIG. 38): 1. Proof of gas seal between the connector and the cylinder before gas flow takes place.

  • Page 28: Warranty

    Coleman, at its option, will repair or replace this product or any component of the product found to be defective during the warranty period.
